WALCOM
®
SPRAY GUN WASHERS
EASY - Ref. 90060
EASY/S - Ref. 90061
Operating and maintenance handbook
AI51/10EN
WALMEC ITALY
PRODUCTION PLANT
WALMEC S.p.A.
Viale della Vittoria
24054 CALCIO (BG) ITALY

2
CONTENTS
Introduction …………………………………………………………………………………………………. 3
Description of the spray gun washer …………………………………………………………………………3
Opening the packing case …………………………………………………………………………………… 4
Installing the spray gun washer ……………………………………………………………………………… 5
Technical data ……………………………………………………………………………………………….. 6
Safety precaution ……………………………………………………………………………………………. 6
Maintenance ………………………………………………………………………………………………… 7
Warranty certificate ………………………………………………………………………………………… 8
Declaration CE of conformity ……………………………………………………………………………… 9

3
INTRODUCTION
EASY spray gun washers are used to wash spray guns and accessories manually.
They are compressed air devices which are easy to use and highly practical; they work at high or low pressure and
consume less than a conventional airbrush.
DESCRIPTION OF THE SPRAY GUN WASHER
It has two parts (see fig. on page 3): the washing chamber (A) and the base (B), as shown schematically in figure 1.
The washing chamber comprises:
1) Ball cock for the continuous jet of clean solvent
2) Ball cock for atomized solvent
3) Ball cock for dirty solvent jet
4) Chimney; an external hose at the top of the device
5) Start-up cock; turn and the fume suction nozzle starts up automatically
6) Hatch; only for EASY/S model
7) Hose for discharge of continuous jet of clean solvent
8) Hose for discharge of clean solvent in atomized jet
9) Hose for discharge of continuous jet of dirty solvent
10) Hose for suction of continuous jet of clean solvent
11) Hose for suction of clean solvent in atomized jet
12) Hose for suction of continuous jet of dirty solvent
13) Hose for discharge of dirty solvent from the tank
The base (B) is a single unit; low down it has brackets to secure the two solvent bins - dirty (16) and clean (17).

4
OPENING THE PACKING CASE
The cardboard packing case includes inner wrapping with corrugated cardboard.
The packing case should only be moved by fork-lift truck and handled at all times by two people, until
installation is complete.
Carry out the following instructions:
1. Remove the unit from the corrugated cardboard and the outside packing.
2. Remove any cardboard protecting the base and washing chamber and then remove the chamber itself (pull out first
the hose for solvent discharge then the hose for solvent fumes).
3. The EASY/S model is fitted with a base hatch containing a knob for hatch opening and closing, a screw and pin.
Remove this unit from the base.
3 2 1
4 5
6
9 8 7
13
12 11
10
14
15
16
B
A
fig. 1

fig. 3
a
b
c
a
fig. 4
fig. 5
fig. 2

fig. 6
fig. 9
fig. 8
g
fig. 7
f

5
INSTALLING THE SPRAY GUN WASHER
a) Place the base vertically; the two brackets for the solvent bins should be at the bottom.
b) For the EASY/S model, assemble the knob at the centre of the hatch and tighten the screw provided. The hatch has
a pin at the bottom left: place this pin in the hole on the left of the base. Then line up the top hatch hole and top
base hole and fit the pin in the small bag containing the knob and screw.
c) Fit the washing chamber on the base, placing the pins in the chamber into the holes in the base.
d) Fit the discharge hose which you will find loose in the packing case.
e) Place the two containers on the base brackets: one for clean solvent (right) and the other empty (left) to discharge
the dirty solvent. Fit the tank discharge hose to the empty bin (fitted as at point 7) and the suction hose from the
left (the dirty solvent). Fit the two hoses for the suction of lean solvent from the right.
f) Fit the hose into the chimney to convey fumes outside the room
g) Hook up the compressed air (max 7 bar) to the start-up cock at the top of the chamber. The spray gun washer is
now ready for use.

6
TECHNICAL DATA
Overall weight 35 kg
Overall height (base + washing chamber) 1400 mm
Width 620 mm
Depth 400 mm
Suction nozzle diameter 1.3 mm
Chimney hose diameter 100 mm
Air consumption of the suction nozzle at 8 bar 90 l/min
Air consumption for continuous jet at 8 bar 70 l/min
Air consumption for atomized jet at 8 bar 10 l/min
Max. compressed air pressure 8 bar
Brought Produced by the side faucets (Static pressure: 5 bar) 800 g/min
SAFETY PRECAUTIONS
1. Use goggles and a face mask to protect the eyes and prevent inhaling
2. Wear suitable protective clothing to prevent contact with solvents, toxic fumes or other substances used
3. Before installing the spray gun washer make sure of the presence of an aspirator to carry the solvent fumes
outside
4. A hose should be fitted on the cimney top to the aspirator to make sure fumes are carried outside
5. In cases of skin contact with solvents or paint, see a doctor immediately
6. Do not use halogenized, acid or alkaline solvents
7. The use of some paint products containing organic solvents is dangerous due to the fumes. Read the technical data
sheets for each product before use
8. Make sure the solvent is not corrosive; if you see signs of corrosion stop work and replace the solvent
9. Keep away from sources of sparks, heat and naked flames which may cause a fire
10. Do not exceed the maximum pressure specified with technical data

7
MAINTENANCE
For routine maintenance operations remove the panel separating the washing chamber from the nozzle section, then
carry out the following instructions weekly:
•Clean the tank
•Clean the level with nozzles and tanks; remove the partition as follows: turn the handle and push towards the
washing chamber for about 1 cm. to lower the panel and then remove the partition.
d
fig. 10
fig. 11
f
fig. 12
fig. 13
ee
6
f
fig. 14

8
WARRANTY CERTIFICATE
This warranty covers all parts of the spray gun washers models EASY – EASY/S.
The duration and the conditions of warranty are those laid down by Directive 1999/44/CE of the
Parliament and the Council of May 25, 1999.
In the event of manufacturing defects the spray gun washer must be returned through the original WALMEC SPA
dealer, together this Warranty Certificate indicating where the problem lies and with all sections properly filled in.
This warranty will only be recognised by WALMEC SPA who reserves the right to refuse liabilty
in the following cases:
1. The defects are not the result of detective workmanship, materials or assembly, but arise from incorrect use and
improper maintenance.
2. The spray gun washer has been tampered with, modified or damaged by unauthorized personnel.
3. The spray gun washer has been used or cleaned with unsuitable products or used for other purposes than those for
which it was intended.
4. The defects are the result of normal wear and tear.
5. The spray gun washer has been returned under guarantee without the accompanying Warranty Certificate completed.
DEALER’S STAMP AND DATE OF SALE
PROBLEM FOUND
________________________________________________________
________________________________________________________
________________________________________________________
________________________________________________________
________________________________________________________
________________________________________________________

9
DECLARATION OF CONFORMITY
Description of the equipment: SPRAY GUN WASHERS. Equipments for cleaning of the spray guns
and accessories used for fogging and spraying of coating and finishing products
Models: EASY; EASY/S
Assistance: WALMEC S.p.A. - Via Trieste, 10 - 31025 S. LUCIA DI PIAVE (Treviso) - Italy
WALMEC S.p.A. - Via Trieste 10, 31025 S. LUCIA DI PIAVE (TV) – Italy, manufacturer of
equipments indicated above
DECLARES UNDER ITS ESLCUSIVE RESPONSABILITY
that these equipments comply to the safety requirements fixed by the European Directive 2006/42/CE
(Machinery Directive).
26th July 2010
