video xtreme VX-3000 User manual

1080p DLP
TM
Home Theater Projector
INSTALLATION/OPERATION MANUAL
VX-3000
Downloaded From projector-manual.com Runco Manuals

Downloaded From projector-manual.com Runco Manuals

VX-3000 Installation/Operation Manual iii
PRELIMINARY
TWO YEAR LIMITED WARRANTY
For Projectors, Video Processors and Controllers
from Runco International, LLC (“Runco”)
Congratulations on your purchase of a Runco video product and welcome to the Runco family! With proper installation, setup
and care, you should enjoy many years of unparalleled video performance.
This is a LIMITED WARRANTY as defined in the Magnuson-Moss Warranty Act. Please read it carefully and retain it with your
other important documents.
The following Runco product models are covered under this Limited Warranty:
VX-3000 (“Product” individually and “Products” collectively).
SERVICE LABOR: Runco will pay for service labor at an Authorized Service Center when needed as a result of manufacturing
defect for a period of two (2) years from the date of delivery to the initial end user (excluding the lamp).
PARTS (not including the lamp): Runco will provide new or rebuilt replacement parts for the parts that fail due to defects in
materials or workmanship for a period of two (2) years from the effective date of delivery to the initial end user. Such
replacement parts are then subsequently warranted for the remaining portion (if any) of the original warranty period.
PROJECTOR LAMP: Runco will pay for service labor at an Authorized Service Center when needed as a result of a
manufacturing defect for a period of six (6) months or 1000 hours, whichever comes first, from the effective date of delivery to
the initial end user. In addition, Runco will provide a new or rebuilt replacement lamp for the lamp that fails due to defects in
materials or workmanship for a period of six (6) months or 1000 hours, whichever comes first, from the effective date of delivery
to the initial end user. Such replacement parts are then subsequently warranted for the remaining portion (if any) of the original
warranty period.
This Limited Warranty only covers failure due to defects in materials and workmanship that occur during normal use and does
not cover normal wear and tear nor any Product on which the serial number has been defaced, modified, or removed. This
Limited Warranty does not cover: cabinets or any appearance items; failure resulting from accident, misuse, abuse, neglect,
mishandling, misapplication, or faulty or improper installation or setup adjustments; improper maintenance; alteration; improper
use of any input signal; damage due to lightning or power line surges, spikes and brownouts; damage that occurs during
shipping or transit; damage that is attributed to acts of God; customer caused defects; or rental costs incurred due to Product
failure. In the case of remote control units, damage resulting from leaking, old, damaged or improper batteries is also excluded
from coverage under this Limited Warranty.
CAUTION: THIS LIMITED WARRANTY ONLY COVERS RUNCO PRODUCTS PURCHASED FROM AUTHORIZED RUNCO
DEALERS. ALL OTHER PRODUCTS ARE SPECIFICALLY EXCLUDED FROM COVERAGE UNDER THIS WARRANTY.
MOREOVER, DAMAGE RESULTING DIRECTLY OR INDIRECTLY FROM IMPROPER INSTALLATION OR SETUP IS
SPECIFICALLY EXCLUDED FROM COVERAGE UNDER THIS LIMITED WARRANTY. IT IS IMPERATIVE THAT INSTALLATION
AND SETUP WORK BE PERFORMED ONLY BY AN AUTHORIZED RUNCO DEALER TO PROTECT YOUR RIGHTS UNDER
THIS WARRANTY. THIS WILL ALSO ENSURE THAT YOU ENJOY THE FINE PERFORMANCE OF WHICH YOUR RUNCO
PRODUCT IS CAPABLE WHEN INSTALLED AND CALIBRATED BY AN AUTHORIZED RUNCO DEALER.
WHAT IS COVERED UNDER THE TERMS OF THIS LIMITED WARRANTY:
WHAT IS NOT COVERED UNDER THE TERMS OF THIS LIMITED WARRANTY:
Downloaded From projector-manual.com Runco Manuals

iv VX-3000 Installation/Operation Manual
PRELIMINARY
THE FOREGOING DESCRIBED WARRANTIES ARE THE ONLY WARRANTIES THAT APPLY TO THE PRODUCTS. RUNCO
MAKES NO OTHER WARRANTY OR REPRESENTATION AND HEREBY DISCLAIMS ALL OTHER WARRANTIES, EXPRESS
OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE. RUNCO’S LIABILITY RELATED TO THE PRODUCT IS LIMITED TO THE COST OF THE
APPLICABLE REMEDY AS NOTED ABOVE. IN NO EVENT SHALL RUNCO BE LIABLE FOR:
• DAMAGE TO OTHER PROPERTY CAUSED BY ANY DEFECTS IN THE PRODUCT, DAMAGES BASED UPON
INCONVENIENCE, LOSS OF USE OF THE PRODUCT, LOSS OF TIME, LOSS OF PROFITS, LOSS OF BUSINESS
OPPORTUNITY, LOSS OF GOODWILL, INTERFERENCE WITH BUSINESS RELATIONSHIPS, OR OTHER COMMERCIAL
LOSS, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES;
• ANY OTHER DAMAGES, WHETHER INCIDENTAL, CONSEQUENTIAL OR OTHERWISE;
• ANY CLAIM AGAINST THE CUSTOMER BY ANY OTHER PARTY; OR
• ANY VERBAL WARRANTY ASSURANCES MADE BY A RUNCO EMPLOYEE OR A RUNCO AUTHORIZED DEALER THAT
CONFLICTS WITH OR ENHANCES THE WRITTEN WARRANTY INCLUDED HEREIN.
This Limited Warranty begins on the date of delivery to the end user. For your convenience, keep the original bill of sale as
evidence of the purchase date.
Repairs made under the terms of this Limited Warranty covering your VX-3000 Product will be performed at the location of the
Product, during usual working hours, provided that the location of the Product is within normal operating distance from an
Authorized Runco Service Center. In some instances it may be necessary for the Product to be returned to the Runco factory
for repairs. If, solely in Runco’s judgment, location of Product to be repaired is beyond normal operating distance of the closest
Authorized Runco Service Center, or the repair requires the unit be returned to the Runco factory, it is the owner’s
responsibility to arrange for shipment of the Product for repair. These arrangements must be made through the selling Runco
Dealer. If this is not possible, contact Runco directly for a Return Authorization number and shipping instructions. Runco will
return Product with transportation prepaid in the United States, unless no Product defect is discovered. In that instance,
shipping costs will be the responsibility of the Product owner.
RIGHTS, LIMITS AND EXCLUSIONS:
EFFECTIVE WARRANTY DATE:
CONTACT AN AUTHORIZED SERVICE CENTER TO OBTAIN SERVICE:
Downloaded From projector-manual.com Runco Manuals

VX-3000 Installation/Operation Manual v
PRELIMINARY
© Copyright 2009 Runco International, LLC (“Runco”). This document contains proprietary information protected by copyright,
trademark and other intellectual property laws. All rights are reserved. No part of this manual may be reproduced by any
mechanical, electronic or other means, in any form, without prior written permission of Runco.
The trademarks reporduced in this Runco Owner’s Manual and used on the Runco Products are either owned by Runco or are
licensed by Runco. You may not reproduce or use the trademarks without the prior written consent of Runco.
Runco Products are manufactured under one or more of the following patents: US. Patent 6755540 and Other Patents
Pending.
To locate the name and address of the nearest Authorized Runco Service Center, or for additional information about this
Limited Warranty, please call or write:
RUNCO INTERNATIONAL, LLC
1195 NW Compton Drive
Beaverton, OR 97006-1992
Ph: [phone]
Fax: [phone]
Toll Free: (800) 23-RUNCO (800-237-8626)
PRODUCT INFORMATION
RETAIN FOR YOUR RECORDS
_________________________________________________________ ________________________________________
Model Purchased Date
____________________________________________________________________________________________________________
Serial Number
____________________________________________________________________________________________________________
Runco Authorized Dealer Name
____________________________________________________________________________________________________________
Address
____________________________________________ __________________ ________________________
City State/Province Postal Code
____________________________________________ _______________________________________________________
Phone Fax
COPYRIGHT AND TRADEMARKS:
ADDITIONAL INFORMATION:
Downloaded From projector-manual.com Runco Manuals

vi VX-3000 Installation/Operation Manual
PRELIMINARY
Thank you for your purchase of this quality Runco video product! It has been designed to provide you with the quality of video
that is expected in a home theater. For the best performance, please read this manual carefully as it is your guide through the
menus and operation.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any of the ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades with one wider
than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong is
provided for your safety. When the provided plug does not fit into your outlet, consult an electrician for the replacement of
the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles and the point
where they exit from the apparatus.
11. Only use the attachments/accessories specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket or table specified by the manufacturer or sold with the apparatus.
When a cart is used, use caution when moving the cart/apparatus to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in
any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
15. The +12V trigger only outputs 12Vdc signal for triggering. Do not connect to any other power input or output. This could
cause damage to this unit.
16. Keep the packing material in case the equipment should ever need to be shipped.
17. The lamp becomes extremely hot during operation. Allow the projector to cool down for approximately 45 minutes prior to
removing the lamp assembly for replacement.
18. Do not operate lamps beyond the rated lamp life. Excessive operation of lamps beyond rated life could cause them to
explode in rare occasions.
Important Safety Instructions
WARNING
This symbol is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electric
shock.
This symbol is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
Downloaded From projector-manual.com Runco Manuals

VX-3000 Installation/Operation Manual vii
PRELIMINARY
19. Never look directly into the lens when the lamp is on.
Manufacturer’s Name: Runco International, LLC
Manufacturer’s Address: 1195 NW Compton Drive, Beaverton, OR 97006-1992
hereby declares that the Products’ Model Numbers:
VX-3000
conform with the provisions of:
Council Directive 2004/108/EC on Electromagnetic Compatibility;
EN 55022 “Limits and methods of measurements of radio interference characteristics of information technology equipment”
1998;
EN 55024 “Limits and methods of measurements of immunity characteristics of information technology equipment” 1998;
Including:
• EN 61000-4-2 “Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 2:
Electrostatic discharge immunity test”
• EN 61000-4-3 “Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 3: Radiated,
Radio-Frequency, Electromagnetic Field Immunity Test”
• EN 61000-4-4 “Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 4: Electrical
fast transient/burst immunity test”
• EN 61000-4-5 "Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 5: Surge
immunity test"
• EN 61000-4-6 "Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 6: Conducted
disturbances induced by radio-frequency fields immunity test"
• EN 61000-4-8 "Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 8: Conducted
disturbances induced by power frequency magnetic fields immunity test"
• EN 61000-4-11 "Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 11: Voltage
dips, short interruptions and voltage variations immunity tests"
And:
• EN 61000-3-2 "Electromagnetic compatibility (EMC) Part 3, Section 2: Limits for harmonic current emissions (equipment
input current up to and including 16 A per phase)" 2000;
• EN 61000-3-3 "Electromagnetic compatibility (EMC) Part 3, Section 3: Limitations of voltage changes, voltage
fluctuations and flicker in public low-voltage supply systems, for equipment with rated current up to and including 16 A
and not subject to conditional connection" 1995;
Council Directive 2006/95/EC and amended by M1 and C1 on Low Voltage Equipment Safety;
EN 60950 “Safety of information technology equipment, including electrical business equipment”
The Technical Construction file required by this Directive is maintained at the corporate headquarters of Runco International,
LLC, located at 1195 NW Compton Drive, Beaverton, OR 97006-1992.
Date of Declaration: September 2009
Compliance Information
DECLARATION OF CONFORMITY:
Downloaded From projector-manual.com Runco Manuals

viii VX-3000 Installation/Operation Manual
PRELIMINARY
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
The Product contains small amounts of tin, lead and/or mercury. Disposal of these materials may be regulated due to
environmental considerations.
Lamp(s) inside this product contain mercury. This product may contain other electronic waste that can be
hazardous if not disposed of properly. Recycle or dispose in accordance with local, state, or federal Laws.
For more information, contact the Electronic Industries Alliance at WWW.EIAE.ORG.
For lamp specific disposal information check WWW.LAMPRECYCLE.ORG.
This symbol found on your product or on its packaging, indicates that this product should not be treated as
household waste when you wish to dispose of it. Instead, it should be handed over to an applicable collection
point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly,
you will help prevent potential negative consequences to the environment and human health, which could
otherwise be caused by inappropriate disposal of this product. The recycling of materials will help to conserve
natural resources. This symbol is only valid in the European Union. If you wish to discard this product, please
contact your local authorities or dealer and ask for the correct method of disposal.
FCC PART 15:
INDUSTRY CANADA (ICES-003):
PRODUCT DISPOSAL:
IMPORTANT RECYCLE INSTRUCTIONS
DISPOSAL OF OLD ELECTRICAL AND ELECTRONIC EQUIPMENT (Applicable throughout the European
Union and other European countries with separate collection programs)
Downloaded From projector-manual.com Runco Manuals

VX-3000 Installation/Operation Manual ix
1Table of Contents
PRELIMINARY
TWO YEAR LIMITED WARRANTY .................................................................................. iii
Important Safety Instructions......................................................................................... vi
Compliance Information ................................................................................................ vii
1. Introduction ................................................................................................................1
About This Manual .......................................................................................................1
Target Audience .....................................................................................................1
If You Have Comments About This Manual.............................................................1
Textual and Graphic Conventions ...........................................................................1
Using This Manual ........................................................................................................2
Description, Features and Benefits ...............................................................................3
Key Features and Benefits ......................................................................................4
Parts List ................................................................................................................4
2. Controls and Functions .............................................................................................5
VX-3000 at a Glance ....................................................................................................5
VX-3000 Rear Panel .....................................................................................................8
VX-3000 Remote Control .............................................................................................9
3. Installation ................................................................................................................13
Remote Control ..........................................................................................................13
Notes on Batteries ................................................................................................13
Notes on Remote Control Operation.....................................................................13
Quick Setup ...............................................................................................................14
Installation Considerations ..........................................................................................15
Installation Type ....................................................................................................15
Ambient Light .......................................................................................................15
Throw Distance.....................................................................................................16
Vertical and Horizontal Position.............................................................................18
Vertical and Horizontal Lens Shift..........................................................................18
Folded Optics .......................................................................................................21
Other Considerations............................................................................................21
Installing the Primary Projection Lens (VX-3000 Ultra only) ..........................................22
Installing the Optional CineWide/AutoScope Lens Mount ...........................................26
Installing the AutoScope Lens Motor.....................................................................27
Installing the Fixed CineWide Base Plate (Prismatic Lens) .....................................31
Downloaded From projector-manual.com Runco Manuals

Table of Contents
x VX-3000 Installation/Operation Manual
PRELIMINARY
Installing the Fixed CineWide Base Plate (Cylindrical Lens) ....................................33
Mounting the VX-3000 ...............................................................................................36
Floor Mounting (Upright) .......................................................................................36
Ceiling Mounting (Inverted)....................................................................................36
Adjusting the Projector Height or Projection Angle ................................................36
Connections to the VX-3000 ......................................................................................36
Connector Panel Access.......................................................................................36
Connecting Source Components to the VX-3000 .................................................37
RS-232 Controller Connection ..............................................................................40
Connecting 12-Volt Trigger Output to External Theater Equipment .......................41
Connecting to AC Power ......................................................................................42
Turning on the Power .................................................................................................42
Primary Lens Adjustments ..........................................................................................43
Focus and Zoom ..................................................................................................43
Focus and Zoom – VX-3000 Ultra.........................................................................43
Lens Shift .............................................................................................................43
Changing the OSD Language .....................................................................................43
Adjusting the Picture Orientation ................................................................................44
Installing and Adjusting the CineWide Anamorphic Lens .............................................44
Cylindrical Anamorphic Lens Installation and Adjustment ......................................45
Whitney (Prismatic) Anamorphic Lens Installation and Adjustment.........................50
4. Operation ..................................................................................................................53
Selecting Video Memory .............................................................................................53
Selecting an Aspect Ratio ..........................................................................................53
Adjusting the Picture ..................................................................................................53
Selecting An Input Source ..........................................................................................53
Using Picture-In-Picture (PIP) .....................................................................................54
Using the On-Screen Menus ......................................................................................54
Main Menu............................................................................................................56
Source Select .......................................................................................................56
Picture Adjust .......................................................................................................56
Aspect Ratio.........................................................................................................61
Installation.............................................................................................................63
Information ...........................................................................................................67
Setup....................................................................................................................67
ISF........................................................................................................................69
5. Maintenance and Troubleshooting.........................................................................73
Downloaded From projector-manual.com Runco Manuals

Table of Contents
VX-3000 Installation/Operation Manual xi
PRELIMINARY
Lamp Replacement ....................................................................................................73
Troubleshooting Tips ..................................................................................................74
6. Serial Communications ...........................................................................................77
RS-232 Connection and Port Configuration ...............................................................77
Serial Command Syntax .............................................................................................77
7. Specifications ........................................................................................................... 87
VX-3000 Specifications ..............................................................................................87
Overall Dimensions – VX-3000i/CineWide and VX-3000d/CineWide ...........................90
Overall Dimensions – VX-3000 Ultra ...........................................................................91
Overall Dimensions – VX-3000i/CineWide with AutoScope and VX-3000d/CineWide with
AutoScope .................................................................................................................92
Supported Timings .....................................................................................................93
Downloaded From projector-manual.com Runco Manuals

Table of Contents
xii VX-3000 Installation/Operation Manual
PRELIMINARY
Downloaded From projector-manual.com Runco Manuals

VX-3000 Installation/Operation Manual xiii
1List of Figures
PRELIMINARY
2-1. VX-3000 Front/Side/Top View ......................................................................................5
2-2. VX-3000 Rear/Bottom/Side View .................................................................................7
2-3. VX-3000 Rear Panel .....................................................................................................8
2-4. VX-3000 Remote Control .............................................................................................9
3-1. Estimating Throw Distance .........................................................................................16
3-2. Projector Placement ...................................................................................................18
3-3. Vertical Lens Shift (Example Only)...............................................................................18
3-4. Horizontal Lens Shift (Example Only)...........................................................................19
3-5. Folded Optics.............................................................................................................21
3-6. VX-3000i/CineWide with AutoScope or VX-3000d/CineWide with AutoScope Motor As-
sembly – Exploded View.............................................................................................27
3-7. VX-3000 Ultra/CineWide with AutoScope Motor Assembly – Exploded View ..............28
3-8. VX-3000 with Ceiling Mount Adapters/Projector Stands .............................................29
3-9. AutoScope Lens Motor Installation .............................................................................30
3-10. Projector with Whitney (Prismatic) Lens Base Plate and Ceiling Mounting Plate - Bottom
View ...........................................................................................................................32
3-11. VX-3000i/CineWide or VX-3000d/CineWide with Rainier II/McKinley (Cylindrical) Lens
Base Plate and Ceiling Mounting Plate - Exploded View .............................................33
3-12. VX-3000 Ultra/CineWide with Rainier II/McKinley (Cylindrical) Lens Base Plate and Ceil-
ing Mounting Plate - Exploded View ...........................................................................34
3-13. HDMI/DVI Source Connections ................................................................................37
3-14. RGB Connections ....................................................................................................38
3-15. Progressive Component Video Connections.............................................................38
3-16. Composite, S-Video and Component Video Connections.........................................39
3-17. RS-232 Control System Connection.........................................................................40
3-18. Connecting the 12-Volt Trigger Output to the AutoScope Lens Motor ......................41
3-19. Connecting the 12-Volt Trigger Output to Other Equipment......................................41
3-20. Cylindrical Anamorphic Lens Mounting Assembly - Exploded View...........................45
3-21. Attaching the Anamorphic Lens to the Lens Ring .....................................................46
3-22. Prismatic Anamorphic Lens Mounting Assembly - Exploded View ............................50
4-1. VX-3000 OSD Menu Structure ...................................................................................55
4-2. Typical PLUGE Pattern for Adjusting Brightness .........................................................57
4-3. Typical Gray Bar Pattern for Adjusting Contrast ..........................................................58
4-4. Typical Color Bar Pattern for Adjusting Color Saturation and Tint................................59
4-5. Typical Test Pattern for Adjusting Sharpness..............................................................60
Downloaded From projector-manual.com Runco Manuals

List of Figures
xiv VX-3000 Installation/Operation Manual
PRELIMINARY
4-6. Keystone Correction...................................................................................................64
4-7. Pincushion Correction ................................................................................................65
4-8. Gain and Offset ..........................................................................................................69
4-9. CIE 1931 Chromaticity Diagram .................................................................................71
7-1. Overall Dimensions – VX-3000i/CineWide and VX-3000d/CineWide (Prismatic Lens)..90
7-2. Overall Dimensions – VX-3000 Ultra ...........................................................................91
7-3. Overall Dimensions – VX-3000i/CineWide with AutoScope .........................................92
Downloaded From projector-manual.com Runco Manuals

VX-3000 Installation/Operation Manual 1
PRELIMINARY
1.1
About This Manual
This Owner’s Manual describes how to install, set up and operate a Runco VX-3000
DLP™ Home Theater Projector.
Target AudienceRunco has prepared this manual to help home theater installers and end users get the
most out of the VX-3000.
Runco has made every effort to ensure that this manual is accurate as of the date it was
printed. However, because of ongoing product improvements and customer feedback, it
may require updating from time to time. You can always find the latest version of this and
other Runco product manuals on-line, at www.Runco.com.
If You Have Comments
About This Manual...
Runco welcomes your comments about this manual. Send them to [e-mail].
Textual and Graphic
Conventions
Text Conventions: The following conventions are used in this manual, in order to clarify
the information and instructions provided:
• Remote and built-in keypad button identifiers are set in upper-case bold type; for
example, “Press EXIT to return to the previous menu.”
• Computer input (commands you type) and output (responses that appear on-screen) is
shown in monospace (fixed-width) type; for example: “To select the Component 1
input, type X133X.”
• All keys with functional names are initial-capped, set in bold type and enclosed in angle
brackets. These keys are the following: <Enter>, <Spacebar>, <Control>,
<Esc> and <Tab>.
•<Enter> indicates that you may press either the RETURN or ENTER key on your
keyboard if it has both keys.
In addition to these conventions, underlining, boldface and/or italics are occasionally used
to highlight important information, as in this example:
1. Introduction
A carriage return must be used after each command or string.
Note
Downloaded From projector-manual.com Runco Manuals

Introduction
2 VX-3000 Installation/Operation Manual
PRELIMINARY
Graphic Conventions: These symbols appear in numerous places throughout the
manual, to emphasize points that you must keep in mind to avoid problems with your
equipment or injury:
1.2
Using This Manual
Use the following table to locate the specific information you need in this manual.
TIPS highlight time-saving short cuts and helpful guidelines for using
certain features.
NOTES emphasize text with unusual importance or special
significance. They also provide supplemental information.
CAUTIONS alert users that a given action or omitted action can
degrade performance or cause a malfunction.
WARNINGS appear when a given action or omitted action can result
in damage to the equipment, or possible non-fatal injury to the user.
DANGER appears when a given action can cause severe injury or
death.
Tip
Note
Caution
WARNING
DANGER!
If you need... ... Turn to page:
Information about obtaining service iv
General information about the VX-3000 Home Theater Projector 3
Installation instructions 13
First-time configuration instructions 43
Advanced configuration instructions 67
Troubleshooting tips 74
Specifications for the VX-3000 Home Theater Projector 87
Downloaded From projector-manual.com Runco Manuals

Introduction
VX-3000 Installation/Operation Manual 3
PRELIMINARY
1.3
Description, Features
and Benefits
The VX-3000 Home Theater Projector offer the astounding picture quality and versatility
heretofore associated with more expensive projectors. Its 1920 x 1080, native-resolution
DLP light engine features Runco's powerful SuperOnyx™ technology for bright, pristine
high-definition (1080p) images.
Contrast ratio and dynamic range extend to new heights with Runco's exclusive
Reflectance Volume Regulation™ (RVR), an electronically-controlled iris system.
This model features a precision optics package with electronic lens shift. The standard
VX-3000 projection lens has a throw range of from 1.87 to 2.20 times the screen width.
The VX-3000's illumination system provides two light intensity levels to allow maximum
flexibility for screen size, ambient light conditions, brightness and contrast balance, and
lamp life preservation. It also has a newly refined cooling system, which increases
efficiency and reduces noise levels.
The VX-3000 has been engineered to comply with Imaging Science Foundation™ (ISF)
standards for maximum home theater image quality. Runco's sophisticated parameters
for white balance and color gamut control have also been implemented for precise
balance of gray scale and color. The VX-3000 incorporates Runco-proprietary
de-interlacing technology that provides exceptional scaling and film-to-video (3:2
pulldown) conversion for the most artifact-free images possible.
For uncompromising widescreen reproduction of movies originally filmed in the “scope”
(2.35:1) format, the VX-3000 can be equipped with Runco’s patent-pending CineWide™
technology, a combination of software, electronics and high-quality anamorphic optics.
CineWide maintains constant vertical height on the screen just as in a movie theater.
When a viewer transitions from 1.78:1 (16:9) program material to 2.35:1, the image simply
gets wider while full height is maintained. Also available with the VX-3000 is CineWide with
AutoScope™, an enhanced, remote-controlled motorized version of CineWide.
Discrete IR and RS-232 control make custom installation seamless, while discrete source
and aspect ratio selection accommodate any automation control system.
CineWide requires the use of a 2.35:1 or similar aspect ratio superwide
format screen.
Note
Downloaded From projector-manual.com Runco Manuals

Introduction
4 VX-3000 Installation/Operation Manual
PRELIMINARY
Key Features and Benefits The VX-3000 offers these key features and benefits:
• Native Resolution: 1920 x 1080 (16:9 Native Aspect Ratio)
• DLP system using SuperOnyx™ Digital Micromirror Device (DMD)
• 6-segment color wheel produces wide dynamic range and rich grayscale
• Picture in Picture function allows you to display two inputs on the screen at the same
time
• Two (2) HDMI Inputs with High-bandwidth Digital Content Protection (HDCP)
• HDTV Compatible
• Reflectance Volume Regulation (RVR™) provides for infinitely variable adjustment of the
light path through the optics, enabling the perfect balance of black and white levels for
each individual installation
Parts List Your VX-3000 is shipped with the following items. If any items are missing or damaged,
please contact your Runco dealer or Runco Customer Service at (800) 23-RUNCO.
• VX-3000 DLP Home Theater Projector
• Remote Control Unit and two (2), AAA-size batteries
• AC Power Cord, 8.2 feet (2.5 meters)
• Source Connection Cables, 9.8 feet (3.0 meters):
• Component Video
•HDMItoHDMI
• VX-3000 Installation/Operation Manual (this document)
Optional Accessories:
• Ceiling mount kit (part number 956-0099-00)
• CineWide™ technology (fixed, secondary anamorphic lens)
• CineWide™ with AutoScope™ system (secondary anamorphic lens and motorized
mount)
➤
➤
Downloaded From projector-manual.com Runco Manuals

VX-3000 Installation/Operation Manual 5
PRELIMINARY
2.1
VX-3000 at a Glance
Figure 2-1 and Figure 2-2 show the key VX-3000 components.
Figure 2-1. VX-3000 Front/Side/Top View
1. EXHAUST VENT
2. ZOOM TAB (Standard VX-3000)
Use this to change the projected image size with a standard VX-3000.
3. TOP IR SENSOR
2. Controls and Functions
12 3
45
678910
Downloaded From projector-manual.com Runco Manuals

Controls and Functions
6 VX-3000 Installation/Operation Manual
PRELIMINARY
4. TEMP LED
Indicates fan status and internal temperature as follows:
• Off during normal operation
• Red when internal temperature is too high or a fan failure occurs
5. INTAKE VENT
6. POWER/STANDBY LED
Indicates power status as follows:
• Orange when the projector is in standby mode
• Flashes green for approximately 45 seconds after the projector is turned on to
indicate that the lamp is warming up
• Green during normal operation
• Flashes orange for approximately 110 seconds after the projector is turned off to
indicate that the lamp is cooling down
• Red when an internal failure requiring service has occurred
7. LAMP LED
Indicates lamp status as follows:
• Off during normal operation
• Red when the lamp has exceeded its usage life or developed a problem
8. RUNCO LOGO
The logo can be rotated to match the projector orientation: inverted (ceiling-mounted)
or upright. To rotate the logo, grip it at the sides, pull it away from the projector and
rotate it 180 degrees.
9. FRONT IR SENSOR
10. FOCUS RING (Standard VX-3000)
To adjust the focus, grasp the lens by the outer ring and rotate it.
Downloaded From projector-manual.com Runco Manuals
