Xenarc RT86 User manual

USER MANUAL
Rugged Mobile Computing Solutions
RT86

April 2022
NOTE
The information in this manual is subject to change without notice.

Table of Contents
ⅰ
Chapter 1 Getting Started ..............................................................
Getting the Tablet Running .......................................................
Unpacking .............................................................................
Connecting to AC Power .......................................................
Turning On and Off the Tablet .............................................
Taking a Look at the Tablet .......................................................
Front Components ...............................................................
Rear Components .................................................................
Left-Side Components .........................................................
Top Components .................................................................
Bottom Components ..........................................................
Chapter 2 Operating Your Tablet ...................................................
Using the Touchscreen ............................................................
Using Multi-touch Gestures ...............................................
Using Wireless Connections ....................................................
Using the WLAN ..................................................................
Using the Bluetooth Feature ..............................................
Chapter 3 Managing Power ..........................................................
AC Adapter ................................................................................
Battery Pack .............................................................................
Charging the Battery Pack .................................................
Checking the Battery Level ................................................
Low Battery ........................................................................
Replacing the Battery Pack ................................................
Power-Saving Tips ...................................................................
1
2
2
3
4
6
6
8
9
9
10
11
12
13
15
15
16
17
18
19
19
20
20
21
22

ⅱ
Chapter 4 Expanding Your Tablet ..................................................
Connecting Peripheral Devices ...............................................
Connecting a USB Device ...................................................
Connecting a USB Type-C Device ......................................
Connecting a Monitor .........................................................
Connecting an Audio Device ..............................................
Chapter 5 Using BIOS Setup .........................................................
When and How to Use ..............................................................
Menu Descriptions ...................................................................
Main Menu ..........................................................................
Security Menu ....................................................................
Advanced Menu & Chipset Menu ......................................
Boot Menu ..........................................................................
Save & Exit Menu ................................................................
Chapter 6 Care and Maintenance ..................................................
Protecting the Tablet ...............................................................
Using an Anti-Virus Strategy ..............................................
Taking Care of the Tablet .........................................................
Location Guidelines ...........................................................
General Guidelines .............................................................
Cleaning Guidelines ...........................................................
Battery Pack Guidelines ....................................................
Touchscreen Guidelines ....................................................
When Traveling ........................................................................
Chapter 7 Troubleshooting ..........................................................
Preliminary Checklist ..............................................................
Solving Common Problems ....................................................
Battery Problems ...............................................................
23
24
24
24
24
24
25
26
27
27
29
30
30
31
32
33
33
34
34
35
35
36
37
38
39
40
41
41

ⅲ
Bluetooth Problems ...........................................................
Display Problems ...............................................................
Hardware Device Problems ...............................................
Power Management Problems ..........................................
Software Problems .............................................................
Sound Problems .................................................................
Startup Problems ...............................................................
WLAN Problems ..................................................................
Restart the Tablet .....................................................................
42
42
43
43
44
44
44
45
46

Getting Started
Chapter 1
1
This chapter first tells you step by step how to get the tablet up and running.
Then, you will find a section briefly introducing the external components of
the tablet.

Unpacking
Getting the Tablet Running
2
After unpacking the shipping carton, you should find these standard items:
● I87J Rugged Tablet
● AC power cord ● AC adapter
● Hand-strap

3
Connecting to AC Power
CAUTION：Use only the AC adapter included with your Tablet. Using other AC
adapters may damage the Tablet.
You must use power when starting up the Tablet for the very first time.
1. Open the Type-C port waterproof plug. (Place the tablet flat on the desktop, left
position)
2. Plug the Type-C power cord of the power adapter into the Type-C port of the tablet.
3. Plug the female end of the power cord to the adapter and the male end to an
electrical outlet.
4. Power is being supplied from the electrical outlet to the adapter and onto your
Tablet. Now, you are ready to turn on the Tablet.
Type-C port

4
Turning On and Off the Tablet
Turning On
2. Press the power button ( ) . The Windows operating system should start.

5
Turning Off
When you finish a working session, you can stop the system by turning off the power
or leaving it in Sleep or Hibernation mode:
* “Sleep” is the default result of the action. You can change what the action does
through Windows settings.
To... Do this...
Power off
(Shutdown) Click →[ Power]→[Shut down].
Sleep Use one of these methods:
● Press the power button.
● Click →[ Power]→[Sleep].
Hibernate By default, this option is not shown in the Start menu. If
you want to use the feature, set up accordingly in
Windows settings.

6
Taking a Look at the Tablet
NOTE：Depending on the specific model you purchased, the color and look of your
model may not exactly match the graphics shown in this document.
CAUTION：You need to open the protective covers to access the connectors. When
not using a connector, make sure to close the cover completely for water-, and
dust-proof integrity.
Front Components
❶
❷
❾
❸
❹ ❹
❺
❻
❼
❽

7
Ref Component Description
Camera
Indicator*2
Microphone
Used to realize the camera function.
The blue light is always on when starting up;
The blue light flashes during standby sleep;
The red light is always on when charging.
Receives sound and voice for the Tablet.
❶
❷
❸
Stereo Speaker Sends out sound and voice from the Tablet.
❹
F Key 2D scan key (can be defined).
❺
Windows HOME Used to open windows shortcuts.
❻
Volume Button + Used to adjust and increase the volume.
❼
Volume Button - Used to adjust or reduce the volume.
❽
Power Button Used for sleep wake-up equipment and
switching equipment.
❾

8
Rear Components
Ref Component Description
Camera
Flash Lamp
Battery Cover Latch
Used to realize the camera function.
Fill light and lighting.
Lock the battery cover.
❶
❷
❸
Battery cover Protect internal battery.
❹
Battery latch Lock internal battery
(Inside the battery cover).
❺
❶❷
❹
❸
❺
❸

Ref Component Description
USB3.0 Port
3.5mm Earphone
Jack
HDMI Connector
Connects a USB device.
Connect the audio device.
Connects a HDMI monitor or TV set.
❶
Ref Component Description
Module port Optional code scanning module.
❶
❷
❸
Type-C Port Connects a USB-C device.
❹
9
Left-Side Components
Top Components
❶ ❷ ❸ ❹
❶

10
Bottom Components
Ref Component Description
Pogo Pin Matched with the positioning hole to connect the
Vehicle Mount and Docking Charger for expanding
USB, RJ45 and RS232 communication interfaces.
❶
Locating Hole It plays a fixed role when connecting the
Vehicle Mount and Docking Charger.
❷
❶
❷

Operating Your
Tablet
Chapter 2
11
This chapter provides information about the use of the Tablet.
If you are new to Tablets, reading this chapter will help you learn the operating
basics. If you are already a Tablet user, you may choose to read only the parts
containing information unique to your Tablet.
CAUTION：
● Do not expose your skin to the Tablet when operating it in a very hot or cold
environment.
● The Tablet can get uncomfortably warm when you use it in high temperatures. As
a safety precaution in such a circumstance, do not place the Tablet on your lap or
touch it with your bare hands for extended periods of time. Prolonged body contact
can cause discomfort and potentially a burn.

The following table shows how you use the touchscreen to obtain equivalent
mouse functions.
Term / Action Equivalent
Mouse Function
Tap：Touch the screen once. Click / Point
Double-tap：Touch the screen twice rapidly. Double-click
Tap and hold：Tap and hold until a popup menu appears. Right-click
Drag：Hold the finger on the screen and drag
across the screen until reaching your destination.
Drag
12
Using the Touchscreen
CAUTION：Do not use a sharp object such as a ballpoint pen or pencil on the
touchscreen. Doing so may damage the touchscreen surface. Use your finger or the
stylus.
Select models have a capacitive touchscreen. This type of touchscreen responds to
objects that have conductive properties, such as fingertips and a capacitive-tipped
stylus. You can navigate on the screen without using a keyboard, or mouse.

Using Multi-touch Gestures
Gestures Descriptions
Actions
( =finger down； =finger up)
Pan
(Scroll)
Use panning to see
another part of a page
that has scroll bars.
Zoom
(Pinch)
Use zooming to make an
item (a photo for example)
on the screen larger or
smaller. The gesture works
in applications that
support mouse wheel
zooming.
Rotate Use rotating to move a
picture or other item on
the screen in a circular
direction (clockwise or
counter- clockwise).
The gesture works in
applications that
support the specific
gesture.
13
You can interact with your Tablet by placing two fingers on the screen. The
movement of the fingers across the screen creates “gestures,” which send
commands to the Tablet.
Here are the multi-touch gestures that you can use:
Drag 1 or 2 fingers up or down.
or
Move two fingers apart / toward each other.
Move two fingers in opposing directions.
-or-
Use one finger to pivot around another.
or

Gestures Descriptions
Press
and Tap
Two-
finger
Tap
Flicks
Use press and tap to
access the shortcut
menu.
The function is defined
by applications that
support the specific
gesture.
Flick left or right to
navigate back and forward
in a browser and other
applications. The gesture
works in most applications
that support back and
forward.
14
Actions
( =finger down； =finger up)
Press on target and tap using a second finger.
Tap two fingers at the same time
(where the target is in the midpoint
between the fingers).
Make quick drag gestures in the desired
direction.

Click  → [Settings] → [Network & Internet] → [WLAN]，Slide the WLAN switch to
the [On] position.
Using the WLAN
Turning On / Off the WLAN Radio
To turn on the WLAN radio:
15
The WLAN (Wireless Local Area Network) module supports WIFI 802.11(a/b/g/n/ac).
Connecting to a WLAN Network
1. Make sure that the WLAN function is enabled (as described above).
2. Click the network icon in the lower right of the task bar.
3. In the list of available wireless networks, click a network, and then click Connect.
4. Some networks require a network security key or passphrase. To connect to one of
those networks, ask your network administrator or Internet service provider (ISP) for
the security key or passphrase.
For more information on setting a wireless network connection, refer to Windows
online help.
To turn off the WLAN radio:
You can turn off the WLAN radio the same way you turn it on.
If you want to quickly turn off all wireless radio, simply switch on Airplane mode.
Click → [Settings] → [Network & Internet] → [Airplane mode]，Slide the
Airplane Mode switch to the [On] position.
Using Wireless Connections
