Village QV32B Assembly instructions

1Quadra-fire • QV32B, QV36B • 2013-900 Rev. F • 9/06
Models:
QV32B
QV36B
Installers Guide
Underwriters
Laboratories Listed
- Do not store or use gasoline or other flam-
mablevaporsandliquidsinthevicinityofthis
oranyotherappliance.
-What to do if you smell gas
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Donot useany phonein your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call
thefiredepartment.
- Installationandservicemustbeperformedbya
qualified installer, service agency, or the gas
supplier.
WARNING: IMPROPER INSTALLA-
TION, ADJUSTMENT, ALTERATION,
SERVICE OR MAINTENANCE CAN
CAUSE INJURY OR PROPERTY DAM-
AGE. REFER TO THIS MANUAL. FOR
ASSISTANCE ORADDITIONAL INFOR-
MATION CONSULT A QUALIFIED IN-
STALLER, SERVICEAGENCY, OR THE
GAS SUPPLIER.
READ THIS MANUAL BEFORE INSTALLING OR
OPERATING THISAPPLIANCE. THIS INSTALLERS
GUIDE MUST BE LEFT WITH APPLIANCE FOR
FUTUREREFERENCE.
1.This appliance may be installed in an af-
termarket,permanentlylocated,manufac-
tured(mobile)home,wherenotprohibited
bylocalcodes.
2. Thisapplianceisonly forusewiththetype
of gas indicated on the rating plate. This
appliance is not convertible for use with
othergases,unlessacertifiedkitisused.
Please contact your Quadra-Fire dealer
with any questions or concerns. For the
number of your nearest Quadra-Fire
dealer,pleasevisitwww.quadrafire.com.
Printed in U.S.A. Copyright 2006
WARNING: IF THE INFORMATION
IN THESE INSTRUCTIONS IS NOT
FOLLOWED EXACTLY,A FIRE OR
EXPLOSION MAY RESULT CAUS-
ING PROPERTY DAMAGE, PER-
SONAL INJURY, OR DEATH.
Quadra-Fire, a brand of Hearth & Home Technologies
1445 North Highway, Colville, WA 99114
Thisproductmaybe coveredby oneor moreof thefollowing patents:(UnitedStates)4593510, 4686807,4766876, 4793322,4811534,5000162,5016609,5076254,5113843,5191877, 5218953,5263471,
5328356,5341794,5347983,5429495,5452708,5542407,5601073,5613487,5647340,5688568,5762062,5775408,5890485,5931661,5941237,5947112,5996575,6006743,6019099,6048195,6053165,
6145502,6170481,6237588,6296474,6374822,6413079,6439226, 6484712,6543698,6550687,6601579,6672860,6688302B2,6715724B2,6729551,6736133,6748940,6748942,6769426,6774802,
6796302,6840261,6848441,6863064,6866205, 6869278,6875012, 6880275,6908039,6919884,D320652,D445174, D462436;(Canada) 1297749,2195264,2225408, 2313972;(Australia)780250,
780403,1418504or other U.S.andforeign patentspending.
IntheCommonwealth of Massachusetts:
• installation must be performed by a licensed
plumberorgas fitter;
SeeTable of Contentsfor location ofadditional
Commonwealthof Massachusetts requirements.

2Quadra-fire • QV32B, QV36B • 2013-900 Rev. F • 9/06
These units MUST use one of the vent systems
described in the Installing the Fireplace section of the
Installers Guide. NO OTHER vent systems or
components MAY BE USED.
This gas fireplace and vent assembly MUST be
vented directly to the outside and MUST NEVER be
attached to a chimney serving a separate solid fuel
burning appliance. Each gas appliance MUST USE
a separate vent system. Common vent systems are
PROHIBITED.
INSPECT the external vent cap on a regular basis to
make sure that no debris is interfering with the air
flow.
The glass door assembly MUST be in place and
sealed, and the trim door assembly MUST be in
place on the fireplace before the unit can be placed
into safe operation.
DO NOT OPERATE this appliance with the glass
door removed, cracked, or broken. Replacement of
the glass door should be performed by a licensed or
qualified service person. DO NOT strike or slam the
glass door.
The glass door assembly SHALL ONLY be replaced
as a complete unit, as supplied by the gas fireplace
manufacturer. NO SUBSTITUTE material may be
used.
DO NOT USE abrasive cleaners on the glass door
assembly. DO NOT ATTEMPT to clean the glass
door when it is hot.
Turn off the gas before servicing this appliance. It is
recommended that a qualified service technician
perform an appliance check-up at the beginning of
each heating season.
Any safety screen or guard removed for servicing
must be replaced before operating this appliance.
DO NOT place furniture or any other combustible
household objects within 36 inches of the fireplace
front.
READ and UNDERSTAND all instructions carefully
before starting the installation. FAILURE TO
FOLLOW these installation instructions may result
in a possible fire hazard and will void the warranty.
Prior to the first firing of the fireplace, READ the
Using Your Fireplace section of the Owners Guide.
DO NOT USE this appliance if any part has been
under water. Immediately CALL a qualified service
technician to inspect the unit and to replace any part
of the control system and any gas control which has
been under water.
THIS UNIT IS NOT FOR USE WITH SOLID FUEL.
Installation and repair should be PERFORMED by a
qualified service person. The appliance and venting
system should be INSPECTED before initial use
and at least annually by a professional service
person. More frequent cleaning may be required
due to excessive lint from carpeting, bedding
material, etc. It is IMPERATIVE that the unit’s
control compartment, burners, and circulating air
passageways BE KEPT CLEAN to provide for
adequate combustion and ventilation air.
Always KEEP the appliance clear and free from
combustible materials, gasoline, and other
flammable vapors and liquids.
NEVER OBSTRUCT the flow of combustion and
ventilation air. Keep the front of the appliance
CLEAR of all obstacles and materials for servicing
and proper operations.
Due to the high temperature, the appliance should
be LOCATED out of traffic areas and away from
furniture and draperies. Clothing or flammable
material SHOULD NOT BE PLACED on or near the
appliance.
Children and adults should be ALERTED to the
hazards of high surface temperature and should
STAY AWAY to avoid burns or clothing ignition.
Young children should be CAREFULLYSUPERVISED
when they are in the same room as the appliance.
!
!
!
!
!
!
!
!!
!
!
!
!
!
!
!
!
SAFETY AND WARNING INFORMATION
!
!

3Quadra-fire • QV32B, QV36B • 2013-900 Rev. F • 9/06
TABLE OF CONTENTS
Safety and Warning Information ......................................................... 2
Service Parts Lists ................................................................................. 4
Section 1: Approvals and Codes.......................................................... 9
ApplianceCertification ............................................................................. 9
InstallationCodes .................................................................................... 9
HighAltitudeInstallations ........................................................................ 9
Requirementsfor the Commonwealthof Massachusetts........................ 10
Section 2: Getting Started .................................................................. 11
IntroducingtheVillage Collection GasFireplaces .................................. 11
Pre-installationPreparation .................................................................... 11
Section 3: Installing the Fireplace..................................................... 14
Constructingthe Fireplace Chase .......................................................... 14
Step 1 Locatingthe Fireplace........................................................... 14
Step 2 Framingthe Fireplace ........................................................... 15
Step 3 Installing the Vent System .................................................... 18
A. Vent SystemApprovals ................................................... 18
B. Installing Vent Components............................................. 28
C. VentTermination.............................................................. 31
Step 4 Positioning,Leveling, and
Securingthe Fireplace .......................................................... 34
Step 5 TheGasControl Systems..................................................... 34
Step 6 TheGasSupply Line............................................................. 35
Step 7 GasPressure Requirements................................................. 35
Step 8 Wiring the Fireplace .............................................................. 36
Step 9 Finishing ............................................................................... 37
Step 10 InstallingTrim, Logs, andEmber Material ............................. 37
Installingthe Trim.................................................................. 37
PositioningtheLogs ............................................................. 38
ShutterSetting...................................................................... 38
Placing the Ember Material................................................... 38
GlassSpecifications ............................................................. 38
Step11 LightingtheAppliance ........................................................... 39
Step12 BeforeLighting theFireplace................................................. 40
Step13 Lightingthe Fireplace............................................................ 40
Afterthe Installation ............................................................................... 40
Section 4: Maintaining and Servicing Your Fireplace .................... 41
Section 5: Troubleshooting ............................................................... 42
Limited Lifetime Warranty ................................................................. 44
Î
Î= Containsupdated information.
Î
Î

4Quadra-fire • QV32B, QV36B • 2013-900 Rev. F • 9/06
*Partnumberlist on followingpage.
5
4
2
1
3
6 Log Set Assembly
11
10
8
7
9
13
12
(NG, LP) Exploded Parts Diagram
Service Parts QV32B
Beginning Manufacturing Date: 6-03
Ending Manufacturing Date: ______
Î

5Quadra-fire • QV32B, QV36B • 2013-900 Rev. F • 9/06
AVAILABLE
TO SHIP IN
24 HOURS
ITEM STANDING PILOT IGNITION SERIAL # PART NUMBER
Burner Orifice NG (#44C) 582-844 Y
Burner Orifice LP (#54C) 582-854 Y
1 Junction Box 100-250A Y
2Burner Pre 10-06
Post 10-06 2013-002 2013-018 Y Y
3 Glass Door Assembly GLA-550TR Y
4LogGrate 2014-001
5 Base Refractory NG, LP 2013-100
6 Log Set Assembly LOGS-2013 Y
7Log1 SRV2014-701
8Log2 SRV2014-703
9Log3 SRV2014-702
10 Log 4 SRV780-707
11 Log 5 SRV2014-704
12 Refractory Kit (Sold as set only) BRICK-296
13 Andirons, Cast 80784
Pilot Tube Pre 10-06
Post 10-06 SRV485-301 N/A Y
Lava Rock Bag 060-721
Mineral Wool 050-721
Exhaust Restrictor 530-299
Glass Latch Assembly 386-122A Y
Touch Up Pai nt TUP-GBK-12
Regulator NG Pre 10-06
Post 10-06 060-518 230-1570 Y Y
Regulator LP Pre 10-06
Post 10-06 060-519 230-1520 Y Y
Pilot Spud NG Pre 10-06
Post 10-06 446-505 2103-116 Y Y
Pilot Spud LP Pre 10-06
Post 10-06 446-517 2103-117 Y Y
ACCESSORIES
Fan Kit GFK-160A
Extended Vertical Baffle Kit BAF-VERT
Wall Switch Kit, Off-white WSK-21-HTI
Wall Switch Kit, White WSK-21-W-HTI
Conversion Kit NG Pre 10-06
Post 10-06 NGK-2013 NGKS-2013 Y Y
Conversion Kit LP Pre 10-06
Post 10-06 LPK-2013 LPKS-2013 Y Y
Door Front - Remington Ave. DF-32RA-BK
Door Front - Remington Ave. DF-32RA-HP
Door Front - Sun Prairie Operable DF-32SPO-BK
Door Front - Sun Prairie Operable DF-32SPO-HP
Door Front - Sun Prairie Operable DF-32SPO-VC
Door Front - Town Square DF-32TS-BK
Door Front - Town Square DF-32TS-HP
Door Front - Harmony Hall DF-32HH-BK
Hood, Black SRV550-175
Hood, Hammered Pewter SRV550-175-HP
(NG, LP) Service Parts List
IMPORTANT: THISIS DATED INFORMATION.The mostcurrent informationis locatedon your
dealersVIPsite.Whenordering,supplyserialandmodelnumberstoensurecorrectserviceparts.
QV32B

6Quadra-fire • QV32B, QV36B • 2013-900 Rev. F • 9/06
*Partnumberlist on followingpage.
4
6 Log Set Assembly
1
11
10
8
7
9
5
2
3
12
(NG, LP) Exploded Parts Diagram
Service Parts QV36B
Beginning Manufacturing Date: 6-03
Ending Manufacturing Date: ______
Î

7Quadra-fire • QV32B, QV36B • 2013-900 Rev. F • 9/06
(NG, LP) Service Parts List /
IMPORTANT: THIS IS DATED INFORMATION. The most current information is located on your
dealersVIPsite.Whenordering,supplyserialandmodelnumberstoensurecorrectserviceparts.
QV36B
AVAILABLE
TO SHIP IN
24 HOURS
ITEM STANDING PILOT IGNITION SERIAL # PART NUMBER
Burner Orifice NG (#43C) 582-843 Y
Burner Orifice LP (#53C) 582-853 Y
1 Junction Box 100-250A Y
2 Burner Pre 10-06
Post 10-06 2015-002 2015-016 Y Y
3 Andirons, Cast 80784
4 Log Grate 2014-001
5 Base Refractory NG, LP 2015-100
6 Log Set Assembly LOGS-2015 Y
7 Log 1 SRV2016-701
8 Log 2 SRV2014-703
9 Log 3 SRV2014-703
10 Log 4 SRV780-707
11 Log 5 SRV700-706
12 Refractory Kit (Sold as set only) BRICK-294
Glass Door Assembly GLA-750TR Y
Pilot Tube Pre 10-06
Post 10-06 SRV485-301 N/A Y
Lava Rock Bag 060-721
Mineral Wool 050-721
Exhaust Restrictor 530-299
Glass Latch Assembly 386-122A Y
Touch Up Paint TUP-GBK-12
Regulator NG Pre 10-06
Post 10-06 060-518 230-1570 Y Y
Regulator LP Pre 10-06
Post 10-06 060-519 230-1520 Y Y
Pilot Spud NG Pre 10-06
Post 10-06 446-505 2103-116 Y Y
Pilot Spud LP Pre 10-06
Post 10-06 446-517 2103-117 Y Y
ACCESSORIES
Fan Kit GFK-160A
Extended Vertical Baffle Kit BAF-VERT
Wall Switch Kit, Off-white WSK-21-HTI
Wall Switch Kit, White WSK-21-W-HTI
Conversion Kit NG Pre 10-06
Post 10-06 NGK-2015 NGKS-2015 Y Y
Conversion Kit LP Pre 10-06
Post 10-06 LPK-2015 LPKS-2015 Y Y
Door Front - Remington Ave. DF-32RA-BK
Door Front - Remington Ave. DF-32RA-HP
Door Front - Sun Prairie Operable DF-32SPO-BK
Door Front - Sun Prairie Operable DF-32SPO-HP
Door Front - Sun Prairie Operable DF-32SPO-VC
Door Front - Town Square DF-32TS-BK
Door Front - Town Square DF-32TS-HP
Door Front - Harmony Hall DF-32HH-BK
Hood, Black SRV550-175
Hood, Hammered Pewter SRV550-175-HP

8Quadra-fire • QV32B, QV36B • 2013-900 Rev. F • 9/06
(NG, LP) Exploded Parts Diagram
Service Parts QV32B, QV36B
Beginning Manufacturing Date: 7-03
Standing Pilot Ignition
ValveAssembly
13
4
2
9
7
11
8
56
AVAILABLE
TO SHIP IN
24 HOURS
ITEM DESCRIPTION SERIAL # PART NUMBER
1 ON/OFF Rocker Switch 060-521A Y
2ValveNG PRE 10-06
POST 10-06 060-522 230-0710 Y Y
2ValveLP PRE 10-06
POST 10-06 060-523 230-0720 Y Y
3 Flexible Gas Connector 530-302A Y
4 Burner Plate Gasket 530-431
5 Burner Neck Gasket 2045-407
6PilotAssemblyNG PRE 10-06
POST 10-06 530-510A 2103-010 Y Y
6PilotAssemblyLP PRE 10-06
POST 10-06 530-511A 2103-011 Y Y
7PiezoIgnitor 291-513 Y
8 Valve Bracket / SIT Bracket ADP PRE 10-06
POST 10-06 2025-101 2025-101/2044-155
9 Flex Ball Valve Assembly 302-320A Y
10 Jumper Wire 049-552A Y
11 Pilot Control Knob PRE 10-06
POST 10-06 291-530 571-534
12 Flame Control Knob PRE 10-06
POST 10-06 291-531 571-533
13 Control Panel PRE 10-06
POST 10-06 291-119 291-125
Pilot Bracket PRE 10-06
POST 10-06 530-164 N/A
1
3
10
12

9Quadra-fire • QV32B, QV36B • 2013-900 Rev. F • 9/06
1Approvals and Codes
NOTE: THESE MODELS ARE UL LISTED TO UL307B,
THESTANDARD FOR GAS-BURNINGHEATING APPLI-
ANCES FOR MANUFACTURED HOMES AND RECRE-
ATIONAL VEHICLES.
Installation Codes
The fireplace installation must conform to local codes.
Before installing the fireplace, consult the local building
code agency to ensure that you are in compliance with all
applicable codes, including permits and inspections.
In the absence of local codes, the fireplace installation
mustconform tothe NationalFuel GasCode ANSIZ223.1
(in the United States) or the CAN/CGA-B149 Installation
Codes (in Canada). The appliance must be electrically
groundedin accordancewith localcodesor, inthe absence
oflocalcodes with the NationalElectric Code ANSI/NFPA
No. 70 (in the United States), or to the CSA C22.1
Canadian Electric Code (in Canada).
Thesemodels may beinstalled ina bedroom orbed-sitting
room in the U.S.A. and Canada.
Appliance Certification
The Village Collection fireplace models discussed in this
Installers Guide have been tested to certification
standards and listed by the applicable laboratories.
Certification
MODELS: QV32B, QV36B
LABORATORY: UnderwritersLaboratories
TYPE: Direct Vent Gas Fireplace Heater
STANDARD:
ANSI Z21.88-2000•CSA2.33-2000•UL307B
HighAltitude Installations
U.L.Listed gasappliancesare testedand approvedwithout
requiringchanges for elevations from0 to 2,000feet in the
U. S.A. and in Canada.
Wheninstalling this applianceatan elevation above2,000
feet, it may be necessary to decrease the input rating by
changingthe existing burnerorificeto a smallersize. Input
rate should be reduced by 4% for each 1000 feet above a
2000 foot elevation in the U.S.A. or 10% for elevations
between2000and4500feet inCanada.If theheatingvalue
of the gas has been reduced, these rules do not apply. To
identify the proper orifice size, check with the local gas
utility.
Ifinstallingthis appliance at anelevation above 4,500 feet
(in Canada), check with local authorities.

10 Quadra-fire • QV32B, QV36B • 2013-900 Rev. F • 9/06
For all side wall horizontally vented gas fueled equipment
installed in every dwelling, building or structure used in
whole or in part for residential purposes, including those
owned or operated by the Commonwealth and where the
side wall exhaust vent termination is less than seven (7)
feetabove finishedgrade inthearea ofthe venting,includ-
ing but not limited to decks and porches, the following re-
quirements shall be satisfied:
Installation of Carbon Monoxide Detectors
Atthe time of installationof the sidewall horizontal vented
gas fueled equipment, the installing plumber or gasfitter
shallobservethat a hardwiredcarbon monoxide detector
with an alarm and battery back-up is installed on the floor
level where the gas equipment is to be installed. In addi-
tion,theinstalling plumber orgasfitter shall observethata
battery operated or hard wired carbon monoxide detector
with an alarm is installed on each additional level of the
dwelling,building or structureservedby the sidewall hori-
zontalvented gasfueled equipment.It shallbetherespon-
sibilityof theproperty ownerto securethe servicesof qual-
ifiedlicensed professionalsfortheinstallationof hardwired
carbonmonoxide detectors.
In the event that the side wall horizontally vented gas fu-
eledequipment is installedin a crawlspace or anattic, the
hard wired carbon monoxide detector with alarm and bat-
tery back-up may be installed on the next adjacent floor
level.
In the event that the requirements of this subdivision can
not be met at the time of completion of installation, the
ownershall haveaperiod ofthirty (30)days tocomplywith
theaboverequirements;provided,however,that duringsaid
thirty(30) dayperiod,a batteryoperated carbonmonoxide
detector with an alarm shall be installed.
Approved Carbon Monoxide Detectors
Eachcarbon monoxidedetector asrequired inaccordance
withthe above provisionsshall complywithNFPA720and
beANSI/UL2034 listed and IAS certified.
Signage
Ametalor plastic identificationplateshall be permanently
mountedto theexterior ofthe buildingat aminimum height
of eight (8) feet above grade directly in line with the ex-
haust vent terminal for the horizontally vented gas fueled
heating appliance or equipment. The sign shall read, in
print size no less than one-half (1/2) inch in size, “GAS
VENT DIRECTLY BELOW. KEEP CLEAR OF ALL OB-
STRUCTIONS”.
Inspection
Thestateor local gas inspectorof the side wallhorizontally
ventedgas fueledequipment shallnot approvethe installa-
tionunless,uponinspection,the inspectorobservescarbon
monoxidedetectorsandsignageinstalledinaccordancewith
theprovisionsof 248CMR5.08(2)(a)1 through4.
Exemptions
Thefollowingequipmentisexemptfrom248CMR5.08(2)(a)1
through4:
• Theequipment listed inChapter 10entitled “Equipment
Not Required To Be Vented” in the most current edition
of NFPA54 as adopted by the Board; and
• ProductApproved side wall horizontally vented gas fu-
eled equipment installed in a room or structure sepa-
ratefromthe dwelling,buildingorstructure usedinwhole
orinpart for residentialpurposes.
MANUFACTURERREQUIREMENTS
Gas Equipment Venting System Provided
Whenthe manufacturerofProductApprovedside wallhor-
izontallyventedgas equipment providesa venting system
designor venting systemcomponents with theequipment,
the instructions provided by the manufacturer for installa-
tionof the equipmentand theventing system shallinclude:
• Detailed instructions for the installation of the venting
system design or the venting system components; and
• A complete parts list for the venting system design or
ventingsystem.
Gas Equipment Venting System NOT Provided
When the manufacturer of a Product Approved side wall
horizontallyvented gasfueledequipment doesnot provide
the parts for venting the flue gases, but identifies “special
venting systems”, the following requirements shall be sat-
isfiedbythe manufacturer:
• Thereferenced“specialventingsystem”instructionsshall
beincluded withtheappliance orequipment installation
instructions;and
• The“specialventingsystems” shallbeProductApproved
by the Board, and the instructions for that system shall
includea parts listand detailed installationinstructions.
A copy of all installation instructions for all Product Ap-
provedside wallhorizontally vented gasfueled equipment,
all venting instructions, all parts lists for venting instruc-
tions, and/or all venting design instructions shall remain
with the appliance or equipment at the completion of the
installation.
See Gas Connection section for additional Common-
wealth of Massachusetts requirements.
NOTE: The following requirements reference various
Massachusettsandnationalcodesnot containedinthis
document.
Requirements for the Commonwealth of
Massachusetts
Î

11Quadra-fire • QV32B, QV36B • 2013-900 Rev. F • 9/06
2Getting Started
Introducing the Village Collection
Gas Fireplaces
The Village Collection direct vent gas fireplaces are de-
signed to operate with all combustion air siphoned from
outside of the building and all exhaust gases expelled to
the outside.
The information contained in this Installers Guide, unless
noted otherwise, applies to all models and gas control
systems. Gas fireplace diagrams, including the
dimensions, are shown in this section.
Pre-install Preparation
Thisgasfireplace and its componentsare tested and safe
when installed in accordance with this Installers Guide.
Report to your dealer any parts damaged in shipment,
particularly the condition of the glass. Do not install any
unit with damaged, incomplete, or substitute parts.
The vent system components and trim doors are shipped
in separate packages. The gas logs are packaged
separately and must be field installed.
Read all of the instructions before starting the
installation. Follow these instructions carefully during
the installation to ensure maximum safety and benefit.
Failure to follow these instructions will void the
owner’s warranty and may present a fire hazard.
TheQuadra-FireWarrantywill be voidedby, andHearth &
Home Technologies disclaims any responsibility for, the
followingactions
• Installation of any damaged fireplace or vent system
component.
• Modification of the fireplace or direct vent system.
• Installation other than as instructed by Hearth & Home
Technologies.
• Improper positioning of the gas logs or the glass door.
• Installationand/or useof anycomponent partnot manu-
facturedand approvedby Hearth& HomeTechnologies,
not withstanding any independent testing laboratory or
other party approval of such component part or acces-
sory.
ANY SUCH ACTION MAY POSSIBLY CAUSE A FIRE
HAZARD.
When planning a fireplace installation, it’s necessary to
determine:
•Where the unit is to be installed.
•Theventsystem configuration to beused.
•Gas supply piping.
•Electricalwiring.
•Framingand finishing details.
•Whether optional accessories—devices such as a fan,
wallswitch,or remote control—are desired.
If the fireplace is to be installed on carpeting or tile, or on
any combustible material other than wood flooring, the
fireplaceshouldbe installed ona metal or woodpanel that
extends the full width and depth of the fireplace.

12 Quadra-fire • QV32B, QV36B • 2013-900 Rev. F • 9/06
RATING PLATE/LABELS
GAS
ACCESS GAS
CONTROLS ELECTRICAL
ACCESS
TOP STANDOFFS
GAS
LINE
ACCESS 5 1/16
(129mm)
2 3/16
(55mm)
34 5/8
(879mm)
30 3/4
(781mm)
15 3/8
(391mm)
15 7/8
(403mm)
36 1/8
(917mm)
40 7/8
(1039mm)
3 9/16
(90mm)
ELECTRICAL
ACCESS
37 7/8
(961mm)
Ø 8
(203mm)
Ø 6 5/8
(168mm)
16 3/8
(416mm)
8 13/16
(224mm)
1/2
(13mm)
20 3/4
(526mm)
6 7/8
(174mm)
40
(1016mm)
Figure 2. Diagram of the QV32B
Î

13Quadra-fire • QV32B, QV36B • 2013-900 Rev. F • 9/06
Figure 2. Diagram of the QV32B
Î
RATING PLATE/LABELS
GAS
ACCESS GAS
CONTROLS ELECTRICAL
ACCESS
TOP STANDOFFS
25 3/4
(653mm)
12 7/8
(326mm)
15 7/8
(402mm) 8 13/16
(223mm)
16 3/8
(414mm)
31 1/8
(790mm)
2 3/16
(55mm)
5 1/16
(129mm)
GAS LINE
ACCESS
31
(790mm)
36
(913mm)
6 7/8
(174mm)
ELECTRICAL
ACCESS
32 9/16
(828mm)
Ø 8
(203mm)
Ø6
5/8 (168mm)
17 1/4
(438mm)
3 9/16
(90mm)
36 7/16
(925mm)

14 Quadra-fire • QV32B, QV36B • 2013-900 Rev. F • 9/06
3Installing the Fireplace
Step 1. Locating the Fireplace
Spaceand clearance requirementsfor locating a fireplace
within a room (see Figure 3).
Minimum Clearances
from the Fireplace to Combustible Materials
Inches mm
Glass Front......................................36........ 914
Floor .................................................0........... 0
Rear ............................................... 1/2 ........ 13
Sides .............................................. 1/2 ........ 13
Top (QV32B) .................................1 1/2....... 38
(QV36B)................................3 1/4 ....... 83
Ceiling* ............................................31........ 787
For minimum clearances, see the direct vent termination
clearance diagrams in Figures 29 and 30 in this manual.
Minimum Clearances
from the Vent Pipe to Combustible Materials
Inches mm
Vertical Sections. ............ 1 ................ 25
Horizontal Sections
Top .................................... 3 ................ 75
Bottom............................... 1 ................ 25
Sides ................................. 1 ................ 25
At Wall Firestops
Top ................................. 2 1/2 ............63.7
Bottom..............................1/2............... 13
Sides ................................. 1 ................ 25
* The clearance to the ceiling is measured from the top
of the unit, excluding the standoffs (see Figure 37).
The distance from the unit to combustible construction is
to be measured from the unit outer wrap surface to the
combustible construction, NOT from the screw heads that
secure the unit together.
ABC*D*E*
QV36B 42” 16 1/4” 31 7/8” 45” 63 3/4”
QV32B 37” 16 1/4” 29 3/8” 41 1/2” 58 3/4”
1/2 “ MIN. (13mm)
C
3” MIN. (76mm)
A
B
D
E
Clearance Requirements
The top and back of the fireplace are defined by stand-
offs. The minimum clearance to a perpendicular wall
extending past theface of the fireplace is3 inches (76mm).
The back of the fireplace may be recessed 16 1/4 inches
(413mm) into combustible construction.
Figure 3. Fireplace Dimensions, Locations,
and Space Requirements
Constructing the Fireplace Chase
A chase is a vertical box-like structure built to enclose the
gasfireplace and/or itsvent system. Verticalvents that run
on the outside of a building may be, but are not required to
be, installed inside a chase.
CAUTION: TREATMENTOF FIRESTOPSPACERSAND
CONSTRUCTIONOFTHE CHASEMAYVARYWITH THE
TYPEOF BUILDING. THESEINSTRUCTIONS ARE NOT
SUBSTITUTES FOR THE REQUIREMENTS OF LOCAL
BUILDINGCODES. THEREFORE,YOUR LOCALBUILD-
ING CODES MUST BE CHECKED TO DETERMINE THE
REQUIREMENTS FOR THESE STEPS.
Factory-built fireplace chases should be constructed in
the manner of all outside walls of the home to prevent cold
air drafting problems. The chase should not break the out-
side building envelope in any manner.
This means that the walls, ceiling, base plate and cantile-
ver floor of the chase should be insulated. Vapor and air
infiltration barriers should be installed in the chase as per
regional codes for the rest of the home. Additionally, we
recommend that the inside surfaces be sheetrocked and
taped for maximum air tightness.
To furtherprevent drafts,the firestopsshould becaulkedto
seal gaps. Gas line holes and other openings should be
caulked or stuffed with insulation. If the unit is being in-
stalled on a cement slab, we recommend that a layer of
plywood be placed underneath to prevent conducting cold
up into the room. Be sure to include spark arrestors for
woodburning units if they are required.
THE CHASE SHOULD BE CONSTRUCTED SO THAT
ALL CLEARANCES TO THE FIREPLACE ARE MAIN-
TAINED AS SPECIFIED WITHIN THIS INSTALLERS
GUIDE.
Note: *If venting with (2) 900elbows off rear of unit
the dimensions C, D and E will change.

15Quadra-fire • QV32B, QV36B • 2013-900 Rev. F • 9/06
Figure 5. Framing Dimensions
Step 2. Framing the Fireplace
Fireplace framing can be built before or after the fireplace
is set in place. Framing should be positioned to accommo-
date wall coverings and fireplace facing material. The dia-
gram below shows framing reference dimensions.
CAUTION: MEASURE FIREPLACE DIMENSIONS AND
VERIFY FRAMING METHODS AND WALL COVERING
DETAILS BEFORE FRAMING.
Framing should be constructed
of 2 X 4 lumber or heavier.
The framing headers may rest
on the fireplace stand-offs.
The center of the framing hole is one
(1) inch (25.4mm) above the center of
the horizontal vent pipe.
Model A B C D E
QV36B 42” 38 1/4”16 1/4” 41” 27 7/8”
QV32B 37” 33” 16 1/4” 36 1/2” 24 3/8”
WARNING:
To ensure proper clearances
the front framing header must
be installed on its narrow edge
and to the front of the frame.
A
B
C
WALL STUD
NON-COMBUSTIBLE ZON
E
IS DEFINED BY 3” ABOVE THE
ELBOW FOR THE ENTIRE
WIDTH AND DEPTH (BEHIND THE
FRONT HEADER) OF THE FIREBOX.
3 1/2”
3 ”
Î
VENT
FRAMING
HOLE
ED

16 Quadra-fire • QV32B, QV36B • 2013-900 Rev. F • 9/06
NOTE: PIPES OVERLAP 1-1/4 INCHES
(34.93mm)AT EACH JOINT.
Figure 6. DVP-Series Direct Vent Component Specifications (5-inch inner pipe / 8-inch outer pipe)
DVP90ST
12-9/16
11-1/4
7-1/4
1-1/4 TYP
1/2 TYP
8-9/16
DVP36
DVP48
48
24
36
4
6
DVP4
DVP6
12
DVP12
2
MIN.
DVP12A
12-3/16
MAX.
DVP24
9-7/8
45.0
O
10-1/4
DVP45
14-1/4

17Quadra-fire • QV32B, QV36B • 2013-900 Rev. F • 9/06
NOTE: PIPES OVERLAP 1-3/8 INCHES (34.93mm) AT EACH JOINT.
Figure 7. SL D-Series Direct Vent Component Specifications (4-inch inner pipe / 6 5/8-inch outer pipe)
120”
(3048mm)
24”
(610mm)
36”
(914mm)
60”
(1524mm)
9 1/4
6 5/8
6 1/2 6 3/8
6 1/2 9 5/8
9 5/8
6 5/8
6 3/8
8 3/4
SL-09D
12-17
SL-12/17D (SL12-17D) SL-24D SL-36D SL-48D
47 3/4
35 3/4
23 3/4
SL-45D
SL-90D
SL-17/24D
(SL17-24D)
17-24
SL-06D
SL-12D
5 3/4
6 5/8
6 1/2
11 3/4
SL-FLEX-2
SL-FLEX-10
SL-FLEX-5
SL-FLEX-3

18 Quadra-fire • QV32B, QV36B • 2013-900 Rev. F • 9/06
Step 3. Installing the Vent System
A. Vent System Approvals
These models have vent starting collars on both the top
and the back of the unit. Depending upon the installation,
decide which ONE set of starting collars will be used to
attachthe ventsystem. Thestarting collarsealing capmust
remainonthe starting collar NOTused.
These models use SL-D-series, direct vent components
when using the TOP vent collars. This pipe is tested and
listedas an approvedcomponent ofthe fireplace. Thepipe
is tested to be run inside an enclosed wall. There is no
requirementfor inspectionopenings ateachjoint withinthe
wall.Thereis no requiredpitchfor horizontal ventruns.
Thesemodels alsouseDVP-series directvent components
whenusing the REAR ventcollars.
The flame and ember appearance may vary based on the
typeof fuel burnedand the ventingconfiguration used.
Identifying Vent Components
Approvedvent system componentsare labeledfor identifi-
cation. NO OTHER VENTING SYSTEMS OR COMPO-
NENTS MAY BE USED. Detailed installation instructions
are included with each vent termination kit and should be
used in conjunction with this Installers Guide. Figure 8
shows vent system components and terminations.
The vent systems installed on this gas fireplace may in-
clude one, two, or three 90°elbow assemblies. The rela-
tionshipsof vertical riseto horizontal runinvent configura-
tions using 90° elbows MUST BE strictly adhered to. The
riseto run relationships areshown in theventing drawings
andtables.Referto thediagramsonthenextseveralpages.
NOTE: Two 45° elbows may be used in place of one
90° elbow. Maximum and minimum rise to run ratios
must always be maintained in the vent system when
using 45° elbows.
Figure 8. Vent System Components and Termination Kits
Vent System Termination Kits Vent System Components
* For use with flex vent only.
** For use on IPI units only.
HORIZONTAL
TERMINATION
WALL
FIRESTOP
90 DEGREE
ELBOW
VERTICAL
TERMINATION
STORM COLLAR
ROOF FLASHING
HORIZONTAL PIPE
SUPPORT
PIPE LENGTH
WALL BRACKET
CEILING
FIRESTOP
SLK-991DA
SLK-01TRD
SLK-01TRF
DVP-TVHW
SL D-SERIES
DVP-SERIES
SL-FLEX2-01TRF
(SL-Series)
(SL-Series)
DVP-TRAP
DVP-TB1
DVP-TV
PVK-80
SLK-SNKD
*
**
(Required
to have a
minimum of 3
feet of vertical
in the vent
system)
(There MUSTbe a25%
reduction in total H
when using the snorkel
cap except when using
the simple up and out
installation (see Fig. 9)
(For use with both DVP
and SL-D venting)
WARNING: YOU MUST NOT MIX DVP-SERIES
ANDSLD-SERIES COMPONENTS INANYVENT
SYSTEMCONFIGURATION.
!

19Quadra-fire • QV32B, QV36B • 2013-900 Rev. F • 9/06
STRAIGHT UP
VERTICAL VENTING
V (FT.)
45' MAX.
Figure 10.
Straight up Vertical Venting
Use SL D-Series
components only.
NOTE: For vertical venting
over 20 feet a restrictor plate
is recommended for
improved flame appearance.
Figure 9.
Flex Vent
The flex vent must be supported with the spacing between
support intervals not exceeding 4 feet, with no more than
½ inch sag between supports.
A support is required at each change in venting direction,
and in any location where it is necessary to maintain the
necessary clearance to combustibles. A simple “up and
out” installation (Figure 9) requires only enough support to
maintain the necessary clearance to combustibles. How-
ever, the vent attachment point and the firestop location
are considered to be supports.
3” CLEARANCE TERMINATION
CAP
FLEX-VENT
1”
CLEARANCE
V
CAP
STRAIGHTOUT HORIZONTALVENTING
H
Max. Run
36" (914 mm)
Use DVP-Series
components only.
Figure 11. Straight Out Horizontal Venting
Note: You may use a
45oelbowin corner
installationsfor these
models,.
45-DEGREE
ELBOW
H
90-DEGREE
ELBOWS
.
The use of two 900
elbows in a corner
installation will affect
space requirements
(see Fig. 4)

20 Quadra-fire • QV32B, QV36B • 2013-900 Rev. F • 9/06
Figure 13. Venting with One 90° Elbow
Use SL D-Series
components only.
MODEL QV32B
V (MIN.) H (MAX.)
90oElbow on Top 2.5 FT (863mm)
1 FT (305mm) 3 FT (914mm)
2 FT (610mm) 4 FT (1.22m)
3 FT (914mm) 6 FT (1.86m)
4 FT (1.22m) 8 FT (2.48m)
5 FT (1.52m) 16 FT (4.8m)
VENTING WITH ONE (1) 90oELBOW NATURAL GAS
H MAX. = 16 FT (4.8m) V + H MAX. = 40 FT (12.2m)
MODEL QV36B
2.5 FT (863mm)
3 FT (914mm)
4 FT (1.22m)
6 FT (1.86m)
8 FT (2.48m)
16 FT (4.8m)
MODEL QV32B
V (MIN.) H (MAX.)
90oElbow on Top 2.5 FT (863mm)
1 FT (305mm) 2.5 FT (863mm)
2 FT (610mm) 4 FT (1.22m)
3 FT (914mm) 6 FT (1.86m)
4 FT (1.22m) 8 FT (2.48m)
5 FT (1.52m) 16 FT (4.8m)
VENTING WITH ONE (1) 90oELBOW PROPANE
H MAX. = 16 FT (4.8m) V + H MAX. = 40 FT (12.2m)
MODEL QV36B
H (MAX.)
NOTALLOWED
2 FT (610mm)
4 FT (1.22m)
6 FT (1.86m)
8 FT (2.48m)
16 FT (4.8m)
H
V
NOTE: There MUST be a 25% reduc-
tion in total H when using flex vent
except when using the simple up and
out installation (see Figure 9).
V H
1' MIN. (305mm) 2' MAX. (610mm)
2' MIN. (610mm) 4' MAX. (1.22m)
3' MIN. (914mm) 6' MAX. (1.86m)
4' MIN. (1.22m) 8' MAX. (2.4m)
V+H=40' MAX. (12.4m)
H = 8' MAX. (2.4m)
Figure 12. Venting with One 90° Elbow
Use DVP-Series
components only.
V
H
