video xtreme VX-22d Operation manual

OWNER’SOPERATING MANUAL
VX-22d
1080p, 3-chip Digital Light Processing
TM
Projector
and DHD Controller

Runco VX-22d Owner’s Operating Manual iii
PRELIMINARY
TWO YEAR LIMITED WARRANTY
For Projectors, Video Processors and Controllers
Congratulations on your purchase of a Runco video product and welcome to the Runco family! We believe Runco produces
“The World’s Finest Home Theater Products.” With proper installation, setup and care, you should enjoy many years of
unparalleled video performance.
This is a LIMITED WARRANTY as defined in the Magnuson-Moss Warranty Act. Please read it carefully and retain it with your
other important documents.
SERVICE LABOR: Runco will pay for service labor by a Runco Authorized Service Center when needed as a result of
manufacturing defect for a period of two (2) years from the effective date of delivery to the end user (excluding the lamp).
PARTS (not including the lamp): Runco will provide new or rebuilt replacement parts for the parts that fail due to defects in
materials or workmanship for a period of two (2) years from the effective date of delivery to the end user. Such replacement
parts are then subsequently warranted for the remaining portion (if any) of the original warranty period.
PROJECTOR LAMP: Runco will pay for service labor by a Runco Authorized Service Center when needed as a result of a
manufacturing defect for a period of six (6) months or 1000 hours, whichever comes first, from the effective date of delivery to
the end user. In addition, Runco will provide a new or rebuilt replacement lamp for the lamp that fails due to defects in materials
or workmanship for a period of six (6) months or 1000 hours, whichever comes first, from the effective date of delivery to the
end user. Such replacement lamps are then subsequently warranted for the remaining portion (if any) of the original warranty
period.
This Limited Warranty only covers failure due to defects in materials and workmanship that occur during normal use and does
not cover normal maintenance. This Limited Warranty does not cover cabinets or any appearance items; failure resulting from
accident, misuse, abuse, neglect, mishandling, misapplication, faulty or improper installation or setup adjustments; improper
maintenance, alteration, improper use of any input signal; damage due to lightning or power line surges, spikes and
brownouts; damage that occurs during shipping or transit; or damage that is attributed to acts of God. In the case of remote
control units, damage resulting from leaking, old, damaged or improper batteries is also excluded from coverage under this
Limited Warranty.
CAUTION: THIS LIMITED WARRANTY ONLY COVERS RUNCO PRODUCTS PURCHASED FROM RUNCO AUTHORIZED
DEALERS. ALL OTHER PRODUCTS ARE SPECIFICALLY EXCLUDED FROM COVERAGE UNDER THIS WARRANTY.
MOREOVER, DAMAGE RESULTING DIRECTLY OR INDIRECTLY FROM IMPROPER INSTALLATION OR SETUP IS
SPECIFICALLY EXCLUDED FROM COVERAGE UNDER THIS LIMITED WARRANTY. IT IS IMPERATIVE THAT INSTALLATION
AND SETUP WORK BE PERFORMED ONLY BY AN AUTHORIZED RUNCO DEALER TO PROTECT YOUR RIGHTS UNDER
THIS WARRANTY. THIS WILL ALSO ENSURE THAT YOU ENJOY THE FINE PERFORMANCE OF WHICH YOUR RUNCO
PRODUCT IS CAPABLE WHEN INSTALLED AND CALIBRATED BY RUNCO AUTHORIZED PERSONNEL.
Runco limits its obligations under any implied warranties under state laws to a period not to exceed the warranty period. There
are no express warranties. Runco also excludes any obligation on its part for incidental or consequential damages related to
the failure of this product to function properly. Some states do not allow limitations on how long an implied warranty lasts, and
some states do not allow the exclusion or limitation of incidental or consequential damages. So the above limitations or
exclusions may not apply to you. This warranty gives you specific legal rights, and you may also have other rights that vary from
state to state.
WHAT IS COVERED UNDER THE TERMS OF THIS LIMITED WARRANTY:
WHAT IS NOT COVERED UNDER THE TERMS OF THIS LIMITED WARRANTY:
RIGHTS, LIMITS AND EXCLUSIONS:

iv Runco VX-22d Owner’s Operating Manual
PRELIMINARY
This warranty begins on the effective date of delivery to the end user. For your convenience, keep the original bill of sale as
evidence of the purchase date.
Please fill out and mail your warranty registration card. It is imperative that Runco knows how to reach you promptly if we
should discover a safety problem or product update for which you must be notified.
Repairs made under the terms of this Limited Warranty covering your Runco video product will be performed at the location of
the product, during usual working hours, providing location of product is within normal operating distance from a Runco
Authorized Service Center. In some instances it may be necessary for the product to be returned to the Runco factory for
repairs. If, solely in Runco’s judgment, location of product to be repaired is beyond normal operating distance of the closest
Runco Authorized Service Center, or the repair requires the unit be returned to the Runco factory, it is the owner’s
responsibility to arrange for shipment of the product for repair. These arrangements must be made through the selling Runco
Dealer. If this is not possible, contact Runco directly for a Return Authorization number and shipping instructions. Runco will
return product transportation prepaid in the United States, unless no product defect is discovered. In that instance, shipping
costs will be the responsibility of the owner.
© Copyright 2007 Runco International. This document contains proprietary information protected by copyright, trademark and
other intellectual property laws. All rights are reserved. No part of this manual may be reproduced by any mechanical,
electronic or other means, in any form, without prior written permission of the manufacturer.
Reflection, Enhanced GEN3, DHD, Vivix, Virtual Cinema, CineWide, AutoScope, O-Path, CinOptx, LiveLink, CSMS, SuperOnyx
and VirtualWide are trademarks of Runco International. All other trademarks and registered trademarks used in this document
are the property of their respective owners.
Runco International products are manufactured under one or more of the following patents: US. Patent 6755540 and Other
Patents Pending.
EFFECTIVE WARRANTY DATE:
IMPORTANT – WARRANTY REGISTRATION:
CONTACT A RUNCO AUTHORIZED SERVICE CENTER TO OBTAIN SERVICE:
COPYRIGHT AND TRADEMARKS:

Runco VX-22d Owner’s Operating Manual v
PRELIMINARY
To locate the name and address of the nearest Runco Authorized Service Center, or for additional information about this
Limited Warranty, please call or write:
RUNCO INTERNATIONAL, INC.
Attn: Customer Service Department
2900 Faber Street
Union City, CA 94587
Ph: [phone]
Fax: [phone]
Toll Free: (800) 23-RUNCO
RUNCO VIDEO-PRODUCT INFORMATION
RETAIN THIS INFORMATION FOR YOUR RECORDS
_________________________________________________________ ________________________________________
Model Purchased Date
____________________________________________________________________________________________________________
Serial Number
____________________________________________________________________________________________________________
Runco Authorized Dealer Name
____________________________________________________________________________________________________________
Address
____________________________________________ __________________ ________________________
City State/Province Postal Code
____________________________________________ _______________________________________________________
Phone Fax
ADDITIONAL INFORMATION:

vi Runco VX-22d Owner’s Operating Manual
PRELIMINARY
Thank you for your purchase of this quality Runco video projector! It has been designed to provide you with the quality of video
that is expected in a home theater. For the best performance, please read this manual carefully as it is your guide through the
menus and operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Do not use this equipment near water, outdoors or otherwise exposed to the elements.
5. Clean only with a dry cloth.
6. Do not block any ventilation openings.
7. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that
produce heat.
8. Do not defeat the safety feature of the polarized or grounding type plug. A polarized type plug has two blades with one
wider than the other. A grounding type plug has two blades and a third grounding prong. The third prong is provided for
your safety. If the provided plug does not fit into your outlet, consult an electrician for the replacement of the obsolete
outlet.
9. The 12V trigger only outputs DC 12V signal for triggering. Do not connect to any other power input or output. This could
cause damage to this unit.
10. Only use accessories specified by Runco International.
11. Keep the packing material in case the equipment should ever need to be shipped.
12. Unplug this projector during lightning storms or when it will not be used for an extended period of time.
13. The lamp becomes extremely hot during operation. Allow the projector to cool down for approximately 45 minutes prior to
removing the lamp assembly for replacement. Do not operate lamps beyond the rated lamp life. Excessive operation of
lamps beyond rated life could cause them to explode in rare occasions.
14. Refer all servicing to qualified service personnel. Servicing is required when the projector has been damaged in any way,
objects have fallen or spilled into the projector, the projector has been exposed to rain or moisture, does not operate
normally, or has been dropped.
Safety Precautions
WARNING
This symbol is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electric
shock.
This symbol is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.

Runco VX-22d Owner’s Operating Manual vii
1Table of Contents
PRELIMINARY
TWO YEAR LIMITED WARRANTY ................................................................................. iii
Safety Precautions......................................................................................................... vi
1. Introduction ...............................................................................................................1
About This Manual .......................................................................................................1
Target Audience .....................................................................................................1
If You Have Comments About This Manual... ..........................................................1
Textual and Graphic Conventions ...........................................................................1
Using This Manual ........................................................................................................2
Description, Features and Benefits ...............................................................................3
Key Features and Benefits ......................................................................................3
Parts List ...............................................................................................................4
2. Controlsand Functions............................................................................................5
VX-22d at a Glance ......................................................................................................5
VX-22d Rear Panel .......................................................................................................6
DHD Controller Front Panel ..........................................................................................8
DHD Controller Rear Panel .........................................................................................10
VX-22d Remote Control .............................................................................................12
3. Installation ...............................................................................................................15
Remote Control ..........................................................................................................15
Notes on Batteries ................................................................................................15
Notes on Remote Control Operation.....................................................................15
Quick Setup ...............................................................................................................16
Installation Considerations ..........................................................................................17
Installation Type .................................................................................................... 17
Ambient Light .......................................................................................................17
Throw Distance.....................................................................................................18
Vertical and Horizontal Position.............................................................................19
Vertical and Horizontal Lens Shift..........................................................................19
Folded Optics .......................................................................................................21
Other Considerations ............................................................................................22
Installing the Primary Projection Lens .........................................................................22

Table of Contents
viii Runco VX-22d Owner’s Operating Manual
PRELIMINARY
Installing the Optional CineWide/AutoScope Lens Motor ............................................24
Remove Projector Front Feet ................................................................................24
Install AutoScope Lens Motor ...............................................................................25
Install Ceiling Mount Extension Brackets ...............................................................26
Mounting the VX-22d .................................................................................................27
Floor Mounting (Upright) .......................................................................................27
Ceiling Mounting (Inverted)....................................................................................27
Adjusting the Projection Angle ..............................................................................27
Connections to the VX-22d and DHD Controller .........................................................28
Connector Panel Access.......................................................................................28
Connecting the DHD Controller to the VX-22d ......................................................28
Connecting Source Components to the DHD Controller .......................................29
RS-232 Controller Connection ..............................................................................34
Connecting 12-Volt Trigger Outputs to External Theater Equipment......................35
Connecting an External IR Receiver to the DHD Controller....................................36
Connecting to AC Power ......................................................................................37
Turning on the Power .................................................................................................37
Adjusting the Picture Orientation ................................................................................37
Primary Lens Adjustments ..........................................................................................38
Focus ...................................................................................................................38
Zoom....................................................................................................................38
Vertical and Horizontal Lens Shift..........................................................................38
Installing and Adjusting the CineWide Anamorphic Lens .............................................39
Attach Lens Mounting Assembly to Lens Motor Carriage Plate .............................39
Configure Lens Motor Trigger ...............................................................................41
Adjust the Anamorphic Lens .................................................................................41
4. Operation .................................................................................................................45
Using the On-Screen Menus ......................................................................................45
Main Menu............................................................................................................47
Input Source .........................................................................................................47
Aspect Ratio ........................................................................................................47
Picture .................................................................................................................49
Input Position........................................................................................................53
ISF Presets ...........................................................................................................54
Information ...........................................................................................................54
Calibration ............................................................................................................55
Service .................................................................................................................57

Table of Contents
Runco VX-22d Owner’s Operating Manual ix
PRELIMINARY
5. Maintenance and Troubleshooting ........................................................................59
Lamp Replacement ....................................................................................................59
Filter Replacement .....................................................................................................60
Troubleshooting Tips ..................................................................................................61
6. Serial Communications..........................................................................................63
RS-232 Connection and Port Configuration ...............................................................63
Serial Command Syntax .............................................................................................63
7. Specifications..........................................................................................................67
VX-22d Specifications ................................................................................................67
DHD Controller Specifications ....................................................................................69
VX-22d Dimensions ....................................................................................................70

Table of Contents
x Runco VX-22d Owner’s Operating Manual
PRELIMINARY
Notes:

Runco VX-22d Owner’s Operating Manual xi
1List of Figures
PRELIMINARY
2-1. VX-22d Front/Bottom/Side View...................................................................................5
2-2. VX-22d Rear Panel ....................................................................................................... 6
2-3. DHD Controller Front Panel ..........................................................................................8
2-4. DHD Controller Rear Panel .........................................................................................10
2-5. VX-22d Remote Control .............................................................................................12
3-1. Estimating Throw Distance .........................................................................................18
3-2. Projector Placement ...................................................................................................19
3-3. Vertical Lens Shift (EXAMPLE ONLY) ..........................................................................19
3-4. Horizontal Lens Shift (EXAMPLE ONLY)......................................................................20
3-5. Folded Optics.............................................................................................................21
3-6. VX-22d With Ceiling Mount Extension Brackets..........................................................26
3-7. Connecting the VX-22d to the DHD Controller............................................................28
3-8. HDMI Source Connections .........................................................................................29
3-9. Digital (DTV) RGB or Component Video Connections (HD1, HD2)...............................30
3-10. Digital (DTV) RGB or Component Video Connections (HD3)......................................31
3-11. Analog RGB Connections.........................................................................................32
3-12. S-Video and Composite Video Connections .............................................................33
3-13. RS-232 Control System Connection.........................................................................34
3-14. 12-volt Trigger Output Connections..........................................................................35
3-15. External IR Receiver Connection...............................................................................36
3-16. VX-22d Anamorphic Lens Mounting Assembly - Exploded View...............................39
3-17. Attaching the Anamorphic Lens to the Lens Adapter Ring ........................................40
4-1. DHD Controller OSD Menu Structure for VX-22d ........................................................46
4-2. Typical PLUGE Pattern for Adjusting Brightness .........................................................50
4-3. Typical Gray Bar Pattern for Adjusting Contrast ..........................................................51
4-4. Typical Color Bar Pattern for Adjusting Color Saturation and Tint................................51
4-5. Typical Test Pattern for Adjusting Sharpness..............................................................53
7-1. VX-22d Dimensions (with Ceiling Mount and CineWide/AutoScope Options) ..............70

List of Figures
xii Runco VX-22d Owner’s Operating Manual
PRELIMINARY
Notes:

Runco VX-22d Owner’s Operating Manual 1
PRELIMINARY
1.1
About This Manual
This Owner’s Manual describes how to install, set up and operate the Runco VX-22d DLP
Projector and DHD Controller. Throughout this manual, the Runco VX-22d DLP Projector
and DHD Controller are referred to collectively as the “VX-22d.”
Target AudienceRunco has prepared this manual to help home theater installers and end users get the
most out of the VX-22d.
Runco has made every effort to ensure that this manual is accurate as of the date it was
printed. However, because of ongoing product improvements and customer feedback, it
may require updating from time to time. You can always find the latest version of this and
other Runco product manuals on-line, at www.runco.com.
If You Have Comments
About This Manual...
Runco welcomes your comments about this manual. Send them to [e-mail].
Textual and Graphic
Conventions
Text Conventions: The following conventions are used in this manual, in order to clarify
the information and instructions provided:
• Remote and built-in keypad button identifiers are set in upper-case bold type; for
example, “Press EXIT to return to the previous menu.”
• Computer input (commands you type) and output (responses that appear on-screen) is
shown in monospace (fixed-width) type; for example: “To change the aspect ratio to
Letterbox, type SAR 2<Enter>.”
• All keys with functional names are initial-capped, set in bold type and enclosed in angle
brackets. These keys are the following: <Enter>, <Spacebar>, <Control>,
<Esc> and <Tab>.
•<Enter> indicates that you may press either the RETURN or ENTER key on your
keyboard if it has both keys.
In addition to these conventions, underlining, boldface and/or italics are occasionally used
to highlight important information, as in this example:
1. Introduction
A carriage return must be used after each command or string.
Note

Introduction
2 Runco VX-22d Owner’s Operating Manual
PRELIMINARY
Graphic Conventions: These symbols appear in numerous places throughout the
manual, to emphasize points that you must keep in mind to avoid problems with your
equipment or injury:
1.2
Using This Manual
Use the following table to locate the specific information you need in this manual.
TIPS highlight time-saving short cuts and helpful guidelines for using
certain features.
NOTES emphasize text with unusual importance or special
significance. They also provide supplemental information.
CAUTIONS alert users that a given action or omitted action can
degrade performance or cause a malfunction.
WARNINGS appear when a given action or omitted action can result
in damage to the equipment, or possible non-fatal injury to the user.
DANGER appears when a given action can cause severe injury or
death.
Tip
Note
Caution
WARNING
DANGER!
If you need... ... Turn to page:
Information about obtaining service iv
General information about the VX-22d DLP Pro-
jector and DHD Controller
3
Installation instructions 15
First-time configuration instructions 45
Advanced configuration instructions 55
Troubleshooting tips 61
Product specifications 67

Introduction
Runco VX-22d Owner’s Operating Manual 3
PRELIMINARY
1.3
Description, Features
and Benefits
Runco further solidifies its leadership role with the introduction of the Video Xtreme™
VX-22d Digital Light Processing (DLP™) Projector. This overachiever combines
state-of-the-art, 1920x1080 SuperOnyx™ DLP™ resolution with advanced 3-chip
engineering. The results are simply stunning, with jaw-dropping images that must be seen
to be believed!
Runco has taken 1080p performance to a new level with this machine and harnessed the
brightness and contrast capabilities inherent in 3-chip light engine design for a powerful
presentation.
The VX-22d comes with an external, all-digital signal processor/controller featuring
advanced Vivix II™ video processing, superb scaling and aspect ratio control. The VX-22d
is enhanced further by significant horizontal and vertical lens shift capability for maximum
installation flexibility.
The VX-22d’s 16:9 native aspect ratio DMD array makes it ideal for widescreen viewing,
while its 3-chip, 1920 x 1080 native resolution produces crisp, crystal clear high-definition
images with richly saturated colors, deep black levels and natural, highly refined detail.
This advanced design provides pure digital connections from input to light engine for
absolutely stellar pictures. In addition, Runco’s multiple aspect ratio control includes its
unique VirtualWide™ mode for viewing standard video formats in widescreen without loss
of image quality.
For uncompromising widescreen reproduction of movies originally filmed in the “scope”
(2.35:1) format, the VX-22d can be equipped with Runco’s patent-pending CineWide™
with AutoScope™ technology, a combination of software, electronics and high-quality
anamorphic optics. CineWide maintains constant height on the screen just as in a movie
theater. When a viewer transitions from 1.78:1 (16:9) program material to 2.35:1 material,
the image simply gets wider while full height is maintained.
Discrete IR and RS-232 control make custom installation seamless, while discrete source
and aspect ratio selection accommodate any automation control system.
Key Features and BenefitsThe VX-22d offers these key features and benefits:
• Native Resolution: 1920 x 1080 (16:9 Native Aspect Ratio)
• Three-chip Digital Light Processing (DLP™) system
• Two HDMI Inputs (on DHD Controller) with High-bandwidth Digital Content Protection
(HDCP)
• HDTV Compatible
• CinOptx™ lens options for stunning sharpness and throw distance flexibility
CineWide requires the use of a 2.35:1 or similar aspect ratio superwide
format screen.
Note

Introduction
4 Runco VX-22d Owner’s Operating Manual
PRELIMINARY
Parts List Your VX-22d is shipped with the following items. If any items are missing or damaged,
please contact your Runco dealer or Runco Customer Service at (800) 23-RUNCO.
• VX-22d DLP Projector and DHD Controller
• Remote Control Unit and two (2), AAA-size batteries
• AC Power Cords for Projector and DHD Controller
• Dual-Link DVI Cable, length specified at time of order; available lengths range from
7.5 meters to 30 meters (24.6 feet to 98.4 feet)
• Rack-mount hardware for the DHD Controller
• Warranty information and registration card
• Runco VX-22d Owner’s Operating Manual (this document)
Optional Accessories:
• CineWide™ with AutoScope™ system (secondary anamorphic lens and motorized
mount)
• Ceiling mount kit (part number RUHK-004105)
• Cool-cube™ Exhaust Kit
➤

Runco VX-22d Owner’s Operating Manual 5
PRELIMINARY
2.1
VX-22d at a Glance
Figure 2-1 shows the key VX-22d components.
Figure 2-1. VX-22d Front/Bottom/Side View
1. INTAKE VENT
2. LENSOPENING
3. RUNCO LOGO
The logo can be rotated to match the projector orientation: inverted (ceiling-mounted)
or upright. To rotate the logo, grip it at the sides, pull it away from the projector and
rotate it 180 degrees.
4. CABLE OPENING
Pass cables through this opening.
5. EXHAUST VENT
2. Controlsand Functions
2
54
13
4

Controls and Functions
6 Runco VX-22d Owner’s Operating Manual
PRELIMINARY
2.2
VX-22d Rear Panel
Figure 2-2 shows the VX-22d rear panel.
Figure 2-2. VX-22d Rear Panel
1. LAMP COVER
Remove this cover to access the lamp compartment.
2. RUN LED
Lights blue to indicate that the projector is functioning normally.
3. LEFT BUTTON
Used to move the menu cursor left in the VX-22d menu system.
4. UP BUTTON
Used to move the menu cursor up in the VX-22d menu system.
5. DOWN BUTTON
Used to move the menu cursor down in the VX-22d menu system.
6. RIGHT BUTTON
Used to move the menu cursor right in the VX-22d menu system.
7. STAND-BY LED
Lights orange to indicate that the projector is in standby mode.
Remove the screw to
pull off the lamp cover.
Remove the screw to
pull off the lamp cover.
L
L
SERVICE PORT
AUTHORIZED
PERSONNEL ONLY
1 4 527863
1115 121314
9
10

Controls and Functions
Runco VX-22d Owner’s Operating Manual 7
PRELIMINARY
8. SOFT POWER BUTTON
Press once to turn on the VX-22d. Press it again to put the projector into Standby
mode. For a discrete on or off command, you can use the direct access buttons on
the remote control (see Figure 2-5).
9. PATTERN BUTTON
Press PATTERN to access the internal test pattern menu. Use arrow keys to select a
pattern and press SELECT to confirm. Press PATTERN again to return to the
selected source.
10. POWER INPUT (100 to 240 VAC)
Connect the VX-22d to power here.
11. SERVICE PORT
For use by authorized service personnel only.
12. USB-B
High-speed service port (for future use).
13. DVI-DL (Dual-Link)
An HDCP-compliant, dual-link digital video input for connecting the output from the
DHD Controller.
14. SELECT BUTTON
Press SELECT to confirm your selection of a highlighted choice on the On-Screen
Display (OSD).
15. MENU BUTTON
Pressing the MENU button brings up the main VX-22d menu. Also, if you are in an
adjustment mode or function, pressing MENU brings the menu back one level.

Controls and Functions
8 Runco VX-22d Owner’s Operating Manual
PRELIMINARY
2.3
DHD Controller Front
Panel
Figure 2-3 shows the controls and indicators on the DHD Controller front panel; the
paragraphs that follow describe them.
Figure 2-3. DHD Controller Front Panel
1. RUNCO ICON
Lights blue to indicate that the DHD Controller is powered up and functioning
normally.
2. IR SENSOR
Receives IR commands from the remote.
3. VACUUM FLUORESCENT DISPLAY (VFD)
Can be used instead of the OSD. Displays currently-selected menu or – if no menu is
selected – the current source, input resolution and aspect ratio.
If an error condition occurs, a message
appears here indicating the cause:
4. PATTERN BUTTON
Press PATTERN to access the internal test pattern menu. Use arrow keys to select a
pattern and press SELECT to confirm. Press PATTERN again to return to the
selected source.
5. LEFT BUTTON
Used to direct-select inputs or move the menu cursor left in the OSD. When no menu
is present on-screen, the LEFT button toggles through the different sources, in this
order:
HDMI 2 - HDMI 1 - HD3 (VGA/Y-Pb-Pr) - HD 2 (BNC) - HD 1 (RCA) - S-Video -
Composite (VID)
3
1
11 10 91214 13
654 87
2
Please check issue(s)
Communication Error
