Vector SPORT LANTERN VEC1197 User manual

VEC1197
USER’S MANUAL
& WARRANTY INFORMATION
IMPORTANT SAFETY INFORMATION, SAVE THESE INSTRUCTIONS
TO REDUCE THE RISK OF INJURY, USER MUST READ AND UNDERSTAND
THIS INSTRUCTIONAL MANUAL. THIS MANUAL CONTAINS IMPORTANT
INFORMATION REGARDING THE OPERATION AND WARRANTY OF THIS
PRODUCT. PLEASE RETAIN FOR FUTURE REFERENCE.
www.vectormfg.com
4140 S.W. 30th Ave., Ft. Lauderdale, FL 33312
Toll Free: [phone]
SSppoorrttLLaanntteerrnn
VEC1197_Manual_042506.qxp 4/27/06 9:52 AM Page 4

IMPORTANT SAFETY INSTRUCTIONS
WARNINGS
• To reduce the risk of fire or electrical shock, do not expose this unit to rain or
moisture; and never submerge this unit in water or any other liquid.
• Other than the dry cell batteries and the 9 watt compact fluorescent (CFL) bulb, there
are no user-replaceable parts. Do not disassemble the main body of the unit.
• DO NOT operate any of the unit’s features unless the unit is fully assembled.
• NEVER attempt to operate the Lantern without both the bulb and housing in place;
and only replace the bulb with a new 9 watt CFL bulb.
• When replacing the “C” dry cell batteries:
DO NOT mix old and new batteries.
DO NOT mix alkaline, standard (carbon-zinc) and rechargeable (nickel cadmium)
batteries.
Manufacturer strongly recommends using alkaline dry cell batteries, not carbon-zinc
batteries, in this unit.
Always insert batteries correctly with regard to polarity (+ and –) marked on the
battery and the equipment.
Remove dead batteries immediately and dispose of per local codes.
• DO NOT dispose of batteries in fire, as this may result in an explosion.
• Keep batteries out of the reach of children.
• Never insert foreign objects in the unit’s ventilation holes as this can short circuit
parts, resulting in fire or electrical shock.
• Do not look directly at the lighted lamp.
CAUTIONS
• DO NOT expose this Lantern to extremely high temperatures.
• NEVER submerge this unit in water or any other liquids. Do not use when wet.
• Make sure all features are turned OFF before installing dry cell batteries.
• Remove batteries if the unit will not be used for several months.
• Do not use any accessory not recommended or provided by the manufacturer.
• Check unit periodically and discontinue use if parts are found to be damaged or defective. If defective
or worn parts are found, contact Vector’s Customer Service department toll-free [phone].
• Follow all warnings, cautions, and instructions marked on this unit.
• Keep unit out of reach of children (whether stored or in use).
PLEASE READ THIS USER’S MANUAL BEFORE USING THIS UNIT.
SAVE THESE INSTRUCTIONS
ONE YEAR LIMITED WARRANTY PROGRAM
This limited warranty program is the only one that applies to this product, and it sets forth all the
responsibilities of Vector Products, Inc., regarding this product. There is no other warranty, other than
those described herein. Any implied warranty of merchantability or fitness for a particular purpose on
this product is limited in duration to the duration of this warranty.
This Vector Products, Inc. product is warranted, to the original purchaser only, to be free of defects in
materials and workmanship for one year from the date of purchase without additional charge. The
warranty does not extend to subsequent purchasers or users. Manufacturer will not be responsible for
any amount of damage in excess of the retail purchase price of the product under any circumstances.
Incidental and consequential damages are specifically excluded from coverage under this warranty.
This product is not intended for commercial use. This warranty does not apply to damage to units from
misuse or incorrect installation/connection. Misuse includes wiring or connecting to improper polarity
power sources.
RETURN/REPAIR POLICY: Defective products may be returned to manufacturer. Any defective product
that is returned to manufacturer within 30 days of the date of purchase will be replaced free of charge.
If such a product is returned more than 30 days but less than one year from the purchase date,
manufacturer will repair the unit or, at its option, replace it, free of charge.
If the unit is repaired, new or reconditioned replacement parts may be used, at manufacturer’s option.
A unit may be replaced with a new or reconditioned unit of the same or comparable design. The
repaired or replaced unit will then be warranted under the terms of the remainder of the warranty
period. The customer is responsible for the shipping charges on all returned items. During the warranty
period, manufacturer will be responsible for the return shipping charges to the customer in the United
States.
LIMITATIONS: This warranty does not cover accessories, such as charging adapters, bulbs, fuses and
batteries, damage or defects resulting from normal wear and tear (including chips, scratches, abrasions,
discoloration or fading due to usage or exposure to sunlight), accidents, damage during shipping to our
service facility, alterations, unauthorized use or repair, neglect, misuse, abuse, failure to follow
instructions for care and maintenance, fire, flood and Acts of God.
If your problem is not covered by this warranty, call our Technical Support Department at (954) 584-
4446 or toll free at [phone] for general repair information and charges if applicable. You may
also contact us through our website at www.vectormfg.com.
STATE LAW RIGHTS: This warranty gives you specific legal rights. Some states do not allow limitations
on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential
damages, so the exclusions or limitations stated herein may not apply. This warranty gives the purchaser
specific legal rights; other rights, which vary from state to state, may apply.
TO REQUEST WARRANTY SERVICE FOR THIS PRODUCT: Contact Technical Support by telephone, fax
or mail (see below). We suggest that you keep the original packaging in case you need to ship the unit.
When returning a product, include your name, address, phone number, dated sales receipt (or copy)
and a description of the reason for return and product serial number. After repairing or replacing the
unit, we will make every effort to return it to you within four weeks.
WARRANTY ACTIVATION: Please complete Warranty Activation Card and mail to Vector Products, Inc..
Enter “VEC1197” as Model and “Sport Lantern” as Product Type. All Vector products must be registered
within 30 days of purchase to activate this warranty. Mail the completed registration form, along with
a copy of the original sales receipt, to:
ATTN.: CUSTOMER SERVICE
4140 SW 30th Ave., Ft. Lauderdale, FL 33312
• TOLL FREE: (866 ) 584-5504 • FAX: [phone] •
WARRANTY IS NON-TRANSFERABLE.
BD042506
© 2006 VECTOR PRODUCTS, INC.
MADE IN CHINA
VEC1197_Manual_042506.qxp 4/27/06 9:52 AM Page ii

1
INTRODUCTION
Thank you for purchasing the VEC1197 Sport Lantern. Please read this guide
carefully before use to ensure optimum performance and to avoid damage to the unit.
FEATURES
• Powerful fluorescent lantern
• Ultra bright 6 LED Auxiliary Light
• Powered by nine (9) “C” dry cell batteries (not included)
• Fold-away Handle/Hanging Hook
• Protective cage
Control and Function Guide
POWER SUPPLY
The unit is powered by 9 “C” dry cell batteries (not supplied).
Turn the knob (counterclockwise) on the front of the Removable Dry Cell Battery Pack
to open, then insert the batteries prior to use.
Note: Manufacturer strongly recommends using alkaline dry cell batteries in this unit.
CAUTIONS
• When replacing the “C” dry cell batteries: DO NOT mix old and new batteries.
DO NOT mix alkaline, standard (carbon-zinc) and rechargeable (nickel cadmium)
batteries. Always insert batteries correctly with regard to polarity (+ and –), marked
on the battery and the equipment. Remove dead batteries immediately and dispose
of per local codes
• DO NOT dispose of batteries in fire, as this may result in an explosion.
• Keep batteries out of the reach of children.
PROTECTIVE
CAGE
COMPACT
FLUORESCENT
BULB
FOLD-AWAY HANDLE/
HANGING HOOK
6 LED AUXILIARY
LIGHT
(BASE OF LANTERN)
LANTERN ON/OFF
SWITCH
AUXILIARY LIGHT
ON/OFF PUSHBUTTON
REMOVABLE
DRY CELL
BATTERY PACK
VEC1197_Manual_042506.qxp 4/27/06 9:52 AM Page iv

3
CAUTIONS
NEVER grasp the glass bulb directly. It can shatter.
DO NOT TWIST to remove the bulb; it pulls straight out of the socket.
Optional Removable Rechargeable Battery Pack
(Not Supplied)
A Removable, Rechargeable Battery Pack (VEC1198BAT) that installs
directly into the unit’s Battery Compartment (in place of the Dry Cell Battery Pack) is
available for purchase separately. Contact Vector Customer Service toll-free, at (866)
584-5504 to order this part.
2
OPERATING THE LANTERN
The Lantern is controlled by the Lantern ON/OFF Switch on the front of the unit (see
the “Control and Function Guide” on page 1).
OPERATING THE 6 LED AUXILIARY LIGHT
The 6 LED Auxiliary Light in the lantern base is controlled by the LED Light ON/OFF
Pushbutton on the front of the unit. (See the “Control and Function Guide” on page 1.)
CARE AND MAINTENANCE
Cleaning
Over time, dust or fingerprints may accummulate on the Lantern glass. Clean with a
soft, clean, oil-free cloth moistened with household window cleaner. Do not use
alcohol based cleaners on plastic surfaces. This will eventually cause surface clouding.
Note: Never submerge this unit in water or any other liquid.
Replacement Parts
Check unit periodically and discontinue use if parts or accessories are found to be
damaged or defective. To replace worn or defective parts, contact Vector Customer
Service toll-free at [phone].
Bulb Replacement
1. Unscrew the top of the Lantern (screws are on the underside of the top lip of the
Lantern). Refer to Figure 1 below.
2. Remove the bulb assembly. Refer to Figure 2 below.
3. Locate the metal spring in the top of the lamp. Refer to Figure 3 below.
4. Grasp the metal spring and the lamp base to remove the bulb. Refer to Figure 4
below.
5. Replace the bulb with a new 9 watt CFL bulb and re-assemble.
WARNINGS
DO NOT operate any of the unit’s features unless the unit is fully
assembled.
NEVER attempt to operate the Lantern without both the bulb and
housing in place; and only replace the bulb with a new 9 watt CFL
bulb.
FIGURE 1 FIGURE 2 FIGURE 3 FIGURE 4
