ORIGO HD-03S User manual

2合1乾衣乾鞋機
: HD-03S
: 220-230伏特~, 50赫茲
: 150 瓦特
型號
電壓
功率
清潔保養
1) 清潔前必須拔除電源插頭，切斷電源。
2) 清理時切勿將主機體浸於水或其他液體中。
3)
4) 可使用濕布加入少許溫和的清潔劑擦淨。
使用方式
1) 將乾衣機掛在衣帽架，晾衣架或晾衣物掛附物品上。
2) 將插頭插入電壓220-230 伏特的獨立插座，然後乾衣機進入
待機狀態，藍燈閃爍。
3) 按下開/關按鈕一次，藍燈停止閃爍並變為紅燈，表示乾衣機
開始運作並設置為熱風模式。
4) 再按下開/關按鈕，設置轉為冷風模式，藍燈亮起。
5) 如需關閉乾衣機，請再按下開/關按鈕。
6) 當乾衣機進入熱風模式後，持續運作3小時會自動轉換為冷風
各部名稱 儲存：連同使用說明書，把乾衣機存放於清涼及乾爽地方。
安裝步驟
1) 將衣架插入乾衣風管。2) 打開折疊掛勾並推上至
乾衣機的頂部。
3) 使用乾鞋模式時，請先
將衣架從乾衣風管拔除。
4) 將乾鞋風管插入乾衣風
管，並在出風口塞上矽
膠塞，以免熱量散失。
安全注意事項安全注意事項
1) 使用本產品前，請小心閱讀說明書並保留給將來翻閱。
2) 使用本產品前，請確定規格標貼上標示的額定電壓與當地供
電電壓相同。如有疑問可向服務中心查詢。
3) 本機不是為體質、感覺或智力有障礙人士(包括小孩)或缺乏
經驗及知識者使用，除非他們曾經接受負責安全人士的監督
或指示。大人應指導小孩不可把玩電器。
4) 本產品只可以用附設的電源線使用。
5) 使用前請先拆除所有包裝物料。
6) 本產品不可放於潮濕或有積水的地方使用。
7) 本產品應放在遠離發熱源頭的位置使用。
8) 本產品不可於室外使用。
9) 本產品設計只適合家居使用。
10) 乾衣前，務必先將衣物脫水，避免出現水珠下滴，弄濕機
身或地面而造成危險，同時亦可縮短乾衣時間。
11) 使用本產品時，切勿觸摸風管及出風口，以免燙傷。
12) 本乾衣機僅供乾燥用水洗滌的衣物使用。
13) 乾衣前，應注意衣物上的標籤，認清該衣物是否可使用乾
衣機及使用溫度限制。
14) 請勿蓋住出入風口以免本機過熱。
15) 經常檢查本產品。如發現有任何損壞，例如電源線損毀，
應立即停止使用，並交由指定維修服務中心檢查及修理。
16) 若乾衣機長期沒有使用或需要在潮濕季節使用。乾衣前，
請使用熱風模式10分鐘，把乾衣機預先吹乾。
保用
本機可獲自購買或領取日起1年免費保用(商業用途享有三個月
免費保用)。此保用只包含生產所導致的品質問題；並不包括
乾衣風管、乾鞋風管及其他附件，因誤用或不依說明書指示使
用而導致的損壞。
服務中心
源澤市務有限公司
香港新界葵涌青山公路403號
匯城集團大廈21樓H室(近華星街12號)
電話：2156 8238
辦公時間
上午10:30 -下午12:30 (星期一至五)
下午02:30 -下午05:30 (星期一至五)
上午10:30 -下午12:30 (星期六)
(星期日及公眾假期休息)
源澤地圖
費延長保用期3個月，即15個月免費保用(商業用途除外)。請即登
入網站 : www.origo.hk
注意：保用時，須帶同收據及請先致電服務中心。
***額外3個月保用: 凡於購買產品後10天內完成網上登記，即可免
折疊掛勾
入風口
指示燈
乾衣風管
右臂
乾鞋風管矽膠塞
開關鍵
乾衣風管
左臂
出風口衣架
衣物掛附
1) 將衣物放在衣架上，然後扣上扣子或或拉上拉鏈，以形成良好
的空氣流通空間。
2) 請勿遮蓋衣架頂部的入風口，以免造成不良影響或引致乾衣機
過熱或關閉。
3) 要掛上內衣、內褲、襪子或其他個人衣物，請用衣夾夾住，然
後將衣物掛在衣架下面。
模式並持續運作5小時後自動轉換為待機狀態。
若乾衣機不小心掉入水中，請立即拔掉電源。拔掉所有配件後，
輕搖主機體，排走機內積水。把主機體放於空氣流通的位置24
小時，直至機內切底風乾。
可使用軟毛刷清理各出風口，並啟動冷風模式將藏於出風口
的碎屑(布屑、塵埃.....)吹出。
警告：嚴禁覆蓋機頂入風口
白底黑字, 中英各一面, 風琴
摺, A4 SIZE, 120g紙或以上

2 in1 Clothes & Shoes Dryer
: HD-03S
: 220-230V~, 50Hz
: 150W
Model
Voltage
Power
Maintance and Care
1) Unplug the power cord before cleaning.
2) Do not immerse the Dryer in water, it may cause electric
shocks.
3) Clean the Dryer with a soft cloth. To remove presistent dirt,
wipe down with a cloth that has been dampened with warm
soapy water.
4) Clean the air outlet by brush and turn the cold wind mode on
to blow the scraps(cotton lint, dust.....) out.
Warranty
This product is guaranteed for 1 year (commercial use for 3
months)from the date of receipt against manufacturing defect.
The warranty does not cover the hanger, shoe pole and other
accessories, damage or defect caused by negligence or use not
according to this instruction manual.
1) Put the cloth dryer to hang onto the hallstand, clotheshorse
or other objects that can satisfy the need to hang the clothes
up.
2) Plug the power cord into a 220-230V~ electrical outlet, and
then the cloth dryer is on standby with the blue light flashing.
3) Press the On/Off button, the blue light stop flashing and turns
into red light means the cloth dryer switch on and setting to
hot wind mode.
4) Press the On/Off button twice to turn to cold wind mode with
blue light.
5) Press the On/Off button three time to turn the cloth dryer off.
6) When the cloth dryer enters into working state, it will blow
hot wind and last for 3 hours, then automatically turn to cold
wind mode and last for 5 hours.
Remark: For repair service, please contact and bring alone the
invoice or receipt to the Service Centre.
***Extra 3 months warranty: just complete Online Warranty
Registration within 10 days from the date of receipt, free
warranty will be extended to 15 months (not applicable to
commercial use). Please enter our website: www.origo.hk
Operation
STORAGE: Store the Dryer with these instructions in the original
box in a cool and dry place.
Installation
1) Insert the hangers into the
air outlet of the poles.
2) Open the folding hook and
pull it on the top of cloth
dryer.
3) For drying the shoes,
please disconnect the
hanger from the air
outlet of the pole.
4) Insert the shoe pole into
the clothes dryer and use
the silica gel stopper
blocking the air outlet
to avoid hot air run off.
Main Parts
Caution
1) Read all instructions carefully before using the Clothes Dryer.
Appropriately keep it for furture reference when necessary.
2) Before using the Dryer, check if the volatage marked on
the rating label corresponds to the mains in your home.
3) This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not
play with the appliance.
4) Only the provided power cord can be used.
5) Remove all the package before using the Dryer.
6) The Dryer is not intended for use in wet or damp locations.
7) Keep the Dryer away from heat source.
8) Do not use the Dryer in outdoor location.
9) The Dryer is designed for domestic use only.
10) Ensure spin-drying completely before using the Dryer.
11) To avoid being scalded, never touch the pole on the air
outlet during drying process.
12) This Dryer is intended only for drying textiles washed in
water.
13) Check the clothing care label before drying, Make sure they
can be dried using the drying machine, pay special attention
to its temperature limits.
14) Do not cover the air inlet to avoid overheating.
15) Always check the Dryer, if the power cord is damaged, it
must be replaced and repaired by authorized service agent.
16) If the Dryer hasn’t been used for a long time or it needs to be
used in wet season, please turn the hot wind mode on and
let it operate for about 10 minutes to dry the Dryer.
Service Centre
ORIGIN MARKRTING LIMITED
Unit H,21/F, Reason Group Tower
(nearby 12 Wah Sing Street), 403 Castle Peak Road,
Kwai Chung, N.T., Hong Kong.
Tel: [phone]
Office Hours
10:30am - 12:30pm (Mon ~ Fri)
02:30pm - 05:30pm (Mon ~ Fri)
10:30am - 12:30pm (Sat)
(Closed on Sunday and Holiday
Origin Map
Folding Hook
Air Inlet
Indicator Light
Air Outlet On
Right Pole
Shoe PoleSilica Gel
Stopper
On/Off Button
Air Outlet On
Left Pole
Air OutletHanger
1) Put the cloth on the hanger and button up or zip up the cloth
to make sure there is a room for air flow.
2) Do not cover the air inlet on the top of the hanger to avoid
resulting adverse effects or the cloth dryer being overheat and
shutting down.
3) To hang unerwear, socks or other personal clothing, please
use the clothespins to clamp them and then them under the
hanger.
Clothes Hanging
If the dryer falls into water, please unplug the power immediately,
disassemble the poles and shake the main body lightly to drain
out the water, lay it on a place where ventilation is fine for 24
hours to evaporate the remaining water.
白底黑字, 中英各一面, 風琴
摺, A4 SIZE, 120g紙或以上
WARNING: Don’t cover the inlet on the top
