Multi-Purpose Housing Installation Instructions
Product summary
The Multi-Purpose Housing (60-928) is designed to hold
several different circuit boards. It can be adapted for many
different installation situations. The Multi-Purpose Housing has
the following features:
• Space for an optional backup battery.
• Holes for an antenna
• Temporary supports for pre-wiring of boards.
• Wiring knockouts.
• Combined wall/cover tamper protection.
Figure 1: Multi-purpose housing features
Optional
Backup
Battery
Optional
Antenna
Holes
Wall/Cover
Tamper
Adjustable Board
Supports
Temporary
Supports (Pre-
Wiring)
Circuit Board
Supports
Wiring
Knockouts
Wiring
Knockouts
Accessory kit
The Multi-Purpose Housing comes with the following
accessories:
• Two screws for adjustable supports.
• One Tinnerman nut for the cover locking mechanism.
• Anchors and screws for mounting
• One screw for the cover locking mechanism.
• Two silicone caps for antenna holes and mounting of loop
antenna.
• Two rubber o-rings for plastic antenna housings.
• One normally closed tamper switch with spring.
Installing 6 in. (15.24 cm) circuit boards
1. Remove the adjustable board supports from the housing.
2. Remove the appropriate wiring knockout.
3. Attach housing to wall.
Note: Be sure adjustable board supports and knockouts are
removed before mounting the housing.
4. Place board in temporary support.
5. Wire the board as needed.
6. Place the board on appropriate supports.
7. Position adjustable board supports as needed for board
size (See the following figures).
8. Attach supports with screws.
Figure 2: Installation of 2.3 x 6 in. (5.83 x 15.24 cm) circuit board
2.30 in
(5.83 cm) 6.00 in
(15.24 cm)
Figure 3: Installation of 3.3 x 6 in. (8.56 x 15.24 cm) circuit board
6.00 in
(15.24 cm)
3.37 in
(8.56 cm)
P/N 466-1959 • REV D • January 2011 1
Figure 4: Installation of 2.87 x 6 in. (7.29 x 15.24 cm) circuit board
6.00 in
(15.24 cm)
2.87 in
(7.29 cm)
Installing smaller width boards
1. Remove the adjustable board supports from the housing.
2. Remove the appropriate wiring knockout.
3. Attach housing to wall.
Note: Be sure adjustable board supports and knockouts are
removed before mounting the housing.
4. Place the board on appropriate supports.
5. Wire the board as needed.
6. Position adjustable board supports as needed for board
size (See the following figures).
7. Attach supports with screws.
Figure 5: Installation of 3.2 x 4 in. (8.13 x 10.16 cm) circuit board
4.00 in
(10.16 cm)
3.20 in
(8.13 cm)
Figure 6: Installation of 4 x 3.77 in. (10.16 x 9.59 cm) circuit board
3.77 in
(9.59 cm)
4.00 in
(10.16 cm)
Figure 7: Installation of 3.83 x 4 in. (9.72 x 10.16 cm) circuit board
4.00 in
(10.16 cm)
3.83 in
(9.72 cm)
Figure 8: Installation of 4.47 x 4.38 in. (11.35 x 11.11 cm) board
4.38 in
(11.11 cm)
4.47 in
(11.35cm)
Installing the optional antenna
See the documentation for your board for complete antenna
installation instructions. The antenna can be attached through
the supplied silicone plugs as shown in the figure on the left.
Or in the case of a wire antenna, the plastic housings and o-
rings can be directly attached to the antenna holes in the top of
the housing.
2 Multi-Purpose Housing Installation Instructions
Figure 9: Optional antenna configurations Specifications
Insert Through Silicone
Plugs
Insert Antenna into
Antenna Holes in
Housing
Attach O-Rings to
Antenna Housings
Outside dimensions 6.82 x 6.50 x 2.00 in. (W x H x D)
(17.32 x 16.51 x 5.08 cm)
Inside dimensions 6.40 x 5.50 x 1.92 in (W x H x D)
(16.26 x 13.97 x 4.88 cm)
Cover dimensions 6.99 x 6.77 x 0.975 in (W x H x D)
(17.75 x 17.20 x 2.48 cm)
Weight 1.0 lb (.45kg) (empty housing and cover)
Installing the wall/cover tamper Regulatory information
Manufacturer UTC Fire & Security Americas Corporation, Inc.
1275 Red Fox Rd., Arden Hills, MN 55112-6943, USA
Certification
1. Push the wall/cover tamper switch into place as shown in
Figure 10 below.
2. Wire the tamper switch to the circuit board. (Refer to the
instructions for your board.)
3. Install the spring on the tamper switch. Contact information
4. Install the wall tamper screw.
www.utcfireandsecurity.com or www.interlogix.com
Figure 10: Installation of the wall/cover tamper switch and
tinnerman nut For customer support, see www.interlogix.com/customer-
support
Tamper Switch
Tinnerman Nut
Copyright © 2011 UTC Fire & Security Company. All rights
reserved.
Attaching the cover
1. Install the Tinnerman nut as shown in Figure 10 above.
2. Attach the cover over the housing with the screw hole
toward the bottom.
3. Install the cover screw through the Tinnerman nut (see
Figure 11 below).
4. If the housing is installed outside, use silicone caulk on the
edge of the cover to provide rain resistance
Figure 11: Bottom profile of housing
Cover Screw Hole
Multi-Purpose Housing Installation Instructions 3
