ASSEMBLY & OPERATING
INSTRUCTIONS
EMCP SERIES 78 - 86 - 94”
Embankment Flail Mower
with Crash Protection
VERSION 1.0 - EN 2023

EMCP Assembly & Operating Instructions - Page 2 of 36 - Version 1.0
COLOPHON
Visitor and Postal address:
65 Pine Ave #857, Long Beach, CA 90802, United States.
E-mail address:
[email protected]
Business hours:
Monday-Friday 9:00 am - 5:00 pm
Phone:
[phone]
Internet address:
https://etractorimplements.com
Manual info:
These are the original Safety Regulations and Instructions. The English language is binding. No part of this
documentation may be reproduced in any form without the written permission of Victory Tractor Implements.
History of changes:
Assembly & Operation Instructions:
Date:
Chapters:
Description:
V1.0
May 2023
-
First edition.
TABLE OF CONTENTS
1 VICTORY TRACTOR IMPLEMENTS WARRANTY ........................................................................................................... 4
1.1 Warranty Provisions ......................................................................................................................................... 4
1.2 Liability ............................................................................................................................................................. 4
2 SAFETY ....................................................................................................................................................................... 5
2.1 Warning Messages in this Manual ................................................................................................................... 5
2.2 GENERAL SAFETY INFORMATION ..................................................................................................................... 5
2.2.1 Introduction ................................................................................................................................................. 6
2.2.2 Personal Protective Equipment ................................................................................................................... 6
2.2.3 Generally Applicable Safety Rules ............................................................................................................... 6
2.2.4 General Safety Rules for Machines ............................................................................................................. 6
2.2.5 Safety and Health Measures when using Hydraulic Fluid ........................................................................... 7
2.3 ADDITIONAL SAFETY RULES FOR EMBANKMENT FLAIL MOWERS ................................................................... 8
2.4 Safety Precautions Continued for Tractor and/or Loader (If Equipped) .......................................................... 9
2.5 Not Allowed Use ............................................................................................................................................... 9
2.6 Safety decals that may be present on your tractor implement ..................................................................... 10
3 ASSEMBLING the EMCP ........................................................................................................................................... 11
3.1 Counterweight and ROPS ............................................................................................................................... 11
3.2 Three-Point hitch linkage ............................................................................................................................... 11
3.3 General Unpacking ......................................................................................................................................... 11

EMCP Assembly & Operating Instructions - Page 3 of 36 - Version 1.0
3.4 Preparing for Assembling ............................................................................................................................... 12
3.5 PTO Shaft Assembly ........................................................................................................................................ 15
3.5.1 Checking the PTO Shaft’s Safe Extended Length ....................................................................................... 16
3.5.2 Checking the PTO Shaft’s Interference ...................................................................................................... 17
3.6 Hinged rear gate ............................................................................................................................................. 17
4 HYDRAULIC SYSTEM ................................................................................................................................................. 18
4.1 Pre-Operation Checklist .................................................................................................................................. 18
5 OPERATION .............................................................................................................................................................. 19
5.1 OPERATING INSTRUCTIONS ............................................................................................................................ 19
6 MAINTENANCE ......................................................................................................................................................... 20
6.1 Preventive Maintenance ................................................................................................................................ 21
6.2 Fluids and Lubricants ...................................................................................................................................... 21
6.3 Service Period ................................................................................................................................................. 22
6.4 Annual Maintenance ...................................................................................................................................... 22
6.5 Lubrication Table: ........................................................................................................................................... 22
6.6 PTO Shaft Maintenance .................................................................................................................................. 22
6.7 Drive Belts and Gearbox ................................................................................................................................. 23
6.8 Cleaning .......................................................................................................................................................... 23
6.9 General Troubleshooting ................................................................................................................................ 24
6.10 List of Consumables ........................................................................................................................................ 24
6.11 WEARING PARTS ............................................................................................................................................. 24
7 TRANSPORT AND STORAGE ..................................................................................................................................... 25
7.1 Essential Rules for Transport: ......................................................................................................................... 25
7.2 Essential Rules for Safe Storage: .................................................................................................................... 25
8 EXPLODED VIEW DRAWINGS ................................................................................................................................... 26
8.1 Torque Specifications ..................................................................................................................................... 34
8.2 Specifications .................................................................................................................................................. 35

EMCP Assembly & Operating Instructions - Page 4 of 36 - Version 1.0
1 VICTORY TRACTOR IMPLEMENTS WARRANTY
Victory Tractor Implements warrants to the original purchaser that this Victory product will be free from defects
in material and workmanship beginning on the date of purchase by the end-user according to the following
schedule when used as intended and under regular service and conditions for personal use.
Overall Unit: Two years of Parts.
Flails: Considered wear items.
This Warranty is limited to the replacement of any defective part and the installation by VTI of any such
replacement part and does not cover common wear items. Victory reserves the right to inspect any equipment or
parts claimed to have been defective in material or workmanship.
This Warranty does not apply to any part or product that, in Victory’s judgment shall have been misused or
damaged by an accident or lack of regular maintenance or care or which has been repaired or altered in a way
that adversely affects its performance or reliability, or which has been used for a purpose for which the product
is not designed. Misuse also specifically includes failure to properly maintain oil levels, grease points, and
driveline shafts.
Claims under this Warranty should be made directly to Victory Tractor Implements, and all warranty adjustments
must be made through an authorized Victory dealer. Victory reserves the right to make changes in materials or
design of the product at any time without notice.
This Warranty shall not be interpreted to render Victory liable for damages of any kind, direct, consequential, or
contingent to property. Furthermore, Victory shall not be responsible for damages resulting from any cause
beyond its reasonable control. This Warranty does not extend to the loss of crops, any expense or loss for labor,
supplies, rental machinery, or for any other reason.
No other warranty of any kind whatsoever, expressed or implied, is made with respect to this sale, and all
implied warranties of merchantability and fitness for a particular purpose that exceed the obligations set forth
in this written warranty are hereby disclaimed and excluded from this sale.
This Warranty is not valid unless registered with Victory within 30 days from the date of purchase by the end-
user. Registration link: https://etractorimplements.com/register-product/
1.1 Warranty Provisions
Victory Tractor Implements guarantees the proper functioning of the provided equipment.
However, Victory is not responsible for unsafe situations, accidents, or damage, which are the result of:
n ignoring warnings and regulations as stated on the machine or in this Operator's manual;
n the use of the device for other applications or under other circumstances than stated in this documentation;
n mutations to the machine; this also includes the application of different replacement parts as specified;
n insufficient or careless maintenance.
1.2 Liability
Victory Tractor Implements can't be held liable for consequential damage (business interruption, product
damage, etc.).

EMCP Assembly & Operating Instructions - Page 5 of 36 - Version 1.0
2 SAFETY
2.1 Warning Messages in this Manual
Please read this manual carefully before using your Tractor Implement to understand how to use it safely.
n After reading, store the manual in a safe place, easily accessible for everyone working with the machine.
n Incorrect handling of the equipment could result in personal injury or physical damage.
n The manufacturer assumes no responsibility for any damage caused by mishandling beyond normal usage
defined in this Safety manual.
DANGER!
• This symbol indicates a potentially and imminently hazardous situation that, if not
avoided, will result in death or severe injury.
This RED symbol indicates All DANGER notifications.
WARNING!
• This symbol indicates a potentially hazardous situation that, if not avoided, could
result in death or severe injury, or machine damage.
This ORANGE symbol indicates All WARNING notifications.
CAUTION!
• This symbol indicates a potentially hazardous situation that, if not avoided, may result
in minor or moderate injury.
This YELLOW symbol indicates All CAUTION notifications.
n Always adhere to this manual's safety instructions, regulations, and warnings. They are the recommen-
dations of Victory Tractor Implements and several essential component manufacturers. If you ignore these
regulations, there will be no warranty.
n Any warranty claim will be rejected if you exceed the maintenance intervals for the essential machine
components claim.
n Tractor implements are not intended for use by persons with reduced physical, sensory, or mental
capabilities or who lack experience and knowledge.
2.2 GENERAL SAFETY INFORMATION
WARNING!
• Read and understand all Safety instructions, regulations, and Warnings before
carrying out any assembly, operation, or adjustments.
• Untrained persons who have not thoroughly read and understood this manual might
never approach the machine.
• Refer to all safety decals in this manual. Please read all instructions noted on them.

EMCP Assembly & Operating Instructions - Page 6 of 36 - Version 1.0
2.2.1 Introduction
The machine design is such that safe use and maintenance are possible. Anyone who works with it must know
the instructions and regulations stated in this manual.
The owner ensures users know the Safety instructions, regulations, and observations.
This distinction is because operators must meet other (safety) requirements than the technical service staff.
n The operator performs the daily cleaning and maintenance work described in the operating instructions.
2.2.2 Personal Protective Equipment
While handling, assembling and maintaining the implement adhering to all recommended safety instructions and
ensuring that the correct Personal Protective Equipment (PPE) is used.
Always wear:
n Safety helmet for head protection and prevention from falling objects.
n Safety gloves for hand protection and prevention of cuts from sharp edges.
n Steel-tipped safety boots for foot protection from falling objects.
n Wrap-around safety glasses for eye protection and to prevent damage caused by shooting particles.
n Safety vest for recognizable presence, visibility and safety.
n Any other Personal Protection Equipment that the working environment might require, specify, or dictate.
n Your Company can prescribe additional (safety) instructions. This Manual does not describe how to comply
with this.
2.2.3 Generally Applicable Safety Rules
This list contains general safety measures which must be complied with for personal safety reasons.
n Only persons who have read and understood the operating instructions might be in the machine's vicinity.
n Tractor implements are not intended for use by persons with reduced physical, sensory, or mental
capabilities or who lack experience and knowledge.
n Make sure children and animals cannot come into the machine's vicinity.
n Unauthorized persons may not perform acts if the machine is in use.
n Never work alone; always ensure that at least one person is nearby.
n Do not remove the brought warning stickers or markings.
n Always clean the machine properly and keep the workplace free of dirt and obstacles.
n Always use the equipment in daylight or ensure sufficient artificial lighting.
2.2.4 General Safety Rules for Machines
n Ensure the work area around the equipment is smooth, clean and free from any obstacles. Keep in mind that
a dangerous situation can always arise. Long loose hair is not allowed.
n Never wear loose or torn clothing. Permanently remove jewelry.
n Do not make any repairs if you are tired or consume alcohol or drugs, affecting your ability to work perfectly.
n When lifting more than 22 kg of heavy parts, use a hoist or ask for help to prevent personal injury.
n Incorrect practice or lack of care can cause burns, wounds, mutilation, suffocation, bodily injuries, or death.

EMCP Assembly & Operating Instructions - Page 7 of 36 - Version 1.0
n Ensure that all hoisting equipment, such as lifting straps, hooks, or ropes, is in a good state of repair and can
safely bear the equipment's weight.
n Never bypass door interlocks or safety sensors and switches.
n Leaking chemicals, oil, or water on electrical equipment can result in severe damage or fire.
n Watch for hot parts on switched-off components and hot liquids in lines, pipes, and compartments to
prevent burns.
n Never open any vent or drain valve or remove any plugs under pressure.
n Ensure that oil pumps are isolated from the system and relieve the pressure before disassembling a pump,
removing plugs, or disconnecting piping.
n Always use tools that are in a good state of repair. Ensure you know how to use tools before doing any work.
n ONLY use replacement parts from the same brand as the relevant part.
n Always use replacement fittings having the same part number. Do not use fitting of inferior quality.
n PROTECT THE ENVIRONMENT: The handling and cleaning of spent oil or chemicals may be subject to national
or local laws and regulations. Use authorized waste processing services, including Municipal facilities and
garages, which provide official facilities for collecting oil and chemicals.
n Parts that rotate can cause cuts, mutilations or strangulation.
n Always switch OFF the main power before performing service and maintenance.
n Switch the power ON only after closing all machine protection guards and covers.
n Never use a high-pressure water beam for cleaning electrical components and cabinets.
n Do not aim a high-pressure water beam directly at wiring, breathers, or hydraulic components' sealings of
drive components.
n Do not allow water or any other fluid to contact electrical components.
n Always protect venting spots from the inlet of large amounts of water.
n Contact the provincial or Municipal authorities or the Environmental Protection Service for guidelines about
handling correctly and cleaning up spent oil and chemicals if in doubt.
2.2.5 Safety and Health Measures when using Hydraulic Fluid
WARNINGS FOR HYDRAULIC-DRIVEN SYSTEMS
• Hydraulic fluid is hot when the machine has just come to a stop.
Allow the implement to cool down entirely before repairing the hydraulic system.
• Avoid contact with high-pressure fluid at all times. Liquid under high pressure quickly
penetrates clothing or skin, resulting in serious injuries.
• Prevent oil leakage or spillage to avoid the risk of slipping.
• Replace rubber and plastic hoses after six years with equivalent hoses.
• Changing the hydraulic system or using it for another purpose is forbidden.
Non-observance of the regulations, as mentioned above, is considered gross negligence. In this case, the supplier
is not liable for any damage.
Anyone working on installations where hydraulic fluid, lubricating oil, grease, or preservatives are used must
observe the following rules:
n Wear protective gloves and safety glasses or goggles when working with hydraulic systems.
n Do not remove the protection sleeves from the hydraulic hoses.

EMCP Assembly & Operating Instructions - Page 8 of 36 - Version 1.0
n Avoid prolonged contact with the liquid on the skin. In the event of contact, carefully cleanse the skin. Wear
clothing that is free of this liquid. Also, be careful when eating and drinking during the operation.
n Avoid skin contact with liquids over 60°C or hot machine parts.
n Avoid eye contact; if this happens, cleanse with plenty of water and contact a doctor.
n Liquid storage must follow official guidelines; pay attention to fire extinguishers and emergency exits.
n Permanently remove spilled liquids immediately to prevent them from slipping.
n Hydraulic liquids should not get into the ground or in surface water.
n Avoid high-pressure fluids hazards. Escaping fluid under pressure can penetrate the skin causing severe
injury.
n Avoid the hazard by relieving pressure before disconnecting hydraulic lines. The hydraulic systems operate
under extremely high pressure.
n Never try to stop leaks from the system by hand.
n Do not attempt makeshift repairs to the hydraulic lines, fittings, or hoses using tapes, clamps, or types of
cement. Such maintenance will fail suddenly and create a hazardous condition.
n Use paper or cardboard, not body parts, to check for suspected leaks.
n Have used liquids removed and recycled by specialized companies.
n If an accident occurs, see a doctor immediately. Always treat any fluid injected into the skin within a few
hours.
WARNING!
• Read and understand all Safety measures and Warnings before operating or
adjusting.
• Untrained persons who have not thoroughly read and understood this manual might
never approach the machine.
• Refer to all safety decals in this manual. Please read all instructions noted on them.
2.3 ADDITIONAL SAFETY RULES FOR EMBANKMENT FLAIL MOWERS
n The operator should be familiar with all functions of the implement.
n Operate the implement from the driver’s seat only.
n Persons under 18 should NEVER operate or be near the verge mower during operation.
n Do not operate the flail mower under the influence of drugs or alcohol, as severe injury or death could result.
n Bystanders must keep a safe distance from an operating flail mower (15’.)
n Ensure all guards and shields are secured before operating the equipment.
n Do not operate the device for any purpose other than what it is meant for. (See warranty for details.)
n Never open safety guards when the machine is working.
n Immediately push the emergency stop and cut off the power if system parts emit smoke, unusual odor, or
unusual sounds. Otherwise, fire may start.
n Never leave the flail mower unattended while it is running.
n Dismounting from a moving tractor could cause severe injury or death.
n Do not stand between the tractor and the implement during hitching.
n When raising and moving implements, watch for wires, trees, etc. Make sure all persons are clear of the
working area.

EMCP Assembly & Operating Instructions - Page 9 of 36 - Version 1.0
n Turning the tractor too tight may cause the implement to ride upon wheels. It can result in injury or
equipment damage.
n Regularly visually inspect the flail mower; check all fasteners and securing parts.
n Ensure the PTO shaft does not come apart or bottom out during the normal lifting range.
n It is NOT recommended to operate the flail mower in temperatures below freezing. Hardened steel (used on
flails) can become brittle in temperatures below freezing and may result in breakage.
n Always switch off the engine and put the keys in your pocket before attempting any alterations, repairs, or
(height) adjustments.
n Keep hands, feet, clothing, and other extremities away from power-driven parts. Wear snug-fitting clothing
to avoid entanglement with moving parts.
n Do not wear long hair and/or loose clothing when working around the flail mower. Personal injury can occur.
2.4 Safety Precautions Continued for Tractor and/or Loader (If
Equipped)
n Read the tractor and/or loader operator's manual to learn how to operate your tractor and/or loader safely.
Failure to do so could result in severe injury, death, and equipment damage.
n The tractor is recommended to be equipped with a Rollover Protective System (ROPS) and a seat belt and
that you use the belt for all loader operations.
n Add wheel ballast or front weight for stability.
n Move wheels to the tractor manufacturer's most comprehensive recommended settings to increase stability.
n Use a tractor with a wide front axle rather than tricycle front wheels for better stability.
n Always move and turn the tractor at low speeds.
n Stop the tractor’s engine, place the transmission in park mode (or neutral), engage the parking brake, lower
loader arms to the ground, cycle all hydraulic controls to relieve pressure, and allow machine moving parts to
stop.
n Remove the ignition key to prevent an unauthorized person from starting the engine before connecting or
disconnecting the tractor or when operating, repairing, or adjusting equipment.
n Wear personal protective equipment (PPE), including but not limited to protection for eyes, ears, lungs,
head, hands, and feet when operating, servicing, or repairing equipment.
n Avoid wearing loose clothing or jewelry that may catch and entangle equipment moving parts.
2.5 Not Allowed Use
It is not allowed to use Victory implements for other activities than described under ‘Intended use’ in the User
Manual.
2.6 Crash Protection System
Crash protection for mower implements refers to a safety construction that tries to prevent accidents or damage
to the mower in the event of a limited crash.
WARNING!
• The crash protection referred to here, only prevents damage during the onset of a
perceived crash. Always stop immediately if the spring elements are energized.
• Avoid a complete crash; otherwise, severe damage will still be caused.

EMCP Assembly & Operating Instructions - Page 10 of 36 - Version 1.0
2.7 Safety decals that may be present on your tractor implement
Your Victory tractor implement comes equipped with all necessary safety decals in place. The decals are designed
to help you safely operate your implement.
n Watch, read, and follow instructions on all safety decals. Try to understand them entirely.
n Keep all safety decals clean and legible.
n Replace all damaged or missing decals or labels. To order new ones, contact Victory Tractor Implements.
n New equipment installed during repair requires safety labels to be affixed to the replaced component as
specified.
n Ensure the correct safety labels are included in the request when ordering new components.
Safety Decals:
WARNING Decal
• Read the operator’s manual before
operating maintenance and repair.
DANGER Decal
• Do not stand behind the tractor or
implement.
DANGER Decal
• High-Pressure Fluid Hazard.
• Wear proper hand and eye
protection.
• Relieve pressure on the system
before repairing or adjusting.
WARNING Decal
• Max. Operating PTO shaft speed
540 rpm.
WARNING Decal
• Danger of being caught by rotating
parts.
WARNING Decal
• Swinging devices, keep a safe
distance.
WARNING Decal
• Do not stand on moving
implements.
WARNING Decal
• Danger of cutting off body parts.
WARNING Decal
• Hazard of rotating components.
WARNING Decal
• Do not come too close to the
machine.

EMCP Assembly & Operating Instructions - Page 11 of 36 - Version 1.0
WARNING Decal
• Finger Pinch Hazard; Driving belts
Danger.
WARNING Decal
• PTO Shaft Hazard.
WARNING Decal
• Remove the Ignition key before
adjustments, repair, or
maintenance, and read the
manual.
WARNING Decal
• Swinging devices, keep a safe
distance.
WARNING Decal
• Finger Pinch Hazard; turning
components.
ATTENTION POINT Decal
• Ad grease regularly to the
desired nipple.
3 ASSEMBLING the EMCP
3.1 Counterweight and ROPS
n Add recommended ballast in the tractor's front-end loader for increased stability; the weight of the EMCP is
very high. Refer to the tractor operator's manual for specific recommendations on the counterweighing
tractor.
n The tractor must have an approved ROPS system to ensure adequate operator protection.
3.2 Three-Point hitch linkage
WARNING!
• NEVER operate the mower unless the tractor’s Lower links are correctly installed and
adjusted.
• Never raise or lift the mower during installation until it is connected with three
connection points.
3.3 General Unpacking
n Before assembling, clear the area of bystanders, especially children, and animals. Ensure sufficient clearance
to access the machine from all sides during assembly.
n The mower is partially disassembled and strapped to a skid for shipping purposes. Initial installation on the
tractor will require a hoist or device capable of safely lifting heavy parts.

EMCP Assembly & Operating Instructions - Page 12 of 36 - Version 1.0
3.4 Preparing for Assembling
NOTICE:
• Before shipping the flail mower to you, we have inspected the implement's functions.
• ALWAYS BEFORE OPERATION, CHECK THE OIL LEVEL IN THE GEARBOX.
• Grease all bearings, check that all flail hammers are installed, and that bolts are torqued
according to specifications.
• Ensure that grease nipples are screwed in tightly.
Occasionally, dried paint may cover the end of the nipples on the PTO shaft. Remove this
by scraping the paint with a knife before injecting grease into these nipples.
• A PTO shaft is part of the delivery.
STEP 1: Unpacking
Unpack the crate and check that all parts are secure. Please contact us immediately if any part is missing or
damaged at Victory Tractor Implements.
Scope of delivery:
n Mower body with flail shaft and side gearbox.
n Rear swing arm & Front swing arm (linkages).
n Swing and Turn over cylinder.
n Connection arm for a 3-point hitch.
n Two Support legs.
n Four Hydraulic hoses with connectors.
n Protective cover for corner gearbox.
n PTO shaft with shear bolt.
n Link to the Instruction manual.
STEP 2:
Check the PTO shaft
n Ensure that the size of the PTO shaft is correct. After mounting, keep the flail mower as close to the tractor
as possible; the shaft must not get stuck.
n Always keep the PTO shaft as straight as possible. Your PTO shaft will be more efficient and have a longer life
if you use it straightforwardly. An angle smaller than 15 degrees is acceptable.
n Ad grease in the PTO shaft junction nipples.
STEP 2: Install Support Legs
n Install one support leg into the floating
bracket for the swing arms.
n Insert the second support leg into the 3-
point hitch.
n Secure both legs with L-pins and R-shaped
cotter pins.

EMCP Assembly & Operating Instructions - Page 13 of 36 - Version 1.0
STEP 3:
n Ensure the swing arms at the joint of the mower’s body and the floating bracket are mounted correctly.
STEP 4:
n Ensure the hydraulic swing cylinder is mounted as shown in the exploded view drawing in Chapter 8.
Mount the cylinder using the pins (7) for the swing cylinder, as shown in the parts drawing.
Secure these pins with mounting bolts M10x35. Ensure the joints can move freely.
STEP 5: Orden the Hydraulic Hoses. Note that the hoses are of different lengths!
n Check all hydraulic line/hose connections, including the quick connectors.
n Check the tightness of all joints.
Step 6: Gearbox Oil
Before first use, you must fill the gearbox with oil. See the specifications table for the oil type.
Gearbox oil check
n Remove the breather nipple and check
the oil level using a dipstick.
The gearbox must be filled 2/3.
n Fill with oil or top up if necessary.
Use Oil SAE-80/95; (Total 1½ Quarts).
n Fit and tighten the breather nipple.
Step 7: Adjust the Mowing height and Rear roller height
Always operate the mower at an acceptable height to conduct precise work. To save power and reduce the wear
of the machine, you must set the mowing height and the rear roller height properly.
Mowing Height:
n Raise and support the mower with suitable
wooden blocks beside the skids.
n Untighten nuts (1 & 2).
n Remove bolt (1) and move the skid to the
desired position for the mowing height (three
options).
n Fit and hand-tighten the nut.
n Remove bolt (2) and move the skid to the
desired position.
n Fit and hand-tighten the bolt and nut.
n Tighten both nuts.
n Repeat this action on the other side.

EMCP Assembly & Operating Instructions - Page 14 of 36 - Version 1.0
Rear Roller Height:
n Raise and support the mower with suitable
wooden blocks beside the skids.
n Untighten nuts (3 & 4) from the rear roller
bearing block.
n Remove bolt (4) and move the rear roller to
the desired height (two options).
n Fit and hand-tighten bolt and nut (4).
n Tighten both nuts (3 & 4).
n Repeat this action on the other side of the
mower.
STEP 8: Driving belts tension check
The belts must always be correctly tensioned for
optimal machine performance and long-lasting
belt lifetime.
n After the first 2 hours of work, check the belt's
tension.
n The belt tension is correct when a force of 22
lbs exerted on one belt at the mid-point
between the upper and lower pulleys deviates
the belts by 5/8”.
n Check the tightening of all Allen bolts in the
taper lock mounting hubs of the pulleys.
If the belts require tensioning, follow the
procedure stated below.
Driving belts adjustment
n Ensure the belts are cold.
n Remove the pulley covers.
n Untighten on both sides four bracket
mounting bolts (1).
n Use both nuts (2 & 3) to move the bracket
up or down until the correct drive belt
tension is reached.
n Do not touch the adjusting bolts (4).
n Tighten the mounting bolts (1).
n Secure both nuts (2 & 3) on both sides.
n Mount the pulley covers.

EMCP Assembly & Operating Instructions - Page 15 of 36 - Version 1.0
STEP 9: Grease the Rotor Shaft for the first time
n Add grease on both lubrication nipples for the rotor shaft bearing blocks.
Ensure that the rotor shaft bearings are well-lubricated.
STEP 10:
n Ensure the PTO protection cap is mounted to the gearbox of the mower.
STEP 11:
n Ensure the drive belt tension is correct.
STEP 12:
n Ensure the gearbox is filled with oil.
STEP 13:
n Attach the mower to the tractor’s 3-point hitch.
n Ensure that all connection points are secured with safety cotter pins.
STEP 14:
n Attach the PTO shaft, the shear bolt at the implement side.
STEP 15:
Systematically tighten all nuts and bolts which may have become loose during transportation.
STEP 16:
n Hooking up the hydraulic hoses to the tractor’s hydraulic system and check all operating functions.
Note that regular operation of the hydraulic cylinders is only achieved when all air in the system is gone.
It takes some time to vent the system.
STEP 17:
n Lower the machine horizontally, with the PTO shaft straight back in a place where no loose sand or other
material could harm yourself, others, or the device.
n Ensure that the machine blades do not get caught while rotating anywhere.
n When the tractor is idling, switch on the power take-off at 540 rpm. Slowly raise the tractor's revolutions
until the power take-off runs at 540 rpm.
n Check that everything works smoothly, correctly, and safely. Correct abnormalities if necessary.
3.5 PTO Shaft Assembly

EMCP Assembly & Operating Instructions - Page 16 of 36 - Version 1.0
1. Park the tractor on a level surface. Slowly adjust the tractor’s three-point hitch until the tractor’s output
shaft is level with the implement’s input shaft.
2. Place the gear selector in the park mode, set the parking brake, shut the tractor off, and remove the
switch key.
3. Block the implement to prevent it from going downward.
4. Slide the PTO shaft's inner yoke (implement end) onto the input shaft.
Secure the PTO shaft with the yoke locking device.
5. Slide the PTO shaft's outer yoke (tractor end) over the output shaft.
Secure the PTO shaft with the yoke locking device.
6. Move the PTO shaft back and forth to ensure both ends are secured (to the tractor and the implement).
7. Your PTO shaft comes with a chain on the shield. Secure the chain to the tractor and the implement. This
will prevent the protection from spinning during operation.
3.5.1 Checking the PTO Shaft’s Safe Extended Length
Make sure the PTO shaft’s collapsible length is acceptable. When fully extended, the PTO shaft's maximum
allowable length must have a minimum overlap of the two driveline sides by not less than 1/3 the free length,
with both inner and outer drivelines being of equal length.
1. Apply multi-purpose grease to the ‘outer shaft’ inside and reassemble the PTO shaft.
2. Assemble the two shaft parts with 1/3 overlapping inner and outer drivelines. Once assembled, measure
and record the maximum allowable length shown below for future reference.
3. Attach the inner driveshaft yoke to the implement’s input shaft. Attach the outer driveshaft yoke to the
tractor’s output shaft.
4. Move the yoke ends of the driveshaft back and forth to ensure they are secured to the tractor and
implement shafts. Re-attach any loose ends.
5. Raise and lower the implement to find the maximum extended PTO shaft length. Check to ensure that the
PTO shaft’s overall length does not exceed the full recorded size in step 2.
6. Set the tractor’s 3-Point lift height if needed to keep the PTO shaft from exceeding the maximum
allowable length.

EMCP Assembly & Operating Instructions - Page 17 of 36 - Version 1.0
3.5.2 Checking the PTO Shaft’s Interference
7. Slowly engage the tractor’s 3-Point hitch to lower the implement while checking for sufficient drawbar
clearance. Move the drawbar ahead, aside, or remove it if required.
8. Set the tractor’s 3-Point hitch lift height to keep the PTO shaft from exceeding the maximum allowable
length and 15° up or down.
3.6 Hinged rear gate
The hinged rear gate allows easier cleaning, flail replacement, and general maintenance.
The closed gate provides additional mulching, and the open gate allows for a more straightforward disposal of
the mowed material.
Open the Rear Gate
n At both sides, remove the locking bolts and
nuts (1).
n Manually open the rear gate.
n Fix the open condition using the removed
bolts and nuts in mounting holes (2).
The rear gate now remains open.
n Always maintain a full view of the working area during operation.
n Keep animals far away from the machine.

EMCP Assembly & Operating Instructions - Page 18 of 36 - Version 1.0
4 HYDRAULIC SYSTEM
n The tractor’s hydraulic system supplies the mower swing and overturning movement system.
Refer to your tractor manual for Hydraulic system instructions. You should know to quickly stop the tractor
and mower movements in an emergency.
Hydraulic Check Valve
With this check valve, you can control the oil flow pressure in one direction in a
hydraulic line.
It allows the operator to control the movement speed of the hydraulic cylinders.
n Turn the knob clockwise to decrease the oil flow/speed.
n Turn the knob anti-clockwise to increase the oil flow/speed.
After operating for 1 hour:
1. Torque all fasteners.
2. Check the condition of all hydraulic components.
3. Lubricate all grease nipples.
After operating for 10 hours:
Repeat steps 1 through 3 listed above. Go to the regular servicing and Maintenance schedule defined in the
Maintenance section.
4.1 Pre-Operation Checklist
n Inspect the whole EMCP mower visually and check all vital components like hoses and their connections;
Check hoses, lines, and wires for damage, kinking, wear or dirt.
n Visually inspect the condition of the hydraulic system. Refer to your tractor manual for Hydraulic system
instructions. You should know to quickly stop the tractor and mower movements in an emergency.
n Check that the working area is relatively smooth and free of obstacles.

EMCP Assembly & Operating Instructions - Page 19 of 36 - Version 1.0
5 OPERATION
WARNINGS!
• Assemble the PTO shaft at an angle of no more than 15 degrees up or down (or
sideways).
• Do not allow the tractor engine or Flail mower to bog down or stall. This causes undue
wear and tear on the mower and tractor. If this continues to happen, reduce ground
speed and raise the working depth of the flail mower.
• Always stop the tractor engine before removing objects from the rotor.
• Never travel at a fast ground speed while using the mower; this could damage the
mower.
• Never attempt to turn the tractor or travel in reverse with the PTO engaged and the
mower in the ground.
• Always raise the mower from the ground when backing up or attempting to turn.
Failure to do so may cause damage to the mower.
• This flail embankment mower is designed to run at 540 PTO rpm only.
5.1 OPERATING INSTRUCTIONS
STEP 1:
n Ensure you understand all the information described in Chapter Safety and Maintenance before assembling
and operating the EMCP Embankment flail mower.
STEP 2:
n With the EMCP Flail mower positioned on level ground, adjust the tractor lift arms so that the rotor bar
remains parallel when lifted.
STEP 3:
n With the Flail mower attached to the tractor, raise and support the mower with suitable blocks. Check or
adjust the mowing height as described in Paragraph 3.4.
STEP 4:
n Raise the mower and remove the wooden blocks. Place the mower on the ground.
STEP 5:
n With the tractor engine at idle speed and the mower lifted off the ground, engage the PTO and slowly
advance the throttle to 540 PTO rpm.
STEP 6:
n Select a low gear for the tractor and begin to move forward. The tractor's ground speed is controlled by gear
selection only and not by engine speed. As the tractor moves forward, slowly lower the mower down.
STEP 7:
n After each use, clean all debris from the mower and replace any missing or illegible safety decals. Inspect for
any damaged or worn parts and replace them before subsequent use. Store the mower in a dry environment.

EMCP Assembly & Operating Instructions - Page 20 of 36 - Version 1.0
6 MAINTENANCE
This manual describes periodic maintenance that the owner can do. However, any care that requires special tools
or technical experience should be left to Victory's authorized service technicians. Check the mower tines
frequently. They must be sharp, free of nicks and cracks, and securely fastened.
GENERAL WARNINGS FOR MAINTENANCE:
• Only qualified service personnel can carry out activities other than operating activities.
• Always perform maintenance on a level and solid surface in a well-lit, clean, and dry
area.
• Do not grease or oil the implement while it is in operation.
• Do not allow debris, grease, or oil to build up on any deck or surface.
• Make sure there is plenty of ventilation. Never operate the engine of the towing
vehicle in a closed building. The exhaust fumes may cause asphyxiation.
• Always prevent an accidental start; it can cause severe injury or death.
• Ensure that electrical outlets and tools are properly grounded.
• Only trained specialists with education and knowledge of the machine and PPE safety
procedures are entitled to maintenance or service work.
• Be sure all moving parts on attachments have come to a complete stop before
attempting maintenance.
• Periodically tighten all bolts, nuts, and screws and check that all cotter pins are
properly installed to ensure the unit is safe.
• Before working on this machine, disengage the PTO, shut off the engine, set the
brakes, and remove the ignition keys.
• Never work under equipment unless it is blocked securely.
• Always strictly adhered to service intervals prescribed by the manufacturer.
• Always follow the maintenance schedule given in the Operator's manual closely.
Failure to do so may result in machine failure and costly repairs or voided warranty.
Do not touch the fluid if you spot any leaking from hoses, pipes, or other parts; it is
dangerous and can lead to burns.
• Provide adequate protection around moving or rotating parts, paying attention to the
risk of pinching.
• When completing a maintenance or service function, ensure all safety covers, shields,
and devices are installed before placing the unit in service.
• After service, remove all tools, parts, and service equipment from the mower.
• A fire extinguisher and the first aid kit must be readily accessible while maintaining
this equipment.
• Only use genuine or equivalent parts and good-quality tools.
