INTRODUCTION
The EasyPC gives the Z-lOO user the best of two worlds: all of
the capabilities and features of the Z-lOO and the ability to run
virtually the entire library of PC programs. Features by mode
include:
Z-lOO Mode
- Identical in operation to Z-lOO
-
All Z-lOO software supported
- No degradation in speed or performance
- No additional memory required
PC Mode
- Supports most PC software including copy protected software
- Supports PC color graphics, keyboard, timer, and sound
generation
- Supports Winchester disk operations
- Supports COMl, COM2, and parallel printer ports through
ROM BIOS
-
No additional memory required
The EasyPC ·consi sts of two S-IOO ci rcui t boards and a piggyback
board. Yet its design requires only one extra slot. The
following parts should be included in your EasyPC package.
- 1 System Board
- 1 Video Master Board
- 1 Floppy Disk Controller Board
- 1 Cable Assembly
- 1
Speaker
- 1 Keyboard Overlay
- 1 74LS74 (integrated circuit)
- 1 74S244 (integrated circuit)
- 1 User's Manual
Note: Do not discard the packaging material: the box, foam, or
black conductive bags. If there is ever any reason for you
to ship the product back to UCI, repack it exactly as you
received it. This will guarentee no electrical or physical
damage is done in shipping.
During the installation procedure, you will be required to
partially disassemble your computer before you can install the
EasyPC. Please refer to the installation section of this manual.
3

CONFIGURATION
-----------------------------------------------------------------
The EasyPC can run at 5 or 8 MHz, with single or double dot video
characters, with 48 TPI or 96 TPI floppy disk drives (PC
operating systems do NOT support 96TPI drives.) and with IBM type
monitors. In addition, all 16 video colors are available if
desired. Refer to discussion below to configure the board set to
your particular system.
5 AND 8 MHz Operation
The EasyPC was designed to operate at either the 5 MHz or the
8 MHz speed. Onboard logic automatically adjusts the EasyPC to
the speed of your Z-lOO system. It is not necessary to set
any hardware jumpers on any of the three boards. The EasyPC
will function with both the 5MHz and 8MHz motherboards
manufactured by Zenith as well as any of the speed kits
retroactively installed such as the UCI Speed Up Module. This
includes kits with frequencies under 8 MHz which are popular
in the field.
16 Color Video
The EasypC's Video Master board is capable of producing all 16
IBM color signals. With the standard Zenith Z-lOO cabling,
only 8 colors are possible. For users who desire the full
color range, UCI offers a16 color cable assembly that is
simple to install. For more information contact UCI.
Single or Double Dot Video Characters
The Video ROM on the Video Master Board contains both the
single and double dot video characters. The double dot
characters are recommended for systems with low resolution
composite monitors and the Zenith All-In-One models. For such
systems the double dot characters provide amore legible
screen. The EasyPC is shipped set for the double dot
characters. No change on the Video Master board is required.
For systems with RGB color monitors, the single or double dot
characters can be used. To display the single dot characters
a hardware jumper must be soldered to the Video ROM. To do
so, remove U7 (the only 24 pin IC on the board) from the Video
Master board. Solder a small insulated wire from pin 21 to
pin 12 as shown below. With a small screwdrive extend pin 21.
Reinsert the ROM back into the Video Master board but do not
insert pin 21. The system is now configured for single dot
characters. The procedure can be reversed if you decide to
display the double dot characters again.
4

CONFIGURATION
--------------------------------------------~--------- -----------
1
Figure 1
Single Dot Video Characters ROM Jumper
Disk Drives 48TPI or 96TPI
The EasyPC
Floppy Controller board can support both 48TPI and
96TPI drives. In the PC mode however, the MS-DOS or PC-DOS
operating system can NOT access 96TPI drives. If your system
has 96TPI drives, when operating in the PC mode, data will be
stored on half of the drive. Any disks formatted for 48TPI
drives can not be read on the system.
The Floppy Disk Controller board comes from the factory set up
for 48TPI drives (most disk drives are 48TPI). In order for
it to function with 96TPI drives under the Z-IOO mode, the
board must be jumpered. Please refer to Appendix E for set up
instructions.
Non-Zenith Monitors
If your system does not use one of the Zenith/Heath monitors,
but an IBM or similar monitor, the horizontal and vertical
sync signals on the Video Master board must be inverted before
the EasyPC can function properly. If this is the case with
your Z-lOO system, refer to Appendix G for set up procedures.
5

INSTALLATION
----------------------------------------------------------------
Installation of the EasyPC requires:
1. The disassembly of your Z-lOO system
2. The removal and discard of the Zenith Z207 floppy
disk controller board
3. The swapping of two ICs on the motherboard.
4. The insertion of two 8-100 cards (Video and Floppy
Controllers) and one piggyback System board
5. The installation of speaker and cable assembly
The step by step instructions for both the Low Profile and All-
In-One models are described in the following pages.
Note: Be sure your computer operates properly before you begin
these instructions.
6

INSTALLATION
DISASSEMBLY of the Z-IOO
Cabinet Removal
1. Disconnect all line cords and peripherals to your
computer.
2. Move the metal slides on each side of the computer toward
the back 1/4 inch (see illustration). For the All-In-One
model a flat headed screwdriver is needed.
3. Lift cabinet top off and set it aside.
METAL
/SLIDE
1/4"
CA BI NET
TOP
f~~~~~~---~~ 1/4"
~r METAL
---SLIDE
Figure 2
Z-IOO
Cabinet Removal
7

INSTALLATION
DISASSEMBLY of the Z-lOO
Low Profile Front Panel Assembly Removal
1. For Low Profile models remove the four screws labeled Aand
two locking pins labeled B.
Figure 3
Low Profile Front Panel Assembly Removal
8

INSTALLATION
DISASSEMBLY of the Z-lOO
Low Profile Front Panel Assembly Removal Continued
2. Lift front panel assembly and move it forward slightly to
reach the connectors.
For floppy disk systems only, remove:
-
flat cable from disk drives and
-power supply cable(s) at disk drives.
Set assembly aside and proceed to Keyboard and Video board
removal on page 14.
9

INSTALLATION
DISASSEMBLY of the Z-lOO
Low Profile Front Panel Assembly Removal Continued
For Winchester disk systems only, remove:
- the two flat cables from the Winchester
controller card
- the power cable from the Winchester controller
card
- the flat cable from the floppy disk controller
card
- the power supply cables at the drives
Set assembly aside and proceed to Keyboard and Video board
removal on page 14.
10

INSTALLATION
----------------------------------------------------------------
DISASSEMBLY of the Z-lOO
All-in-One Front Panel Assembly Removal
1. For the All-In-One models remove the one screw labeled A
and four screws labeled B.
0101010101010101010101010101010
O'ldIQlgIQIQIQIQIQIQIQIQI~lIQIQIP
gj16~~1~Ft~~£g%%%%~lg
1E5ld'OIOI~nOrO'OIOlfjIO'P,rm,t=J
11 II
0101010
0/010/0
0101010
0101010
CJIOl
Figure 6
All-In-One Front Panel Assembly Removal
11

INSTALLATION
DISASSEMBLY of the Z-lOO
All-in-One Front Panel Assembly Removal Continued
2. Lift the display and disk drive assembly up and forward
slightly to reach connectors.
For floppy disk systems only, remove:
- the flat cable from floppy disk controller card.
- the power supply cable(s) at the drive(s). and
- video signal/power cable on the video deflection
board.
Set assembly aside and proceed to Keyboard and Video board
removal on page 14.
DRIVE/VIDEO
SUBASSEMBLY
Figure 7
All-In-One Cable Disconnect
Floppy Disk Systems Only
12

remove:
INSTALLATION
~~~~~~~~;-----------------
of the Z-lOO -----------
All-in-One F --------------
ront P -----------
anel Assembl
For W· y
lnchester di sk
video the on
cable from the
disk
controller
drives
cable
A11-In-O Figure 8
W. ne Cab1 .
lnchester Disk e Dlsconnect
Systems Only
13

INSTALLATION
DISASSEMBLY of the Z-lOO
Keyboard and Video Board Removal
1. Remove the two screws labeled A near the top of the key-
board.
For Low Profile models only remove the two locking pins
labeled B at the rear of the computer.
2. Lift off the keyboard shell and set it aside.
KEYBOARD
SHELL
Figure 9
Keyboard Shell Removal
14

INSTALLATION
DISASSEMBLY of the Z-lOO
Keyboard and Video Board Removal Continued
3. Move the keyboard forward
4. Remove the three screws labeled A holding the video board.
disconnect P301, P303 and P302 (for AII-In-One models only)
from the left side of the video board, unplug the two
cables from the motherboard, and set the video board aside.
Figure 10
Keyboard and Video Board Removal
15

EasyPC INSTALLATION
-----------------------------------------------------------------
System Board Installation
The EasyPC system board will piggyback the Z-100 motherboard.
Remove
the
following
nine IC's from the motherboard.
See
figure lIon
page 17.
Notation Description
--------
-----------
1.
U164 74LS240
2.
U196
74LS373 or
74ALS373
3.
U197
74LS373 or
74ALS373
4.
U208
8259A
5. U211
8088
6. U213 74LS373
or
74ALS373
7. U217
74L5244 or 74AL5244
8.
U219
74574
9.
U241 74L5244 or
74AL5244
Lay
aside the ICs removed from U196, U197, U213, U217, U219.
and U241. These 6 chips will not be used in the EasyPC instal-
lation. They are spares.
16

EasyPC INSTALLATION
•
.,
..
e.
..
Ie
••
I CHASSIS I
•
•
•
'.
N'
Figure 11
Ie Locations Z-100 Motherboard
17

EasyPC INSTALLATION
System Board Installation Continued
Insert the two ICs provided with your EasyPC as follows:
74L574 into U219
745244 into U241
The proper orientation is critical for successful operation.
The notch or dot on top of the Ie must be aligned with the
notch on the socket on the motherboard. Follow the IC
instructions presented below.
Ie INSfALLATION
CAUTION: Integrated circuits. [ICs) are complex
electrical devices that perfonn maAy complicated
operations in acilcuit. These devices can be dam-
aged during installation. Reed all of the following
infonnation before you install the ICs.
Some of the IC pins may have become bent during
their removal.
If this is tbe case. they will not line
up with the holes in the IC socket. Before you install
all IC. make SW'll all of its pins are straight.
Once you remove
all Ie from its socket or protective
foam packing. 00 NOT lay the IC down or let go
of it until it is installed in its soc:;ket. When you bend
the leads of an IC. hold it in one band and place
your other band on your work surface before you
touch the
IC to your work surface. This will equallu
the static electricity between the work surface and
the IC.
The pins on ICs that have not been installed before
[UZI9 and UZ41!. may be bent out at an angle. so
they do not line up with Ihe holes in the IC socket.
00 NOT try to install an IC without first bending
the pins
a.s described below. To do so may damage
the Ie pins or the socket. causing inlennittent con-
tact.
FJE\
'V
Ie LIAO.
Before you install an IC for the first time. lay it down
on its side as shown below and very carefully roll
il toward the pins to bend the lower pins into line.
Then
tum the IC overand bend the pins on the other
side.in the same manner.
Before you install an IC. you must first identify its
pin 1end. Compare the
IC to the drawing below.
Then determine which end of the
IC is the pin 1
end.
Position the pin 1end
of the IC over the index mark
as shown below. Then start the IC pins into the sock·
et. Make sure all of the pins are started: then push
the
IC firmly into the soc:;ket. NOTE: An IC pin can
become bent under the
IC and it appear a.s though
it is correctly installed.
Figure 12
IC Installation Instructions
18
