Unify OpenStage M3 EX Operator's manual

OpenStage M3/M3 Plus
OpenStage M3 Ex/M3 Ex Plus
on HiPath Cordless 
Alarm and Emergency Call Configuration
Administrator Documentation
A31003-M2000-M103-2-A9

Our Quality and Environmental Management Systems are
implemented according to the requirements of the ISO9001 and
ISO14001 standards and are certified by an external certification
company.

Copyright © Unify GmbH & Co. KG 07/2014 
Hofmannstr. 51, 81379 Munich/Germany
All rights reserved.
Reference No.: A31003-M2000-M103-2-A9
The information provided in this document contains merely general descriptions or
characteristics of performance which in case of actual use do not always apply as

described or which may change as a result of further development of the products. 
An obligation to provide the respective characteristics shall only exist if expressly agreed in
the terms of contract.
Availability and technical specifications are subject to change without notice.
Unify, OpenScape, OpenStage and HiPath are registered trademarks of Unify GmbH & Co. KG.
All other company, brand, product and service names are trademarks or registered trademarks
of their respective holders.
unify.com

SHB_PNG_TOC.fm
A31003-M2000-M103-2-76A9, 07/2014
Alarm and Emergency Call Configuration, Administrator Documentation 0-1
For internal use only Contents
Contents 0
Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0-3
1 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1.2 Privacy and data security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.3 Notational conventions and symbols used. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
2 Operating modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.1 Mode dependent functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.2 Basic Mode: Availability, alarm and emergency call . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.3 Alarm Mode: Freely configurable monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2.4 PNG Mode: Monitoring in compliance with BGR 139 . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2.4.1 HiPath PNA (personal alarm system) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2.4.1.1 In alarm status: Callback by HNA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
3 Configuration and activation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3.1.1 [Mode] Activation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3.1.2 Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
3.1.3 Operating mode (OpenStage M3 Plus and OpenStage M3 Ex Plus only) . . . . . . 3-2
3.1.4 Display Rotate (OpenStage M3 Plus and OpenStage M3 Ex Plus only) . . . . . . . 3-3
3.2 Configuration menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
3.2.1 Alarm Konfiguration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
3.2.1.1 Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
3.2.1.2 [Mode] Activation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
3.2.1.3 Control Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
3.2.1.4 Techn. Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
3.2.1.5 Adjust Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
3.2.1.6 Reset to default . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16
3.2.1.7 Alarm Signal PIN (only in Alarm and PNG Mode) . . . . . . . . . . . . . . . . . . . . 3-16
3.2.2 Emergency Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-17
3.2.2.1 Emergency Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-18
3.2.2.2 Resetting emergency call configuration to defaults . . . . . . . . . . . . . . . . . . . 3-19
3.2.3 Service PIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-19
3.3 Exporting and transmitting the configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-21
4 Control ports and alarm destinations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.1 Syntax of the control ports and alarm destinations . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.1.1 Calls to the alarm server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.1.2 Calls from the alarm server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
4.2 Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
5 Response times under VDE 0825 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

Contents For internal use only
A31003-M2000-M103-2-76A9, 07/2014
0-2 Alarm and Emergency Call Configuration, Administrator Documentation
SHB_PNG_TOC.fm
6 Structure of the Additional Features menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
6.1 OpenStage M3/OpenStage M3 Ex . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
6.2 OpenStage M3 Plus/OpenStage M3 Ex Plus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
6.2.1 Operating Mode 1: Basic Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
6.2.2 Operating Mode 2: Alarm Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
6.2.3 Operating Mode 3: PNG Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Y-1
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Z-1

SHB_PNG_LOT.fm
A31003-M2000-M103-2-76A9, 07/2014
Alarm and Emergency Call Configuration, Administrator Documentation 0-3
For internal use only Tables
Tables 0
Table 2-1 Function overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Table 3-1 Parameter – General Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Table 3-2 Parameter – Manual Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Table 3-3 Parameter – Manual Alarm, example . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Table 3-4 Parameter – Non Movement Alarm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
Table 3-5 Parameter – Man Down Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
Table 3-6 Parameter – Time Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
Table 3-7 Parameter – Escape Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
Table 3-8 Parameter – Pull Cord Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
Table 3-9 Parameter – Prealarm/Alarming Signal. . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
Table 3-10 Parameter – [Mode] Activation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
Table 3-11 Parameter – Control Ports in Basic Mode . . . . . . . . . . . . . . . . . . . . . . . . 3-14
Table 3-12 Parameter – Control Ports in Alarm/PNG Mode . . . . . . . . . . . . . . . . . . . 3-14
Table 3-13 Parameter – Techn. Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
Table 3-14 Parameter – Alarm Signal PIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-17
Table 3-15 Parameter – Emergency Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-18
Table 4-1 Phone number syntax – Calls to the alarm server . . . . . . . . . . . . . . . . . . 4-1
Table 4-2 Phone number syntax – Calls from the alarm server . . . . . . . . . . . . . . . . 4-2
Table 4-3 Phone number example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Table 5-1 Response times under VDE 0825 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Table 6-1 Launching the Additional Features - Configuration - Basic Configuration menu
6-1
Table 6-2 Additional Features - Configuration - Basic Configuration menu . . . . . . . 6-1
Table 6-3 Additional Features - Configuration menu. . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Table 6-4 Additional Features - Configuration - Basic Configuration - Alarms menu 6-2
Table 6-5 Launching the Additional Features - Configuration - Basic Configuration menu
6-3
Table 6-6 Launching the Additional Features - Operating Mode menu. . . . . . . . . . . 6-3
Table 6-7 Additional Features - Configuration - Basic Configuration menu . . . . . . . 6-3
Table 6-8 Additional Features - Configuration - Basic Configuration menu . . . . . . . 6-4
Table 6-9 Additional Features - Configuration menu. . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Table 6-10 Additional Features - Configuration - Basic Configuration - Alarms menu 6-5
Table 6-11 Additional Features - Configuration - Basic Configuration - Alarms menu 6-5
Table 6-12 Launching the Additional Features - Configuration - Alarm Configuration menu
6-6
Table 6-13 Launching the Additional Features - Operating Mode menu. . . . . . . . . . . 6-6
Table 6-14 Additional Features - Configuration - Alarm Configuration menu . . . . . . . 6-6
Table 6-15 Additional Features - Configuration - Alarm Configuration menu . . . . . . . 6-7
Table 6-16 Additional Features - Configuration menu. . . . . . . . . . . . . . . . . . . . . . . . . 6-7
Table 6-17 Additional Features - Configuration - Alarm Configuration - Alarms menu 6-8

Tables For internal use only
A31003-M2000-M103-2-76A9, 07/2014
0-4 Alarm and Emergency Call Configuration, Administrator Documentation
SHB_PNG_LOT.fm
Table 6-18 Additional Features - Configuration - Alarm Configuration - Alarms menu. 6-8
Table 6-19 Launching the Additional Features - Configuration - PNG Configuration menu
6-9
Table 6-20 Launching the Additional Features - Operating Mode menu . . . . . . . . . . . 6-9
Table 6-21 Additional Features - Configuration - PNG Configuration menu. . . . . . . . . 6-9
Table 6-22 Additional Features - Configuration - PNG Configuration menu. . . . . . . . 6-10
Table 6-23 Additional Features - Configuration menu . . . . . . . . . . . . . . . . . . . . . . . . 6-10
Table 6-24 Additional Features - Configuration - PNG Configuration - Alarms menu 6-11
Table 6-25 Additional Features - Configuration - PNG Configuration - Alarms menu 6-11

SHB_PNG-Einleitung.fm
A31003-M2000-M103-2-76A9, 07/2014
Alarm and Emergency Call Configuration, Administrator Documentation 1-1
Introduction
Overview
1 Introduction
Contents
This chapter covers the following topics:
●Section 1.1, "Overview"
●Section 1.2, "Privacy and data security"
●Section 1.3, "Notational conventions and symbols used"
1.1 Overview
The OpenStage M3 Plus and OpenStage M3 Ex Plus handsets can be used as personal alarm
devices with voice communication capability (PNG-S) in Alarm Mode and PNG Mode. Various
settings are performed on the handset for this purpose, which enable automatic or manual
alerting. An alarm and emergency call function is already available in Basic Mode.
The OpenStage M3 and OpenStage M3 Ex handsets do not have alarm sensors, rather they
also have an alarm and emergency call function. The function range corresponds to that of
Basic Mode.
An emergency call via an alarm key is possible regardless of selecting and activating an
operating mode.
The PNG-S monitors the person and reports an alarm when alarm conditions are detected. The
following types of alarms and signals are possible:
●Man Down Alarm:
The integrated movement sensors identify deviations of approx. 70° from the vertical
position of the handset.
●Non Movement Alarm:
The integrated movement sensors detect immobility of the handset.
●Escape Alarm:
The integrated movement sensors detect sudden, violent movements of the handset.
●Pull Cord Alarm:
Removal of a magnetic contact, which is inserted below the handset and can be secured
by a cord to the individual, is detected.
●Time Alarm:
The operator's ability to respond can be controlled through regular operation of the
handset. The user is prompted to input something at set times.
●Manual Alarm:
The user can trigger an alarm by pressing the alarm key.

Introduction
A31003-M2000-M103-2-76A9, 07/2014
1-2 Alarm and Emergency Call Configuration, Administrator Documentation
SHB_PNG-Einleitung.fm
Privacy and data security
●Technical Warning Signal:
The handset detects local technical faults or DPS requests. These are signalled to the user.
Example: The handset is out of range or the battery charge is too low. The user can
subsequently initiate measures in order to resolve the fault.
>All settings that are non BGR 139-compliant are not permitted for BGR 139
applications.
A prealarm informs the monitored persons of an impending alarm. The alarm can still be reset
during the prealarm time in order to avoid false alarms.
The response time, prealarm time, possibly sensitivity level, alarm signal and alarm destination
can be configured for each alarm type.
1.2 Privacy and data security
This telephone system uses and processes personal data, for example in the case of call detail
recording, display messages and customer data recording.
In Germany, the processing and use of such data is subject to various regulations, including
those of the Federal Data Protection Law (Bundesdatenschutzgesetz, BDSG). Observe all
applicable laws in other countries.
Employees of Unify GmbH & Co. KG are bound to safeguard trade secrets and personal data
under the terms of the company's work rules.
A conscientious and responsible approach helps protect data and ensure privacy:
●Use the password features of the system with no exceptions: Change the default password
immediately.
●Never give passwords to an unauthorised person, for example in the form of a note.
●Prevent unauthorised persons from gaining access to data media, for example on backup
disks or printed reports. This applies to service calls as well as storage and transport.
●Ensure that storage media that are no longer required are completely destroyed. Ensure
that no sensitive documents are left unprotected.

SHB_PNG-Einleitung.fm
A31003-M2000-M103-2-76A9, 07/2014
Alarm and Emergency Call Configuration, Administrator Documentation 1-3
Introduction
Notational conventions and symbols used
1.3 Notational conventions and symbols used
>"i" identifies useful information.
7Safety notes Hazard information.
This manual uses the following symbols:

SHB_PNG-Modes.fm
A31003-M2000-M103-2-76A9, 07/2014
Alarm and Emergency Call Configuration, Administrator Documentation 2-1
Operating modes
Mode dependent functions
2 Operating modes
The OpenStage M3 Plus and OpenStage M3 Ex Plus handsets can be used as personal alarm
devices with voice communication capability (PNG-S).
Depending on the available infrastructure and requirements, different ranges of functions can
be defined for the OpenStage M3 Plus and OpenStage M3 Ex Plus handsets, which are
grouped under the operating modes Basic Mode (BM), Alarm Mode (AM) and PNG Mode
(PNG).
Following input of a service PIN, each operating mode can be configured independently of the
others with toggling possible between the different modes.
Contents
This chapter covers the following topics:
●Section 2.1, "Mode dependent functions"
●Section 2.2, "Basic Mode: Availability, alarm and emergency call"
●Section 2.3, "Alarm Mode: Freely configurable monitoring"
●Section 2.4, "PNG Mode: Monitoring in compliance with BGR 139"
●Section 2.4.1, "HiPath PNA (personal alarm system)"
2.1 Mode dependent functions
An overview of the functions with handset and mode dependencies is provided below.
OpenStage M3
OpenStage M3 Ex
OpenStage M3 Plus
OpenStage M3 Ex Plus
Function BM (Basic Mode) BM AM PNG
Emergency call using alarm signal key X X X X
Signalling technical faults such as out of DECT
range, no connection to alarm server
X X X X
Sensory alarms such as Man Down Alarm,
Non Movement Alarm, Escape Alarm, Pull
Cord Alarm, Time Alarm
- X X X
Function testing of alarm sensors required for
mode activation
- - X X
Table 2-1 Function overview

SHB_PNG-Modes.fm
A31003-M2000-M103-2-76A9, 07/2014
Alarm and Emergency Call Configuration, Administrator Documentation 2-2
Operating modes
Basic Mode: Availability, alarm and emergency call
2.2 Basic Mode: Availability, alarm and emergency call
Different alarms, including sensory alarms, can be triggered in Basic Mode of the
OpenStage M3 Plus and OpenStage M3 Ex Plus handsets. An alarm destination entered in
the handset can be selected in the event of alarms. Three alarm destinations are possible on
the HiPath 3000/4000.
Only Basic Mode is available on the OpenStage M3 and OpenStage M3 Ex handsets.
Sensory alarms are not possible with these devices.
Emergency calls via the alarm key are possible on all devices, even if no mode is activated.
In order to ensure that alarm calls reach the alarm destination as reliably as possible, the alarm
calls are repeated until the configured number of retries has been reached or the alarm retry
has been interrupted manually on the handset. Despite alarm retries, it cannot be fully
guaranteed that an alarm call will reach the programmed alarm destination.
Alarm callback from alarm server on the
handset
- - X X
Signalling of technical faults on the handset X X X X
Signalling of alarms on an alarm server (with
acknowledgement by the alarm server)
- - X X
Signalling of alarms on an alarm server
(without acknowledgement by the alarm
server)
X X X -
Monitoring in compliance with BGR 139 - - - X
Operation via HiPath Cordless Office on a
HiPath 3000
X X X -
Operation via HiPath Cordless Enterprise on a
HiPath 4000
X X X X
Operation via HiPath Cordless IP on an
OpenScape Office/OpenScape Voice
X X X -
OpenStage M3
OpenStage M3 Ex
OpenStage M3 Plus
OpenStage M3 Ex Plus
Function BM (Basic Mode) BM AM PNG
Table 2-1 Function overview

7Note: A call connection must be established to enable operation of the second and third emergency call/alarm number when the handset has registered on the HiPath
3000/OpenScape Business or HiPath/OpenScape 4000. All other systems only
support dialing of one emergency call or alarm number.
For HiPath 3000/OpenScape Business, emergency and alarm call numbers are only
supported from within the same system. Call waiting protection for these emergency
numbers must be set to ON. The functionality of the emergency and alarm numbers
in the handset must be checked after the configuration.
>If a prealarm is signalled during a call, you have to first confirm the prealarm in order
to prevent the pending alarm. You can then continue the call.
Operating modes
A31003-M2000-M103-2-76A9, 07/2014
2-3 Alarm and Emergency Call Configuration, Administrator Documentation
SHB_PNG-Modes.fm
Alarm Mode: Freely configurable monitoring
2.3 Alarm Mode: Freely configurable monitoring
>PNG Mode should be used for BGR 139 compliant configuration.
All alarms can be freely configured in Alarm Mode of the OpenStage M3 Plus and
OpenStage M3 Ex Plus handsets. Alarm Mode only works in conjunction with an alarm server.
The alarm parameters can be configured freely. Adjust the handset to your requirements.
Monitoring is activated and deactivated directly via the handset. A function test is performed for
the alarm elements when monitoring is activated.
2.4 PNG Mode: Monitoring in compliance with BGR 139
>All settings that are non BGR 139-compliant are not permitted for BGR 139
applications.
PNG Mode of the OpenStage M3 Plus and OpenStage M3 Ex Plus handsets provides the
option of BGR 139-compliant triggering of alarms on a HiPath 4000. Monitoring in compliance
with BGR 139 only works in conjunction with an alarm server.
Appropriately trained service personnel are responsible for the BGR 139-compliant
configuration of the handset and BGR 139-compliant usage.
This guide describes the options for configuring the handset. Reference is thereby made to the
BGR 139-compliant settings.

SHB_PNG-Modes.fm
A31003-M2000-M103-2-76A9, 07/2014
Alarm and Emergency Call Configuration, Administrator Documentation 2-4
Operating modes
PNG Mode: Monitoring in compliance with BGR 139
Specific handset settings (e.g. Mobilteil-Reset, Basisauswahl, MT anmelden, ...) can be
blocked for ordinary users by activating PNG functionality.
If a blocked function is selected, you will be requested to enter a service PIN. The function is
only activated if a correct PIN is entered.
2.4.1 HiPath PNA (personal alarm system)
The HiPath alarm system is required for operation in PNG Mode and allows operation in
compliance with BGR 139. It is based on HiPath Cordless Enterprise CMI 3.0 from KV 415.
The alarm server acts as the control centre for this personal alarm system (PNA system). The
alarm server controls and monitors the PNG-S and responds to its messages and alarms. The
CLIP information from the setup message at connection setup is required for managing the
PNG-S.
The user performs a function test on the sensors prior to activation. Monitoring is activated by
the alarm server if the function test has been performed successfully.
Alarm calls from the PNG-S are directed to the configured alarm destination. To ensure that the
alarm calls reach the alarm destination, the calls are repeated until an alarm callback from the
alarm server has been detected or the configured number of retries has been reached.
Nevertheless, it cannot be fully guaranteed that an alarm call will reach the programmed alarm
destination. The alarm server therefore also checks the communication paths to the PNG-S
and polls the PNG-S cyclically. If there are no responses, the alarm server generates a
technical alarm and assistance is deployed. A local alarm is triggered additionally on the
PNG-S.
The handset and therefore the person who triggers the alarm can then be located using
positioning services. When the alarm has been processed, an alarm signal is emitted on the
PNG-S, which serves to further pinpoint the location of the party who triggered the alarm.
The alarm server is responsible for resetting the alarm and disabling monitoring. The alarm
server checks in the process whether monitoring can be disabled if necessary. For example the
disabling location is checked as a criterion.

Operating modes
A31003-M2000-M103-2-76A9, 07/2014
2-5 Alarm and Emergency Call Configuration, Administrator Documentation
SHB_PNG-Modes.fm
PNG Mode: Monitoring in compliance with BGR 139
2.4.1.1 In alarm status: Callback by HNA
>As an employee at the HNA, make sure to obtain permission to listen in from the
monitored person before monitoring.
If individual workplaces are prohibited in the applicable regulations, this ban may not
be circumvented with a personal alarm device.
The handset has sent an alarm signal to the PNEZ and is consequently in alarm status. The
HNA acknowledges the alarm call with an alarm callback. The handset answers this control call
automatically.
The alarm callback allows the events at the alarm location to be monitored at the HNA. The
speakerphone function can be used to communicate with the alerting party if necessary.

SHB_PNG-Konfig.fm
A31003-M2000-M103-2-76A9, 07/2014
Alarm and Emergency Call Configuration, Administrator Documentation 3-1
Configuration and activation
Overview
3 Configuration and activation
In order to be able to configure all of the handset's possible alarm and signalling functions in
accordance with your requirements, it is important to understand fundamental relationships
and concepts.
You should therefore familiarise yourself with the following topics:
●For operating mode features, see Chapter 2, "Operating modes".
●For control ports and alarm destinations, see Chapter 4, "Control ports and alarm
destinations".
Contents
This chapter covers the following topics:
●Section 3.1, "Overview"
●Section 3.2, "Configuration menu"
3.1 Overview
The "Additional Features" menu contains all parameters for configuring the alarm and
signalling functions.
3.1.1 [Mode] Activation
Use this menu option to manually activate and deactivate the mode configured in the
"Configuration" menu and selected in the "Operating Mode" menu. Depending on this, the
menu option in Basic Mode will be called "BM Activation", in Alarm Mode "AM Activation" or in
PNG Mode "PNG Activation".
When Alarm Mode and PNG Mode are activated, a sensor test is performed first in each case.
Only the sensors that are activated in the respective mode are checked. It is only if the test has
been concluded successfully that the corresponding Alarm Mode is active.
Manual activation is only possible if this has been activated for the corresponding operating
mode. It is also possible to configure automatic activation.
See Section 3.2.1.2, "[Mode] Activation".
If one of the operating modes is active, the monitoring LED above the display flashes green.
Procedure:
When the display is idle, press the centre key three times (central key on the control key) to
activate/deactivate.

SHB_PNG-Konfig.fm
A31003-M2000-M103-2-76A9, 07/2014
Alarm and Emergency Call Configuration, Administrator Documentation 3-2
Configuration and activation
Overview
Alternatively:
1. Select the Additional Features icon in the main menu.
2. Select [Mode] Activation.
>In monitoring mode: Do not remove the battery pack! Removal of the battery pack
will result in a technical alarm being triggered in the HNA.
3.1.2 Configuration
You can configure all operating mode parameters in this menu independently of one another
as well as define emergency call numbers and change the service PIN. This configuration may
only be performed by appropriately trained service personnel.
Service personnel are also responsible for ensuring that the service PIN is set to a secret value
before the configured handset is given to the user. See also Section 3.2.3, "Service PIN".
The service PIN must be entered in order to perform the configuration.
Access to the Configuration menu is blocked as long as one of the operating modes is active,
see Section 3.1.1, "[Mode] Activation".
For more information on this menu please refer to Section 3.2, "Configuration menu".
3.1.3 Operating mode (OpenStage M3 Plus and OpenStage M3 Ex Plus
only)
You can select one of the three operating modes Basic Mode, Alarm Mode or PNG Mode in
this menu:
●Basic Mode: All sensory alarms are available: Three alarm destinations for sensory alarms
can be configured in the same way as for the emergency call. Operation is possible with or
without an alarm server.
●Alarm Mode: All sensory alarms forwarded to an alarm server are available.
●PNG Mode: All sensory alarms forwarded to an alarm server in compliance with BGR 139
are available.
This selection may only be performed by appropriately trained service personnel.
The service PIN must be entered in order to change the operating mode.
It is not possible to change the operating mode while one of the operating modes is active, see
Section 3.1.1, "[Mode] Activation".
For more information on operating modes please refer to Chapter 2, "Operating modes".

Configuration and activation
A31003-M2000-M103-2-76A9, 07/2014
3-3 Alarm and Emergency Call Configuration, Administrator Documentation
SHB_PNG-Konfig.fm
Overview
Procedure:
1. Select the Additional Features icon in the main menu.
2. Select Operating Mode.
3. Enter the five-position service PIN and confirm with OK.
4. Select one of the three operating modes and confirm with Selection.
3.1.4 Display Rotate (OpenStage M3 Plus and OpenStage M3 Ex Plus
only)
Use this menu option to activate and deactivate the automatic position-dependent rotation of
the information on the display.
When activated, the display is rotated by 180° (upside down) in non movement and call
statuses when you move the handset from a vertical to a horizontal position.
This setting is useful if you are wearing the handset on a belt and you would like to see the
display in the event of an alarm or call without having to remove the handset from the belt. You
can then read the information on the display by simply tilting the handset outwards.
Procedure:
1. Select the Additional Features icon in the main menu.
2. Select Display Rotate.

SHB_PNG-Konfig.fm
A31003-M2000-M103-2-76A9, 07/2014
Alarm and Emergency Call Configuration, Administrator Documentation 3-4
Configuration and activation
Configuration menu
3.2 Configuration menu
The alarming signal parameters that define the alarm response are defined under the
Configuration menu option. Configuration can be performed here for each operating mode,
independently of the other operating modes.
The parameters are described independently of the operating mode. If a parameter is not
available in an operating mode, this is noted in the parameter description.
Apart from the alarming signal parameters, emergency numbers can be configured in the
Configuration menu and the service PIN changed.
3.2.1 Alarm Konfiguration
3.2.1.1 Alarms
The following alarms are supported by the handset:
●Manual Alarm
●Non Movement Alarm
●Man Down Alarm
●Time Alarm
●Escape Alarm
●Pull Cord Alarm
7Use PNG Mode for BGR 139-compliant operation and observe the settings prescribed there.
At least one automatic alarm has to be activated here in addition to the manual
alarm.
It is not possible to switch off all alarms in PNG Mode.
General values are entered for all alarms. Furthermore, parameters are preconfigured for each
alarm type, which can be adapted individually however for the corresponding application.
General Settings
These values are used in general for all alarm types within an operating mode. If an alarm
server is available, then only the Control Port Basic parameter has to be entered here.
Procedure:
1. Select the Additional Features icon in the main menu.
2. Select Configuration.

Configuration and activation
A31003-M2000-M103-2-76A9, 07/2014
3-5 Alarm and Emergency Call Configuration, Administrator Documentation
SHB_PNG-Konfig.fm
Configuration menu
3. Enter the five-position service PIN and confirm with OK.
4. Select one of the three operating modes.
5. Select Alarms.
6. Select General Settings.
7. Change the values of the following parameters:
Table 3-1 Parameter – General Settings
Parameters Operating
Mode
Value Range Standard Value
Control Port Basic BM - -
AM/PNG (up to 32 digits) (blank)
Alarm Destination BM - -
AM/PNG (up to 32 digits) (blank)
Alarm Destination 1 BM (up to 32 digits) 112
AM/PNG - -
Alarm Destination 2 BM (up to 32 digits) (blank)
AM/PNG - -
Alarm Destination 3 BM (up to 32 digits) (blank)
AM/PNG - -
Alarm Call Count
BM - -
AM 1 ... 99 15
PNG 1 ... 99 99
Autom. Alarm
BM On / Off / Off in Charger On
AM On / Off / Off in Charger On
PNG On / Off in Charger On
Calling Time BM 0 ... 60 s 30 s
AM/PNG - -
Audio Channel BM/AM/PNG Handset mode / 
Handsfree Handset mode
8. Confirm with Save.

SHB_PNG-Konfig.fm
A31003-M2000-M103-2-76A9, 07/2014
Alarm and Emergency Call Configuration, Administrator Documentation 3-6
Configuration and activation
Configuration menu
Manual Alarm
>
You can configure all settings here for the manual alarm, in other words for the alarm triggered
with the red alarm key.
Depending on how the red alarm key is pressed (SP: Shortpress, LP: Longpress), different
alarms are signalled and different alarm destinations are dialled.
For more information on alarm destinations please refer to Chapter 4, "Control ports and alarm
destinations".
Procedure:
1. Select the Additional Features icon in the main menu.
2. Select Configuration.
3. Enter the five-position service PIN and confirm with OK.
4. Select one of the three operating modes.
5. Select Alarms.
6. Select Manual Alarm.
7. Change the values of the following parameters:
Table 3-2 Parameter – Manual Alarm
AM/PNG
Parameters Value Range Standard Value
Alarm Key SP On/off On
Alarm Key LP On/off On
Alarm Key locked On/off Off
Alarm Signal SP On/off On
Alarm Signal LP On/off Off
Alarm Destination SP (up to 32 digits) (blank)
Alarm Destination LP (up to 32 digits) (blank)
8. Confirm with Save.
The red key is assigned for the manual alarm in Alarm Mode and PNG Mode
following activation. The numbers configured under the emergency call (Section
3.2.2, "Emergency Call") are selected if no mode is active. The emergency number
is overwritten by the alarm server with its own emergency number when the Control
Port Basic parameter is entered.
