USSC Clayton 1537Q User manual

UNITED STATES STOVE COMPANY
227 Industrial Park Road
P.O.Box 151
South Pittsburg, TN 37380
[phone]
Model 1537Q
SOLID FUEL WARM AIR FURNACE
Owners Manual
C
O
M
P
A
N
Y
U
N
I
T
E
D
S
T
A
T
E
S
S
T
O
V
E
C
S
S
U
WARNOCK HERSEY
R
*FOR PARALLEL INSTALLATION WITH AN
EXISTING FORCED AIR, GAS OR OIL
FIRED FURNACE (U.S. ONLY)
*FOR INSTALLATION AS A CENTRAL FURNACE
DO NOT USE THIS FURNACE IN A MOBILE HOME OR TRAILER
Improper Installation May
Void Your Warranty
Save This Manual For
Future Reference
CAUTION:
Read All Instructions Carefully Before
StartingtheInstallationorOperatingthe
Furnace.
851239B 10/98
TM

CONGRATULATIONS!
You've purchased one of America's Finest Wood and Coal Burning Furnaces.
By heating with wood and coal you're helping to CONSERVE AMERICA'S ENERGY!
Wood is our Renewable Energy Resource. Please do your part to preserve our wood
supply. Plant at least one tree each year. Future generations will thank you.
NOTE: YOUR UNIT MUST BE INSTALLED BY A QUALIFIED FURNACE INSTALLER.
IMPROPER INSTALLATION COULD VOID YOUR WARRANTY!
NOTE: (See Page 5, First Paragraph)
tools and materials needed
MATERIALSTOOLS
Pencil
6 Foot Folding Rule or Tape
Tin Snips
Drill, Hand or Electric
Drill Bit (For Sheet Metal Screws) 1/8" Dia.
Screw Driver (Blade-Type)
Gloves
Sabre Saw
5/16" Nut Driver or
5/16" Socket with Rachet
6" Pipe, 6" Elbow, Collar and Thimble; as required
(24 gauge min.)
1/2" Sheet Metal Screws
6" Inside Diameter Listed Residential Type or
Building Heating Appliance Chimney or Existing
Masonry Chimney (SEE Page 8).
Electrical Wiring
6" Draft Regulator
1/2" Conduit
(Conduit Connectors)
Furnace Cement (Manufacturer Recommends:
Rutland Black - Code 78 or Equivalent
Plenum and Duct Work as Required
2

Caution Labels
Your Furnace has the following labels. Read and obey all labels.
DANGER: RISK OF FIRE OR EXPLOSION.
DO NOT burn garbage, gasoline, drain oil, or other flammable liquids.
WARNING: FIRE HAZARD.
DO NOT operate with fire draft exceeding .06 inches W.C.
DO NOT operate with fuel loading or ash removal doors open.
DO NOT store fuel or other combustible material within the marked installation clearances.
DO NOT store fuels, paints, thinners, flammable liquids, or other highly volatile substances in the
furnace room.
CAUTION: HOT SURFACES
Keep children away.
Do not touch during operation.
CAUTION!
INSPECT FLUE PIPES, FLUE
PIPE JOINTS AND FLUE PIPE
SEALS REGULARLY TO EN-
SURETHATSMOKEANDFLUE
GASES ARE NOT DRAWN
INTO, AND CIRCULATED BY,
THE AIR CIRCULATION SYS-
TEM.
CAUTION!
CLEANOUT OF THE HEAT EX-
CHANGER,FLUEPIPE,CHIMNEY,AND
DRAFT INDUCER IF USED, IS ESPE-
CIALLY IMPORTANT AT THE END OF
THE HEATING SEASON TO MINIMIZE
CORROSION DURING THE SUMMER
MONTHS, CAUSED BY ACCUMU-
LATED ASH.
If this heater is not properly installed, a house
fire may result. For your safety, follow the in-
stallation directions. Contact local building or fire
officials about restrictions and installation in-
spection requirements in your area.
SAFETY
NOTICE:
3

rules for safe installation and operation
Read these rules and the instructions carefully. Failure to follow them will cause a hazard that could result in
death, serious bodily injury, and/or property damage.
Check your local codes. This installation must comply with their rulings.
Do not install this furnace in a mobile home or trailer.
Always connect this furnace to a chimney and vent to the outside. Never vent to another room or
inside a building.
Do not connect this furnace to an aluminum Type B gas vent. This is not safe and is prohibited by the
National Fire Protection Association Code. This furnace requires a masonry or listed factory built
chimney for residential type or building heating appliance chimney. Use a 6" diameter chimney or
larger, that is high enough to give a good draft. (See Page 8)
Be sure that if a masonry chimney is used, it is safely constructed and in good repair. Have the
chimney inspected by the Fire Department or an inspector.
Inspect chimney connector and chimney before and frequently during the heating season for any
deposit of creosote or soot which must be removed (see Chimney Maintenance, page 21.)
Provide air for combustion into the room where the furnace is located. If the intake is not in the same
room, air must have free access to the room.
CAST IRON PARTS MUST BE "SEASONED" TO AVOID CRACKING. BUILD ONLY SMALL FIRES
ON FIRST USE.
To prevent injury, do not allow anyone to use this furnace who is unfamiliar with the correct operation
of the furnace.
For further information on using your furnace safely, obtain a copy of the National Fire Protection
Association (NFPA) publication "Chimney's, Fireplaces and Solid Fuel Burning Appliances" NFPA
211. The address of the NFPA is Batterymarch Park, Quincy, MA 02269.
Keep the ashpit section free of excess ashes. Do not allow ashes to stack higher than the sides of the
ash pan.
DISPOSAL OF ASHES - Place ashes in a metal container with a tight fitting lid. Keep the closed
container on a noncombustible floor or on the ground, well away from all combustible materials. Keep
the ashes in the closed container until all cinders have thoroughly cooled. The ashes may be buried
in the ground or picked up be a refuse collector.
CAUTION - The special paints used on your furnace may give off some smoke while they are curing
during first few fires. Build small fires at first. The metal used in construction of the furnace and duct
work has a light coating of oil. This could give off smoke and/or odors from registers when furnace is
used for the first time. This should disappear after a short period of time. Once this burn-off has
occurred, it should not reoccur.
CARING FOR PAINTED PARTS - This furnace has a painted outside jacket, which is durable but it
will not stand rough handling or abuse. When installing you furnace, use care in handling. Clean with
soap and warm water when furnace is not hot. DO NOT use any acids or scouring soap, as these
wear and dull the finish. DISCOLORATION WILL OCCUR IF THE FURNACE IS OVERFIRED.
FOLLOW OPERATING INSTRUCTIONS CAREFULLY.
Keep the feed and ash doors closed at all times except while tending the furnace.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
Your Furnace is designed to be installed in a parallel air flow arrangement with a gas or oil-fired
forced air upflow-type central furnace, or it may be installed as a central furnace.
4

Your Supplemental Furnace is designed to be
asupplementalorcentralheatingsourcefor
your home. This solid fuel furnace may be
installedinconjunction withaproperlyoperating
central furnace that is listed or certified in
accordancewithnationally recognizedsafety
standardsandequippedwiththerequired
controls and other safety features and which has
beeninstalledwithappropriatestandardsof
National Fire Protection Association with
installation clearances specified in the furnace
nameplatemarking. The installationmust be
accomplished by a qualified agency (one who is
engaged in, and is responsible for, or is thor-
oughlyfamiliarwiththeinstallation and operation
of the gas, oil, and solid fuel burning heating
appliances, who is experienced in such work,
familiarwithallprecautions required, and has
complied with all the requirements of the
authorityhavingjurisdiction.)Theinstallation
shall be in strict accordance with the
manufacturer'sinstallationinstructionsfurnished
with the solid fuel furnace.
The chimney connector of the furnace is to
be installed to provide clearances to combus-
tible material not less than specified in the
individual classifications and marked on the
furnace. The chimney connector must be
connected to a chimney suitable for use with
residentialtypeorbuildingheatingappliances
which burn solid fuel.
The furnace is designed to operate in either
parallelorseries air flowarrangementwiththe
central furnace or as a central furnace.
PARALLEL INSTALLATION: The design is such
that when the blower comes on,
the blower on the central system also comes on.
Theblowerwillonlycome on when the tempera-
ture in the plenum has reached the setting on
the blower control. This is to insure that there is
sufficient warm air in the system to make it
efficient for the unit to operate. When the central
system thermostat calls for heat, the central
system will operate by the burner igniting and
the blower coming on. It is possible that both
systems will operate simultaneously. It is
recommended that for the most efficient use of
your Supplemental Furnace, that it be fired as
much as possible in order to reduce the demand
on your existing central heating system. This
unit has an optional motorized natural draft kit
that operates from a wall thermostat. When the
temperature falls below the setting on the wall
thermostat,the motorized natural draft willopen
to increase heat.
The warm air supply outlet of the supplemen-
tary furnace shall not be connected to the cold
air return inlet of the central furnace because the
possibility exists of components of the central
furnaceoverheatingandcausingthecentral
furnacetooperateother than is intended.
SERIES INSTALLATION: This type of installa-
tion uses only the blowers of the existing central
furnace. The solid fuel fan/limit control must
also control the functions of the existing fur-
nace. All electrical power must come from a
single branch circuit (see Fig. 15).
CENTRALFURNACEINSTALLATION:Asa
centralfurnace,theunitfunctionsindependently
of any other system. The blower will come on
whentheplenumtemperaturereachesthe
setting on the blower control.
HOW THE FURNACE FUNCTIONS
5

24-1/16
40-11/16
32-1/4 3-1/2
9"
33-7/8
43-7/8
Model 1537Q Dimensions
FIG. 1
6

12" 9"
48"
18"
CENTRAL
FURNACE
6" CHIMNEY
18"
18"
6" SOLID DAMPER
6" BAROMETRIC
DRAFT REGULATOR
(OPTIONAL)
NON-COMBUSTIBLE FLOOR
The furnace should be located in the
same room as the central system
and as close as possible, but no
closer than 9". There should be no
wall between the furnace and the
warm air outlet duct that is con-
nected directly to the warm air outlet
plenum of the central furnace. See
Fig. 2.
The unit will require installation with
the following clearances:
Unit to sidewall . . . . . .12" (305 mm)
Unit to backwall . . . . . 30" (760 mm)
Chimney connector pipe to sidewall
. . . . . . . . . . . . . . . . . . 21" (530 mm)
Chimney connector pipe to backwall
. . . . . . . . . . . . . . . . . . 18" (460 mm)
Hot air ducts to combustibles
. . . . . . . . . . . . . . . . . . . 6" (150 mm)
NOTE: Install only on a noncom-
bustible floor.
(REFER TO FIG. 2 & 3)
Place the furnace on a noncombus-
tible floor.
Check figures 2 and 3. Be sure you
have the clearances shown from the
furnace and the connector pipe to
combustible surfaces. If you have a
solid brick or stone wall behind your
heater, you can place the furnace as
close as you wish to the wall. If the
wall is only faced with brick or stone,
treat it as a combustible wall.
1.
2.
3.
4.
Locating the Furnace
7
FIG. 3
FIG. 2

chimney connection
MASONRY CHIMNEY
Before using an existing masonry chimney, clean the chimney and inspect the flue liner to be sure it is safe
to use. Make repairs before attaching the furnace. See Page 4, item 5.
Look at Fig. 4. The connector pipe and fittings you will need to connect directly to a masonry chimney are
shown.
The chimney connection should be as short as possible.
If the connector pipe must go through a combustible wall before entering the masonry chimney, consult a
qualified mason or chimney dealer. The installation must conform to local fire codes, and N.F.P.A. 211.
DO NOT CONNECT THIS FURNACE TO A CHIMNEY FLUE SERVING ANOTHER APPLIANCE.
The chimney used for a furnace must not be used to ventilate the cellar or basement. If there is a cleanout
opening at the base of the chimney, close it tightly.
LISTED FACTORY BUILT CHIMNEY
Carefully follow chimney manufacturer's instructions. Use only a Listed Residential Type or Building
Heating Appliance Chimney. If your chimney starts at the ceiling (Fig. 5), you will need enough 6" pipe to
reach the ceiling.
The top of the chimney must be at least 3 feet above the roof and be at least 2 feet higher than any point of
the roof within 10 feet (Fig. 5).
10'
2' MIN.
3' MIN.
6" CHIMNEY CONNECTOR
6" ELBOW
6" SOLID DAMPER
6" BAROMETRIC
DRAFT REGULATOR
(OPTIONAL)
REFER TO CHIMNEY
MANUFACTURER'S
INSTRUCTIONS AND
PARTS.
6" SOLID DAMPER
6" BAROMETRIC
DRAFT REGULATOR
(OPTIONAL)
THIMBLE
6" ELBOW
6" CHIMNEY
CONNECTOR
6" ELBOW
NON-COMBUSTIBLE
WALL
FIG. 4
FIG. 5
8

The crimped end of the chimney con-
nector fits inside the furnace flue collar.
Installadditionalchimney connectorand
elbowwiththeCRIMPEDENDTOWARD
THEFURNACE. Thiswillallow anycon-
densation in the flue to run back into the
furnace.Use6"dia.(minimum24gauge)
black chimney connector.
Slopeanyhorizontalpipeupwardtoward
thechimneyatleast1/4inchforeachfoot
of horizontal run.
You must have at least 18 inches of
clearancebetweenanyhorizontalpiping
and the ceiling. (See Fig. 3)
The chimney connector must not extend
into the chimney flue (See Fig. 6).
Seal each chimney connector pipe joint
with furnace cement. Also seal the pipe
at the chimney.
Use 3 sheet metal screws at each chim-
ney pipe joint to make the piping rigid.
The chimney connector may include a
section for a barometric draft regulator
between the furnace and the chimney
(Fig. 4, 5, 6, & 7). The barometric draft
regulator must be installed in the same
room (same pressure zone) as the fur-
nace.
Install the barometric draft regulator
strictly in accordance with the instruc-
tionsthat are provided with the baromet-
ric draft regulator.
A solid damper can be placed between
the barometric draft regulator and the
chimney. (Fig. 4, 5, 6, & 7)
1.
2.
3.
4.
5.
6.
7.
8.
9.
Drill a hole in the chimney connector
within 18" of the flue collar below the
barometric draft regulator just large
enough for the tube of the manometer.
Build a fire after all chimney connec-
tions have been made.
Use a manometer to measure the draft
in the flue. (U.S. Stove Model DG-26)
Adjust the barometric draft regulator to
obtain a draft of 0.05" - 0.06" W.C.
under stable conditions.
1.
2.
3.
4.
Rules for Connector
Pipe Installation
Adjusting the
Barometric Draft Regulator
6" SOLID DAMPER
6" BAROMETRIC
DRAFT REGULATOR
(OPTIONAL)
MEASURE FLUE
DRAFT HERE
NON-COMBUSTIBLE
INSTALLATION PER
NFPA 211
RIGHT WRONG WRONG
FIG. 6
FIG. 7
9

Your furnace requires the following
items to be assembled or installed by
the service person:
Feed Door Handle
Feed Door Latch
Smoke Curtain
Blowers and Blower Controls
Electrical Connections
Remove all parts from inside the
furnace and inspect for damage,
including the firebrick as some
breakagecouldoccurduringship-
ment.
Assemble the feed door handle
as shown in Figure 8. Install the
latch as illustrated in Figure 9.
Attach the smoke curtain to the
firebox as shown in Figure 10.
Install Honeywell thermostat on
rear of furnace cabinet as shown
in Figure 11.
Remove blowers from cartons.
Remove junction box cover. At-
tach clip nuts as per Figure 11.
Install blowers and gaskets with
1/4"-20 x 3/4" bolts as shown.
Wire right side blower first per
wiring diagram (Figure 12) and
replace cover on junction box on
blower.
Wire left blower same as above
and replace cover.
Completeallwiringinjunctionbox
by referral to the wiring diagram
and Figure 11 - Blower and Com-
ponentAssembly. Replace cover
on junction box.
Checkoperationof shaker grates
with grate handle before operat-
ing furnace.
1.
2.
3.
4.
5.
6.
7.
8.
9.
Assembly of Furnace
10
WASHER
LOCKNUT
FEED DOOR HANDLE
FIG. 8
FIG. 9
FIG. 10
SMOKE CURTAIN
CARRIAGE BOLT
NUT
SMOKE DOOR CLIP

11
Honeywell
FAN/LIMIT
CONTROL
4" ELECTRICAL
JUNCTION BOX
BLOWER
ASSEMBLY
GASKET
CLIP NUTS
(DO NOT USE CLIP NUT
ON UPPER CENTER HOLE)
Blower & Component Assembly - FIG. 11

Model 1537Q Wiring Diagram - FIG. 12
12
BLOWER
LIMIT
CONTROL
LOAD
FAN
LINE
LOAD
LIMIT
LINE
BLACK
BLACK
WHITE
WHITE
RED
JUNCTION
BOX
GROUND
BLACK
BLACK
RED
110 VAC
60 HZ
WHITE
BLACK
FORCED
DRAFT
BLOWER
BLUE
BLACK WHITE
WHITE
BLACK
BLOWER BLOWER
BLACK WHITE
FAN CONTROL
CENTER (FRONT)
BLUE
BLACK
BLACK
123
456
COIL COIL
BROWN
BLUE
BLACK
RGC
WY
FAN CONTROL
CENTER (FRONT)
ROOM
THERMOSTAT
24 VOLT
NOTE: WHEN USING A ROOM
THERMOSTAT, YOU MUST
BREAK OFF JUMPER FOR
LOW VOLTAGE.

13
Installation
Pleaseseeallmethods ofInstallation
inAppendixattherearofthisbooklet.
This is a furnace, not a free standing stove.
You must direct heated air from 8" outlets away
from the furnace, or it will not function properly.
1. This installation must be donebyaqualified
heatingequipmentinstaller.
2. The installation is to be done in compliance
withNationalFireProtectionAssociationinstalla-
tion standards: No. 89M, 90B, 211, 70 (National
Electric Code) and Uniform Mechanical Code
913, 6-4, in the states where applicable. (Their
code offers connecting smoke pipe connectors
intochimneywithotherfuelburningappliances.)
3. Rooms large in comparison with size of the
appliances:
a)WoodorCoalBurningFurnaceneedsairfor
combustion and circulation to house.
b) Provision must be made to make up this air
and not starve gas or oil furnace of combustion
air.
c) Have "Authority Having Jurisdiction" deter-
minethatairisofadequatemakeup.(Reference
N.F.P.A. Nos. 30 & 54, Code for Installation of
Gas & Oil Equipment)
4. Have "Authority Having Jurisdiction" to
inspect all chimneys and installations for ad-
equateventingandforcompliancewithstandard
andlocalcodesandregulationsregardinginstal-
lationofwoodburningappliances.
5. Installation of Supplemental Heat Applica-
tion to Existing Central System. (See Fig. 2 for
typical installation.)
a)PlaceWoodorCoalBurningFurnacesothat
the chimney connector will be as short as pos-
sibleandavoidingunnecessarysharpturnsinthe
smoke pipe connector and the installation of
devices that would create excessive resistance
to the flow of flue gases.
b)LocatetheWoodorCoalBurningFurnaceas
close as practical to the existing central hot air
heatingsystem,maintainingclearancesasstated
on the label below the fuel door.
c)Clearancesfromcombustiblematerialsmust
becompliedwithasstatedonthelabelbelowthe
fueldoor:
Unit to Combustible:
Front: 48"
Back: 30"
Sides: 12"
Plenum to Ceiling: 6"
Pipe to Combustible:
Sides: 21"
Back: 18"
The installation must be made only on a
noncombustiblefloor.
d) Install the smoke pipe connector to the
chimney with 26-gauge pipe and elbows (to be
purchased separately), maintaining the proper
clearancesforthespecificmodel.Makesurethat
theproper clearancesasstated onthelabeland
earlier in this manual are maintained. Seal the
smokepipeinthechimneywithfurnacecement.
(The chimney connector shall be securely sup-
ported, and joints fastened with sheet metal
screws or rivets.)
e)Install8"diameterheatpipetoplenumofthe
central hot air furnace. Use 26-guage pipe and
connectors (to be purchased separately). (See
Fig.14)Ifcentralairconditioningisinstalledinthe
plenum,installheatpipeabovetheaircondition-
ing unit. Secure heat pipe connection with sup-
ports and sheet metal screws.
f) Connect electrical supply in the electrical
junction box that is mounted on the back of the
WoodBurningFurnace.SeeWiringDiagram(Fig.
12). Remove the cover from electrical junction
box connect power supply wires to wires desig-
nated,usingwirenuts.Thepower cord supplied
maybeusedfor installation, if permittedbylocal
codesandregulations.Ifthepowercordsupplied
cannotbeused,thepowersupplywiringmustbe
90 degrees Centigrade in a metal cable and
shouldbecompletedbyaqualifiedinstallercom-
plying with NFPA Standard No. 70 and local
codes.
g) Optional Plenum Fan Control Switch (Part
No. 11PCS) is available for installation on the
plenum of central hot air heating furnace. The
purposeofthisswitchistoactivatethecirculating
fanofthecentralhotairheatingfurnacewhenthe
temperatureintheplenumexceeds120degrees
Fahrenheit.The switch wouldactivate the fan at
120 degrees Fahrenheit, and would shut off the
circulating fan when the temperature in the ple-
numisreducedto100degreesFahrenheit.This
avoidsoverheatingtheplenum.
The electrical supply for operation of this fan
control switch is to be obtained from same elec-
tricalsupplyasthecentralhotairheatingsystem.
(SeeFig.14)Followtheinstructionsofthe wiring
diagram (Fig. 15). Do not make connections
across Limit Control in the furnace.
Make electrical connections in electrical junc-
tionboxpresentlymountedonthefurnace.Make
electricalconnections in accordance withNFPA
Standard No. 70 and local codes in the power
supply junction box (See Fig. 15). The wiring to
complete the connections should be 18 AWG
minimumcopperand90degreesCentigradeina
cable.

Power Failure Instructions:
Operation after loss of power
Remove filter if provided.
Do not expect to keep home at normal temperatures.
Do not load fuel above bottom of feed door.
Set ash pan spin draft maximum one turn open.
1
2
3
4
2" MIN. AIR SPACE
REQUIRED BY CODE
18" MIN.
CENTRAL
FURNACE
(U.S. ONLY)
FIG. 13
14

COLD AIR DUCT
6" PIPE
DAMPER
OPTIONAL
11 RPT
90 ELBOW
FURNACE
PIPE
CONNECTOR
Central Installation (U. S. & Canada)
FIG. 14
15

COLD AIR DUCT
6" PIPE
DAMPER
90 ELBOW
FURNACE
PIPE
CONNECTOR
EXISTING GAS/OIL/ELECTRIC FURNACE
8" PIPE
Add-On Installation (U. S. Only)
FIG. 14-1
16

Series Installation Wiring Diagram - FIG. 15
TO GAS/OIL/ELECTRIC
TRANSFORMER AND
COMBUSTION FAN OF
SOLID FUEL UNIT
H
N
POWER
SUPPLY
FURNACE
BLOWER
MOTOR
FAN
LIMIT
COMBINATION CONTROL
GAS/OIL/ELECTRIC
POWER SUPPLY
JUNCTION BOX
JUMPER IN
CAUTION!
DO NOT CONNECT
PLENUM FAN CONTROL
SWITCH ACROSS FURNACE
LIMIT CONTROL.
17

operating instructions
18
YourClaytonFurnaceiscapableofburningWoodorCoal.
WOODBURNING: (1)useHardwood,18"to26",splitandairdried(seasoned)forsixmonths. (2)setthermostat
to "HIGH" before opening feed door. (3) add wood to a convenient level.
BURNING COAL: Clayton Furnaces are capable of burning Bituminous coal and Anthracite coal. Anthracite is
perhapsthebestcoalfuelbecauseitslongevenburntime,highheatoutput,andcleanlinessmakeitagoodchoice
forthehome. However,keepinminditisamuchmoredifficultfueltouse,requiresmorecareandpatience,isnot
so widely available, and is usually much more expensive than Bituminous.
SIZE OF COAL: Mostsizes of Bituminous Coalwill work in theClayton Furnace; for bestresults we recommend
large"nut"coaltosmall"egg"coal(1-3/4"diameterto4"diameter). WhenburningAnthracite,use"egg"or"broken"
withsizesbetween 2-5/16" thru 4-3/8". Notethatit is important to thelonglife of your stove tobuycoal which has
beensizedandcleaned. Cleaninginsuresremovalofrocksandotherminerals. Neverusecoalsmallerthan1"or
larger than 5" in diameter. Small sized coal will smother the fire. Too large a size of coal will not burn well.
STOVEOPERATION: Allcoalfiresshouldbestartedwithwoodwhichwillallowthefiretogethotenoughtoignite
thecoal. Thebestignitionfiresutilizedrypineorotherresinoussoftwoodsaskindling,withhardwood(oak,hickory,
ash) added to increase the heat prior to addition of the coal.
BURNING BITUMINOUS: Once your kindling and wood fire has produced a bed of well established coals, start
addingcoalinlayersallowingeachto ignite before adding more. Bituminous has a high volatile contentand,asa
result,shouldbefiredwiththe"conicalmethod"-withthehighestportionofyourfirebedinthecenterofthefirebox.
The first flames will be long and generally orange or yellow and produce quite a bit of smoke. As the gases burn
off the flames become shorter, change color and produce less smoke.
OncethefireisWELLESTABLISHEDaddcoaltothecenterofthefireboxformingthecone. Burninginthisfashion
allowsheattodriveoffthevolatilegases,andturbulencecreatedincreasestheburnefficiency. Therewillhaveto
besomeexperimentingwiththeindividualsetupasnotwochimney'sorinstallationsaregoingtobethesame. Just
remembertoallowenoughsecondaryairtoenterthefireboxandkeepthestovepipedamperopensothatvolatiles
areproperlyburned. Beforerefueling,takethetimetobreakuptheconealittlewithapoker,especiallyifithascaked
overorformedacrust. But,becarefulnottomixthecoalasthisincreasesthechancesofformingclinkers. When
shakingthe grate(s) be gentle. Justa few short movements-a couple of "cranks" isbetter than a lotof agitation.
The objective is to remove a small amount of the ashes without disturbing the fire. Stop when you see a glow in
the ashes or the first red coals fall into the ash pan. Excessive shaking wastes fuel and can expose the grate(s)
toveryhightemperatureswhich can cause warpage or burnout.
Forovernight operation(longdurationburntime)shakethefireandadd coal,retainingthecentercone. Oncethe
volatiles are burned off, close the feed door and adjust the stove pipe damper. Then adjust the thermostat to the
desiredheatlevel.
More MAINTENANCE will be need with bituminous than with anthracite coal as more soot will collect on heating
surfacesand inpipes,requiringmore frequentcleaning.
ANTHRACITE: Beforestarting thefireopen- thestovepipedamper, turntheautomaticthermostattohigh,open
theashpitdoorandfeeddoor,placenewspaperandfinelysplitkindlingonthegrate,lightthepaper,addlargerhard
woodafterthekindlingisburningbrightly. Caution: Neverusegasoline,lanternfuel,kerosene,charcoallighter
fluid,orotherflammableliquidstostart orfreshenupafireinany heater. Placethelargerpiecesofwoodon
thefiresothattheyareslightlyseparatedandformalevelfortheadditionofcoal. Itwilltake10to20minutesbefore
this wood is thoroughly ignited. Adding coal too soon will cut the air supply and smother the fire.

Add a thin layer of coal (preferably smaller chunks) to the wood fire, being careful not to disturb it too much or cut
off the draft. Then, add a second heavier layer after the coal is ignited and burning well. If necessary, add a third
layer to bring the coal up to the top of the front liner (not above!). Be sure to close the ash door.
Beforeaddingfurtherfuel,besuretoleavearedspotofglowingcoalsinthecenterof thefireboxtoinsurethatthe
firehasnotbeensmotheredandtohelpignitethegasesgivenoffbythenewcharge. Adeepchargewillgiveamore
even heat and a longer fire, but it may take one to two hours before the whole bed is fully ignited.
Whenthefireiswellestablishedandtheroomisbecomingwarm,partiallyclosethedampers. Someexperimenting
will have to take place with each particular setting of all dampers and controls as the chimney provides the draft
necessarytonotonlyexhaust the smoke, but topullcombustionairintotheheateraswell - and no twochimney's
performthesame. Underidealdraftconditionsoneshouldbeabletoturnthesecondaryairsupplyonthefeeddoor
(somemodels)toanearclosedposition-butleavetheashpitdamperatleastpartiallyopentopreventthefirefrom
goingout. Adjustthestovepipedampertoreducethedraftonthefire. Withanthracitetherewillbeshortblueflames
above the coal, except when the fire is started or a new charge is added. If, however, there is no flame then the
fire needs more air from the bottom (unless it is near the end of its burn cycle and needs to be recharged).
Only when the coal is burned down to half its original depth it is time to add fresh coal. When doing so, open the
stovepipedamperandturnthethermostatdampertohigh,whichwillallowthefiretoburnoffanyaccumulatedgases.
Open the feed door, and with a small rake, hoe, or hooked poker pull the glowing coals to the front of the firebox.
Trynottodisturbthefiretoomuch. Next,addafreshchargetothebackbeingcarefulnottosealoffthetop. Close
thefeeddoor,butleavethespindamper(orthermostat)openforafewminutesuntilthevolatilegaseshaveburned
off. It is not necessary to shake down the ashes each time you refuel the furnace. Experience will be your best
teacher.
BANKING THE FIRE: Forextendedoperation,such as overnight, the fire will need to bebanked. Todosoheap
coal up along the sides and back of the firebox so that the fire gradually burns it over a longer period of time. The
intensity of the fire will also be reduced without letting it go out. Follow the same procedure as for refueling. If
possible,avoidshaking,asaheavierlayerofashwillhelpreducetheintensityofthefireduringthistime. Afterloading
letthefire establish itself forabout30 minutes. Then close your damperandautomatic control to the pointwhere
thehousedoesnotbecometoocold. Itisimportantthatyoubeginbankingearlyenoughbeforeretiringorleaving
that you can make necessary adjustments after the fire is well established.
Toreviveacoalfirethatisalmostout, (1)opentheashdoorandstovepipedamperandclosethespindamperon
the door to get a good draft through the grate. (2) place a thin layer of dry coal over the entire top of the fire. DO
NOTPOKEORSHAKETHEFIREATTHISTIME! (3)afterthefreshcoalhasbecomewellignitedshakethegrate
(just a little), refuel.
DONOTburncoke,charcoal,highvolatilebituminouscoal,subbituminous,ligniteorcannelcoal(sometimescalled
channelcoalorcandlecoal). NEVERburnwaxorchemicallyimpregnatedsawdustlogs-theirintendeduseisfor
fireplaces only. NEVER fill the stove or furnace above the firebrick or cast iron liner.
19
CAUTION
GASESTHAT ARE DRIVENFROM FRESH COALMUST
BE BURNED OR THEY WILL ACCUMULATE AND EX-
PLODE. NEVER SMOTHER A FIRE WHEN ADDING
FRESH COAL.
CAUTION
DO NOT OPERATE WITH THE FEED AND/OR ASH
DOOROPEN.THISFURNACEISDESIGNEDFORTHER-
MOSTATIC OPERATION. OPERATION WITH ANY OF
THESEDOORSOPENWILLOVERHEATANDDAMAGE
THE FURNACE.
CAUTION
NEVER USE GASOLINE, GASOLINE-TYPE LANTERN
FUEL, KEROSENE, CHARCOAL LIGHTER FLUID, OR
FLAMMABLELIQUIDSTOSTARTOR"FRESHENUP"A
FIRE IN THE FURNACE.
CAUTION
NEVER STORE FLAMMABLE LIQUIDS, ESPECIALLY
GASOLINE, IN THE VICINITY OF THE FURNACE.

20
service hints
Do not expect a furnace to draw. It is the chimney that
creates the draft. Smoke spillage into the house or exces-
sive build-up of water or creosote in the chimney is not
functioning properly. Correct the problem before using
furnace. Possible causes are:
The connector pipe may be pushed into the chimney
too far, stopping the draft (Fig. 6).
Do not connect two furnaces or a stove and a furnace
into the same chimney flue.
The chimney used for a furnace must not be used to
ventilate the cellar or basement. If there is a cleanout
opening at the base of the chimney, it must be closed
tightly.
1.
2.
3.
If the chimney is operating too cool, water will condense in
thechimneyandrunbackintothefurnace.Creosoteforma-
tion will be rapid and may block the chimney. Operate the
furnace at a high enough fire to keep the chimney warm
preventing this condensation.
Ifthefireburnswellbutsometimessmokesorburnsslowly,
it may be caused by the chimney top being lower than
anotherpartofthehouseoranearbytree.Thewindblowing
overa houseor atree, fallson topof thechimney likewater
over a dam, beating down the smoke. The top of the
chimney should be at least 3 feet above the roof and be at
least 2 feet higher than any point of the roof within 10 feet
(Fig. 5).
See page 28 for list of trouble shooting tips.
4.
5.
6.
A DRAFT READING OF .05 TO .06 W.C. IS SUGGESTED FOR PROPER BURNING
OF THIS UNIT WHEN USING WOOD OR BITUMINOUS COAL AS FUEL. WHEN
USING ANTHRACITE COAL, THIS DRAFT READING IS A MINIMUM READING.
chimney maintenance
Creosote and Soot - Formation and Need for Removal
When wood is burned slowly, it produces tar and other
organic vapors, which combine with expelled moisture to
form creosote. The creosote vapors condense in the rela-
tively cool chimney flue of a slow-burning fire. As a result,
creosote residue accumulates on the flue lining. When
ignited, this creosote makes an extremely hot fire.
When coal is burned, the products of combustion combine
with moisture to form a soot residue which accumulates on
the flue lining. When ignited, this soot makes an extremely
hot fire.
The chimney should be inspected at least twice monthly
duringtheheatingseasontodetermineifacreosoteorsoot
build-up has occurred.
If soot or creosote has accumulated, it should be removed to
reduce the risk of a chimney fire.
Chimney fires burn very hot. If the chimney catches fire, imme-
diatelycallthefiredepartment,thenreducethefirebyclosingthe
inletaircontrol.Poura large quantityofcoarsesalt,bakingsoda
or cool ashes on top of the fire in the firebox.
CAUTION
A Chimney fire may cause ignition of wall studs or rafters
which you thought were a safe distance from the chimney.
If you have a chimney fire, have your chimney inspected by
a qualified person before using again.
ADJUSTING BLOWER LIMIT
CONTROL SETTINGS
The temperature in the plenum of the warm air furnace at
which the blower turns on or turns off, is controlled by the
setting of the pointers in the blower limit control (See Fig.
12). These pointers may be adjusted through their entire
range of settings to achieve the desired warm air output
from the furnace. (See Fig. 16 Below)
1.
2.
3.
Move both pointers towards the right (counter clock-
wise)-thisincreasesthetemperaturesettingatwhich
the blower will turn on and off.
Move both pointers towards the left (clockwise) - this
decreasesthetemperaturesettingatwhichtheblower
will turn on and off.
Move pointers away or apart from each other- this
increases the time that the blower will run on each
warm cycle.
BLOWER FAN
"OFF" POINTER
BLOWER FAN
"ON" POINTER
BLOWER LIMIT
POINTER & STOP
FIG. 16
