W Box Technologies 0E-SB80 User manual

SLIMLINE POWERED
SOUNDBAR
0E-SB80 WITH WIRELESS 8” SUBWOOFER
0E-SB65 WITH WIRELESS 6.5” SUBWOOFER
BLUETOOTH® enabled

Safety Instructions
1. Read these instructions completely prior to use or hook-up.
2. Understand and heed all warnings.
3. Follow all instructions.
4. Do not use soundbar or subwoofer near water, rain or high moisture.
5. Clean only with a dry cloth. Never use solvents. A microfiber cloth is recommended.
6. Do not block any of the ventilation openings. See Instructions.
7. Do not install near heat sources such as stoves, radiators and amplifiers.
8. Use only with supplied power sources, with polarized power cord.
9. Protect power cord from being walked on or pinched. Do not have cord stretched taut.
10. Use only connections and auxiliary equipment suggested by manufacturer.
11. Unplug this system during lightning storms or when left unattended for extended periods.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operation or maintenance instructions.
The lightning flash with arrowhead symbol within an equilateral triangle
is intended to alert the user to the presence of non insulated dangerous
voltages within the product’s enclosure that may be sufficient magnitude
to constitute a risk of electric shock to people.
WARNING
TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT
EXPOSE THIS EQUIPMENT
TO RAIN OR MOISTURE
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER OR BACK. NO
USER-SERVICABLE PARTS INSIDE. REFER TO
QUALIFIED SERVICE PERSONNEL.
The BLUETOOTH® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
1

Thank you for purchasing the W BOX Home Theater Soundbar.
Please read this manual thoroughly before making any connections or applying AC power. This manual
applies to the 0E-SB80 and 0E-SB65 Soundbar Systems. Follow the instructions in this manual. It will
allow you to obtain the maximum performance and listening pleasure from your new soundbar. Please
retain this manual to use as a future reference.
Supplied accessories
The boxes include the following equipment and accessories:
• (1) Soundbar
• (1) 100 - 240VAC to 18VDC power supply
• (1) RCA stereo audio cable
• (1) 3.5mm stereo audio cable
• (1) Hand held remote control unit
• (1) 2.4GHz wireless MegaBass unit with power cord
• (1) Wall mounting brackets with screws
• (2) Table Top Mounting feet
• (1) Instruction Manual
0E-SB80 Specications
Soundbar Power 60 Watts RMS 120 Watts Peak
Subwoofer Power 80 Watts RMS 180 Watts Peak
Total Power 140 Watts RMS 300 Watts Peak
SPL 103.6dB
Sound Mode 3 Enhanced DSP Surround Modes
Speakers 8 Speakers. 6 2.5” Midrange Drivers and 2 1.25” Tweeters
Subwoofer 2.4GHz 8” Long Throw Ported Woofer
BLUETOOTH® Connectivity for iPhone, Android, MP3 and PC
Audio Inputs Digital Optical, Digital Coaxial RCA, 3.5mm
Frequency Response 20 Hz to 20 kHz
Soundbar Dimensions (weight) 39 9/16” (1005mm) x 3 1/2” (89mm) x 3 5/16” (84mm) 9lbs
Subwoofer Dimensions (weight) 17 1/8”(435mm) x 8 11/16”(221mm) x 14 1/4”(362mm) 21 lbs
Soundbar Power 40 Watts RMS 80 Watts Peak
Subwoofer Power 60 Watts RMS 135 Watts Peak
Total Power 100 Watts RMS 215 Watts Peak
SPL 102dB
Sound Mode 3 Enhanced DSP Surround Modes
Speakers 6 Speakers. 4 2.5” Midrange Drivers and 2 1.25” Tweeters
Subwoofer 2.4GHz 6.5” Long Throw Ported Woofer
BLUETOOTH® Connectivity for iPhone, Android, MP3 and PC
Audio Inputs Digital Optical, Digital Coaxial, RCA, 3.5mm
Frequency Response 25 Hz to 20 kHz
Soundbar Dimensions (weight) 39 9/16” (1005mm) x 3 1/2” (89mm) x 3 5/16” (84mm) 9lbs
Subwoofer Dimensions (weight) 16 3/8” (416mm) x 7 7/8” (200mm) x 13” (330mm) 17lbs
0E-SB65 Specications
2

The 0E-SB80 and 0E-SB65 Soundbar describes the latest digital technology in amplified speaker sound
bars with a powerful wireless amplified subwoofer by W BOX. The powerful subwoofer can be located
anywhere in the room. This is the perfect Home Theater System with a wide sound stage. The system
comes with a handheld remote to control power, switch inputs and adjust sound fields. The slim depth
and sleek design blends with all flat LED/LCD TV models.
Soundbar 0E-SB80 and 0E-SB65 by W BOX
Features and Connections for Soundbar
Rear panel of Soundbar
1. RCA - analog inputs, left and right analog stereo input
2. COAXIAL digital input - supports 2 channel or PCM bitstreams
3. OPTICAL digital input - supports 2 channel or PCM bitstreams
4. AUX IN - 3.5mm audio jack for TV, MP3, computers, mobile devices, etc
5. Power switch - rear panel switch to cut power for service or hook-up
6. Input power jack - connect the 18VDC power supply here
1 2 3 4 5 6
7
8
9
Rear panel of Subwoofer
7. Match button and status LED - used to sync the
Soundbar with the wireless subwoofer
8. Power mode - power ON or OFF
9. Input power jack - connect 100 - 240VAC 2
conductor power cord here
3

INSTALLATION
Getting started
Soundbar placement
Where to locate Soundbar
Either mount the soundbar on a flat horizontal surface centered in front of the TV or surface wall mount
the soundbar on the wall via the key hole slots. Use proper wall anchors to support the weight of the
soundbar.
Where to locate subwoofer
Install the wireless subwoofer preferably near the front wall next to an electrical outlet. The power cord
is the only wire needed for hook-up. Corner placement will give an added bass boost.
TV
4

Connecting source equipment to analog inputs on the soundbar:
• RCAinputs,usingthesuppliedRCAcables,connectthesourceequipmenttothesoundbar.
Connect red cable end to red jack, white cable end to white jack.
• Auxinput,usea3.5mmmaleplugtoconnecttothejackonthebackofthesoundbar.
• Usinganaloginputsistheeasiestmannertoconnectsourceequipmenttothesoundbar.
In most instances (check the manufacturer’s manual) you can connect all source equipment to a
television using HDMI, digital coax, digital optical or RCA connections and the 3.5mm or RCA
output of the TV will be an analog 2 channel signal. No menu changes on source equipment will
be necessary. If you are having trouble using the optical or coax digital inputs on the soundbar
use one of the analog inputs. They are very low noise and very high quality, in most instances it
is difficult to notice a difference in sound quality.
Making connections
Caution: All connections and switching should be done with the AC power switched OFF.
The final connection should be the power cords.
INPUTS
The inputs are located on the back of the soundbar. They include 18VDC power, analog RCA, Digital
Optical, Digital Coaxial and 3.5mm jack
Connect red and black
stereo RCA plug from TV
Coax digital
supporting 2
channel PCM
Bitstream
Optical digital
cable
supporting 2
channel PCM
Bitstream
3.5mm stereo plug
from mobile device,
TV, etc.
5

INSTALLATION
Making connections (cont.)
Connecting with BLUETOOTH® devices:
• PresstheBLUETOOTH®buttonontheremotecontroluntiltheblueLEDonthesoundbar
is visible.
• TaketheBLUETOOTH®activedevice(laptop,phone,tablet,etc)andturnontheBLUETOOTH®
function.
• Scanfordevicesandyouwillndthesoundbar.
• Pairorconnectwiththesoundbar.
• Playthemusicasdesired.
Connecting the soundbar with the wireless subwoofer:
• Inmostcasesthisisnotnecessary.Thesubwooferispairedwiththesoundbarfromthefactory.
However, if necessary take the following steps to connect the soundbar to the subwoofer
wirelessly.
• ContinuouslypresstheMatchbuttonontheremotecontroluntiltheLEDisvisiblyblinkingonthe
soundbar.
• WhiletheLEDisstillblinkingonthesoundbar,continuouslypressthebuttonontherearofthe
subwoofer next to the blue LED until the LED starts to blink. Use of a paper clip or similar item
will be necessary to access the button.
• WhentheLEDonthesubwooferblinksandtheLEDisstillblinkingonthesoundbar,releasethe
button on the subwoofer and the two will connect to each other.
• Itmaytakeafewsecondsforthisconnectiontobemade.Repeattheprocessasnecessaryto
make the connection.
Connecting source equipment to an Optical or Coax Digital input on the soundbar:
• Bothdigitalopticalanddigitalcoaxinputsonthesoundbarsupport2channelorPCMdigital
bitstreams.
• Allsourceequipmentmustbesettoeither2channelorPCMoutput.
• Nosoundwillbepresentonthesoundbarifthissettingisnotmadewhenthedigitalopticalor
digital coax input is used on the soundbar.
• Ifyouconnectyourequipment(satellite/cablebox,BluRayplayer,etc)toyourTVviaHDMI
cables and then connect the TV to the soundbar via digital coax or digital optical connection
you must set each source device to 2 channel or PCM output.
• Shownbelowaresomeexamplesofsettingsourceequipmentto2channelorPCMmode.Most
equipment is similar, please consult your owner’s manual for exact instructions.
• DirecTVsatellitereceivers:
o Select the menu button on the remote control
o Select settings
o Select audio settings
o Under audio settings select Dolby Digital and Select OFF
o Press exit on the remote
6

• DishNetworksatellitereceivers:
o Select the menu button on the remote control
o Select settings
o Select audio settings
o Select PCM Only
o Press save
o Press exit on the remote
• Mostcommoncableboxreceivers:
o Select the menu button on the remote control
o Select settings
o Select audio settings
o Select stereo output
o Select exit
o If there is no option for audio settings use the RCA or 3.5mm inputs
o Please consult your cable box receiver manufacturer’s manual if the information above is
not correct
• MostcommonBluRayplayers:
o Without a disc in the player select the home button or main menu button on the remote
control. You want to choose the setup menu for the player not a disc
o In most cases you will use the arrow keys on the remote control to navigate to a settings
icon or menu selection
o Select audio setup
o Select PCM audio or 2 channel output
o If the BluRay player has an option to select PCM down sampling mode then press ON or
YES to allow PCM down sampling
o If the BluRay player has an option to select down-mixing mode then select normal stereo
mode
o Please consult your BluRay player manufacturer’s manual if the information above is no
correct
• Mostcommontelevisions:
o Select the menu button on the remote control
o Select settings
o In some instances select speaker settings or TV sound output
o Turn off the TV speakers. Some manufacturers will not allow sound to be output from the
TV outputs when the TV speakers are actively playing
o Select audio, audio format or sound settings. The names vary by manufacturer
o Ensure that the audio format for digital output or the SPDIF output is set to 2 channel or
PCM mode
o Press exit or the menu again to return to the home screen
o If there is no sound from the soundbar when using the digital output from the TV use the
RCA or 3.5mm inputs to connect to the soundbar
o Please consult your television manufacturer’s manual if the information above is not
correct
INSTALLATION
Making connections (cont.)
7

INSTALLATION
Remote control functions
Universal remote codes:
The soundbar is compatible with many different universal remote controls supplied with satellite
receivers, cable box receivers, AV receivers, televisions. Please refer to the on-line link for further
information.
Discrete power on, turns
the soundbar power on
Discrete power off, turns
the soundbar power off
Mute, toggles mute on
and mute off
VOL +, increases the volume
level of the soundbar
BASS +, increases the bass
level of the subwoofer
VOL -, decreases the volume
level of the soundbar
BASS -, reduces the bass
level of the subwoofer
TREBLE +, increases the treble
level of the soundbar
COAXIAL, digital coaxial input
OPTICAL, digital optical input
NIGHT, night mode, reduces
the level of the subwoofer
POWER TOGGLE, power
toggle on/off
MATCH, to connect or “pair” the
soundbar to the subwoofer
TREBLE -, reduces the treble
level of the soundbar BLUETOOTH®, used to connect or pair the
soundbar to mobile devices with
BLUETOOTH®
MOVIE, movie mode, this is a DSP
enhanced movie sound effects for
wider soundeld
AUX, 3.5mm input
MUSIC, music mode, at
response normal listening
mode
AUDIO, RCA input
8

Trouble Possible Cause Possible Solution
No sound
Unit not plugged into AC power Check that the rear power switch on the
soundbar is turned on. The LED lights on the
soundbar and on the power supply for the
soundbar should be visible.
Audio cable not properly connected Check cable connections. Replace cable.
Check if connected to proper inputs.
Audio cable not properly connected Connect a phone or other similar device to
the 3.5mm jack on the rear of the soundbar. If
sound is present check all cables, connectors
and source devices. Fault may be with one
of them. If the problem is with the coaxial or
optical digital input then try to use an analog
input. If the analog input works then check the
menu settings in the equipment for 2 channel
or PCM operation.
Master power switch on rear Place master power switch to on.
Front power switch Switch from standby to on
Change to proper input Change from any input back to desired input.
Optical input has 2 channel signal Insure TV/DVD is set to 2 channel audio out.
No audio from subwoofer Soundbar and subwoofer not matched Repeat match sequence
Volume turned down Turn up sub volume
Remote control not
responding correctly
Remote not directed to receive window Aim remote to receive window on soundbar.
Remote too far from soundbar Move to within 8 meters of soundbar
Remote batteries weak or dead Change batteries
For further assistance please contact us at:
USA 1-800-233-6261
Canada 1-877-234-7378
9
This product conforms to all EU Directive
requirements as applicable by law.
