WineEnthusiast 48-Bottle 2-Temp Silent Wine Refrigerator User manual

48-Bottle 2-Temp
Silent Wine Refrigerator
INSTRUCTION MANUAL
Please read carefully and follow all safety rules
and operating instructions.
WineEnthusiast.com
800.356.8466

Table of Contents
Structure and Electro Circuit Control Diagram ...…………...… page 2
Technical Data………………………………………………..... page 3
Important Safety Instructions………………………………….. page 4
Installation Instructions............................................................... page 5
Stainless Steel Handle Installation…………………………...... page 6
Electrical Connection………………………………………….. page 7
Operating your Wine Refrigerator……………………………... page 8
Care and Maintenance…………………………………………. page 9
Troubleshooting Guide………………………………………… page 10
Limited Warranty………………………………………………. page 11
1

Structure
1. Fan Mask 6. Light On/Off Button
2. Shelf 7. Gasket
3. Water Box 8. Door
4. Hinge Cover 9. Door Handle
5. Temperature Control Button 10. Foot
Electro Circuit Control Diagram
2

Technical Data
Model No. 48-Bottle 2-Temp Silent Wine
Refrigerator
Capacity 140L
Voltage 110V
Current 2A (@77°F)
Protection Class I
Frequency 60Hz
Climate Class SN ; N
Input Power 155W (@77°F)
Power Consumption
KW · h/24h
1.8
(@59°F)
Max Temperature Difference Left Zone: >59°F
Right Zone: >55.4°F
Temperature Control Range Left Zone: 50-64.4°F
Right Zone: 53.6-64.4°F
Approx. Net Weight 89.3LBS
Approx. Gross Weight 103.2LBS
Approx. Shape Size
(H x W x D) inch 27.5" x 33.3" x20.2"
Approx. Packing Size
(H x W x D) inch 32.8" x 37.2" x 25.2"
3

IMPORTANT SAFETY INSTRUCTIONS
WARNING
To reduce the risk of fire, electrical shock,
or injury when using your appliance,
follow these basic precautions;
zRead all instructions before using the wine refrigerator.
zDANGER or WARNING: Risk of child entrapment.
zChild entrapment and suffocation are not problems of the past. Junked or
abandoned appliances are still dangerous…even if they will “just sit in the garage
for a few days.”
zBefore you throw away your old wine refrigerator: Take off the
door. Leave the shelves in place so that children may not easily climb inside.
zNever allow children to operate, play with, or crawl inside the appliance.
zNever clean appliance parts with flammable fluids. The fumes can create a fire
hazard or explosion.
zDo not store or use gasoline or any other flammable vapors and liquids in the
vicinity of this or any other appliances. The fumes can create a fire hazard or
explosion.
-Save these instructions-
4

INSTALLATION INSTRUCTIONS
Before Using Your Wine Refrigerator
zRemove any exterior and interior packing material.
zCheck to be sure the following parts are included:
14 Slide out shelves.
2 Handles and 4 Screws
1 Instruction manual.
zBefore connecting the appliance to the power source, let it stand upright for
approximately 2 hours. This will reduce the possibility of a malfunction in the
cooling system from handling during transportation.
zClean the interior surface with lukewarm water using a soft cloth.
INSTALLINGYOUR WINE REFRIGERATOR
zPlace your appliance on a floor that is strong enough to support the appliance when
it is fully loaded. To level your appliance, adjust the front legs at the bottom of the
appliance.
zKeep away from direct sunlight and excess of heat (stove, heater, radiator, etc.).
Direct sunlight may affect the acrylic coating and heat sources may increase
electrical consumption. Extreme cold or hot ambient temperature may also cause the
appliances not to perform properly.
zThis model is not meant to be built-in to cabinetry, recessed or put underneath a
counter. Additionally this model is not meant to be used in an enclosed area. While
the back of the unit does produce a minimal amount of heat, it still needs to vent to
an open area.
5

How to install your stainless steel door handle
Step 1 Take out the handle from the cellar and remove the plastic
bag. Remember, 4 screws are packed inside the plastic
bag.
Step 2 Pull out a bit of the gasket from the back side of the hole.
Step 3 Insert the screw through the hole and connect with the
handle.
6

ELECTRICALCONNECTION
Warning
Improper use of the grounded plug can result in the risk of electrical shock. If the
power cord is damaged, please contact the Wine Enthusiast..
.
zThis unit should be properly grounded for your safety. The power cord of this unit is
equipped with a 3-pin plug which mates with 3-pin wall outlets to minimize the
possibility of electrical shock. Do not under any circumstances cut or remove the
ground wire from the power cord supplied
zUse of extension cords is not recommended
zThis unit requires a standard 110V ~ 60Hz electrical outlet with 3-pin plug.
zThe cord should be secured behind the wine refrigerator and not left exposed or
dangling to prevent accidental injury.
IMPORTANT SAFEGUARDS
Do not store food in wine refrigerator, as interior temperature may not get cool enough to
prevent spoilage.
7

OPERATINGYOUR WINE REFRIGERATOR
It is recommended that you keep the wine refrigerator in a place where the ambient
temperature is between 70-75°F. If the ambient temperature is above or below
recommended temperature, the performance of the unit may be affected. For example,
placing in extreme cold or hot conditions may cause interior temperature to fluctuate. The
range of 50-66°F may not be reached.
The display reflects the temperature at the center of the wine refrigerator. Temperature
may fluctuate approximate +/-7 degrees at the top to the bottom.
The temperature may fluctuate depending on whether or not the interior light is on or off
or whether the bottles are located on the upper/middle or lower section.
How to use the press-buttons on the Display Panel:
You can set the temperature as you desire by using the press buttons. Use the “▲” and
“▼” to adjust the temperature by 1°F among 50-66°F. You can turn the interior light on or
off by pressing the “light” button.
8

CARE AND MAINTENANCE
Cleaning Your Wine Refrigerator
zUnplug the wine refrigerator and remove the bottles.
zWash the inside with a warm water and baking soda solution. The solution should be
about 2 tablespoons of baking soda to a quart of water.
zThe outside of the wine refrigerator should be cleaned with mild detergent and warm
water.
zUnscrew the water box at the bottom, and wash it.
Storage
Shelving is meant to hold standard 750ml size bottles, using larger Pinot Noir / Rhone size
bottles may limit the capacity. If you would like to store larger bottles you can easily
remove any of the shelves. This will also prevent scraping the labels on the larger bottles.
Our wine Refrigerators are made to store your wine at the perfect temperature. The
proper storing temperature for the all wine, both red and white, is 53°F - 57°F.
Moving Your Wine Refrigerator
zRemove all the bottles.
zSecurely tape down the shelves inside your wine refrigerator.
zSpin the leveling legs up to the base to avoid damage.
zTape the door shut
zBe sure the wine refrigerator stays in the upright position during transportation.
9

PROBLEM WITH YOUR WINE REFRIGERATOR?
You can solve many common wine refrigerator problems easily, saving you
the cost of a possible service call. Try the suggestions below to see if you
can solve the problem before calling Wine Enthusiast customer service.
TROUBLESHOOTING GUIDE
PROBLEM POSSIBLE CAUSE
Wine refrigerator
does not operate.
Not plugged in.
The circuit breaker tripped or a blown fuse in your
home.
Wine refrigerator is
not cold enough.
Check the temperature control setting.
External environment may be too hot.
The door is opened too often.
The door is not closed completely.
The door seal does not seal properly.
The wine refrigerator does not have the correct
clearances.
The light does not work. Call the service center.
Vibrations. Check to assure that the wine refrigerator is level.
The wine refrigerator seems
to make too much noise.
The wine refrigerator is not level.
Check the fan.
The door will not close
properly.
The wine refrigerator is not level.
The doors were reversed and not properly installed.
The seal is weak.
The shelves are out of position.
LED could not display. Main control board does not work.
Press-buttons are
not functional. Control panel is damaged.
10

zUpon receipt of unit and inspection, if supply cord is damaged, it must be
replaced. Contact customer service at Wine Enthusiast for assistance. For
any additional technical service, please contact Wine Enthusiast at
800.648.6058.
The limited warranty does not cover: Damage due to such things as accident,
misuse, abuse, mishandling, neglect, unauthorized repair or any other cause
beyond the control of the seller whether similar or dissimilar to the foregoing.
Purchaser understands and acknowledges that the goods sold here are wine
refrigerators, which house wine. Purchaser assumes all the risk of using these
units, including risk of spoilage, humidity variations, temperature variations, leaks,
fires, water damage, mold, mildew, dryness and similar perils that may occur.
zWARNING : Please do not use where children can touch the unit, nor let
children use the unit by themselves.
Limited warranty – 90 day replacement plan with a free 9 month upgrade, totaling
1 year, on parts and labor from the date of shipment. For customer service, please
contact Wine Enthusiast by e-mail ([e-mail]) or by phone
(800.648.6058).
Please speak to your Retailer before calling Wine Enthusiast if you did not
purchase your Wine Cellar directly from Wine Enthusiast.
SERVICE & IMPORTANT NOTICE
LIMITED WARRANTY
11
