Wireless Technologies WTE TReX User manual
TReX User Manual v2.14 Firmware
Table of Contents
Intro uction...............................................5
TReX Features........................................5
TReX Versions........................................6
Safety Information.....................................8
Operation..................................................12
Buttons......................................................13
MENU/BACK:.....................................13
UP:........................................................13
DOWN:.................................................13
RIGHT:.................................................13
ENTER:................................................13
Main Screens............................................14
IO Screens.............................................15
TX Screens............................................17
RX Screens...........................................19
Site Configuration Tools..........................21
Spectrum Analyser................................21
Demodulated Signal Viewer.................22
Two-Way Paging......................................23
Configuration Metho s...........................24
Front Panel Menu Configuration..........25
Web Browser Configuration.................27
Serial Command Configuration............29
MENU Configuration..............................31
SYSTEM Menu....................................33
TEST Sub Menu...................................36
FACTORY Sub Menu...........................37
TIME Sub Menu...................................38
SPECTRUM Menu...............................39
RX Menu...............................................41
FILTERS..........................................43
Protocol Menu.......................................46
TCP-IP Menu........................................47
Telemetry Menu....................................49
SERIAL LINK Menu............................51
STORE FWD Menu..............................52
Inputs Menu..........................................53
ADC CAL Sub-Menu...........................54
Input Config Sub-Menu...................56
Outputs Menu.......................................59
Output Config Sub-Menu.................61
DAC CAL Sub-Menu.......................62
Serial Comman Configuration.............64
Main Commands...................................64
*REBOOT........................................64
*CONFIG.........................................64
*SAVE..............................................64
*LIST...............................................64
*DEFAULTS....................................64
*RSSI...............................................65
*USERPASS....................................65
*IO....................................................65
*TEMP.............................................66
*PWR...............................................66
*VER................................................66
*BYPASS.........................................66
*LAB................................................67
Transmit Commands.............................68
*TX_FREQ......................................68
*TX_PROTO...................................68
*TX_BAUD.....................................68
*TX_MODE.....................................68
*TX_LEVEL....................................69
*TX_CAP.........................................69
*TX_PERIODIC..............................69
*TX_PREAMBLE...........................69
*TX_LEAD......................................70
Receive Commands..............................71
*RX_ENABLE................................71
*RX_FREQ......................................71
*RX_BAUD.....................................71
*RX_PROTO...................................71
*RX_MODE....................................71
*RX_RANGE..................................72
*RX_BUSY......................................72
Store Forward Commands....................73
*STORE_FWD................................73
Input Commands...................................74
*IN_CONFIG_L..............................74
*IN_CONFIG_H..............................74
*IN_MSG_L....................................75
*IN_MSG_H....................................75
*IN_ANALOG.................................75
Output Commands................................77
*OUT_CONFIG...............................77
*UNIT_ID........................................77
System Commands...............................78
*TREX_LANG................................78
*TREX_BACKLIGHT....................78
*TREX_SOUND..............................78
*TREX_RS232_BAUD...................78
*TREX_RS422_BAUD...................79
© WTE Limited, 2018 Christchurch New Zealand Page 2 of 158
TReX User Manual v2.14 Firmware
*TREX_ALERT_OUT....................79
*TREX_ALERT...............................79
*TREX_FILTERS............................79
*TREX_TELEMETRY....................80
*TREX_SCREEN............................80
*TREX_PIN.....................................80
*TREX_AN_CAL............................81
*TREX_MISMATCH......................81
TCP-IP Commands...............................83
*IP_ENABLE..................................83
*IP_HOST........................................83
*IP_ADD.........................................83
*IP_PORT........................................83
*IP_MASK.......................................84
*IP_GATE........................................84
*IP_DNS..........................................84
*IP_MAC.........................................84
Protocols...................................................85
WT Protocol..........................................85
Variable Content Macros..................88
Modbus.................................................89
Modbus RTU....................................89
Modbus TCP....................................89
Function Codes.................................89
Modbus Mapping Table...................90
Custom Protocol...................................92
Custom Protocol Response..............95
Custom Protocol Output...................95
RAW Protocol.......................................97
SCADA Support.......................................99
Terminology..........................................99
SCADA System Single TReX
Configuration......................................101
Unit Configuration.........................102
SCADA System Multiple TReX
Configuration......................................103
Units Configuration........................104
Viewing Multiple TReX Unit IO on the
MASTER Unit....................................106
SCADA Communication Between
MASTER and SLAVE........................107
IO Mirror Operation.............................108
Input Han ling.......................................110
Output Han ling....................................112
WTE Output Control Protocol.............113
Introduction.........................................113
Digital Output Format.........................113
Examples:.......................................113
Analog & Digital Output Format........114
WTE Ack an Confirm Protocol..........116
Introduction.........................................116
Store Forwar Operation.....................120
Installation..............................................121
Cables Supplied..................................121
Connecting to the TReX.....................122
Connector Pin descriptions.................123
RHS (Right Panel)..........................123
LHS (Left Panel)............................125
Input Output Har ware Connection...127
Inputs..................................................127
Outputs................................................128
Serial Connections.................................129
RS-232................................................129
RS-422/RS-485...................................130
Point To Point Connection.............131
Multi-Point Connection..................131
2 Wire Connection..........................132
Bus Terminating Resistor...............132
RF Connections......................................134
Power Connections................................135
Ethernet Interface..................................136
TReX Firmware Upgra e.....................137
Firmware Upgrade Utility...................137
Upgrade Process.................................138
Physical Dimensions..............................139
Mounting Har ware..............................140
DIN Rail..............................................140
Mounting Channels.............................141
TOP Mount.........................................141
SIDE Mount........................................142
Bottom Mount.....................................143
Mount Bolts Dimensions....................144
Top and Bottom Drilling Template.....145
Side Drilling Template........................146
Omni or Directional Antenna...............147
Omni antenna......................................147
Directional antenna.............................147
Antenna Elevation.................................148
Disclaimer...............................................150
Manufacturing marking an labels.....151
Maintenance...........................................151
Pro uct En Of Life..............................152
Pro uct Warranty..................................153
Abbreviations an Glossary.................154
© WTE Limited, 2018 Christchurch New Zealand Page 3 of 158
TReX User Manual v2.14 Firmware
Introduction
Thank you for choosing the TReX.
The TReX is an Ethernet, Serial (RS232 plus RS485/RS422) and USB capable transceiver for
data, paging (one and two-way) and general telemetry use. The TReX can be configured
through; a simple integrated display and keypad, serial commands, TCP, USB or via a web
browser. The TReX is suitable for commercial, industrial and remotely managed
control/monitoring applications.
Use the TReX when high reliability, long range and high speed control or messaging is
required .
The TReX can be use to:
•Transmit and receive paging messages.
•Connect to third party SCADA control and monitoring systems using Modbus
protocols.
•Log messages to internal memory to meet auditing requirements.
•Mirror analog and digital inputs to a remote unit.
•Inspect potential site interference using the integrated spectrum analyser.
•Report system and installation errors, such as loss of communications, and battery
states.
•Detect antenna faults during normal operation.
•Transmit and receive serial and telemetry data at high data rates.
•Act as a repeater for forwarding telemetry and paging messages in poor coverage areas.
TReX Features
•Up to 4W power output.
•DIN rail mountable aluminium enclosure that also allows simple mounting from top,
bottom or sides.
•Data transmit rates from 512 baud to 32K baud. Supported channel spacing of 25kHz,
12.5kHz and 6.25kHz.
•Support for two-way paging. Provides receipt of delivery and optionally receipt for
accepted jobs.
•Supports 512, 1200, 2400, 4800 and 9600 baud POCSAG paging messages.
•Receives 1600 baud 2 level FLEX™ paging messages.
•Modbus RTU and TCP support for easy SCADA system integration.
•Paging store and forward repeater operation with configurable duplicate reject.
•8 digital inputs and outputs.
•Two 0-10V/4-20mA analog outputs
•Two 0-10V analog inputs.
•Integrated spectrum analyser (optional).
© WTE Limited, 2018 Christchurch New Zealand Page 5 of 158
TReX User Manual v2.14 Firmware
•Simple to configure back to back mirroring and monitoring of analog and digital IO.
•Extended SCADA system expansion supporting up to 11 wirelessly connected units per
system (optional).
•Optional logging to SD card of all received and transmitted messages.
•Graphics display shows all radio activity including I/O state.
•Multi language support (English and Spanish) and additional languages available on
request.
•Fully configurable via front panel without the need for an external PC connection.
•Configurable via serial port, direct USB connection or Ethernet.
•RS232, RS422 and RS485 (both 4 and 2 wire) support.
•USB connection allows downloading of message logs or direct access to configuration
files.
•Configured inputs can be programmed to output messages when triggered.
•Configured digital and analog outputs can be controlled via received messages.
•Any output can be assigned to indicate:
◦Channel busy. The channel busy output level is configurable.
◦Alert on filtered match of message payload.
◦Comms link fail.
◦Antenna fault.
◦Low output power.
◦High temperature.
•Periodic message support to ensure radio link integrity.
•Low battery messaging.
•Inclusion of the WTE “CUSTOM” protocol, that allows support of many existing
paging protocols without the need for new firmware.
•Support for additional protocols upon request and negotiation.
•Firmware upgradable.
•High stability oscillator ensuring a maximum of 80Hz drift (at 160MHz) over the entire
specified temperature range.
•Antenna mismatch detection capability.
•High sensitivity receiver.
•Internal real time clock.
•Long-life design uses no moving or electromechanical parts. No limited life
components such as electrolytic capacitors.
TReX Versions
TReX-460, TReX-461:
Telemetry, I/O and Messaging Transceiver
© WTE Limited, 2018 Christchurch New Zealand Page 6 of 158
TReX User Manual v2.14 Firmware
TReX-460-P, TReX-461-P:
Ethernet Paging I/O Transceiver.
TReX-460-R, TReX-461-R:
Ethernet Paging I/O Receiver (no transmit capability)
The TReX can be supplied to operate within these bands:
•TReX-16x (142MHz to 175MHz)
•TReX-46x (421MHz to 480MHz). Variants TReX-460 (USA), TReX-461 (Europe, AU
and NZ).
© WTE Limited, 2018 Christchurch New Zealand Page 7 of 158
TReX User Manual v2.14 Firmware
Safety Information
Read these instructions carefully, and look at the equipment to become familiar with the device
before trying to install, operate, or maintain it.
The following special messages may appear throughout this documentation or on the
equipment to warn of potential hazards or to call attention to information that clarifies or
simplifies a procedure.
!This is the safety alert symbol. It is used to alert you to a potential personal
injury hazards. Obey all safety messages that follow this symbol to avoid
possible injury or death.
!WARNING
WARNING indicates a hazardous situation which, if not avoided, could result in death or serious
injury.
!CAUTION
CAUTION indicates a hazardous situation which, if not avoided, could result in minor or moderate
injury
NOTICE
NOTICE is used to address practices not related to physical injury.
© WTE Limited, 2018 Christchurch New Zealand Page 8 of 158
TReX User Manual v2.14 Firmware
!WARNING
LOSS OF CONTROL
•The designer of any control scheme must consider the potential failure modes of control paths
and, for certain critical control functions, provide a means to achieve a safe state during and
after a path failure. Examples of critical control functions are emergency stop and over travel
stop.
•Separate or redundant control paths must be provided for critical control functions.
•System control paths may include communication links. Consideration must be given to the
implications of anticipated transmission delays or failures of the link.
Failure to follow these instructions can result in eath or serious injury
!WARNING
THIS EQUIPMENT IS NOT INTENDED FOR MAINS VOLTAGES
•TReX was NOT designed to operate and/or be connected directly to live main voltages. The
TReX must be connected to a certified, suitably rated low voltage DC supply.
Failure to follow these instructions can result in eath or serious injury
© WTE Limited, 2018 Christchurch New Zealand Page 9 of 158
TReX User Manual v2.14 Firmware
NOTICE
HAZARD OF EQUIPMENT DAMAGE
•This product is not chemical resistant, detergent, alcohol, aerosol sprays, and/or petroleum products
may damage the front panel. Clean using a soft cloth moistened in water.
•The radio can be damaged if there is any potential difference between the chassis-ground,
Serial signal ground, power (-) input, or antenna coaxial shield. Before connecting any
wiring, ensure that all components are earthed to a common ground point.
•The antenna port will be damaged if signals greater than 13 dBm are injected/received.
•Do not connect any other transmitter to the RF connector or share the antenna with any
other device.
•Extreme Heat or High temperatures can damage TReX components. DO NOT expose or
operate the unit in extreme heat (above 70 degrees Celsius) or leave in direct sunlight or
any other UV source.
•Although this product is designed to be rugged, it will not survive excessive shock or
vibration abuse. The TReX is intended to be mounted permanently either in a land based
location or in a vehicle. When fitting in a vehicle, vibration damping mounts may be
required.
•The TReX IP rating is IP-51. TReX is not waterproof or dustproof. DO NOT directly
expose to rain or use in a condensation forming environment.
•When antennas are co-located on a community (shared) site the correct site engineering
must be performed to ensure that RF exposure limits are met.
NOTICE
CARE REQUIRED WHEN TRANSPORTING
Safety and care must be taken when transporting, handling, installing and/or replacing radio
equipment.
•Packaging should be adequate to ensure connectors are not damaged
•Store and handle the radio equipment in dry, clean safe environment
•Handle the equipment with care
•Avoid intrusion of any object/material into the radio case
•Care when stacking TReX boxes must be taken to not damage part of the radio, such
as connectors.
NOTICE introduction of foreign object into the TReX radio enclosure will void warranty.
© WTE Limited, 2018 Christchurch New Zealand Page 10 of 158
TReX User Manual v2.14 Firmware
FCC NOTICE
This device complies with Part 15.247 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference and
2. This device must accept any interference received, including interference that may
cause undesired operation.
This device must be operated as supplied by the equipment supplier. Any changes or
modifications made to the device without the written consent of the equipment supplier may
void the user’s authority to operate the device.
End user products that have this device embedded must be installed by experienced radio and
antenna personnel, or supplied with non-standard antenna connectors, and antennas available
from vendors specified by the equipment supplier. Please contact the equipment supplier for
end user antenna and connector recommendations.
Exposure to RF energy is an important safety consideration. The FCC has adopted a safety
standard for human exposure to radio frequency electromagnetic energy emitted by FCC
regulated equipment as a result of its actions in General Docket 79-144 on March 13 1996.
This equipment complies with the FCC RF radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with a
minimum distance of 43cm between the radiator and any part of your body.
NOTICE
This symbol on the product or its packaging indicates that this product must not be
disposed of with other waste.
Instead, it is your responsibility to dispose of your waste equipment by handing it
over to a
designated collection point for the recycling of waste electrical and electronic
equipment.
The separate collection and recycling of your waste equipment at the time of disposal will
help conserve natural resources and help ensure that it is recycled in a manner that protects
human health and the environment. For more information about where you can drop off your
waste equipment for recycling, contact the dealer from whom you originally purchased the
product.
© WTE Limited, 2018 Christchurch New Zealand Page 11 of 158
TReX User Manual v2.14 Firmware
Operation
Once a 13.8V source has been connected to the power connector the TReX start-up status is
displayed on the LCD.
When the TReX is operating normally, the two green status LEDs flash briefly once every
second.
When decoding messages, the “A” green LED is held on for approximately one second.
The “C” red LED is held on for the duration of a transmission, while processing TCP data,
Modbus protocol commands and decoding received messages. Both the “C” and ‘D’ red LEDs
light while starting.
On start-up under normal operation there is a message sent out the serial port. The message
indicates the firmware revision, serial number other software related information.
After finishing the start-up procedure and loading of configuration settings the TReX enters its
receive and decode mode of operation. The TReX now waits for commands to be entered
serially for processing or inputs to be triggered. These may be either protocol messages to be
processed or commands related to the configuration of the device. Serial messages may arrive
on any serial port, or may also arrive through a TCP connection.
When messages are received and decoded, they are immediately sent out the serial port in the
format of the configured protocol in use.
Messages are transmitted as per the input configuration when inputs change state. Please refer
to Input Output Har ware Connection or Input Han ling sections on this manual for
further information.
The TReX outputs are driven high or low, or for a particular period of time depending on
configuration. The outputs are controlled via the WTE Output Control Protocol message
received and decoded. Each output can be configured to operate under various error states
(Refer to Outputs).
© WTE Limited, 2018 Christchurch New Zealand Page 12 of 158
TReX User Manual v2.14 Firmware
Buttons
MENU/BACK:
When on the MAIN SCREENS used to enter the MENU. When inside the
MENU used to return back one level from within the MENU until returning
back to the MAIN SCREENS.
UP:
When on the MAIN SCREENS used to cycle between sub-screens. When in
the MENU used to navigate or alter selected configuration items.
DOWN:
When on file related screens of the MAIN SCREENS shifts between entries.
When in the MENU used to navigate or alter selected configuration items.
RIG T:
When on the MAIN SCREENS used to cycle between main screen. Within
the MENU used to enter sub MENU items or select items for configuration.
ENTER:
Used to select file related items from within the MAIN SCREENS.
© WTE Limited, 2018 Christchurch New Zealand Page 13 of 158
TReX User Manual v2.14 Firmware
Main Screens
The TReX top icon bar provides information about the display screen and operating
status. .The far right text indicates the selected main screen. This is either “IO” (inputs and
outputs), “TX” (transmit) or “RX” (receive).
The far left icon indicates system voltage as a proportion of the configured high and low
battery levels (MENU->INPUTS->BATT HIGH/LOW V).
The “X” icon is visible when no messages have been received for 2 minutes and on start-up.
The time in the middle is the current RTC time (MENU->SYSTEM->TIME).
The “S” letter indicates that the master or slave SCADA telemetry modes are in operation.
The “M” letter, when present indicates that a Modbus telemetry request packet has been
processed within the last 2 seconds.
The “Incoming” down arrow indicates that the TReX is receiving (absent when
RX is DISABLED). The “Outgoing” up arrow indicates that the TReX is
transmitting (if a transmitter enabled TReX).
The Icon “T” below indicates the TReX has been configured for telemetry stand-
alone “Back-to-Back Mirror Mode”.
The back to back arrows indicate the unit is operating in “Serial Link”
Telemetry mode.
© WTE Limited, 2018 Christchurch New Zealand Page 14 of 158
TReX User Manual v2.14 Firmware
IO Screens
Screens that relate to inputs and outputs.
IO (1):
All input and output states. Each IO highlighted state changes if the IO level is HIGH or
LOW. There is a small line above each input or output if HIGH, and a line below if LOW. All
ADCs (analog inputs) and DACs (analog outputs) show a bar graph as a proportion of full
scale and display a raw count from 0-1023. When scaling has been applied to an analog
output, the DAC value shown is the unscaled value.
In the middle, shown in larger text is “01”. The number“01” in this case is the telemetry UNIT
ID. When TELEMETRY->MODE is configured to SCADA_MASTER a small down arrow
may be visible if the TELEMETRY->REMOTES have been configured to be more than 0.
Pressing the down arrow (when configured as a SCADA_MASTER) allows the UNIT ID to be
cycled to view the IO of each remote slave in the system allowing a possible system of up to
88 digital IO, 22 ADCs and 22 DACs to be viewed.
Next to the UNIT ID is the smaller number “123”. Each TReX resets this number to the LINK
FAIL TIME each time a message is decoded. This “link count” reduces, and if reaches 0, the
link fail output can be operated.
SCADA_MASTER TReX units allow the “link count” to be viewed for all remote TReX
SCADA_SLAVE units.
© WTE Limited, 2018 Christchurch New Zealand Page 15 of 158
TReX User Manual v2.14 Firmware
IO (2):
System voltage, current and internal operating temperature. RF is the temperature read directly
next to the RF power stage and will be higher than than the DIG board temperature while the
TReX is transmitting (not applicable for receiver only TReX units). Temperatures of the RF
power stage may reach 100 degrees Celsius under normal long term operation. These
temperatures are not the ambient temperature. The case of the TReX will NOT reach these
temperatures.
As with the previous IO screen, systems voltages and temperatures of all SCADA_SLAVE
TReX units (up to 10 SLAVE units) can be viewed by pressing the down button if the TReX is
configured to be a SCADA_MASTER.
© WTE Limited, 2018 Christchurch New Zealand Page 16 of 158
TReX User Manual v2.14 Firmware
TX Screens
Screens that relate to messages transmitted.
TX (1):
Last message transmitted. Includes the time the message was transmitted, message RIC (radio
identifying code/CAP Code) and level (0-3). To the right the modulation type and rate is
displayed also with the transmit frequency.
TX (2):
List of all time-stamped messages retrieved from internal storage. Most recent message
displayed at top. Next sub-screen can only be selected when top entry is displayed. Note that
messages are only available here when TX logging has been enabled (MENU->TX->MSG
LOG).
When an entry is selected pressing the UP/DOWN buttons, pressing the ENTER button
displays the entire message.
© WTE Limited, 2018 Christchurch New Zealand Page 17 of 158
TReX User Manual v2.14 Firmware
TX (3):
Displays the last transmitted message in large font. If the message exceeds the screen size, the
DOWN button allows scrolling.
TX (4):
A TX power bar graph is displayed as a proportion of full power during a message
transmission. Above the power bar is the text “POWER 2W (168)”. “2W” relates to the
power setting in use. In brackets is the power amplifier DAC setting which is for factory use
only.
The POWER ADC count is used to indicate forward power. RF TEMP relates to the RF
amplifier temperature (not ambient) in degrees Celsius. VOLTS is the supply voltage and
AMPS is the total supply current.
© WTE Limited, 2018 Christchurch New Zealand Page 18 of 158
TReX User Manual v2.14 Firmware
RX Screens
Screens that relate to messages received. Note, when messages are received, additional icons
may be displayed in the top bar.
The second left icon changes from the “X” icon to the satellite icon when a message has been
received. This indicates that the receiver is operational.
When the “BELL” icon is displayed with a following number, this means that system ALERTS
are enabled. See ALERTS for ALERT configuration and operation.
RX (1):
Basic summary of last received message. If the message is too large to fit on the screen the
DOWN arrow will be visible in the title bar. Pressing the DOWN button will now scroll
through the rest of the message.
RX (2):
List of all time-stamped received messages retrieved from internal storage. Most recent
message displayed at top. Next sub-screen can only be selected when top entry is displayed.
Note that messages are only available here when RX logging has been enabled (MENU->RX-
>MSG LOG).
Messages starting with “*” are messages that met the ALERT filter requirements, and were
eligible to operate the ALERT output when logged.
© WTE Limited, 2018 Christchurch New Zealand Page 19 of 158
TReX User Manual v2.14 Firmware
RX (3):
Displays the last received message in large font. If the message exceeds the screen size, the
DOWN button allows scrolling.
RX (4):
Displays the signal strength of the configured channel in real time. Displays signal strength
from -128dBm to 0dBm.
© WTE Limited, 2018 Christchurch New Zealand Page 20 of 158
