Vizualogic Phoenix 7 User manual

ank you
Owners Manual

Table of Contents
Table of Contents
Introduction
Getting Started
How To Navigate The Home Screen
How To Play A DVD Movie
How To Setup SmartDVD
How To Use Your Wireless Headphones
How To Use The Source Tab
How To Use The FM Transmitter
Connecting To Wi-Fi
How To Turn On Bluetooth
How To Navigate Home Screen when Undocked
1.
2-3.
4-5.
6-8.
9-11.
12-14.
15.
16.
17.
18-19.
20.
21.
Pg 1

Introduction
Thank you for choosing Vizualogic. We recommend that you take the time to get to know your New
Rear Seat Infotainment System by reading this manual. The more that you know about it, the easier
it is to operate.
Vizualogic Tablet
Camera HDMI USB Power
SD Card Dock Connector Ext Speaker
Camera
- Volume +
Camera: Take pictures or video Skype.
HDMI: Plug in a Micro HDMI cable to view Tablet image on TV.
USB: Plug a Micro USB cable to charge the Tablet or to connect to a PC.
Power: Power ON/OFF the Tablet or put into sleep/wake up.
Camera: Take pictures.
SD Card: Plug in a Micro SD for more storage.
Note: Cant exceed 32 GB
Dock connector: Plugs into Headrest dock.
Ext Speaker: Audio from the Tablet when not docked.
Pg 2

Introduction Cont.
USB Lock Headphone
Jack
Vizualogic Headrest
USB
Lock
Headphone Jack
Plug in any standard Type A USB peripheral,
not to exceed 2.0 Amps.
When Tablet is docked, slide lock switch to the
right to un-lock Tablet to remove.
Plug any 3.5 Headphones for Audio Playback.
DVD Slot
Eject Button
Insert DVD with Label facing the back of the
vehicle.
Press to eject the DVD.
Note: Tablet must be powered on and docked
for eject button to work.
DVD Slot
Eject Button
Pg 3

Getting Started
Vizualogic Headrest
In this section we will explain how to Dock and Undock the Tablet into the Headrest.
1. Start with opening the Dock tray. With 2 hands grab hold of the pull tabs and pull the tray for-
ward. (Fig 1)
2. Slide the Tablet into the tray making sure the Tablet dock connector is on the bottom.
3. Push the Tablet down until you hear the lock engage. (Fig 2)
Pull Tabs
Fig 1 Fig 2
Tablet
Tray
Dock
Connector
Pg 4

Getting Started Cont.
4. To remove the Tablet slide the Lock lever to the right, you should hear a small click. (Fig 1)
5. Pull on the 2 pull tabs to pull the tray forward. (Fig 1&2)
6. Place the palm of your hand in front of the Tablet camera, then grab the back side. (Fig 2)
7. Pull straight up to release the Tablet.
Lock Lever
((Click!!!))
Fig 1 Fig 2
Pg 5

How To Navigate The Home Screen
Your Vizualogic Tablet supports standard Android navigation.
This section will teach you how to control the Tablet when docked in the vehicle.
Note: When undocked Tablet reverts to standard Android screen.
1. Navigation bar: These icons provide common navigation functions, such as return to the
previous screen, open the main Home screen, and view recently opened apps.
2. Notication bar: Notication icons show what channel your IR headphones need to be on,
if the DVD is connected, or if there are any devices connected to the USB.
3. System bar: System icons show the Wi-Fi signal strength, battery level, Bluetooth connectivity,
the Time and other statuses.
Notication bar
Navigation bar
System bar
Speaker -: Turns volume down
Back: Return to previous screen
Home: Return to the main Home screen
Recent Apps: View apps that are currently
open, in order of recent use
Speaker +: Turns volume up
Source: View the Other Tablets source
Pg 6

How To Navigate The Home Screen Cont.
In this section we will explain how to move new downloaded games into the Games folder.
1. Touch the Apps icon on the Home screen. (Fig 1)
You should now see all the apps that are available in the Tablet.
2. Find the app you wish to move. (We will be using BB Racing for this example)
3. Touch and hold the BB Racing icon. (Fig 2)
Continued on next page
Home Screen All Apps
Fig 1 Fig 2
Pg 7

How To Navigate The Home Screen Cont.
Home Screen Games Page
4. While your nger is holding down the icon your Home screen will now appear. (Fig 1)
5. Move your nger over the Games icon, then release your nger. (Fig 2)
The BB Racing app is now located in your Games folder.
Note: You can put as many games in the folder until it lls the screen
6. Stream Movies, Media and Stream Music are also folders. To add more apps follow the same steps
as 2-5.
Fig 1 Fig 2
Pg 8

How To Play A DVD Movie
Each Headrest is equipped with a DVD player. In this section we will show you how to operate the
DVD player.
1. Insert the DVD into the DVD slot located behind the Tablet. See page 3 DVD slot.
2. Once the DVD is inserted open the SmartDVD app located on the main Home screen. (Fig 1)
3. When you see the Ready symbol you are now ready to begin playback of the DVD.
4. Press the Play icon to start playback. (Fig 2)
Continued on next page
Home Screen
Fig 1 Fig 2
Pg 9

How To Play A DVD Movie Cont.
5. Your DVD will begin with the DVD warning info, to skip this press the Exit DVD Menu located on
the top right upper corner. (Fig 1)
6. The DVD should now show the DVD Menu. (Fig 2)
7. Press the Play icon on the DVD Menu.
Continued on next page
Fig 1 Fig 2
Pg 10

How To Play A DVD Movie Cont.
8. While the DVD is playing you can control the following functions using the touch screen.
a. Slide bar: Touch anywhere on the bar to advance the movie.
Note: This function may not work on all DVD’s
b. Forward Arrow: This allows you to track to the next DVD track.
c. Backward Arrow: This allows you to track back to the previous DVD track.
d. Pause: This allows you to pause the DVD.
f. Stop: This allows you to stop the DVD.
Note: After DVD is stopped you can eject the DVD. (This can also be done with the eject button)
Eject Button
Tablet removed to show eject
button location
Eject button will not function
without Tablet
a. Slide bar
Backward Arrow Pause Stop Forward Arrow
Pg 11

How To Setup SmartDVD
SmartDVD has a built in Preferences menu. To access this menu simply press the small 3 square dots
located in the upper right corner. (Fig 1)
Note: Preference menu can only be activated when the DVD is stopped.
Follow the following steps to adjust your SmartDVD as wanted.
1. AutoPlay: Automatically plays the DVD after the set period of time.
a. To turn AutoPlay on touch the On icon. When it turns Blue it is ON.
Note: AutoPlay will not work until SmartDVD is restarted.
2. AutoPlay after Manual Stop: Runs the AutoPlay timer even if playback was manually stopped.
a. To turn AutoPlay after Manual Stop on touch the On icon. When it turns Blue it is ON.
Fig 1
Preference Menu
Pg 12

5. Loudness Boost: Increases the audio of SmartDVD.
a. Touch the (Loudness Boost) to open the Loudness Boost menu.
b. Default is set to 0db. You can choose from 0 to +5db.
How To Setup SmartDVD Cont.
Pg 13

3. Time until AutoPlay: The amount of time until playback will start.
a. Touch the (Time until AutoPlay) icon, the menu will appear for the times you can set.
Note: Default is set for 20s.
4. Resume Playback: Resume playback where DVD was stopped.
a. To turn Resume Playback on touch the On icon. When it turns Blue it is ON.
Note: Default is set to On.
How To Setup SmartDVD Cont.
Pg 14

How To Use Your Wireless Headphones
POWER
OFF A B
Each Headrest comes with a Wireless Headphone.
In this section we will explain how to turn on the headphones and adjust the listening
volume.
1. When your vehicle receives power the Tablets will display what channel the wire-
less headphones need to be set on.
a. Locate the A/B OFF switch on the Wireless Headphones.
b. If the Tablet is displaying channel A, then slide the switch to A.
c. If the Tablet is displaying channel B, then slide the switch to B.
2. To adjust the volume of the Wireless Headphones, simply move the volume wheel
clock wise to raise the volume and counter clock wise to lower the volume.
POWER
OFF
A
B
A/B OFF Switch
Power Light
Volume Wheel
Pg 15

How To Use The Source Tab
Each Tablet has the ability to see the other Tablets image.
In this section we will explain how to use the Source Tab.
1. Each Tablet has the ability to view its own source. See Fig 1.
2. Each Tablet also has the ability to view the opposite Tablets source as well.
3. When there is a image being viewed on the Driver side headrest, the Passenger can view the Drivers headrest by pressing the Source
Tab located on the bottom right of the tablets screen.
4. When there is a image being viewed on the Passenger side headrest, the Driver can view the Passengers headrest by pressing the
Source Tap located on the bottom right of the tablets screen.
Note: Only one Tablet Source Tab can be used at one time.
Note: When viewing the Source of the other Tablet you have no control of the other Tablets functions.
Driver Side Tablet Passenger Side Tablet
Fig 1
Pg 16

How To Use The FM Transmitter
Each Tablet has the ability to use the FM Transmitter.
In this section we will describe how to turn on the FM Transmitter and how to adjust it.
1. To access the FM Transmitter you need to open the Apps menu from the Home screen. Fig 1.
2. Find the FM Transmitter Icon on the apps screen. Fig 2.
3. Touch the FM Transmitter Icon.
4. To power on the FM Transmitter simply press the Power icon. Fig 3.
5. To adjust the preferred frequency touch the Left or Right arrows. Fig 4.
6. Once the desired frequency has been picked you can lock it in by touch and holding 1 of the 6 preset icons. Fig 5.
7. Now adjust the vehicles radio to the same FM frequency.
Note: Only 1 Tablet can use the FM transmitter at a time.
Fig 1
Fig 3
Fig 4
Fig 4
Fig 5
Fig 2
Pg 17

Connecting To Wi-Fi
Your Tablet scans automatically for available Wi-Fi networks and connects to known networks when you are within range.
The Android operating system provides several options for connecting to Wi-Fi. This section describes the most common options.
How To Connect to Wi-Fi
1. Go to Settings icon located on the Home Screen. Fig 1.
2. Under Wireless & Networks in the settings menu you will nd the Wi-Fi, touch the Wi-Fi icon. Fig 2
3. If Wi-Fi is set to OFF touch the ON/OFF icon to turn it ON.
Fig 1
Fig 2
Pg 18

How To Connect to Wi-Fi Cont.
4. Touch Wi-Fi, The Wi-Fi control panel shows the wireless networks that are in range and indicates their signal strength.
The control panel also shows any wireless network that your Tablet has connected to in the past. If you are already connected to
Wi-Fi, the name and signal strength of the current Wi-Fi network is displayed.
5. In the Wi-Fi control panel, select the network you want to connect to.
6. If prompted, enter the password and touch Connect.
Connecting To Wi-Fi Cont.
Home 1
Home 2 Home 1
Pg 19
