Violet 3D ECHO-WS-01 User manual

User Manual
Model Number: ECHO-WS-01

www.violet3d.com

Dear Customer,
Hearty congratulations on possessing a revolutionary 3D surround sound system which is
completely wireless and extremely convenient to install and use.
This system is such that you can place the speakers wherever convenient and unlike conventional
systems, there are no pre-xed viewing/listening positions. The system can create theater like
sound right in your home for you to enjoy music and movies along with your family and friends.
We sincerely hope, you will continue to enjoy the performance of this system for years to come.
Should you need any clarication please do not hesitate to write to us. If you are satised with it,
please do tell all your friends about it. We shall be happy to arrange demonstrations for them at
their homes.
Kind regards,
Bhatia L. H.
Chairman
SNAP Networks Pvt. Ltd

Contents
1
1 UnderstandingYour Product 3
1.1 Wireless Speakers 3
1.2 Speaker Stand 3
1.3 Wireless Sound Transmitter 4
1.4 Microphone 5
1.5 Wireless Remote Control 6
1.6 Wireless Subwoofer System 7
2 Unpacking & Assembly 8
2.1 Echo WS-01 Unpacking 8
2.2 Speaker Assembly 9
2.3 WSub-01 Unpacking 10
2.4 Power On Subwoofer 11
2.5 Power On Speakers 11
2.6 Speaker Placement 12
2.7 Microphone Assembly 13
3 Installation 14
3.1 Connect Microphone to Transmitter 14
3.2 Microphone Placement for System Characterization 15
3.3 Power On Transmitter 16
3.4 System Learning 16

Contents
4 Connectors 18
4.1 Front Side Connector 18
4.2 Back Side Connector 19
5 Listen & Enjoy 20
6 LED Status Indicator 21
7 Connectors Description 21
7.1 Connectors - Front Side 21
7.2 Connectors - Back Side 22
8 Remote Control 23
9 Tr o ubleshooting 24
9.1 During Normal Usage 24
9.2 During Learning 24
10 Caution 25
11 Warranty 26
12 Contact 27
2

1. UnderstandingYour Product
1.1 Wireless Speakers (henceforth called as a Speaker)
1.2 Speaker Stand
E26 Light Blub Connector. 230V AC Input
E26 Light Bulb Holder
230V AC Input
3
LED On indicating Power is ON

1.3. Wireless SoundTransmitter (henceforth called as Transmitter)
Front Side
Back Side
Mic Ana Sub Out Aux 1 Dig 2 Dig 1 Power
4
6C
A1 A2 D1 D2
aux 2
Mic Ana
Aux 1
Power
5VDC, 1.5A
Dig
SUB
OUT
FL SL C
L1
R 2
FR SR SUB
Power Mute Source Status
3.5mm
Stereo
Jack

5
1.4 Microphone

Power
Volume +
Volume -
Source -
Bass +
Bass -
Mute
Unmute
Mid +
Treble +
Treble -
Mid -
Learn
Source +
1.5 Wireless Remote Control (henceforth called as Remote Control)
-
-
Learn
Bass
Volume
Source Source
+
+
++ +
Volume
-
- - -
-
Treble
Treble
Bass Mid
Mid
6

230 V
1.6 Wireless Subwoofer System
Connect Switch
ON
OFF
LED On indicating
Power is ON
Connect
Note: Check LED is "ON" when connected to Power source
7

2.Unpacking & Assembly
2.1 Echo WS-01 Unpacking Mic wing bracket (1)
+ coupler (1)
Mic Rods (2)
Mic Wings (3)
with Cable
Speakers (5)
Transmiter (1)
Speaker Stand (5)
Mic Base (1)
Adapter (1)
Batteries (2)
Remote (1)
8

2.2 Speaker Assembly
Screw Speaker into Speaker Stand
Speaker
CAUTION!
Do not over-tighten the Speaker into Speaker Stand,
doing this may damage the plug and sockets
Speaker Stand
9

2.3 WSub-01 Unpacking
Subwoofer
10

2.4 Power On Subwoofer
LED On indicating Power is ON
2.5 Power On Speakers
11
230 V
Connect Switch
ON
OFF
LED On indicating
Power is ON
Connect
Note: Check LED is "ON" when connected to Power source

2.6 Speaker Placement
12

2. 7 Microphone Assembly
Step-1 : Wings with cable
Step-2 : Bracket
Step-3 : Pipe+ Coupler
Step-4 : Base
1. Insert Wing 1, 2 and 3 into the Bracket in the
sequence as shown in the gure
2. Insert the Cable through the Bracket, Pipe,
Coupler and Base
3. Tighten/Fix the Pipes to the Bracket,
Coupler and Base
1
2
3
Green
Wing
Bracket
Pipe
Pipe
Base
Coupler
Red
Yellow
Cable
13

1
3.Installation
3.1 Connect Microphone to Transmitter
Connect Microphone
to Transmitter
14
Aux 1
2
3

1
2
3
15
4 ft
3.2 Microphone Placement for system characterization
a) Place microphone close to listening position
b) Wing 1 (Red) should point to the front (to TV) of the room
c) Height should be around 4 ft.Place both rods with base on the oor or one rod with base
on the sofa/couch or a table.
d) All 5 speakers should be in line of sight of the microphone.

3.4 System Learning
a. Make sure steps 3.1 to 3.3 are completed
b. Make sure all 5 speakers and subwoofer are powered ON
c. Make sure there are no loud noises in the room
d. Switch o any fans or air conditioners
e. Be prepared for loud tones that will come out of the speakers
Press and hold
Learn Button
3.3 Power On Transmitter
Mic Ana
Aux 1
Power
5VDC, 1.5A
Dig
SUB
OUT
FL SL C
L1
R 2
FR SR SUB
Power Connector
16
-
-
Learn
Bass
Volume
Source Source
+
+
++ +
Volume
-
- - -
-
Treble
Treble
Bass Mid
Mid

3.4.1 Press and hold the learn button on the remote control.
The status LED will start to blink Orange.
a. Step aside such that you are NOT in between any speaker and the microphone.
b. Make sure you can see the front of the transmitter.
c. Keep quiet until the Orange Status LED stops blinking (2 minutes).
3.4.2 You will hear set of rapid tones from all speakers. Make sure you hear all ve speakers and
the subwoofer sound.
3.4.3 Observe the transmitter front panel for any error
a. ERROR CASE: Blinking of Red Status LED and ‘D1’ for 10 sec. This indicates that the
noise in the room is too loud for learning. Reduce room noise and start again.
b. ERROR CASE: Blinking of Red Status LED and ‘D2’ for 10 sec. This indicates that the
MIC has been damaged.
c. ERROR CASE: Blinking of all source LED’s and Red Status LED for 10 sec. This indicates that the
MIC is not connected.
Power Mute Source Status 3.5mm
Stereo
Jack
17
