VUE Audiotechnik VUEDrive V242 User manual

This manual does not include all of the details of design, production, or variations of the equipment. Nor
does it cover every possible situation which may arise during installation,operation or maintenance.
The information provided in this manual was deemed accurate as of the publication date. However,
updates to this information may have occurred. To obtain the latest version of this manual, please visit the Vue
Audiotechnik website at www.vueaudio.com.
USER MANUAL
V242 V3, V4, V6
NETWORKED DSP AMPLIFIERS

The lightning bolt triangle is
used to alert the user to the risk
of electric shock.
The exclamation point triangle
is used to alert the user
to important operating or
maintenance instructions.
WATCH FOR THESE SYMBOLS:
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding-type plug has two blades and a third grounding
prong. The wide blade or the third prong is provided for your safety. If the provided plug does not fit into
your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to
avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
15. Use the mains plug to disconnect the apparatus from the mains.
16. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPARATUS TO RAIN OR MOISTURE.
17. DO NOT EXPOSE THIS EQUIPMENT TO DRIPPING OR SPLASHING AND ENSURE THAT NO OBJECTS
FILLED WITH LIQUIDS, SUCH AS VASES, ARE PLACED ON THE EQUIPMENT.
18. THE MAINS PLUG OF THE POWER SUPPLY CORD SHALL REMAIN READILY OPERABLE.
TO PREVENT ELECTRIC SHOCK DO NOT REMOVE TOP OR BOTTOM COVERS. NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
19. For help and service contact your local dealer or installer. You may also contact Vue at service@
vueaudio.com.


REIMAGINE LOUDSPEAKERS
WWW.VUEAUDIO.COM
1. Power LED indicator
2. Amplifier indicators for: Protection and Temperature
3. Sleep indicator lights when the amplifiers is in power
down sleep mode.
4. Wink indicator for identifying the amplifier over the
network.
5. Input channel meters with input Clip, input Limiter
engaged indicator, -6dB down from full input, and
Signal present indicator.
6. Input channel audio Mute indicator.
7. Output channel Amplifiers 1, 2 and 3 meters with output
Clip, output Limiter engaged indicator, -6dB down from
full output, Signal present, and channel mute indicator.
8. Output channel Amplifiers 1, 2 and 3 Mute indicators.
9. Front cooling vent - Do not block vent openings and
clean vent filter when visibly dirty.
1. AC Power switch
2. Locking PowerCon connector (100 - 240VAC, 50-60 Hz)
3. Cooling fan (rear exhausting, air is pulled in the front of
the amp) do not to block the fan opening.
4. Speaker output - Single NL8 Speakon connector
5. Analog input and hard wired loop through XLR jacks.
6. AES / EBU digital input and buffered loop through XLR
jacks.
V3-i REAR PANEL FEATURES
V3-i FRONT PANEL FEATURES
7. Two Ethernet port jacks for control with SystemVue
network software and audio input with Dante network
audio. Either port can be used. These jacks are
individual ports on an internal Ethernet switch, so they
can be linked to the next VDrive amplifier in a rack.
When using an external Ethernet switch one
jack should be connected to the network
switch. Connecting both ports to the same
network will cause continents on the network.

5
REIMAGINE LOUDSPEAKERS
WWW.VUEAUDIO.COM
1. AC Power switch
2. Locking PowerCon connector (100 - 240VAC, 50-60 Hz)
3. Cooling fan (rear exhausting, air is pulled in the front of
the amp) Do not block the fan and vent openings.
4. Speaker output A and B - two NL4 Speakon connectors
5. Analog input A and hard wired loop through XLR jacks.
6. Analog input B and hard wired loop through XLR jacks.
7. AES / EBU digital input and buffered loop through XLR
jacks.
1. Front panel network port jack.
2. Power on indicator
3. A and B Amplifier indicators for: Protection and
Temperature
4. Sleep indicator lights when the amplifiers is in power
down sleep mode.
5. Wink indicator for identifying the amplifier over the
network.
6. Input channels A and B meters with input Clip, input
Limiter engaged, -6dB down from full input, and Signal
7. Input channels A and B audio mute indicator.
V4-d FRONT PANEL FEATURES
V4-d REAR PANEL FEATURES
8. Output channel A amplifiers 1 and 2 meters with input
Clip, output Limiter engaged indicator, -6dB down from
full output, and Signal present indicator.
9. Output channel A amp 1 and amp 2 Mute switches and
indicators.
10. Output channel B amp 1 and amp 2 meters with input
Clip, output Limiter engaged indicator, -6dB down from
full output, Signal present, and channel mute indicator.
11. Output channel B amp 1 and amp 2 Mute switches and
indicators
12. Front cooling vent - Do not block vent openings and
clean vent filter when visibly dirty.
8. Two Ethernet port jacks for control with SystemVue
network software and audio input with Dante network
audio. Either port can be used. These jacks are
individual ports on an internal Ethernet switch, so they
can be linked to the next VDrive amplifier in a rack.
When using an external Ethernet switch one
jack should be connected to the network
switch. Connecting both ports to the same
network will cause continents on the network.

REIMAGINE LOUDSPEAKERS
WWW.VUEAUDIO.COM
1. Front panel network port jack.
2. Power LED indicator
3. Protection, Temperature for A and B amplifiers,
4. Sleep indicator for when the amplifiers is in power
down sleep mode.
5. Wink indicator for identifying the amplifier over the
network.
6. Input channel A and B meters with input Clip, input
Limiter engaged indicator, -6dB down from full input,
and Signal present.
7. Input channels A and B audio mute indicator.
V6-d REAR PANEL FEATURES
1. AC Power switch
2. Locking PowerCon connector (100 - 240VAC, 50-60 Hz)
3. Cooling fan (rear exhausting, air is pulled in the front of
the amp) do not to block the fan opening.
4. Speaker output A and B - two NL8 Speakon connectors
5. Analog input A and hard wired loop through XLR jacks.
6. Analog input B and hard wired loop through XLR jacks.
7. AES / EBU digital input and buffered loop through XLR
jacks.
V6-d FRONT PANEL FEATURES
8. Output channel A amp 1 and amp 2 meters with input
Clip, output Limiter engaged indicator, -6dB down from
full output, and Signal present.
9. Output channel A amp 1 and amp 2 Mute switches and
indicators
10. Output channel B amp 1 and amp 2 meters with input
Clip, output Limiter engaged indicator, -6dB down from
full output, and Signal present.
11. Output channel B amp 1 and amp 2 Mute switches and
indicators
12. Front cooling vent - Do not block vent openings and
clean vent filter when visibly dirty.
8. Two Ethernet port jacks for control with SystemVue
network software and audio input with Dante network
audio. Either port can be used. These jacks are
individual ports on an internal Ethernet switch, so they
can be linked to the next VDrive amplifier in a rack.
When using an external Ethernet switch one
jack should be connected to the network
switch. Connecting both ports to the same
network will cause contintion on the network.

7
REIMAGINE LOUDSPEAKERS
WWW.VUEAUDIO.COM
V242 FRONT PANEL FEATURES
1. AC Power switch
2. Locking IEC power connector (100 - 240VAC, 50-60 Hz)
3. Cooling fan (rear exhausting, air is pulled in the front of
the amp) Do not block the fan and vent openings.
4. Speaker outputs A, B, C, and D on two 4-pin high
current locking removeable 7.62mm spacing terminal
block connectors,
V242 REAR PANEL FEATURES
1. Power on indicator
2. A and B Amplifier indicators for: Protection and
Temperature
3. Sleep indicator lights when the amplifiers is in power
down sleep mode.
4. Wink indicator for identifying the amplifier over the
network.
5. Front cooling vent - Do not block vent openings and
clean vent filter when visibly dirty.
5. Analog input A and B on two 3-pin 5.08mm spacing
removable terminal block connectors.
6. Ethernet port jack for control with SystemVue network
software and digital audio input with Dante network
audio.

REIMAGINE LOUDSPEAKERS
WWW.VUEAUDIO.COM
MENU EXIT
VUEDrive V6
al-8 array 3
MENU EXIT
Configuration:
al-8 array 3
PRESET ASSIGNMENT, ACCESS AND CONTROL
FRONT PANEL PRESET ACCESS
Standard operation display showing the name of
the amplier on the top line, which can be changed in
the System Vue software, and the current loaded preset
on the second line.
Preset select display shown after the MENU
button has been pressed.
The V3-i and the V242 do not have front panel displays or access to preset selection at the amplier. For
these two amplier models you will need to access the amplier through the SystemVue software. The V4
and V6 models can also be locked out of front panel access through the SystemVue software.
The V4-d and V6-d have front panel displays and
controls to access presets at the amplier.
In normal operation the front panel display will
show the default name or the name assigned
the amplier in the SystemVue software, and the
preset currently loaded.
Changing Preset at amplier:
To change the currently loaded preset:
1. Press the MENU button and the display will
change to show “Configuration:” on the top
line.
2. Turn the control knob to run through the
available presets in the amplifier’s memory.
3. When the desired preset is found stop and
press exit and the preset will be loaded, and
the display will return to the normal operation
display.
Preset assignment, Access can be achieved through
and one of the three network connectors. The
V-drive series is best run on a Dynamically assigned
IP address, DHCP, managed Ethernet network. The
SystemVue software will automatically identify any
Vue networked products on the network when it is
launched. For non-DHCP networks the VDrive System
Engines will work and auto identify using the ad-hoc
network conventions. This may be slower or take
some time to re-access if the ampliers were already
on a DHCP network. Static addresses may also be
used. Caution must be taken to manage the static
IP addresses, so they are not repeated or place out
of the users subnet mask range. If placed out of the users Subnet mask range, SystemVue will still see the
products, but it can not connect and communicate with them.
The SystemVue software is available for download from vueaudio.com. In the software you can, control the
input volumes, select presets, adjust input EQ, manage all your network controlled Vue products and much
more.

9
REIMAGINE LOUDSPEAKERS
WWW.VUEAUDIO.COM
SPECIFICATIONS
MODEL V242 V3 V4 V6
DESCRIPTION Installation Systems
Engine
Touring Systems
Engine
Touring Systems
Engine
Touring Systems
Engine
User Interface Network Software Network Software LCD Display with Encoder & Network Software
Front Panel Display N/A N/A 16 character LCD display
Input Channels 2 Dante or XLR Analog 2 Dante or XLR Analog 2 AES3, Dante or Analog
Output Channels 4 3 4 6
Latency (analog in to out) Less than 1 msec
User Input Delay up to 200 msec
Nominal Input Level 0dBu
Max Input Level 23 dBu
Inputs
Three pin Phoenix
Connectors, Dante
and control through
Ethernet jack.
Female XLR input with male XLR loop output for both analog input and
AES EBU digital input (default digital AES channel 1, channel 2 selectable
remotely via software). If clock is present system uses AES digital input.
System will fall back on analog input if clock is not present. Dante and
control through ethernet jack- selectable through software.
AMPLIFIER POWER
Long Term Sine Wave
before protection 8Ω/4Ω 4x 250/500 watts rms 2x 830/1600 watts rms
1x 275/550 watts rms
2x 830/1600 watts rms
2x 275/550 watts rms
2x 830/1600 watts rms
4x 275/550 watts rms
Average Burst
8Ω/4Ω 4x 300/700 watts 2x 1,250/2500 watts
1x 400/800 watts
2x 1,250/2500 watts
2x 400/800 watts
2x 1,250/2500 watts
4x 400/800 watts
Output Connectors 2x Phoenix touch proof
IPC
1x NL8 (Pin1± Amp Ch1,
Pin2± Amp Ch2, Pin3±
Amp Ch3)
2x NL4 (Pin1± Amp Ch1,
Pin2± Amp Ch2)
2x NL8 (Pin1± Amp Ch1,
Pin2± Amp Ch2, Pin3±
Amp Ch3)
THD+N (typical) < 0,05 % (20 Hz - 20 kHz, 3 dB below rated power)
Amplier Protection
Input limiter, short circuit protection, DC protection of output, under & over voltage protection,
intellgent mains fuse protection, power stage overload protection, temperature protection of
transformers and heat-sinks
Network Ethernet / IP (DHCP, Ad-Hoc or xed IP) for remote monitoring and control
Network Connectors 1x Rear RJ45 Ethercon 2x Rear RJ45 Ethercon
1x Front RJ45 Ethercon
Operational Voltage Universal Mains, 85-268V (dual voltage auto selection). UREC™ power supply integrated amplier
modules provide universal mains operation for 120 V and 230 V
Dimensions
2U - 482.6 x 88.9 mm
(19 x 3.5 in) - depth
328.6 mm (13 in)
2U - 482.6 x 88.9 mm (19 x 3.5 in) - depth to rear panel 384.2 mm (15.125 in)
depth to rear rack ears 844.9 mm (16.125 in)
Weight 7.7 kg (17 lbs) 10.9 kg (24 lbs) 11.3 kg (24.9 lbs) 11.45 kg (25.2 lbs)

VUE AUDIOTECHNIK PRODUCTS LIMITED WARRANTY
VUE Audiotechnik, LLC (“VUE”) guarantees its products to be free from defective material and / or workmanship and will replace
defective parts and repair malfunctioning products under this warranty when the defect occurs under normal installation and use
– provided the unit is returned to our factory or an authorized VUE International Distributor via pre-paid freight with a copy of proof
of purchase (i.e., sales receipt). This warranty requires that the examination of the returned product indicates, in our judgment, a
manufacturing defect.
This warranty does not extend to any product which has been subjected to misuse, neglect, accident, improper installation, or
where the date code has been removed or defaced. VUE shall not be liable for incidental and/or consequential damages. This
warranty gives you specic legal rights. VUE’s liability under this product warranty is limited to the repair or replacement of the product
(at our option) and VUE shall have no liability for any loss of use, interruption of business, lost prots or goodwill, or for any incidental
or consequential damages of any kind arising from the purchase or use of VUE products.
Customers may have additional rights, which vary from state to state or from country to country. In the event that a provision of
this limited warranty is void, prohibited or superseded by local laws, the remaining provisions shall remain in eect. The VUE limited
warranty is valid for a period of ve (5) years from date of purchase in the United States and many (but not all) other countries.
Other questions regarding this warranty can be answered by e-mailing VUE, or by contacting your local authorized VUE dealer or
distributor.
Email: warran[email protected]
Phone: +1(760)520-1069
This manual suits for next models
3
Table of contents
