W Box Technologies 0E-HDD1MP28 User manual

Special Announcement
For more information, please refer to wboxtech.com or call W Box
Tech Support 1-833-574-9124.
Fully understand this document before using this device, and
strictly observe rules in this document when using this device. If
you install this device in public places, provide the tip "You have
entered the area of electronic surveillance" in an eye-catching
place. Failure to correctly use electrical products may cause fire
and severe injuries.
It alerts you to moderate dangers which, if not
avoided, may cause minor or moderate injuries.
It alerts you to risks. Neglect of these risks may
cause device damage, data loss, device
performance deterioration, or unpredictable results.
It provides additional information.






Strictly observe installation requirements when installing the
device. The manufacturer shall not be held responsible for
device damage caused by users' non-conformance to these
requirements.
Strictly conform to local electrical safety standards and use
power adapters that are marked with the LPS standard when
installing and using this device. Otherwise, this device may be
damaged.
Use accessories delivered with this device. The voltage must
meet input voltage requirements for this device.
If this device is installed in places with unsteady voltage, ground
this device to discharge high energy such as electrical surges in
order to prevent the power supply from burning out.
When this device is in use, ensure that no water or any liquid
flows into the device. If water or liquid unexpectedly flows into
the device, immediately power off the device and disconnect all
cables (such as power cables and network cables) from this
device.
Do not focus strong light (such as lighted bulbs or sunlight) on









Avoid heavy loads, intensive shakes, and soaking to prevent
damages during transportation and storage. The warranty does
not cover any device damage that is caused during secondary
packaging and transportation after the original packaging is
taken apart.
Protect this device from fall-down and intensive strikes, keep the
device away from magnetic field interference, and do not install
the device in places with shaking surfaces or under shocks.
Clean the device with a soft dry cloth. For stubborn dirt, dip the
cloth into slight neutral cleanser, gently wipe the dirt with the
cloth, and then dry the device.
Do not jam the ventilation opening. Follow the installation
instructions provided in this document when installing the device.
Keep the device away from heat sources such as radiators,
electric heaters, or other heat equipment.
Keep the device away from moist, dusty, extremely hot or cold
places, or places with strong electric radiation.
If the device is installed outdoors, take insect- and moisture-
proof measures to avoid circuit board corrosion that can affect
monitoring.
Remove the power plug if the device is idle for a long time.
Before unpacking, check whether the fragile sticker is damaged.
If the fragile sticker is damaged, contact customer services or
sales personnel. The manufacturer shall not be held responsible
for any artificial damage of the fragile sticker.




All complete products sold by the manufacturer are delivered
along with nameplates, and accessories after
strict inspection. The manufacturer shall not be held responsible
for counterfeit products.
The manufacturer will update this manual according to product
function enhancement or changes and regularly update the
software and hardware described in this manual. Update
information will be added to new versions of this manual without
prior notice.
This manual may contain misprints, technology information that
is not accurate enough, or product function and operation
description that is slightly inconsistent with the actual product,
the final interpretation of company is as a standard.
This manual is only for reference and does not ensure that the
information is totally consistent with the actual product. For
consistency, see the actual product.
quick setup guide
Precautions
Open the package, check the appearance of product for no
obvious damage, and confirm the item for t 1-1 is
consistent.
list able
Table 1-1 Packing list
2.1 Power and video cables
Component Quantity Remark
Turret HD Camera
Black stainless self-tapping screw
PA4.0×35mm
Swell plastic button φ10.8×39mm
Black stainless self-tapping screw
PA4.0×30mm
L wrench
Installation location sticker
Quick Setup Guide
1
4
3
1
1
1
NOTE
NOTE
this device. Otherwise, the service life of the image sensor may
be shortened.
If this device is installed in places where thunder and lightning
frequently occur, ground the device nearby to discharge high
energy such as thunder strikes in order to prevent device
damage.

T15 screwdriver
Swell plastic button S8×30mm
1
Figure 2-1 Power and video cable
2.3 Camera Dimensions（Unit:mm）
Figure 2-3 Fixed focus small Eyeball
Different device may have different dimensions, please refer
to the .actual product
NOTE
CAUTION
WARNING
WARNING
CAUTION
Open Package Examination
1
Device Structure
2
Video
12V DC
Connect the BNC connector of the power or video cable to a
video signal cable and connect the other connector to a low-
voltage power cable 12V DC After installing the
camera, directly connect the video cable and power cable.
2.2 Function Keys
Users can call OSD main menus through multi function switch
control keys, and check and set camera parameters, function keys
is shown as figure 2-2.
Figure 2-2 Function keys
Up
Down
Left Right
SET
DN
UP
Operation description
SET key: It is used to enter OSD menus or select menu items
when you press this key in the middle of the multi function switch.
UP/DOWN keys: The UP and DOWN keys are used to select menu
items upwards and downwards by prodding the multi function
switch upwards and downwards,
LEFT/RIGHT keys: The LEFT and RIGHT keys are used to select
menu items horizontally or modify parameters by prodding the
multi function switch towards the left or the right,
the menu items rapidly roll
upwards and downwards accordingly;
the parameter
values will rapidly decrease or increase.
Press and hold the LEFT button for 5s to switch to AHD mode.
Press and hold the RIGHT button for 5s to switch to TVI mode.
Press and hold the UP button for 5s to switch to CVBS mode.
Press and hold the DOWN button for 5s to switch to CVI mode.
94
84
48.5
48.5
NOTE
The detail operation of OSD refer to Camera OSD Operation
Guide.
Alternative
Alternative
HD EYEBALL Camera
Quick Setup Guide
0E-HDD1MP28
0E-HDD2MP28
0E-HDDMO2812
100
119
Figure2-4 Zoom lens large eyeball
98
98
0E-HDD1MP28G
0E-HDD2MP28G
0E-HDDM2812G

you can route cables from the top or from aside. If you use the top
routing method, drill a hole in the surface first. If the aside
routing method. When you route cables from aside,
you use
please cut the
compression ring outlet, as shown in figure 3-3, and route the cable
out from the side gap at the bottom of the camera.
NOTE
Figure 3-3 Cutting the compression ring outlet
Step 4 Install the dome shell and the compression ring on the mount-
ing base, adjust the position so that the camera faces the moni-
tored area, then tighten the screw, as shown in figure 3-4.
Figure 3-1 Removing compression ring
Step 2 Stick the Installation location sticker on the ceiling or wall,
Drill three holes based on the marks on the sticker. Drive
the swell plastic buttons into the holes.
Step 3 Fix the camera mounting base to the mounting surface, by
use of self-tapping screws, as shown in figure 3-2.
Figure 3-2 Fixing the mounting base
Installation Steps:
Step 1 Open a package, take out the camera and the accessories,
unscrew the compression ring or use the screwdriver to
loosen the screw, remove the compression ring, as shown
in figure 3-1.
3Device Installation
Compression ring
Outlet
Figure 3-4 Installing and djusting camera
Mounting base
Compression ring
Dome shell fixed base
Dome shell
If you have any questions, please call W Box Tech Support 1- 833-574-9124 for assistance.
