WANWAY TECH G19H User manual

G19H
USER MANUAL
Thank you for choosing WanWayTech GPS Tracker. The instruction manual will explain in details how to operate
this device. Please read it carefully before installation. We reserve the rights to change the appearance, color and
accessories of this product without prior notice.

1、Functions and Parameters
1.1 Functions
Location check, geo fence, track playback.
1.2 Parameters
Parameter
Description
GPS chip
MTK6261D
Dimension
72(L)*30(W)*12(H)
GSM frequency
850/900/1800/1900MHZ
GPRS
Class12.TCP/IP build in GSM Module
Chanel
20
Acquisition sensitivity
-144dBm
Tracking sensitivity
-160dBm
Voltage input
9~90V
Working temperature
-20°C to 60°C, can work 4 hours under
80°C
Locating time
Hot＜2SEC(Open Sky)
Warm＜15SEC
Cold＜38SEC(Open Sky)
GSM antenna
Antenna spring
GPS antenna
Built in 18mm*18mm*4mm ceramic
chip antenna
SOS button
NO
Power button
YES
Vibration sensor
YES
Oil/electricity Cut off
YES
Microphone
NO
ACC detection
YES
Power status indication light
RED
GPS light
BLUE
GSM light
GREEN
Built-In Battery
YES
Battery Capacity
55mA
Data uploading port
NO
Function port
NO

Software specification：
Parameter
Description
Parameter setting
SMS, Platform
GPRS uploading interval
10 seconds
Working mode
Always connect to be online
Remotely voice monitoring
NO
Third party query
WEB/APP
SOS button
NO
GEO-FENCE
YES
Remotely cut off power
YES
Cut wire alert
YES
Vibration alert
YES
Remotely hardware status checking
GPS location status(Backend showing)
GSM signal strength (Backend
showing)
2、Accessories and LED working status
2.1Accessories:
Standard Packing: Device+Manual+Warranty Card
2.2 LED working status

3、Installation instructions
3.1 Preparations before installation:
1.Open the box and check whether the equipment model is correct and the
accessories are complete, otherwise please contact your supplier;
2.SIM card selection, the terminal needs to insert a SIM card with normal internet
services.
Notes:
1) Please disconnect the power of the terminal before installing or removing the SIM
card;
2) SIM card needs to enable GPRS function；
3) The SIM card needs to enable the caller ID display function;
4) Please make sure the SIM card is at service.
3.2 Instruction

4、Trouble Shooting
After the terminal is installed for the first time, it has been unable to connect to the
background server, and the device is not online. Please check the terminal installation:
Please refer to the following problems and solutions to do trouble shooting; if the
problem still cannot be solved, please contact your supplier.
Common issues
Description
Solutions
Poor signal
Device is under poor
signal areas like
basement and tunnels.
Move to open sky areas
Platform showing
Inactive
SIM Card not inserted
properly
Yellow light long bright;
Check SIM Card
LED Status
Check LED blinking status

SIM Card not enabled
with GPRS functions
Contact SimCard provider
Wrong Location
GPS not located
Move to open sky areas
Vehicle keeps showing
static
Drive out to open sky area
and test
Platform showing
offline
SIM Card problem
Check SIMCard status
Poor signal
Move to open sky areas
