VorOtek V SCOPE User manual

23 Point Henry Road
MOOLAP VIC 3224, Australia
T [phone]
E [e-mail]
www.VorOtek.com Technical Manual
Technical Manual
SCOPE
SCOPE
Working distance
•Not close enough or too close –see section on
‘Working with Corrective Lenses’.
Optical Alignment is out
•See section on ‘Set Up’.
Light is to High/Low
•See section on ‘Set Up’.
Focusing
•Difficulty focusing i.e. Seeing two images. See section
on ‘Set Up’.
•Tip: Focus on an object (such as thumb nail) at arm’s
length and slowly bring the object closer to your eyes.
Switch between each eye, one at a time.
For all other questions contact VorOtek
Cleaning
•Unplug the VorOtek Scope or Light from power source
prior to cleaning.
•Visually inspect the VorOtek Scope or Light for soiling.
•Remove all visible soiling by first wiping external
surfaces & cables with a soft cloth slightly dampened
with mild detergent and water (mixed to the
manufacturer’s instructions).
•Wipe all external surfaces*, including Headband
model leather covers & velcro straps using a soft cloth
slightly dampened with 70% isopropyl Alcohol (IPA).
*SpecFrame model cables should be wiped with a
hospital approved disinfectant wipe.
•Allow all surfaces to air dry for at least 60 seconds.
•Re-wipe all surfaces with a lint free soft cloth to
remove any residue from cleaning products.
•Ensure all surfaces & cables are dry before operating
the VorOtek Scope or Light.
•Caution: Do not immerse or saturate any component
of the VorOtek Scope or Light in a cleaning solution.
•Caution: Do not autoclave any component of the
VorOtek Scope or Light.
Maintenance
•Before every procedure, carefully inspect the
VorOtek Scope or Light to ensure it is fully functional.
DO NOT use if inspection reveals any damage.
•The VorOtek Scope & Light Range does not require
any other routine maintenance.
•For repair or warranty, refer to the support & repair
page on VorOtek’s website.
Warranty
•Scopes & Lights -3 years for any component defect
or manufacturing failure.
•Power Pack -18 months for any component defect or
manufacturing failure.
•Warranty does not cover abuse, misuse or transit
damage.
•Please contact VorOtek prior to sending for repair.
Notices &Precautions
•Should aserious incident occur while using the device
please report the incident to the manufacturer
(VorOtek)and the competent authority of the
Member State in which the user and /or patient is
established.
•Only to be used by qualified health professionals.
•Do not use in the presence of flammable
anaesthetics.
•Do not expose electrical equipment to liquids or
excessive moisture.
IFU-002-V Scope TechMan-R4

Technical Manual
SCOPE
LED Illumination
•High efficiency LED (Light Emitting Diodes) are rated at
50,000 hours operating life.
•5,700 Degrees Kelvin Colour Temperature (Daylight).
•Colour Rendering Index: CRI 75.
•Caution: Hot surface. Avoid direct skin contact with
aluminium heat sink during extended periods of use.
•Caution: Do not look directly into the LED Light.
Power Pack
•Power Packs are Lithium Ion: 11.1 Volts, 2,900 mAh.
•The Power Pack delivers 7hrs to >20hrs “on time”
depending on illumination level.
•The Power Pack features short circuit protection and
charging control circuitry.
•Two position switch -ON/OFF.
•Designed to be worn in the breast pocket or to be
clipped to a belt. It can also be clipped to the back of a
surgical gown.
•Caution: Do not expose the Power Pack to heat, fire or
mechanical shock
•Caution: Do not open or dismantle the Power Pack.
•Caution: Only use approved Power Packs supplied by
VorOtek.
Charger -Charging Power Pack
Connect Power Pack to Charger.
•The Power Pack can be charged in either the ON or OFF
position.
•RED INDICATORS –Charging (takes up to 5 hours).
•GREEN INDICATORS –100% Charged.
•Charging is best done overnight, frequently and before
the Power Pack runs flat.
•Caution: Use the supplied 12.6V Charger only.
•Caution: Do not attempt to operate the c
•Charger if the cord and/or plug appear to be damaged.
•Caution: Do not use Charger in patient vicinity.
Set Up
Converged Binocular Optics Alignment
Converged binocular optics with 2 dioptre magnification.
Without this, binocular vision in narrow cavities (e.g. ears
and noses) is not possible.
The best guide to precise set up is to look into a mirror
(with light switched off!) and look back through the
converged binocular optics at the position of your eyes.
You should be able to see both of your pupils clearly.
(Refer Figure 1)
Interpupillary Distance (IPD)
The IPD can be adjusted by sliding the tabs located at
each end of the converged binocular optics. Slide the
tabs to move the mirrors to match your eye width (IPD).
(Refer illustration above)
Tilt Adjustment –SpecFrame Model
If the converged binocular optics are tilted, adjust the
nose pads & temple tips/arms on SpecFrame until level.
Tilt Adjustment –HeadBand Model
If the converged binocular optics are tilted, adjust the
HeadBand position until level.
Height Adjustment -SpecFrame Model
The height of the converged binocular / illumination
system is adjusted by moving the system up or down on
the SpecFrame bracket:
•Loosen the screw that connects the illumination
system to the SpecFrame bracket by 1 turn and adjust
the height.
•Do not leave screw loose, always re-tighten.
Height Adjustment -HeadBand Model
The height of the converged binocular / illumination
system is adjusted by moving the HeadBand up or down
on the forehead.
Illumination Adjustment
If the light spot seems too high, the height adjustment
will be too low. (i.e. the user is looking down through the
converged binocular optics and below the light spot) The
converged binocular optics will need to be positioned
higher to correct.
If the light seems too low the reverse will apply. See
‘Height Adjustment’.
HeadBand Bracket Adjustment
The HeadBand mounting bracket has 2 adjustable links
allowing separate adjustment of viewing angle and
forward positioning of the converged binocular /
illumination system:
•The converged binocular optics must be positioned as
close to the eyes as possible i.e. almost touching the
nose or spectacles.
•For ENT use, the viewing direction should be almost
horizontal.
•If the converged binocular optics are not in use (rotated
up) then the illumination can be angled further
downwards.
SpecFrame Toggle
The toggle on the cable lead should be used for all lengthy
procedures, e.g. Operating to:
•Prevent SpecFrame sliding down the nose when head is
tilted down.
•Take pressure off the nose.
Working with Corrective Lenses
Corrective Lenses can be fitted to the SpecFrame of the V
Scope by an Optometrist.
•There is no need to unscrew the illumination system or
dismantle the V Scope in any way, other than the frame
screws for the lenses.
Reading Lenses (used for close work)
•Should be fitted to the SpecFrame Model.
•The HeadBand model should be used over the
individuals own corrective spectacles.
•When reading lenses are installed and used, the working
distance becomes closer.
•If the working distance is not close enough then an extra
0.5 or 1.0 dioptres in the corrective lens should be tried.
•The opposite may be encountered –especially for users
with intrinsic short sight
Bifocal Lenses
•Can be fitted effectively, so long as the converged
binocular optics sits in front of the reading section and
below the distance section.
•To achieve this, the reading section must be larger (i.e.
lower two thirds) and the distance section must be
smaller (i.e. upper one third only).
•The height of the nose bridge may need to be adjusted
to sit the SpecFrame higher on the face. This extra frame
height allows lower positioning of the converged
binoculars so that they are in front of the reading
section.
•Alternative nose bridges are available from most
optometrists.
Multifocal Lenses
•Are best avoided because it is difficult to achieve sharp
focus.
Dimmable Illumination
The dimmer switch is located on the cable near the Power
Pack Plug (Refer figure 2)
The dimmer function provides 8 levels of illumination
with “H” being the highest .
Dimming: Press the “+” or “-” button on the dimmer
switch to select the preferred level of illumination.
ON/OFF function: Click & hold either button on the
dimmer switch for 2 seconds to turn illumination “on” or
“off” at the selected level.
Troubleshooting
LED illumination cuts out and resets
repeatedly
•The LED illumination does not fade, but the protective
circuit breaker keeps switching off (and resetting) when
the Power Pack requires recharging. See section on
‘Charger’.
•LED’s rarely need replacing, but if this is necessary it
must be done by VorOtek.
Power Pack will not charge
•See section on ‘Charger’.
SpecFrame damage
•Most problems can be dealt with by an optometrist e.g.
missing screws, lenses, new nose pads and bent frames.
•For SpecFrame replacement contact VorOtek.
Correct Alignment
IPD –slide tabs in
IPD –Slide tabs out
Tilt
Height –too high
Height –too low
Figure 1
Figure 2. Dimmer Switch
LCD Display
Increase Illumination
Decrease Illumination
