Westeel EasyDry Wide-Corr Centurion 24 Series User manual

Read this manual before using product. Failure to
follow instructions and safety precautions can
result in serious injury, death, or property
damage. Keep manual for future reference.
Part Number: 250050 R1
Revised: July 2019
EasyDry® Wide-Corr Centurion®
Grain Bin
Grain Bin Dryer
Installation and Operator’s Instructions
This manual applies to the following grain bin models:
2407 — 2410
2707 — 2712
3008 — 3012
3608 — 3612
Original Instructions
