UTC Fire and Security UltraView UVD-IP-EVRDNR(-P) User manual

Security Products by GE are now part of the UTC Fire & Security family
UVD-IP-EVRDNR(-P)
Camera User Manual
EN User Manual
DE Benutzer Handbuch
ES Manual de usuario
FR Manuel d’utilisation
IT Manuale utente
NL Gebruikershandleiding
PL Instrukcja obsługi
PT Manual do Utilizador
RU Руководство пользователя
TR Kullanım Kılavuzu
P/N 1069889 • REV 4.0 • ISS 02AUG10

Copyright © 2010 UTC Fire & Security. All rights reserved.
Trademarks and
patents
The UltraView name and logo are trademarks of
UTC Fire & Security.
GE and the GE monogram are trademarks of the
General Electric Company and are under license
to UTC Fire & Security, 9 Farm Springs Road,
Farmington, CT 06034-4065, USA
Other trade names used in this document may
be trademarks or registered trademarks of the
manufacturers or vendors of the respective
products.
Manufacturer Authorized EU manufacturing representative:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, The Netherlands
Certification
FCC compliance Class A: This equipment has been tested and
found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference when the equipment is operated in
a commercial environment. This equipment
generates, uses, and can radiate radio
frequency energy and, if not installed and used
in accordance with the instruction manual, may
cause harmful interference to radio
communications. Operation of this equipment in
a residential area is likely to cause harmful
interference in which case the user will be
required to correct the interference at his own
expense.
European Union
directives
1999/5/EC (R&TTE directive): Hereby, UTC Fire
& Security declares that this device is in
compliance with the essential requirements and
other relevant provisions of Directive 1999/5/EC.

2002/96/EC (WEEE directive): Products marked
with this symbol cannot be disposed of as
unsorted municipal waste in the European
Union. For proper recycling, return this product
to your local supplier upon the purchase of
equivalent new equipment, or dispose of it at
designated collection points. For more
information see: www.recyclethis.info.
Contact
information
For contact information see our Web site:
www.utcfireandsecurity.com.

UVD-IP-EVRDNR(-P) Camera User Manual 5 - EN
UVD-IP-EVRDNR(-P) Camera
User Manual
Content
Introduction 6
Product description 6
Features 6
User guidelines 7
Package contents 7
Installation 8
Viewing the camera via a digital (IP) connection 8
Software requirements 8
Connecting analog cables 10
Installing the camera 10
Angle adjustment 10
Zoom and focus adjustment 11
Connecting an analog monitor to set camera functions 12
Setting camera functions 12
White balance (WB) 12
Backlight compensation (BLC) 13
AI/AE exposure 13
Day/Night 13
Mirror 13
Flickerless control 13
Contacting Technical Support 14

EN - 6 UVD-IP-EVRDNR(-P) Camera User Manual
Introduction
This user manual provides basic information on setting up and using
the UVD-IP-EVRDNR(-P) camera.
Product description
The UVD-IP-EVRDNR(-P) color video camera uses a digital signal
processor (DSP) to process video signals. The video camera includes
a microcontroller to provide high-quality images with high-color
reproduction and sharp pictures
Features
Camera features include:
• H.264-SVC video compression with multistream capability.
• Super HAD (hole accumulated diode) technology with 470,000
PAL (410,000 pixels NTSC).
• Use of LSI (large scale integration) digital processors to produce
540 lines of horizontal resolution.
• High-resolution picture production using digital signal processors
for horizontal and vertical aperture enhancement.
• Smart digital automatic BLC (back light control).
• Advanced autoexposure system to optimize the amount of light to
the imager.
• Internal or line lock external synchronization.
• Long life and high reliability.
• DIP switch control of camera settings.
• Signal-to-noise ratio better than 48 dB.
• Power over Ethernet (PoE) or Isolated switching power 12 VDC or
24 VAC.

UVD-IP-EVRDNR(-P) Camera User Manual 7 - EN
User guidelines
Use the following guidelines:
• Take appropriate safety precautions while completing
programming after installation.
• Always use a proper PoE switch or a 12 VDC or 24 VAC UL listed
Class 2 power supply to power the camera.
• Do not use the camera outside the temperature range
specifications: -30 to +50°C (-22 to +122°F)
• If the light source where the camera is installed experiences rapid,
wide-variations in lighting, the camera may not operate as
intended.
WARNING: To reduce the risk of fire or electronic shock, do not
expose the camera to rain or moisture and do not remove the cover or
back.
Package contents
The UVD-IP-EVRDNR camera is shipped with the following items:
• The camera assembly
• 1 channel passive video transceiver
• AC power wiring harness
• Mounting screws, wall anchors, and hex key
• 150 mm DC jack to terminal adapter
Use the video output BNC and power jack for normal system
operation.

EN - 8 UVD-IP-EVRDNR(-P) Camera User Manual
Figure 1: Camera assembly
Camera body
RJ45 Ethernet/PoE input
24 VAC / 12 VDC input
Video output (BNC)
Installation
To install the camera you will need to prepare the mounting surface,
make cable connections, and mount the camera.
Viewing the camera via a digital (IP) connection
You can connect the IP camera to a network and view the images
through a browser. To view via a Network Video Recorder or similar
digital video system, please refer to the documentation associated with
that system.
Software requirements
The UVD-IP camera requires:
 Microsoft Internet Explorer

UVD-IP-EVRDNR(-P) Camera User Manual 9 - EN
 A VLC player ActiveX plug-in is required to play video when
Internet Explorer is used to monitor the camera.
Figure 2: ActiveX plug-in option
To configure the camera:
1. Configure the UVD-IP camera with a default IP address: 10.1.2.11
2. Configure your host PC/laptop within the same subnet, ex:
10.1.2.10
3. Connect the URL http://10.1.2.11 with Internet Explorer.
4. Select the “Live” menu to view live video.
5. Enter the following username and password to access the
Maintenance menu.
Login:
admin
Password:
admin
The IP address of the camera can be changed from the
Maintenance menu. Reboot the camera for the changes to take
effect.

EN - 10 UVD-IP-EVRDNR(-P) Camera User Manual
Connecting analog cables
To connect the cables:
1. Connect a coaxial cable from the camera’s BNC connector to a
CCTV monitor or video recording device.
2. Connect a PoE switch, a 12 VDC or 24 VAC power supply to the
power input. Do not connect both the PoE connection and DC or
AC connection at the same time. The label on the camera gives
the following information:
Red cable. Power in.
Black cable. Power in.
White cable. Video out.
Black cable. Video ground.
Note: For 24 VAC or 12 VDC, Black or Red may be used for ground.
Installing the camera
To mount the camera, attach the camera to the mounting surface using
the appropriate fasteners.
Angle adjustment
To adjust the horizontal angle of the platform up to 180 degrees, turn
the platform (Figure 3 on page 11).
To adjust the horizontal angle of the rotor up to 350 degrees, turn the
rotor on the platform (Figure 3 on page 11).
To adjust the vertical angle of the platform up to 90 degrees, turn the
platform (Figure 3 on page 11).

UVD-IP-EVRDNR(-P) Camera User Manual 11 - EN
Figure 3: Camera adjustment
Platform horizontal adjustment
Platform vertical
adjustment
Rotor horizontal
adjustment
Zoom and focus adjustment
See Figure 4 below for the location of the zoom and focus ring
thumbscrews.
Figure 4: Zoom and focus adjustment
Zoom ring thumbscrew for
VA2 and focus ring for
VA9 lens
Focus ring thumbscrew for
VA2 and zooming ring for
VA9 lens

EN - 12 UVD-IP-EVRDNR(-P) Camera User Manual
To adjust the camera zoom and focus:
1. Loosen the zoom ring thumbscrew.
2. Turn the zoom ring to set the desired zoom.
3. Tighten the zoom ring thumbscrew.
4. Loosen the focus ring thumbscrew.
5. Turn the focus ring to set the desired focus.
6. Tighten the focus ring thumbscrew.
Connecting an analog monitor to set camera functions
Connect a standard video monitor to the system to adjust the quality of
the video image using the DIP switches. The DIP switches can also be
adjusted when connected to the IP system.
To connect a video monitor:
1. Plug the monitor output cable to the video monitor output
connector (see Figure 1 on page 8).
2. Connect the BNC cable to the video monitor.
3. Adjust the DIP switches as desired.
Setting camera functions
You can set up six camera functions using the DIP switch bank on the
back of the camera. Figure 5 on page 14 shows the DIP switch layout.
White balance (WB)
White balance tells the camera what the color white looks like. Based
on this information, the camera will then display all colors correctly.
There are two methods to determine the WB:
• ATW (auto tracking white balance). The value used depends on
the lighting condition selected. It ensures reliable color
reproduction when lighting conditions change frequently.

UVD-IP-EVRDNR(-P) Camera User Manual 13 - EN
• PTL (push-to-lock) white balance. WB is fixed at the moment the
DIP switch it set to ON.
Backlight compensation (BLC)
The backlight compensation function improves image quality when the
background illumination is high. It prevents the object in the center
from appearing too dark.
AI/AE exposure
Use this setting to select the method the camera uses to adjust to
different light levels. Use the Automatic Iris (AI) setting to fix the iris
value at F1.6. Use Auto Exposure (AE) setting to automatically set the
proper exposure according to the existing light conditions.
Day/Night
This function controls whether the camera is in automatic day/night
mode or forced into night mode. When set to Auto Day/Night mode,
the camera produces high-quality color video during the day or when
light levels are high. It then switches to monochrome and removes the
infrared filter to improve IR sensitivity at night or when light levels are
low. Black and white mode forces the infrared filter to stay removed
therefore the camera stays in black and white mode.
Mirror
Use this function to change the original image into a mirror image
(horizontal).
Flickerless control
Flickerless control eliminates the flicker caused by the differences
between the frequencies (60 Hz) of the ionization of the gas in a
fluorescent light bulb with that of the vertical frequency (59.95 Hz) in
the camera. Although the difference is very small, it results in a slight
flicker at the top of the monitor scene or, in video over IP applications,
it would be interpreted as motion. Flickerless control helps reduce the
file size and transfer bit rates of compressed video images.

EN - 14 UVD-IP-EVRDNR(-P) Camera User Manual
Figure 5: DIP switch layout (back of camera)
Table 1: DIP switch functions (Default ON)
Switch Description
1. White Balance
ON: ATW mode; OFF: PTL mode
2. Backlight Compensation
ON: BLC off; OFF: BLC on
3. Exposure AI/AE
ON: Auto Iris (AI) mode; OFF: Auto Exposure (AE)
mode
4. Day/Night setting
ON: Auto Day/Night mode; OFF: Color mode only
5. Mirror
ON: Normal; OFF: Mirror Enable
6. Flickerless Control
ON: Normal; OFF: Flickerless enabled
Contacting Technical Support
For assistance installing, operating, maintaining, and troubleshooting
this product, refer to this document and any other documentation
provided. If you still have questions, you may contact technical support

UVD-IP-EVRDNR(-P) Camera User Manual 15 - EN
during normal business hours (Monday through Friday, excluding
holidays, between 5 a.m. and 5 p.m. Pacific Time).
Note: Be ready at the equipment before calling.
Table 2: Technical Support
North America Latin America
T: 888.437.3287 Toll-free in the
US, Puerto Rico, and
Canada.
+1.503.885.5700 outside the
toll-free area.
F: 888.329.0332 (Tualatin tech
support)
561.998.6232 (Boca Raton
tech support)
E:
[email protected]
gesecurity.customerservice
@ge.com
T: +1.305.593.4301
F: +1.305.593.4300
E:
InfraSec.TechnicalServicesLa
[email protected]
InfraSecCustomerService.Lat
i
[email protected]
Australia, New Zealand Europe, Middle East, and Africa
E:
[email protected]
T: + 48 (58) 326 2240
F: + 48 (58) 326 2241
E:
[email protected]
W: At www.gesecurity.eu , select
Customer Support .
China, India, Singapore, Taiwan, Southeast Asia
E: [email protected]

EN - 16 UVD-IP-EVRDNR(-P) Camera User Manual

UVD-IP-EVRDNR(-P) Kamera Benutzer Handbuch 17 - DE
UVD-IP-EVRDNR(-P) Camera
Benutzer Handbuch
Inhalt
Beschreibung 18
Produktbeschreibung 18
Funktionen 18
Nutzungsrichtlinien 19
Packungsinhalt 19
Installation 20
Anzeigen der Kamera per digitaler (IP) Verbindung 20
Softwareanforderungen 20
Anschließen analoger Kabel 22
Installieren der Kamera 22
Winkeleinstellung 22
Zoom- und Fokuseinstellung 23
Anschließen eines analogen Monitors zur Festlegung der
Kamerafunktionen 24
Einstellen der Kamerafunktionen 25
White Balance (Weißabgleich, WB) 25
Backlight compensation (Gegenlichtkompensation, BLC) 25
AI/AE Exposure (Automatische Blende/automatische
Bildverstärkung) 25
Day/Night (Tag/Nacht) 26
Mirror (Gespiegelt) 26
Flickerless Control (Flimmerfrei-Steuerung) 26
Kontaktaufnahme mit dem technischen Support 27

DE - 18 UVD-IP-EVRDNR(-P) Kamera Benutzer Handbuch
Beschreibung
Dieses Benutzerhandbuch enthält grundlegende Informationen zur
Einrichtung und Verwendung der UVD-IP-EVRDNR(-P) Kamera.
Produktbeschreibung
Die UVD-IP-EVRDNR(-P) Farbvideokamera ist mit einem digitalen
Signalprozessor für die Verarbeitung des Videosignals ausgestattet.
Darüber hinaus ist ein Mikrocontroller integriert, der gestochen scharfe
Bilder mit hoher Farbtreue gewährleistet.
Funktionen
Die Kamera zeichnet sich durch folgende Merkmale aus:
• H.264-SVC Videokomprimierung mit Multistream-Funktionalität.
• Super-HAD-Technologie (Hole Accumulated Diode) mit PAL, das
470.000 Pixel bietet (bei NTSC sind es 410.000).
• LSI-Digitalprozessoren (Large Scale Integration) ermöglichen eine
horizontale Auflösung von 540 Zeilen.
• Produktion hochauflösender Bilder mithilfe von digitalen
Signalprozessoren, die die horizontale und vertikale Blende
verbessern.
• Intelligente digitale automatische Gegenlichtkompensation (BLC).
• Ausgereifte Belichtungsautomatik zur Optimierung des
eintretenden Lichtpegels.
• Interne Synchronisierung oder externe Linelock-Synchronisierung.
• Das Gerät ist langlebig und äußerst zuverlässig.
• Steuerung der Kameraeinstellungen über DIP-Schalter.
• Rauschabstand besser als 48dB.
• Power over Ethernet (PoE) oder isolierte Schaltleistung 12V
(Gleichspannung) oder 24V (Wechselspannung).

UVD-IP-EVRDNR(-P) Kamera Benutzer Handbuch 19 - DE
Nutzungsrichtlinien
Halten Sie sich an folgende Richtlinien:
• Schließen Sie die Programmierung nach der Installation unter
Beachtung aller notwendigen Sicherheitsmaßnahmen ab.
• Schließen Sie diese Kamera ausschließlich an einen in der UL-
Liste eingetragenen PoE-Switch oder ein 12-V-Gleichstrom- bzw.
24-V-Wechselstrom-Netzteil der Klasse 2 an.
• Verwenden Sie die Kamera nicht außerhalb der angegebenen
Temperaturbereiche: -30 bis +50°C (-22 bis +122°F)
• Wenn die Lichtverhältnisse, unter denen die Kamera eingebaut
wird, schnellen, starken Schwankungen unterworfen sind,
funktioniert die Kamera möglicherweise nicht wie vorgesehen.
WARNUNG: Um das Risiko eines Brandes oder elektrischen Schlages
zu vermeiden, sollten Sie die Kamera vor Regen und Feuchtigkeit
schützen sowie die obere und hintere Abdeckung nicht entfernen.
Packungsinhalt
Die folgenden Teile sind im Lieferumfang der UVD-IP-EVRDNR
Kamera enthalten:
• Kamera
• Passiver 1-Kanal-Video-Transceiver
• Netzkabelsatz
• Montageschrauben, Dübel für Wandmontage und
Sechskantschlüssel
• 150mm DC-Buchse-auf-Terminal-Adapter
Verwenden Sie die Videoausgangsbuchse (BNC) und die
Stromversorgungsbuchse für den normalen Systembetrieb.

DE - 20 UVD-IP-EVRDNR(-P) Kamera Benutzer Handbuch
Abbildung 6: Kamera
Kameragehäuse
RJ45 Ethernet/PoE-Eingang
24V AC/12V DC Eingang
Videoausgang (BNC)
Installation
Vor der Installation der Kamera müssen Sie die Montagefläche
vorbereiten, die Kabel anschließen und die Kamera montieren.
Anzeigen der Kamera per digitaler (IP) Verbindung
Sie können die IP-Kamera an ein Netzwerk anschließen und die Bilder
über einen Browser anzeigen. Informationen zur Anzeige über einen
Netzwerk-Videorecorder oder ein ähnliches digitales Videosystem
finden Sie in der zu dem jeweiligen System gehörigen Dokumentation.
Softwareanforderungen
Für die UVD-IP Kamera ist erforderlich:
 Microsoft Internet Explorer
