Celestron Skymaster Pro User manual

BINOCULARS | JUMELLE | BINOCULARES | FERNGLAS | BINOCOLI

ENGLISH ..................................2
FRANÇAIS................................15
ESPAÑOL .................................28
DEUTSCH.................................41
ITALIANO ..................................54

ENGLISH
BINOCULARS

2 IENGLISH
Red Dot
Finder Rail
Objective
Lens Caps
Rainguard
Standard Eyecup Standard
Eyecup
Thank you for purchasing your Celestron SkyMaster Pro binocular. We trust that this binocular will
provide you with years of enjoyment and faithful service. Please read the instructions carefully before
using your binocular to ensure proper use and care.
CELESTRON®SKYMASTER PRO BINOCULARS
Logo Plate / Tripod Adapter Threads
Winged
Eyecup
Tripod
Adapter
(15x70)
Objective Lens
Eyepiece
Diopter
Adjustment Ring
Diopter
Adjustment Ring
Focus Wheel
Focus Wheel
Center Support Rod
(20x80)
Tripod Adapter –
Built In (20x80)
Fig 1
Eyepiece
Objective Lens

ENGLISH I3
The interpupillary distance, or the distance
between the pupils, varies from person to
person. The binocular must be correctly
aligned (adjusted) to the distance between
your pupils to achieve a single, clear image.
To adjust this distance, lift the binocular up to
your eyes (using both hands) and look through
them at an object in the distance. Move the
two barrels (halves) of the binocular closer
together or further apart until you see a single,
clear image. Check that the interpupillary
distance is set correctly every time you use
your binocular.
ADJUSTING THE INTERPUPILLARY DISTANCE
WARNING: Never look at the sun while using your binocular.
Looking at the sun can cause permanent eye damage.
Fig 2

4 IENGLISH
SETTING THE DIOPTER / FOCUSING
To ensure a crisp, sharp image the focusing
system of the binocular must be set to
compensate for any differences in your eyesight.
This is achieved by setting the diopter (located
on the right eyepiece) before use. To set the
binocular to your eyesight follow the instructions
below.
To focus the binocular:
1. View an object in the distance through the
binocular.
2. Cover the right objective lens with your hand
or the objective lens cap.
3. Rotate the focus wheel until the image viewed
with your left eye is clear and sharp.
4. Cover the left objective lens with your hand or
objective lens cap.
5. Viewing the same object, rotate the right
eyepiece (the diopter) until the image viewed
with your right eye is clear and sharp.
6. Your binocular is now adjusted to your eyes
and focusing on any object can now be achieved
by simply turning the focus wheel.
TIP: Eyeglasses worn for nearsightedness should be worn when
using binoculars as you may not be able to obtain focus at
infinity without them.
Diopter
Adjustment Ring
Fig 3
Focus Wheel

ENGLISH I5
The SkyMaster Pro features interchangeable
eyecups to accommodate a variety of viewing
situations. Included with the SkyMaster Pro are
a set of standard eyecups and a set of winged
eyecups. The standard eyecups are ideal for
general observation and most viewing situations
while the winged eyecups are recommended for
viewing situations when the amount of stray light
entering the eyepieces needs to be reduced for
optimal viewing. The winged eyecups may need
to be used are during astronomical viewing. To
change the eyecup grasp it with the thumb and
forefinger near the base of the eyepiece housing
and simply pull it away from the eyepiece
housing. Once removed the other eyecup can
be attached.
CHANGING THE EYECUPS
Fig 5
Fig 4

6 IENGLISH
STANDARD EYECUP ADJUSTMENT
RED DOT FINDER RAIL
The standard eyecups of the SkyMaster Pro
feature foldable rubber to accommodate both
eyeglass and non-eyeglass wearers. If you do
not wear eyeglasses, leave the rubber eyecups
in the up position. If you wear eyeglasses,
make sure that the eyecups are folded down to
obtain the maximum field of view. When done
observing, make sure the rubber eyecups are in
the up position for storage.
The SkyMaster Pro includes a red dot finder rail
that allows a red dot finder to be attached to the
binocular. Attaching a red dot finder allows you
to easily find objects and then view them through
the binocular. The rail is not required to use the
binocular and can be attached at any time. On the
15x70 it easily clips onto the top of the included
tripod adapter and on the 20x80 it easily clips onto
Fig 6
Fig 7
15x70

ENGLISH I7
Fig 8
20x80
the center rod. Once the finder rail is attached, flip
the locking lever to lock it in place and slide an
aftermarket red dot finder onto the top of the rail.
Celestron offers red dot finders that are compatible
with the finder rail that can be found on our website.
Before using the red dot it will have to be aligned
with the binocular to ensure accurate aiming.
Follow the instructions included with the red dot
finder for alignment information.
Fig 9

8 IENGLISH
SkyMaster Pro 15x70
The SkyMaster Pro 15x70 features built-in
threads that allow the binocular to be attached to
a tripod using the included tripod adapter. These
threads can be accessed by unscrewing the logo
plate found on the front of the hinge. To attach
the binocular to a tripod, thread the adapter into
the binocular and attach the other end of the
adapter to a photographic tripod. Mounting the
binocular on a tripod allows for added stability
and comfort during prolonged viewing.
TRIPOD ADAPTABILITY
Fig 10
Fig 11

ENGLISH I9
SkyMaster Pro 20x80
The SkyMaster Pro 20x80 features a built in
tripod adapter that allows the binocular to be
attached to a tripod without the need of any
additional accessories. The tripod adapter
is attached to the center support rod of the
binocular and slides along the rod so that
the perfect balance point can be found when
attached to a tripod. To attach the binocular
to a tripod, thread the mounting screw of the
tripod (or quick release plate) into the bottom
of the tripod adapter. Loosen the lock lever
on the top of the built in tripod adapter and
slide the binocular back and forth along the
center rod until the perfect balance point is
found. Mounting the binocular on a tripod
allows for added stability and comfort during
prolonged viewing.
Fig 12

10 IENGLISH
WATERPROOF / FOGPROOF
The SkyMaster Pro binoculars are waterproof and filled with dry nitrogen gas to prevent the housing
from fogging internally.
CARE AND STORAGE
1. Protect the binocular from impact and do
not force any of the moving parts beyond
their limits.
2. Protect the optics of your binocular by
putting on all lens caps when not in use.
3.
Store your binocular in a cool, dry place
whenever possible.
4. When storing for an extended period of time,
place the binocular in a plastic bag or airtight
container with a desiccant.
5. Do not leave the binocular in a car on a
hot/sunny day or near anything that
generates heat as this may cause damage.
6. Clean any dust, dirt or water that may get
on the binocular or inside moving parts
as soon as possible to prevent any
unforeseen damage.
Your Celestron binocular will provide you years of dependable service if it is cared for and
stored properly.

ENGLISH I11
CLEANING
SERVICE AND REPAIR
Proper cleaning of the lenses is essential
to maintaining the optical integrity of your
binocular. Dirty lenses diminish the amount of
light transmitted through the binocular and your
overall viewing experience.
1. Remove any dust on the lenses with a soft
lens brush or can of pressurized air.
2. Remove any fingerprints, stains or smudges
from the lens surface with a soft, clean lens
cloth or lens tissue by rubbing in a circular
motion. Start in the middle of the lens and
work your way to the edges. Breathe lightly
on the lens to provide moisture if needed.
3. For a more thorough cleaning we recommend
the use of a lens/optics cleaning kit available
at most photo or optical shops. Follow the
directions supplied with the cleaning kit for
best results.
If warranty problems arise or repairs are
necessary, contact the Celestron customer
service department if you live in the United
States or Canada. If you live outside of
these countries, please contact the dealer
you purchased your binocular from or the
Celestron distributor in your country. A list of
our distributors can be found on our website.

12 IENGLISH
WARRANTY
Your binocular is covered under the Celestron
Limited Lifetime Warranty. Celestron warrants
these binoculars to be free from defects in
materials and workmanship for the binocular’s
usable lifetime to the original owner. Celestron
will repair or replace the binoculars which, upon
inspection by Celestron, are found to be defective
in materials or workmanship and within the
definitions of the limits described below.
This warranty does not cover products that
have been subject to abuse, misuse, physically
damaged, altered, or had unauthorized repairs
or modifications. This warranty does not cover
defects due to normal wear and tear and other
conditions.
This warranty is valid to U.S.A. and Canadian
customers who have purchased their binocular
from an authorized Celestron dealer in the U.S.A.
or Canada. For products purchased outside
of the U.S.A. or Canada please contact your
local Celestron Distributor or authorized Dealer
for applicable warranty information. Additional
warranty information and eligibility details can be
found on the Celestron website.
This product is designed and intended for use by those 14 years of age and older.
Product design and specifications are subject to change without prior notification.
For complete specifications and product
information, visit: www.celestron.com
