Webasto Cool Top Vario 10 E User manual

Standklimaanlage
Parking Cooler
Climatiseur de toit
autonome
Condizionatore da
parcheggio
Aire Acondicionado
autónomo
Standairco
Klimatyzacja postojowa
Nezávislá klimatizácia
Einbauanweisung
Installation Instructions
Notice de montage
Istruzioni di montaggio
Instrucciones de montaje
Montagehandleiding
Instrukcja montażu
Návod na montáž
Cool Top Vario 10 E

Cool Top Vario 10 E
To install and repair Webasto heating and cooling systems you need to have completed a Webasto
training course and have the appropriate technical documentation, special tools and special
equipment.
Only genuine Webasto parts may be used.
NEVER try to install or repair Webasto heating or cooling systems if you have not completed a
Webasto training course, you do not have the necessary technical skills and you do not have the
technical documentation, tools and equipment available to ensure that you can complete the
installation and repair work properly.
ALWAYS carefully follow Webasto installation and repair instructions and heed all WARNINGS.
Webasto rejects any liability for problems and damage caused by the system being installed by
untrained personnel.

Cool Top Vario 10 E
Table of Contents
1 General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.1 Contents and purpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.2 Meaning of signal words . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.3 Additional documents to be used. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.4 Description of parking cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.5 Conditions for installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.1 General safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.2 Exclusion of liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.3 Proper use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.4 Improper use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.1 Delivery scope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.1.1 Cool Top Vario 10 E Parking cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.1.2 Installation kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.2 Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.3 Mechanical installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.4 Put parking cooler into operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.5 Advanced settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.5.1 Setting of the switch-off limit for low battery voltage (F1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.5.2 Setting of the switch-on limit for low battery voltage (F2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.5.3 Setting of the minimum display brightness (F3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.5.4 Setting of the maximum display brightness (F4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.6 Treatment of surfaces. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4 Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.1 Disposing of packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.2 Disposing of used parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5 Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

1 General information Cool Top Vario 10 E
10
1 General information
1.1 Contents and purpose
These installation instructions contain important
information on installation, commissioning and
troubleshooting of the Cool Top Vario 10 E parking cooler.
1.2 Meaning of signal words
In these instructions the signal words DANGER,CAUTION,
NOTE and ENVIRONMENTAL NOTE have the following
meaning:
DANGER
Danger to life and limb.
CAUTION
Danger of damage.
NOTE
This heading is used to point out a special
feature or aspect.
ENVIRONMENTAL NOTE
Information on environmental protection.
1.3 Additional documents to be used
For additional information, in particular on start-up and
operation of the parking cooler, see the Cool Top Vario 10
E operating instructions.
1.4 Description of parking cooler
The parking cooler is mounted on top of a lorry driver's cab
in place of an existing roof hatch.
The Cool Top Vario 10 E parking cooler cools the driver
compartment of the lorry driver's cab according to the
recirculating air principle: Warm air is sucked in from the
driver compartment, cooled by the heat exchanger of the
parking cooler and routed back into the driver
compartment. The operation of the parking cooler does not
result in any fresh air being fed in.
To prevent the vehicle battery from being too heavily
drained by the operation of the parking cooler, the parking
cooler is equipped with a battery protection function. The
voltage value at which the battery protection function
switches off the parking cooler can be set.
1.5 Conditions for installation
Time required: Approximately two to three working hours.
At times two persons are required for installation (mounting
and aligning the parking cooler).
A suitable lifting device is required to lift the parking cooler
onto the roof of the lorry driver's cab. A travelling crane or
forklift truck are best suited for this purpose. No further
special tools are required for the installation.

Cool Top Vario 10 E 2 Safety
11
2Safety
2.1 General safety precautions
The parking cooler may only be installed by persons who are
authorised to carry out work on the electrical system or on
the body of lorries.
At times, two persons are required to install the parking
cooler.
Use a suitable lifting device to lift the parking cooler onto
the vehicle roof.
Do not walk on the vehicle roof.
Do not make any technical changes to the parking cooler.
The parking cooler may only be opened, repaired or serviced
by instructed service personnel.
Do not operate the parking cooler if it is damaged
externally.
Only wash vehicle equipped with the Cool Top Vario 10 E
parking cooler if the upper washing brush has been
switched off. Make sure that the parking cooler is switched
off while washing the vehicle.
Make sure that the parking cooler is switched off before the
driver's cab (e.g. maintenance work on the vehicle) is tilted.
If the Cool Top Vario 10 E parking cooler is tilted by more
than 30° out of the normal position, (for example, during
installation or when the driver's cab has been tilted), a
waiting time of at least two hours must be complied with
before switching it on. Otherwise, a malfunction can occur.
The parking cooler may only be used for the purpose
described in Section 2.3, "Proper use".
Make sure that no flammable materials are located closer
than 50 cm to the air outlet opening during operation.
Make sure that no flammable gases, liquids or other objects
can get into the parking cooler.
If the parking cooler catches on fire, use a powder or foam
extinguisher (not water).
Please note that following installation, the vehicle height
may have changed and a corresponding change in the
vehicle registration papers may be required.
2.2 Exclusion of liability
Webasto shall assume no liability for damage due to the
following points:
• Use for any purpose other than those described
in the operating instructions.
• Changes to the parking cooler without the
explicit approval of Webasto.
• Damage to the parking cooler by external
influences.
DANGER
Please read these installation instructions
carefully before putting the parking cooler
into operation. In particular, be sure to
observe the following general safety
precautions and the special safety precautions
in the individual chapters.
ENVIRONMENTAL NOTE
Also observe the information on disposal.

2 Safety Cool Top Vario 10 E
12
2.3 Proper use
The Cool Top Vario 10 E parking cooler is intended for
cooling lorry driver's cabs while parked. As a result, the
environmentally harmful running of the engine to operate
the vehicle air-conditioning system can be avoided.
The parking cooler can also be used during driving, however
does not replace the vehicle air-conditioning system.
The parking cooler can be used independently of the
operation of the vehicle air-conditioning system.
Optimum climate control and energy utilisation are achieved
when the driver's cab is pre-cooled with the vehicle air-
conditioning system before using the parking cooler.
Operate the Cool Top Vario 10 E approx. 5 minutes
together with the vehicle air-conditioning system before
using it while parked to dissipate stored heat.
2.4 Improper use
The parking cooler is not suitable for use in agricultural
machines or construction machines.
DANGER
In case of improper use of the parking cooler,
there is a danger of injuries or damage.

Cool Top Vario 10 E 3 Installation
13
3 Installation
3.1 Delivery scope
3.1.1 Cool Top Vario 10 E Parking cooler 3.1.2 Installation kit
Fig. 1
8
1 3 4 5 13
7
6 2 10 9 11 12
Item Designation Quantity
1 Parking cooler 1
2 Power supply cable, 5 m 1
3 Remote control 1
4 Type AAA battery 2
5 Operating instructions 1
Item Designation Quantity
6 Cabin cover 1
7 Mounting bar 2
8 EPDM seal 1
9 Nut, self-locking, M8
For Volvo: M8x40 screws, incl.
cover caps
4
4
10 Nut, plastic, M8 4
11 Washer 4
12 Spacer sleeve
For Volvo and Renault Premium
For Scania
4
2
0
13 Installation Instructions 1

3 Installation Cool Top Vario 10 E
14
3.2 Electrical connection
The power supply cable of the parking cooler runs from the
fuse box in the passenger footwell to the front of the
parking cooler.
1. Disconnect batteries.
2. Remove the interior trim of the roof hatch.
3. Route the power supply cable from the fuse box
in the passenger footwell to the front of the
parking cooler and connect.
4. Connect the power supply cable to the parking
cooler and the fuse box.
3.3 Mechanical installation
The parking cooler is mounted in place of an existing roof
hatch.
Before installing the parking cooler, it must be checked
whether the parking cooler can be operated together with
a roof spoiler which may be present. If modifications are
required, it must be noted that the vehicle homologation
may be voided by removing, installing a new or modifying
an existing roof spoiler. This requires an approval by a
recognised test organisation. Contact the vehicle
manufacturer, the manufacturer of the roof spoiler or a
recognised test organisation for more detailed information
on this subject. The parking cooler cannot be modified.
1. Remove the existing roof hatch together with all
fastening parts and sealing materials.
2. Clean and degrease the sealing surface.
3. Glue on the EPDM gasket around the rear roof
hatch cut-out in the centre beginning outside.
4. Cut off the start and end of the EPDM gasket
with an angled cut so that the largest common
cross-sectional area results.
5. Glue the cross-sectional areas of the EPDM
gasket with windows sealant (butyl sealant).
6. Remove the protective film from the hood
surface of the parking cooler.
7. Lift the parking cooler onto the roof of the
driver's cab with a suitable lifting device.
8. Align the parking cooler centred to the right and
left side and carefully place it on the roof hatch
opening.
In case of any existing roof extension (e.g. aerial),
position the parking cooler so that it is a
sufficient distance from the roof extensions.
8.1. For Scania: Move parking cooler 25 mm to
left seen in driving direction.
9. Check whether the screw bolts are firmly
screwed into the parking cooler.
SHORT CIRCUIT AND DANGER OF FIRE
Always disconnect the batteries before
working on the electrical system.
CAUTION
The connection line for an electric roof hatch
installed at the factory may not be used for the
power supply of the parking cooler, as the line
cross-section is not sufficient for this purpose.
Use the power supply cable provided.
If the power supply cable provided must be
extended, use cables with a sufficient line
cross-section.
Do not route the power supply cable near
signal lines or control lines.
Route the power supply cable so that no
tensile loading is exerted on it during
operation. Use strain-relief clamps if
necessary.
Do not kink the power supply cable or route it
over sharp edges. Use plastic grommets or a
protective pipe if necessary.
CAUTION
The connection of the parking cooler to the
vehicle power supply must be carried out with
a sufficiently dimensioned fuse (see DIN
72581).
ACCIDENT DANGER
When working on the vehicle roof there is a
danger of accidents occurring from persons
falling or from falling objects. Ensure secure
holding of persons and raised loads during
installation. Use only suitable lifting devices
during installation. A travelling crane is best
suited for this purpose.
ENVIRONMENTAL NOTE
Dispose of all waste resulting during
installation in an environmentally friendly
manner.

Cool Top Vario 10 E 3 Installation
15
10. Align the parking cooler on the inside roof trim of
the vehicle. This can vary depending on the
vehicle model.
11. Position the mounting bars on the screw bolts so
that the greatest possible contact surface is
provided at the front and rear. The mounting
bars must be mounted between the inside roof
trim and the roof skin.
12. Screw four self-locking nuts with washers onto
the studs and tighten diagonally with 5 Nm.
13. Connect the power supply cable to the parking
cooler.
14. Position spacer sleeves on all four screw bolt of
the parking cooler.
14.1. For Renault Premium: Two spacer sleeve
are positioned on the front screw bolts of
the parking cooler.
14.2. For Scania: No spacer sleeves are used.
15. Place the interior trim provided on the studs and
screw it on with four plastic nuts.
15.1. For Volvo: Use four M8 screws. Mount
cover caps on the screw heads.
16. Connect the power supply cable to the fuse box
in the passenger footwell.
17. Connect the batteries and conduct an operating
test.
3.4 Put parking cooler into operation
For information on start-up and operation of the parking
cooler, see the operating instructions.
3.5 Advanced settings
The advanced settings enable adjustment to special
environmental conditions (F1, F2, F3, F4, F5) and service
settings (F6, F7, F8).
The service menus (F6, F7, F8) should only be changed by
trained service personnel.
The following advanced settings are possible:
•F1
Setting of the switch-off limit for low battery
voltage
•F2
Setting of the switch-on limit for low battery
voltage
•F3
Setting of the minimum display brightness
•F4
Setting of the maximum display brightness
•F5
Controller offset = temperature difference
between target and actual temperature (six 1 °C
steps).
•F6
Memory for communication status of parking
cooler.
•F7
Memory for operating status of parking cooler.
•F8
Factory settings
To access the Settings menu:
1. Briefly press the On/Off button on the control
panel to access the stand-by mode.
2. Press the Temperature +and Temperature –
buttons on the control panel simultaneously.
3. The Settings menu is active. F1 appears on the
display.
To change between the settings F1 to F9, press the
Temperature +or Temperature –button on the control
panel. Then activate the desired setting by pressing the
Timer button on the control panel.
To change the value of the selected setting, press the Fan +
or Fan –button on the control panel.
CAUTION
If the Cool Top Vario 10 E parking cooler is
tilted by more than 30° out of the normal
position, at least 2 hours must be waited
before switch-on. Otherwise, a malfunction
can occur.

3 Installation Cool Top Vario 10 E
16
3.5.1 Setting of the switch-off limit for low
battery voltage (F1)
In this setting the voltage value is set at which the parking
cooler is automatically switched off as soon as the value is
dropped below.
• Setting range: 20.1 to 25.0 V.
• Factory setting: 23.5 V.
1. Call setting F1.
2. To change the value, press the Fan +or Fan –
button on the control panel.
3. Confirm the desired value by pressing the Timer
button on the control panel.
3.5.2 Setting of the switch-on limit for low
battery voltage (F2)
In this setting the voltage value is set at which the parking
cooler can be switched on again (after an automatic switch-
off due to low battery voltage has taken place).
• The switch-on voltage must be at least 1.5 V over
the switch-off voltage.
• Setting range: 21.6 to 26.5 V.
• Factory setting: 25 V.
1. Call setting F2.
2. To change the value, press the Fan +or Fan –
button on the control panel.
3. Confirm the desired value by pressing the Timer
button on the control panel.
3.5.3 Setting of the minimum display
brightness (F3)
The display brightness is automatically adjusted to the
ambient brightness. The minimum display brightness can be
set.
• Setting range: six levels, however not greater
than the maximum brightness (F4).
• Factory setting: Level 2.
1. Call setting F3.
2. To change the value, press the Fan +or Fan –
button on the control panel.
3. Confirm the desired value by pressing the Timer
button on the control panel.
3.5.4 Setting of the maximum display
brightness (F4)
The display brightness is automatically adjusted to the
ambient brightness. The maximum display brightness can be
set.
• Setting range: six levels, however not less than
the minimum brightness (F3).
• Factory setting: Level 6.
CAUTION
If the parking cooler is switched off due to low
battery voltage, the battery must be recharged
as soon as possible. If the battery continues to
be discharged, the battery voltage may not be
sufficient to start the engine.

Cool Top Vario 10 E 3 Installation
17
1. Call setting F4.
2. To change the value, press the Fan +or Fan –
button on the control panel.
3. Confirm the desired value by pressing the Timer
button on the control panel.
3.6 Treatment of surfaces
The outside of the parking cooler consists of a PMMA
surface. This can be painted with water-soluble paints
(acrylic paints). For more detailed information on painting,
we recommend contacting the paint manufacturer. The
manufacturer of the parking cooler is not liable for damage
caused by incorrectly executed painting. The surface should
be painted with light colours if possible for optimum
efficiency of the parking cooler.
The surfaces of the parking cooler can be cleaned with
water (maximum of 70 °C) and a common household
washing-up liquid.
Household cleaners can be used for heavier soiling. Observe
the information of the cleaning agent manufacturer.
However, do not use cleaning agents which contain
chemical solvents or abrasive ingredients.
During cleaning, make sure that no liquid gets into the
inside of the parking air conditioner.

4 Environment Cool Top Vario 10 E
18
4 Environment
4.1 Disposing of packaging
Separate the packaging materials into cardboard and
plastic.
Bring the sorted packaging materials to an appropriate
recycling centre.
4.2 Disposing of used parts
Contact a specialist company for disposal of hazardous
waste or contact Webasto to dispose of used parts.
5 Technical Data
The technical data are contained in the operating
instructions.
ENVIRONMENTAL NOTE
Also observe the official waste disposal
regulations.

Im Fall einer mehrsprachigen Version ist Deutsch verbindlich.
In multilingual versions the German language is binding.
Dans le cas d'une version rédigée en plusieurs langues, l'al-
lemand est alors la langue qui fait foi.
Nel caso di una versione plurilingue il tedesco è vincolante.
Este manual esta traducido en varios idiomas, le informamos
que sólo la versión en alemán será vinculante.
Bij een meertalige versie is de Duitse versie bindend.
W przypadku wersji kilkujęzycznej wiążący jest tekst w
języku niemieckim.
V prípade nesúladu jazykových verzií je záväzná
nemecká.
Ident-Nr. 2012112A • 03/12 • Änderungen und Irrtümer vorbehalten • © Webasto AG, GCS 2012
Webasto AG
Postfach 80
D - 82132 Stockdorf
Germany
National:
Hotline: [phone]
(€0,14/Min. aus dem deutschen Festnetz)
Hotfax: 0395 5592 353
Hotmail: technikcente[email protected]
www.webasto.de
International:
www.webasto.com
http://dealers.webasto.com
