Yamaha SEASCOOTER 275L User manual

CAUTION
ELECTRICALLY OPERATED PRODUCT
Not recommended for children under 16 years of age. As with all
electrical products, precautions should be observed during handling
to reduce the risk of electric shock.
English Version
User Manual
YMEP#18014
Distributors in the United States and Canada provide a Standard Limited
Warranty for 6 months from the date of purchase for new products. If you're
not located in the United States or Canada, please contact your Local
Distributor for warranty arrangements in your territory. Please visit
www.seascooter.net for Distributor / Service Center details. Distributors ONLY
warrant Yamaha Seascooter products purchased from an authorized dealer
and with an original purchase receipt. All warranties are limited to a single
original owner on the purchase of new and current product from an
authorized reseller. Closeouts, Discontinued and Secondary sales of any kind
including “like new” or out of box are not eligible for warranty consideration.
This warranty gives the consumer specific legal rights, and those rights may
vary from place to place. Ask your Local Distributor for the warranty period in
your region by calling their Service Center. Any part of the product supplied
by the Distributor and found in the reasonable judgment of the Distributor to
be defective in material or workmanship will be repaired or replaced then
returned by the Distributor without charging for parts and repair costs. The
product including any defective part must be sent to the Distributor within the
warranty period. The customer will pay for the expense of delivering the
product to the Distributor.
This warranty does not cover any product that has been subject to misuse
negligence or accident, or that has been operated in any way contrary to the
operating instructions as specified in the User Manual. Any flood, loss or
damage, for any reason, that is caused by accidental release and sinking of
the unit, or from flooding an o-ring sealed or water tight area will not be
covered under warranty. This warranty does not apply to theft, loss, abuse or
tampering, lack of maintenance, improper storage, exposure to excessive
temperature, extended sunlight, material interactions, deteriorating chemicals
or fumes, any damage to the product that is the result of improper
maintenance or parts replacement performed by someone other than the
official Distributor Service Center or to any product that has been altered or
modified so as to change its intended use. This warranty does not extend to
repairs made necessary by normal wear or by the use of parts or accessories
which are either incompatible with the product or adversely affects its
operation, performance or durability.
CONSUMER WARRANTY
& SERVICE INFORMATION
SEE NEXT PAGE
Yamaha, the Crossed Tuning Fork Design, and any likeness thereof are trademarks
of Yamaha Motor Corp. U.S.A. and Yamaha Motor Co., Ltd. (“Yamaha”) used
under license by Sport Dimension Inc. www.yamaha-motor.com.
This Product is not manufactured by Yamaha. For consumer purposes,
please contact Sport Dimension Inc. at 1-800-678-7873.
LICENSED PRODUCT

Contents Introduction
Introduction 1
Parts diagram 2
WARNINGS 3
Fit rubber seal 6
before first use!
Getting started 8
Battery use 12
Charging the Battery Pod 16
Care & Maintenance 19
Trouble Shooting 21
Technical Specifications 26
1
Discarded electrical appliances are
recyclable and should not be discarded
in the domestic waste! Please actively
support us in conserving resources and
protecting the environment by returning
this appliance to the collection centers
(if available).
Thank you for having Choosing the SEASCOOTER
™
275L –
the ultimate dive propulsion vehicle for professional divers.
(Only use the seascooter for scuba diving if you are a
qualified diver)
Use appropriate equipment such as wetsuit, buoyancy
control device, fins, mask & snorkel, surface signaling
device, regulator(s) approved life jacket etc. when
operating the seascooter.
Only operate the Seascooter in water.
• Speed up to 3.3 mph / 5.3 km/h
• Run up to 2 hours with normal use
• Rated to130ft / 40m
• Weight just 32.4 lbs / 14.7 kg including battery
There are many features incorporated in this sophisticated
design. These include soft start power circuit, battery status
indicator, water ingress alert, overheating protection,
adjustable buoyancy, safety grilles, retractable rubber
handle, auto shut off when triggers are released and master
safety lock.
Please take a little time to study this manual to learn about
them all to get the most out of your 275L.
The Seascooter is designed for use in seawater. It will
have less buoyancy in fresh water, lake or pool and
may sink in such waters.
• The seascooter is designed for 1 person use
• The seascooter is not a life saving device. Do not use it as
a buoyancy aid
Warning

Parts Diagram
1. Nose Cone
2. Latch
3. Battery Pod
4. Battery Housing
5. Handle
6. Trigger
7. Master Switch
8. LED Battery Status
Indicator
9. Propeller Nozzle
10. Propeller
11. Front Grille
12. Rear Grille
13. O-ring seals
14. Charging Base
15. Ballast Weight x 4pcs
16. Inner Nozzle
17. Retractable Rubber
Handle
18. O-ring Seals
19. Rubber Ring
20. Pump
21. Vent Plug
22.Lubricant
23
Fig.1
18
19 20
22
21
Warnings
14 +
16 +
•Read the user's manual carefully before use.
•Always follow this age recommendation: a
child under 16 years old should never operate
this SEASCOOTER™.
•The seascooter is designed for 1 person use.
•Crushing / Cutting Hazard
•Be careful when you are transporting the
Seascooter and setting it down to avoid
crushing hazard on hands, foot or toes.
•This is not a life saving device.
DO NOT use it as a buoyancy aid.
•Always inspect the swimming area to ensure
it is free of hazards or obstacles such as
boats and swimmers before using the
SEASCOOTER™.
• ALWAYS wear a life vest (personal floatation
device - PFD) approved by your local
authorities for Snorkeling: (U.S. Coast Guard
Type III vest in the US or Canadian Coast
Guard approved life vest in Canada or SAI
Approval PFD in Australia or ISO/CE
Approved PFD in Europe).

54
• Familiarize yourself with the SEASCOOTER™ functions
and battery life before embarking on any dives or
excursions.
• The Seascooter™ is not a personal floatation device -
always wear a Approved Personal Flotation Device /
Approved Life-Preserver when using the Seascooter™ for
snorkeling.
• Do not allow sun tan oils or lotions to be in prolonged
contact with the SEASCOOTER™ plastic as it may cause
the plastic to become brittle and break apart.
• If the propeller becomes intermittent, and/or a buzzer is
heard, water has entered the housing(s). If safe to do so,
turn OFF the master switch, remove the SEASCOOTER™
from the water and check it for water ingression. ALWAYS
observe safe diving practice if this occurs during a dive.
• ALWAYS keep the SEASCOOTER™ out of direct sunlight
when not in use. HEAT KILLS BATTERIES AND IT MAY
EXPLODE OR LEAK.
• When using the SEASCOOTER™ 275L for Scuba Diving,
ascents and descents should be made in accordance with
recognized diving practices.
• The SEASCOOTER™ 275L should only be used for
Scuba Diving by qualified divers.
• Never open the Nose Cone of the SEASCOOTER™
in the water.
• When not in use, always turn the Master Switch to the
OFF position.
• Do not use the SEASCOOTER™ 275L below the
recommended maximum depth of 40m/130ft.
• ALWAYS remove the battery pod from the unit when not in
use.
• DO NOT store the battery pod in the unit.
CAUTION:
• In different waters (seawater, lake, pool) and conditions
such as currents, temperature and pressure can affect the
buoyancy of the unit which may cause the unit to sink if
accidentally released.
• DO NOT release or leave the Seascooter in the water.
Always take the unit out of water when not in use.
• NEVER remove the grilles except for maintenance.
• Always charge battery to its maximum before using the
SEASCOOTER™. After charging is complete the battery
will continue to emit gas. Wait at least 30 minutes after
charging before removing the battery from the charger or
placing the battery into the battery housing. Failure to do
so could result in an explosion.
•Never stick body parts, clothing or other
objects in the vicinity of the Propeller. Do not
wear loose or flowing clothing or equipment
that could be drawn into the propeller.
•Particular care should be exercised when
using the SEASCOOTER™ near anybody
with long hair. Users with long hair should tie
it up or wear a swimming cap when using the
SEASCOOTER™.
• Do not use alcohol or drugs prior to and
during use of this product.
• Always ensure sufficient charge remains in
the battery to return to the shore surface
before using the Seascooter.
• Be aware of appropriate water levels, tidal
changes, dangerous currents, weather
change and strong offshore winds. ALWAYS
scout unfamiliar water before venturing out.
• Do not attach your body, clothing, other
equipment to the seascooter in any way.

FIT RUBBER SEAL
BEFORE FIRST USE!
6 7
2. Both Rubber seal must be fitted as shown and
fully lubricated with the supplied grease
EVERYTIME before replacing th nose cone.
Sealing
Surface
O-ring Seals
STEP 3
Fig.2C
Fit two seals in
the grooves.
STEP 2
Fig.2b
FIT RUBBER SEAL
BEFORE FIRST USE!
1. Unlock four latches and remove Nose Cone.
STEP 1
Fig.2a
CRUSHING HAZARD:
The following action during assembly, disassembly, and
transportation of the seascooter may incur crushing hazards
to your fingers or toes:
-Closing the nose cone latches
-Putting on the nose cone housing
-Placing the battery into the seascooter
-Accidental dropping of the seascooter or battery.
Silicone
Grease
Vent O Ring

8
To Remove the 275L Nose Cone and charge the Battery
Pod, User MUST follow these instructions to avoid any
injury.
1. ALWAYS ensure that the Master Switch is in OFF position.
2. ALWAYS ensure that the 275L is out of the water, dry and
placed in a dry area.
3. Pull the four Latches down and remove the nose cone by
using the left and right Latches to break the seal if
necessary (see Fig. 11 and Fig. 12) and jump to Step 9.
4. If the nose-cone cannot be opened by pressing the
latches, replace the Retractable rubber handle on the
SEASCOOTER™ 275L. (see Fig. 13)
5. Release the Vent plug on top of the Nose Cone.
6. Pull the rubber ring through the retractable rubber handle
and attach both ends around the top and bottom latch
hinge as shown in Fig. 13.
7. Screw the pump nozzle to the vent chamber and pump air
in until the Nose Cone pops off
(see Fig. 14).
IMPORTANT: ALWAYS attach the Rubber Ring before
using the pump. The Nose Cone can pop off and cause
injury if the Rubber Ring is not attached and tighly
secured.
8. Remove the Rubber Ring and remove the Nose Cone
(see Fig. 15).
9. Allow two minutes for any gases to dissipate.
10. Take out the Battery Pod from the unit.
11. Connect the Battery Pod to the Charging Base.
(see Fig. 16)
12. Plug the Charging Base into the mains, and turn on the
supply.
13. Charging will take around 12-14 hours for a fully
discharged battery. When the Battery Pod is charging, the
RED LED light on the Battery Pod remains flashing.
When the battery is fully charged, the GREEN LED
flashes. (see Fig. 16)
14. Unplug the Charging Base from the electrical socket/plug.
15. Allow battery to stand for 30 minutes before using it.
16. Unplug the Battery Pod from the Charging Base.
17. When ready to use, reconnect to the unit in the correct
position. (see Fig. 17)
18. MAKE SURE the O-ring Seals and sealing surfaces are
clean and fully lubricated
with the supplied grease
EVERYTIME (you can also
buy this at your local
hardware store) before
replacing the Nose Cone.
(see Fig. 18)
19. Ensure the Vent O Ring is
fitted correctly into the
groove and fully lubricated
with the supplied grease. (see
Fig. 18)
20. MAKE SURE to screw in the
Vent Plug to seal the vent.
21. Replace the Nose Cone and
close the Latches.
Getting Started
10. Always set the Master Switch to the OFF position when
it is out of the water. (see fig.6)
Use of variable speed
Your SEASCOOTER™ 275L features three speeds. To
change the speed, pull and the Triggers repeatedly to switch
between low, middle and high speed. See steps 5, 6 and 7
on page 8 and page 9.
Fig.3
LED Battery
Status Indicator
Slide the Master Switch
down to "ON" position
When using the SEASCOOTER™ 275L for the first time,
the battery needs to be charged. Follow the the Battery
Instruction on pages 12, 13, 14 and 15 and charging
instructions on pages 16 and 17.
Your SEASCOOTER™ 275L can be used for swimming,
snorkeling or diving up to 40m/130ft (by qualified divers).
To use the SEASCOOTER™275L follow these
instructions.
1.Charge the battery and install just before use.
2.Place the SEASCOOTER™ 275L into the water and rock
gently to release trapped air.
3.Adjust buoyancy to suit conditions and personal
preferences - see page 10, Adjustable Buoyancy.
4.When ready to set off, switch the Master Switch to the
ON position (see fig.3).
5. For US version : Pull and hold the left or the right trigger
to start the propeller (see fig.4). The SEASCOOTER™
275L will accelerate up to speed 1.
For EU version : Pull and hold both Triggers to
start the Propeller (see fig.4). The SEASCOOTER™
275L will accelerate up to speed 1.
(There is a short delay before the Propeller begins to
rotate).
Fig.4
Triggers
Master switch
is ON.
6. To increase speed at any time, simply pulse the triggers
off and on again within half a second. The
SEASCOOTER™ 275L will accelerate up to the next
speed. Make sure that only one Trigger is being used at a
time.
7. When at speed 3, further pulses will have no effect.
8. To stop the Propeller, simply release the Trigger(s).
9. Maintain proper posture to achieve the maximum speed
when using the SEASCOOTER™ 275L – see fig.5 for the
correct position of the SEASCOOTER™ 275L when using
it.
9
Fig.5
GOOD
BEST

11
Adjustable Buoyancy
Plug in Ballast Weight to reduce buoyancy or remove to
increase buoyancy. (see fig.7)
Use of Retractable rubber
handle
Your SEASCOOTER™ 275L
comes with an attached
Retractable rubber handle for
easy transport and handling
of the unit.
Simply pull the Retractable
rubber handle up to transport
the unit. (see fig.8)
Simply push the Retractable
rubber handle down prior to
swimming, snorkeling or
diving. (see fig.9)
Note: The Retractable rubber
handle can be removed if
preferred. (see fig.10)
Ballast Weight x 4 pcs
Plug in and click
to hold
Fig.7
Fig.8
Fig.9
Fig.10
To Remove the 275L Nose Cone and charge the Battery
Pod, User MUST follow these instructions to avoid any
injury.
1. ALWAYS ensure that the Master Switch is in OFF position.
2. ALWAYS ensure that the 275L is out of the water, dry and
placed in a dry area.
3. Pull the four Latches down and remove the nose cone by
using the left and right Latches to break the seal if
necessary (see Fig. 11 and Fig. 12) and jump to Step 9.
4. If the nose-cone cannot be opened by pressing the
latches, replace the Retractable rubber handle on the
SEASCOOTER™ 275L. (see Fig. 13)
5. Release the Vent plug on top of the Nose Cone.
6. Pull the rubber ring through the retractable rubber handle
and attach both ends around the top and bottom latch
hinge as shown in Fig. 13.
7. Screw the pump nozzle to the vent chamber and pump air
in until the Nose Cone pops off
(see Fig. 14).
IMPORTANT: ALWAYS attach the Rubber Ring before
using the pump. The Nose Cone can pop off and cause
injury if the Rubber Ring is not attached and tighly
secured.
8. Remove the Rubber Ring and remove the Nose Cone
(see Fig. 15).
9. Allow two minutes for any gases to dissipate.
10. Take out the Battery Pod from the unit.
11. Connect the Battery Pod to the Charging Base.
(see Fig. 16)
12. Plug the Charging Base into the mains, and turn on the
supply.
13. Charging will take around 12-14 hours for a fully
discharged battery. When the Battery Pod is charging, the
RED LED light on the Battery Pod remains flashing.
When the battery is fully charged, the GREEN LED
flashes. (see Fig. 16)
14. Unplug the Charging Base from the electrical socket/plug.
15. Allow battery to stand for 30 minutes before using it.
16. Unplug the Battery Pod from the Charging Base.
17. When ready to use, reconnect to the unit in the correct
position. (see Fig. 17)
18. MAKE SURE the O-ring Seals and sealing surfaces are
clean and fully lubricated
with the supplied grease
EVERYTIME (you can also
buy this at your local
hardware store) before
replacing the Nose Cone.
(see Fig. 18)
19. Ensure the Vent O Ring is
fitted correctly into the
groove and fully lubricated
with the supplied grease. (see
Fig. 18)
20. MAKE SURE to screw in the
Vent Plug to seal the vent.
21. Replace the Nose Cone and
close the Latches.
10. Always set the Master Switch to the OFF position when
it is out of the water. (see fig.6)
Use of variable speed
Your SEASCOOTER™ 275L features three speeds. To
change the speed, pull and the Triggers repeatedly to switch
between low, middle and high speed. See steps 5, 6 and 7
on page 8 and page 9.
LED battery status indicator
Your SEASCOOTER™ 275L has a LED Battery Status
Indicator (see fig.3), which can be seen through the LED
Window located in the Handle. When the battery is full the
GREEN LED flashes, when the battery is normal the
ORANGE LED flashes, when the battery is low the RED
LED flashes. If the battery is exhausted the LED will be off
and the unit needs to be recharged.
Note: The battery status indicator only functions when the
propeller is turning.
Important Notice: This machine is not to use to mix or
to work with sand, concrete and material with similar
physical characteristics. This machine is only to use for
diving in water.
10
When using the SEASCOOTER™ 275L for the first time,
the battery needs to be charged. Follow the the Battery
Instruction on pages 12, 13, 14 and 15 and charging
instructions on pages 16 and 17.
Your SEASCOOTER™ 275L can be used for swimming,
snorkeling or diving up to 40m/130ft (by qualified divers).
To use the SEASCOOTER™275L follow these
instructions.
1.Charge the battery and install just before use.
2.Place the SEASCOOTER™ 275L into the water and rock
gently to release trapped air.
3.Adjust buoyancy to suit conditions and personal
preferences - see page 10, Adjustable Buoyancy.
4.When ready to set off, switch the Master Switch to the
ON position (see fig.3).
5. For US version : Pull and hold the left or the right trigger
to start the propeller (see fig.4). The SEASCOOTER™
275L will accelerate up to speed 1.
For EU version : Pull and hold both Triggers to
start the Propeller (see fig.4). The SEASCOOTER™
275L will accelerate up to speed 1.
(There is a short delay before the Propeller begins to
rotate).
6. To increase speed at any time, simply pulse the triggers
off and on again within half a second. The
SEASCOOTER™ 275L will accelerate up to the next
speed. Make sure that only one Trigger is being used at a
time.
Fig.6
Slide the Master Switch
up to "OFF" position
7. When at speed 3, further pulses will have no effect.
8. To stop the Propeller, simply release the Trigger(s).
9. Maintain proper posture to achieve the maximum speed
when using the SEASCOOTER™ 275L – see fig.5 for the
correct position of the SEASCOOTER™ 275L when using
it.

Battery Use
CAUTION
• Your SEASCOOTER™is supplied with a battery that
needs to be treated carefully as it will release
potentially explosive gases during its normal cycle of
use (off-gassing). Failure to do so can result in an
explosion occurring. Please read the entire manual
thoroughly and follow all instructions.
•
Always remove the battery from your SEASCOOTER™
when it is not in use and store separately in a well
ventilated area where it is out of the reach of children
and away from heat and ignition sources.
• Do not attach the battery in your SEASCOOTER™ until
prior to using it.
• Before removing/placing the battery, open the nose
cone and allow two minutes for any explosive gases to
dissipate.
• Do not use/store/charge the battery in temperatures
above
40ºC (104ºF) as excessive off-gassing may
occur. Keep the battery and SEASCOOTER™
in the
shade when not in use.
• Always ensure the unit is dried thoroughly before
opening the Nose Cone.
•
Only use the charger supplied with the SEASCOOTER™ .
Battery Use
1312
To Remove the 275L Nose Cone and charge the Battery
Pod, User MUST follow these instructions to avoid any
injury.
1. ALWAYS ensure that the Master Switch is in OFF position.
2. ALWAYS ensure that the 275L is out of the water, dry and
placed in a dry area.
3. Pull the four Latches down and remove the nose cone by
using the left and right Latches to break the seal if
necessary (see Fig. 11 and Fig. 12) and jump to Step 9.
4. If the nose-cone cannot be opened by pressing the
latches, replace the Retractable rubber handle on the
SEASCOOTER™ 275L. (see Fig. 13)
5. Release the Vent plug on top of the Nose Cone.
6. Pull the rubber ring through the retractable rubber handle
and attach both ends around the top and bottom latch
hinge as shown in Fig. 13.
7. Screw the pump nozzle to the vent chamber and pump air
in until the Nose Cone pops off
(see Fig. 14).
IMPORTANT: ALWAYS attach the Rubber Ring before
using the pump. The Nose Cone can pop off and cause
injury if the Rubber Ring is not attached and tighly
secured.
8. Remove the Rubber Ring and remove the Nose Cone
(see Fig. 15).
9. Allow two minutes for any gases to dissipate.
10. Take out the Battery Pod from the unit.
11. Connect the Battery Pod to the Charging Base.
(see Fig. 16)
12. Plug the Charging Base into the mains, and turn on the
supply.
13. Charging will take around 12-14 hours for a fully
discharged battery. When the Battery Pod is charging, the
RED LED light on the Battery Pod remains flashing.
When the battery is fully charged, the GREEN LED
flashes. (see Fig. 16)
14. Unplug the Charging Base from the electrical socket/plug.
15. Allow battery to stand for 30 minutes before using it.
16. Unplug the Battery Pod from the Charging Base.
17. When ready to use, reconnect to the unit in the correct
position. (see Fig. 17)
18. MAKE SURE the O-ring Seals and sealing surfaces are
clean and fully lubricated
with the supplied grease
EVERYTIME (you can also
buy this at your local
hardware store) before
replacing the Nose Cone.
(see Fig. 18)
19. Ensure the Vent O Ring is
fitted correctly into the
groove and fully lubricated
with the supplied grease. (see
Fig. 18)
20. MAKE SURE to screw in the
Vent Plug to seal the vent.
21. Replace the Nose Cone and
close the Latches.
WARNING
BATTERY SAFETY
CAUTION
BATTERY SAFETY
• Must remove and store the battery separately from the unit when
not in use!
• Must re-charge the battery after use WITHIN 24 HOURS.
• Must re-charge the battery at least EVERY THREE MONTHS
when not in use.
User Manual must be read and understood before use.
Please read and follow the Battery Safety Instruction.
Incorrect battery maintenance may reduce the battery life and
influence its function.
• Our lead-acid battery is designed specifically for
each Seascooter. For your own safety, NEVER
REPLACE THE ORIGINAL SEASCOOTER BATTERY
WITH AN AFTERMARKET BATTERY.
• Only Seascooter with original battery will be warranted by our
service center.
• Always contact official dealer/service center to service the
Seascooter. Any changes made by consumer/unauthorized
parties will void the warranty of the Seascooter.
• Visit our website to purchase replacement battery for Seascooter.
• Visit our website to find an original equipment battery distributor in
your region.
www.seascooter.net
RE-CHARGE THE BATTERY
3
3
AT LEAST
MONTHS
EVERY
MONTHS

Battery Use
CAUTION
•
Never short circuit the battery or battery connectors.
• Always ensure the charger is dry before use.
• The charger gets quite warm in use - this is normal.
• If in doubt of the state of the battery, recharge it until the
indicator on the battery charger indicates a full charge.
• If the battery is not to be used for an extended period,
store it in a well ventilated area away from children,
heat, and ignition sources. Recharge it every three
months to maintain charge and avoid excess
off-gassing. DO NOT store the battery inside the
SEASCOOTER™.
• If the battery appears damaged or will not fully charge,
the battery must be replaced. If battery life is noticeably
reduced, the battery should be replaced.
• The battery supplied with your SEASCOOTER™
should last about 200 cycles or two years before it
should be replaced. Please contact your local customer
service center/distributors. Using a battery in excess of
these recommendations can result in excessive
off-gassing of explosive gases.
Battery Use
CAUTION
• The battery supplied with your SEASCOOTER™
releases a potentially explosive gas during charging.
Charging should only take place in a well ventilated
area, away from children and open flames or other
ignition sources (cigarettes, sparks).
• Charge the battery as soon as possible after use within
24 hours.
• Always charge the battery to the fullest before using
the
SEASCOOTER™ .
• Always switch off Main power to the charger before
connecting or disconnecting the battery pod from the
charger.
• After charging is complete the battery will continue to
emit gas. Wait at least 30 minutes after charging before
removing the battery from the charger or placing the
battery into the battery housing. Failure to do so could
result in an explosion.
•
Remove battery from charger once fully charged.
• Never charge the battery in sealed container.
• Never charge the battery near water.
1514
To Remove the 275L Nose Cone and charge the Battery
Pod, User MUST follow these instructions to avoid any
injury.
1. ALWAYS ensure that the Master Switch is in OFF position.
2. ALWAYS ensure that the 275L is out of the water, dry and
placed in a dry area.
3. Pull the four Latches down and remove the nose cone by
using the left and right Latches to break the seal if
necessary (see Fig. 11 and Fig. 12) and jump to Step 9.
4. If the nose-cone cannot be opened by pressing the
latches, replace the Retractable rubber handle on the
SEASCOOTER™ 275L. (see Fig. 13)
5. Release the Vent plug on top of the Nose Cone.
6. Pull the rubber ring through the retractable rubber handle
and attach both ends around the top and bottom latch
hinge as shown in Fig. 13.
7. Screw the pump nozzle to the vent chamber and pump air
in until the Nose Cone pops off
(see Fig. 14).
IMPORTANT: ALWAYS attach the Rubber Ring before
using the pump. The Nose Cone can pop off and cause
injury if the Rubber Ring is not attached and tighly
secured.
8. Remove the Rubber Ring and remove the Nose Cone
(see Fig. 15).
9. Allow two minutes for any gases to dissipate.
10. Take out the Battery Pod from the unit.
11. Connect the Battery Pod to the Charging Base.
(see Fig. 16)
12. Plug the Charging Base into the mains, and turn on the
supply.
13. Charging will take around 12-14 hours for a fully
discharged battery. When the Battery Pod is charging, the
RED LED light on the Battery Pod remains flashing.
When the battery is fully charged, the GREEN LED
flashes. (see Fig. 16)
14. Unplug the Charging Base from the electrical socket/plug.
15. Allow battery to stand for 30 minutes before using it.
16. Unplug the Battery Pod from the Charging Base.
17. When ready to use, reconnect to the unit in the correct
position. (see Fig. 17)
18. MAKE SURE the O-ring Seals and sealing surfaces are
clean and fully lubricated
with the supplied grease
EVERYTIME (you can also
buy this at your local
hardware store) before
replacing the Nose Cone.
(see Fig. 18)
19. Ensure the Vent O Ring is
fitted correctly into the
groove and fully lubricated
with the supplied grease. (see
Fig. 18)
20. MAKE SURE to screw in the
Vent Plug to seal the vent.
21. Replace the Nose Cone and
close the Latches.

Charging the Battery Pod
To Remove the 275L Nose Cone and charge the Battery
Pod, User MUST follow these instructions to avoid any
injury.
1. ALWAYS ensure that the Master Switch is in OFF position.
2. ALWAYS ensure that the 275L is out of the water, dry and
placed in a dry area.
3. Pull the four Latches down and remove the nose cone by
using the left and right Latches to break the seal if
necessary (see Fig. 11 and Fig. 12) and jump to Step 9.
4. If the nose-cone cannot be opened by pressing the
latches, replace the Retractable rubber handle on the
SEASCOOTER™ 275L. (see Fig. 13)
5. Release the Vent plug on top of the Nose Cone.
1716
Fig.16
Charging Base
Battery Pod
Charging
Indicator
Warning!
Replace the battery immediately if it is damaged.
Rubber
Ring
Retractable rubber handle
Latch
Hinge
Left and
right Latches
Top and
Bottom
(on Back)
Latches
Press
inward
to open
Inner
Latches up
Fig.12Fig.11 Fig.13
6. Pull the rubber ring through the retractable rubber handle
and attach both ends around the top and bottom latch
hinge as shown in Fig. 13.
7. Screw the pump nozzle to the vent chamber and pump air
in until the Nose Cone pops off
(see Fig. 14).
IMPORTANT: ALWAYS attach the Rubber Ring before
using the pump. The Nose Cone can pop off and cause
injury if the Rubber Ring is not attached and tighly
secured.
8. Remove the Rubber Ring and remove the Nose Cone
(see Fig. 15).
9. Allow two minutes for any gases to dissipate.
10. Take out the Battery Pod from the unit.
11. Connect the Battery Pod to the Charging Base.
(see Fig. 16)
12. Plug the Charging Base into the mains, and turn on the
supply.
13. Charging will take around 12-14 hours for a fully
discharged battery. When the Battery Pod is charging, the
RED LED light on the Battery Pod remains flashing.
When the battery is fully charged, the GREEN LED
flashes. (see Fig. 16)
Fig.14 Fig.15
14. Unplug the Charging Base from the electrical socket/plug.
15. Allow battery to stand for 30 minutes before using it.
16. Unplug the Battery Pod from the Charging Base.
17. When ready to use, reconnect to the unit in the correct
position. (see Fig. 17)
18. MAKE SURE the O-ring Seals and sealing surfaces are
clean and fully lubricated
with the supplied grease
EVERYTIME (you can also
buy this at your local
hardware store) before
replacing the Nose Cone.
(see Fig. 18)
19. Ensure the Vent O Ring is
fitted correctly into the
groove and fully lubricated
with the supplied grease. (see
Fig. 18)
20. MAKE SURE to screw in the
Vent Plug to seal the vent.
21. Replace the Nose Cone and
close the Latches.

Care and Maintenance
Battery and Catalyzer Care
Please read and understand important Battery Use safety
information on pages 12, 13, 14 and 15.
• The battery supplied with your SEASCOOTER
™
should
last about 200 cycles or two years before it should be
replaced. Please contact your local customer service
center/distributor. Using a battery in excess of these
recommendations can result in excessive off-gassing of
hazardous gases.
• If the catalyzer is wet, it will not function and must be
allowed to dry out before use.
1918
Catalyzer
Fig.19
To Remove the 275L Nose Cone and charge the Battery
Pod, User MUST follow these instructions to avoid any
injury.
1. ALWAYS ensure that the Master Switch is in OFF position.
2. ALWAYS ensure that the 275L is out of the water, dry and
placed in a dry area.
3. Pull the four Latches down and remove the nose cone by
using the left and right Latches to break the seal if
necessary (see Fig. 11 and Fig. 12) and jump to Step 9.
4. If the nose-cone cannot be opened by pressing the
latches, replace the Retractable rubber handle on the
SEASCOOTER™ 275L. (see Fig. 13)
5. Release the Vent plug on top of the Nose Cone.
Fig.18
Sealing Surface
Fig.17
O-ring Seals
Battery Pod
6. Pull the rubber ring through the retractable rubber handle
and attach both ends around the top and bottom latch
hinge as shown in Fig. 13.
7. Screw the pump nozzle to the vent chamber and pump air
in until the Nose Cone pops off
(see Fig. 14).
IMPORTANT: ALWAYS attach the Rubber Ring before
using the pump. The Nose Cone can pop off and cause
injury if the Rubber Ring is not attached and tighly
secured.
8. Remove the Rubber Ring and remove the Nose Cone
(see Fig. 15).
9. Allow two minutes for any gases to dissipate.
10. Take out the Battery Pod from the unit.
11. Connect the Battery Pod to the Charging Base.
(see Fig. 16)
12. Plug the Charging Base into the mains, and turn on the
supply.
13. Charging will take around 12-14 hours for a fully
discharged battery. When the Battery Pod is charging, the
RED LED light on the Battery Pod remains flashing.
When the battery is fully charged, the GREEN LED
flashes. (see Fig. 16)
14. Unplug the Charging Base from the electrical socket/plug.
15. Allow battery to stand for 30 minutes before using it.
16. Unplug the Battery Pod from the Charging Base.
17. When ready to use, reconnect to the unit in the correct
position. (see Fig. 17)
18. MAKE SURE the O-ring Seals and sealing surfaces are
clean and fully lubricated
with the supplied grease
EVERYTIME (you can also
buy this at your local
hardware store) before
replacing the Nose Cone.
(see Fig. 18)
19. Ensure the Vent O Ring is
fitted correctly into the
groove and fully lubricated
with the supplied grease. (see
Fig. 18)
20. MAKE SURE to screw in the
Vent Plug to seal the vent.
21. Replace the Nose Cone and
close the Latches.
Vent O Ring
Silicone
Grease

• ALWAYS remove the battery pod from SEASCOOTER™
immediately after use.
• DO NOT STORE BATTERY POD IN SEASCOOTER
• DO NOT leave the Seascooter in the water. Always take the
unit out of water when not in use.
Washing and Care
• Always rinse the SEASCOOTER™ in fresh water and
allow it to dry before storage immediately after use.
• To clean the SEASCOOTER™do not use detergents,
only use a damp cloth to wipe the unit clean.
• The Battery Housing interior should be kept dry at all
times.
• If the Battery Housing interior gets wet, see page 23,
Accidental Flooding for procedure.
• Always store your SEASCOOTER™vertically when not
in use to prevent deformation of the Propeller Nozzle.
Buying Parts
Additional Battery Pods and Charging Bases can be
purchased separately. Contact your local Customer
service center/ distributor to purchase them.
To Remove the 275L Nose Cone and charge the Battery
Pod, User MUST follow these instructions to avoid any
injury.
1. ALWAYS ensure that the Master Switch is in OFF position.
2. ALWAYS ensure that the 275L is out of the water, dry and
placed in a dry area.
3. Pull the four Latches down and remove the nose cone by
using the left and right Latches to break the seal if
necessary (see Fig. 11 and Fig. 12) and jump to Step 9.
4. If the nose-cone cannot be opened by pressing the
latches, replace the Retractable rubber handle on the
SEASCOOTER™ 275L. (see Fig. 13)
5. Release the Vent plug on top of the Nose Cone.
Trouble Shooting
3. Disconnect and
remove the Battery
Pod - see page 15,
step 1 - 10.
4. Unscrew the twelve
Grille screws as
shown in fig.20 to
remove the Inner
Nozzle and Propeller
Nozzle.
5. While holding the
Propeller, use an M6
socket wrench to
remove the nut from
the Propeller shaft as shown in fig.21.
6. Slide the Propeller off the shaft, taking care not to lose
the drive pin or washers.
7. Remove the blockage from the Propeller or Propeller
Shaft.
8. Replace the drive pin (if removed), see fig.22, and
Propeller. Turn the Propeller slowly until you locate the
pin and push the Propeller fully on.
Fig.20
x 12
1. Take the SEASCOOTER™ 275L out from the water.
2. Make sure the Master Switch is in the OFF position.
Opening the grilles to remove obstruction
Unit does not function
If the Propeller does not start when the triggers are
pressed, make sure:
1. The Master Switch is ON (see fig.3)
2. The Battery Pod is fully charged. (see page 15, charging
the Battery Pod)
3. The battery compartment is dry.
Blocked Propeller
If the Propeller becomes blocked, it will be necessary to
open the Protective Grilles to remove the obstacle.
UNDER NORMAL USE the grilles must not be opened.
NEVER turn ON the propeller when it is blocked, it will
cause serious damage to the gear box.
9. Replace the washer and nut and tighten with the
socket wrench while holding the Propeller, make sure it
is securely fastened. (see fig.23)
10. Replace the Front Grille and Propeller Nozzle.
11. Install the Battery Pod and replace the Nose Cone
when ready for use.
Sand or Grit on O-ring Seal
Ensure that sand/grit does not get on the seals as Correct
maintenance and care is essential. To remove sand or grit
from the O-ring Seal, rinse the O-ring Seals in fresh water
and apply fresh lubricant. If there is sand inside the Battery
Housing, gently brush the sand from the unit, take care not
to scratch the sealing surfaces.
If an O-ring Seal is damaged, replace it with a new one
(see fig.1, item18) and apply fresh lubricant before use.
Warning!
Crushing / Cutting Hazard
Before opening the grille for maintenance purpose, make
sure the master switch is in off position, and the battery is
disconnected.
2120
6. Pull the rubber ring through the retractable rubber handle
and attach both ends around the top and bottom latch
hinge as shown in Fig. 13.
7. Screw the pump nozzle to the vent chamber and pump air
in until the Nose Cone pops off
(see Fig. 14).
IMPORTANT: ALWAYS attach the Rubber Ring before
using the pump. The Nose Cone can pop off and cause
injury if the Rubber Ring is not attached and tighly
secured.
8. Remove the Rubber Ring and remove the Nose Cone
(see Fig. 15).
9. Allow two minutes for any gases to dissipate.
10. Take out the Battery Pod from the unit.
11. Connect the Battery Pod to the Charging Base.
(see Fig. 16)
12. Plug the Charging Base into the mains, and turn on the
supply.
13. Charging will take around 12-14 hours for a fully
discharged battery. When the Battery Pod is charging, the
RED LED light on the Battery Pod remains flashing.
When the battery is fully charged, the GREEN LED
flashes. (see Fig. 16)
14. Unplug the Charging Base from the electrical socket/plug.
15. Allow battery to stand for 30 minutes before using it.
16. Unplug the Battery Pod from the Charging Base.
17. When ready to use, reconnect to the unit in the correct
position. (see Fig. 17)
18. MAKE SURE the O-ring Seals and sealing surfaces are
clean and fully lubricated
with the supplied grease
EVERYTIME (you can also
buy this at your local
hardware store) before
replacing the Nose Cone.
(see Fig. 18)
19. Ensure the Vent O Ring is
fitted correctly into the
groove and fully lubricated
with the supplied grease. (see
Fig. 18)
20. MAKE SURE to screw in the
Vent Plug to seal the vent.
21. Replace the Nose Cone and
close the Latches.

23
To Remove the 275L Nose Cone and charge the Battery
Pod, User MUST follow these instructions to avoid any
injury.
1. ALWAYS ensure that the Master Switch is in OFF position.
2. ALWAYS ensure that the 275L is out of the water, dry and
placed in a dry area.
3. Pull the four Latches down and remove the nose cone by
using the left and right Latches to break the seal if
necessary (see Fig. 11 and Fig. 12) and jump to Step 9.
4. If the nose-cone cannot be opened by pressing the
latches, replace the Retractable rubber handle on the
SEASCOOTER™ 275L. (see Fig. 13)
5. Release the Vent plug on top of the Nose Cone.
3. Disconnect and
remove the Battery
Pod - see page 15,
step 1 - 10.
4. Unscrew the twelve
Grille screws as
shown in fig.20 to
remove the Inner
Nozzle and Propeller
Nozzle.
5. While holding the
Propeller, use an M6
socket wrench to
remove the nut from
the Propeller shaft as shown in fig.21.
6. Slide the Propeller off the shaft, taking care not to lose
the drive pin or washers.
7. Remove the blockage from the Propeller or Propeller
Shaft.
8. Replace the drive pin (if removed), see fig.22, and
Propeller. Turn the Propeller slowly until you locate the
pin and push the Propeller fully on.
Fig.21
Beware of
sharp corners
when servicing
1. Take the SEASCOOTER™ 275L out from the water.
2. Make sure the Master Switch is in the OFF position.
Fig.22
Drive Pin In Position
9. Replace the washer and nut and tighten with the
socket wrench while holding the Propeller, make sure it
is securely fastened. (see fig.23)
10. Replace the Front Grille and Propeller Nozzle.
11. Install the Battery Pod and replace the Nose Cone
when ready for use.
Sand or Grit on O-ring Seal
Ensure that sand/grit does not get on the seals as Correct
maintenance and care is essential. To remove sand or grit
from the O-ring Seal, rinse the O-ring Seals in fresh water
and apply fresh lubricant. If there is sand inside the Battery
Housing, gently brush the sand from the unit, take care not
to scratch the sealing surfaces.
If an O-ring Seal is damaged, replace it with a new one
(see fig.1, item18) and apply fresh lubricant before use.
Fig.23
Washer
Drive pin
Propeller
Propeller Shaft
Nut
22
6. Pull the rubber ring through the retractable rubber handle
and attach both ends around the top and bottom latch
hinge as shown in Fig. 13.
7. Screw the pump nozzle to the vent chamber and pump air
in until the Nose Cone pops off
(see Fig. 14).
IMPORTANT: ALWAYS attach the Rubber Ring before
using the pump. The Nose Cone can pop off and cause
injury if the Rubber Ring is not attached and tighly
secured.
8. Remove the Rubber Ring and remove the Nose Cone
(see Fig. 15).
9. Allow two minutes for any gases to dissipate.
10. Take out the Battery Pod from the unit.
11. Connect the Battery Pod to the Charging Base.
(see Fig. 16)
12. Plug the Charging Base into the mains, and turn on the
supply.
13. Charging will take around 12-14 hours for a fully
discharged battery. When the Battery Pod is charging, the
RED LED light on the Battery Pod remains flashing.
When the battery is fully charged, the GREEN LED
flashes. (see Fig. 16)
14. Unplug the Charging Base from the electrical socket/plug.
15. Allow battery to stand for 30 minutes before using it.
16. Unplug the Battery Pod from the Charging Base.
17. When ready to use, reconnect to the unit in the correct
position. (see Fig. 17)
18. MAKE SURE the O-ring Seals and sealing surfaces are
clean and fully lubricated
with the supplied grease
EVERYTIME (you can also
buy this at your local
hardware store) before
replacing the Nose Cone.
(see Fig. 18)
19. Ensure the Vent O Ring is
fitted correctly into the
groove and fully lubricated
with the supplied grease. (see
Fig. 18)
20. MAKE SURE to screw in the
Vent Plug to seal the vent.
21. Replace the Nose Cone and
close the Latches.

2524
Accidental Flooding
It is important that the seal is kept sand and grit free to
ensure it keeps water out and to close the latches fully
after accessing the battery chamber. However, should the
O-ring Seal not be clean or the latches not fully closed and
water enters the battery chamber, your SEASCOOTER™
will not be damaged as it is designed for protection against
accidental flooding.
Water Leakage Sensor
(operates when propeller is turning)
Your SEASCOOTER™has a built-in water leakage sensor
– when the unit experiences accidental flooding, the motor
will stop momentarily every 10 seconds. At the same
moment, a buzzer will beep every 10 seconds.
If water enters the battery chamber:
1. Remove the SEASCOOTER™from the water if safe to
do so. Always observe safe diving practice.
2. Remove nose cone and tip out any excess water.
3. Wait two minutes for any gases to dissipate, then
remove battery pod.
4. If salt water has entered, rinse battery, battery pod and
housing with fresh water.
5. Dry housing and battery pod thoroughly.
6. A safety catalyzer, to protect against explosive gas in
normal use, is held in a spring in the bottom of the
battery housing. If the catalyzer is wet it will not function
and must be allowed to dry out before use.
Water Leakage Sensor (continued)
(operates when propeller is turning)
If the battery chamber is dry and the water leakage sensor
continues to beep then there is a leakage in the motor
housing, contact customer service center/repair center for
maintenance.
DO NOT OPERATE A UNIT WITH A SUSPECTED LEAK
INTO THE MOTOR CHAMBER.
To Remove the 275L Nose Cone and charge the Battery
Pod, User MUST follow these instructions to avoid any
injury.
1. ALWAYS ensure that the Master Switch is in OFF position.
2. ALWAYS ensure that the 275L is out of the water, dry and
placed in a dry area.
3. Pull the four Latches down and remove the nose cone by
using the left and right Latches to break the seal if
necessary (see Fig. 11 and Fig. 12) and jump to Step 9.
4. If the nose-cone cannot be opened by pressing the
latches, replace the Retractable rubber handle on the
SEASCOOTER™ 275L. (see Fig. 13)
5. Release the Vent plug on top of the Nose Cone.
6. Pull the rubber ring through the retractable rubber handle
and attach both ends around the top and bottom latch
hinge as shown in Fig. 13.
7. Screw the pump nozzle to the vent chamber and pump air
in until the Nose Cone pops off
(see Fig. 14).
IMPORTANT: ALWAYS attach the Rubber Ring before
using the pump. The Nose Cone can pop off and cause
injury if the Rubber Ring is not attached and tighly
secured.
8. Remove the Rubber Ring and remove the Nose Cone
(see Fig. 15).
9. Allow two minutes for any gases to dissipate.
10. Take out the Battery Pod from the unit.
11. Connect the Battery Pod to the Charging Base.
(see Fig. 16)
12. Plug the Charging Base into the mains, and turn on the
supply.
13. Charging will take around 12-14 hours for a fully
discharged battery. When the Battery Pod is charging, the
RED LED light on the Battery Pod remains flashing.
When the battery is fully charged, the GREEN LED
flashes. (see Fig. 16)
14. Unplug the Charging Base from the electrical socket/plug.
15. Allow battery to stand for 30 minutes before using it.
16. Unplug the Battery Pod from the Charging Base.
17. When ready to use, reconnect to the unit in the correct
position. (see Fig. 17)
18. MAKE SURE the O-ring Seals and sealing surfaces are
clean and fully lubricated
with the supplied grease
EVERYTIME (you can also
buy this at your local
hardware store) before
replacing the Nose Cone.
(see Fig. 18)
19. Ensure the Vent O Ring is
fitted correctly into the
groove and fully lubricated
with the supplied grease. (see
Fig. 18)
20. MAKE SURE to screw in the
Vent Plug to seal the vent.
21. Replace the Nose Cone and
close the Latches.

Technical Specifications
26
*Normal Use
The definition of normal use is based on the average general time
of use the user activates the seascooter in the water.
∆
Continuous Use
The definition of continuous use is based on a fully charged battery
whereby the seascooter is used continuously in the water without
stopping.
12.6 inches x 12.6 inches x 28 inches
(320 x 320 x 710 mm)
Unit Dimensions
Unit Weight
32.4 lb (14.7 kg) (with rechargeable battery)
14.3 lb (6.5 kg) (without rechargeable battery)
Battery Type 1 x 12V / 24Ah rechargeable battery
Battery Life /
Fully Charged
*Run up to 2 hours with normal use
∆
Continuous use up to 50 minutes (high speed)
Depth rating 40m/130ft
Speed Up to 3.3 mph (5.3 km/h)
To Remove the 275L Nose Cone and charge the Battery
Pod, User MUST follow these instructions to avoid any
injury.
1. ALWAYS ensure that the Master Switch is in OFF position.
2. ALWAYS ensure that the 275L is out of the water, dry and
placed in a dry area.
3. Pull the four Latches down and remove the nose cone by
using the left and right Latches to break the seal if
necessary (see Fig. 11 and Fig. 12) and jump to Step 9.
4. If the nose-cone cannot be opened by pressing the
latches, replace the Retractable rubber handle on the
SEASCOOTER™ 275L. (see Fig. 13)
5. Release the Vent plug on top of the Nose Cone.
6. Pull the rubber ring through the retractable rubber handle
and attach both ends around the top and bottom latch
hinge as shown in Fig. 13.
7. Screw the pump nozzle to the vent chamber and pump air
in until the Nose Cone pops off
(see Fig. 14).
IMPORTANT: ALWAYS attach the Rubber Ring before
using the pump. The Nose Cone can pop off and cause
injury if the Rubber Ring is not attached and tighly
secured.
8. Remove the Rubber Ring and remove the Nose Cone
(see Fig. 15).
9. Allow two minutes for any gases to dissipate.
10. Take out the Battery Pod from the unit.
11. Connect the Battery Pod to the Charging Base.
(see Fig. 16)
12. Plug the Charging Base into the mains, and turn on the
supply.
13. Charging will take around 12-14 hours for a fully
discharged battery. When the Battery Pod is charging, the
RED LED light on the Battery Pod remains flashing.
When the battery is fully charged, the GREEN LED
flashes. (see Fig. 16)
14. Unplug the Charging Base from the electrical socket/plug.
15. Allow battery to stand for 30 minutes before using it.
16. Unplug the Battery Pod from the Charging Base.
17. When ready to use, reconnect to the unit in the correct
position. (see Fig. 17)
18. MAKE SURE the O-ring Seals and sealing surfaces are
clean and fully lubricated
with the supplied grease
EVERYTIME (you can also
buy this at your local
hardware store) before
replacing the Nose Cone.
(see Fig. 18)
19. Ensure the Vent O Ring is
fitted correctly into the
groove and fully lubricated
with the supplied grease. (see
Fig. 18)
20. MAKE SURE to screw in the
Vent Plug to seal the vent.
21. Replace the Nose Cone and
close the Latches.
US & CANADA MARKET ONLY
Toll Free (US) : 1-800-678-7873
[email protected]
www.yamahaseascooters.com
(US & CANADA MARKET ONLY)
For more information on
Seascooter™Products
(Warranty, Customer Care / Maintenance,
Parts & Battery Purchase)
PLEASE VISIT
www.yamahaseascooters.com
Please visit our website at www.yamahaseascooters.com to find out your local distributor.
Yamaha, the Crossed Tuning Fork Design, and any likeness thereof are trademarks of
Yamaha Motor Corp. U.S.A. and Yamaha Motor Co., Ltd. (“Yamaha”) used
under license by Sport Dimension Inc. www.yamaha-motor.com.
This Product is not manufactured by Yamaha. For consumer purposes,
please contact Sport Dimension Inc. at 1-800-678-7873.
All corresponding specification appear in this manual are correct at the time of printing.
For the latest updates and further information on the complete range of the Seascooter™,
PLEASE VISIT www.yamahaseascooters.com

For any questions or queries you may have regarding your
SEASCOOTER™, please follow the below steps for easy and
fast resolution:
- STEP 1-
Please read your User Manual. For a copy of the User Manuals, please visit
www.yamahaseascooters.com
- STEP 2-
Go to www.yamahaseascooters.com and see our FAQ section to find instant
answers.
- STEP 3-
Contact one of our Customer Service representatives at the Customer Service
Center in your region.
CUSTOMER ENQUIRIES
If your unit is not operating, please refer to your User Manual before
contacting our Customer Service Center. For any damage or repair work
required, please do not return your product to the store where it was
purchased.
RETURN / REPAIR POLICY
Customers must contact their Local Distributor Service Center to ask for an
official Claim Form. The Claim Form must be returned with the customer’s
contact details and a photo of the Seascooter, defective parts, the serial
number and the Original Purchase Receipt. The Distributor Customer Service
Center will review the case and issue a Return / Repair Authorization Number
before sending the product to the Distributor Service Center. Returned
products must be shipped with original packaging including the polystyrene
packing material and all defective parts. Please contact your Local Distributor
Service Center for assistance in handling your case.
Please visit our website www.yamahaseascooters.com
for a listing of most update distributor contacts and
service center contacts.
RETURN / REPAIR PROCEDURE
1. Call the Customer Service Center for your Return / Repair Authorization
Number.
2. Make a copy of your Proof of Purchase (receipt).
3. Pack the defective unit in its original packaging including the polystyrene
foam and include the unit and all defective parts.
4. Attach the copy of your Proof of Purchase (receipt) to the outside of the box
(clearly visible), together with the Return / Repair Authorization Number.
5. Ship the package to the Service Center on your cost.
PLEASE NOTE: Deliveries that do not have the Proof of Purchase (receipt)
and Return / Repair Authorization Number attached clearly to the outside of
the box, will not be accepted by the Service Center.
In addition, this warranty does not cover items that
experience normal wear and tear.
ALL IMPLIED WARRANTIES ARE LIMITED IN THE DURATION TO THE
WARRANTY PERIOD. AND SUCH IMPLIED WARRANTIES INCLUDING
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, OR
OTHERWISE, ARE DISCLAIMED IN THEIR ENTIRETY AFTER THE
EXPIRATION OF THE APPROPRIATE WARRANTY PERIOD. THE
DISTRIBUTOR’S OBLIGATION UNDER THE WARRANTY IS STRICTLY
AND EXCLUSIVELY LIMITED TO THE REPAIR OR REPLACEMENT OF
DEFECTIVE PARTS AND RETURN OF THE PRODUCT TO THE
CUSTOMER. THE DISTRIBUTOR DOES NOT ASSUME OR AUTHORIZE
ANYONE TO ASSUME FOR THEM ANY OTHER OBLIGATION.
THE DISTRIBUTOR ASSUMES NO RESPONSIBILITY FOR INCIDENTAL,
CONSEQUENTIAL OR OTHER DAMAGES INCLUDING, BUT NOT LIMITED
TO EXPENSE OF RETURNING THE PRODUCT TO THE DISTRIBUTOR,
LOSS OF USE OF PRODUCT AND LOSS OF TIME OR INCONVENIENCE.
THIS PRODUCT IS DESIGNED AND INTENDED FOR PERSONAL
RECREATIONAL USE ONLY!
THIS PRODUCT IS NOT WARRANTED FOR COMMERCIAL OR
RENTAL USE!
REPAIR WORK OR DELIVERY OF A REPLACEMENT DOES NOT
EXTEND OR RENEW THE WARRANTY PERIOD.
WARRANTY SHALL AUTOMATICALLY BE VOID IF DAMAGE IS
RESULT OF NON-ORIGINAL PARTS.
LIMITED WARRANTY for seascooters with camera mount:
• ALWAYS inspect to ensure the product works properly every time before
use. Warranty of this product does not cover any damages due to misuse.
• Failure to follow the user(s) instructions on packaging and/or user(s)
manual may result in damages or loss of your cameras including but not
limited to any user’s personal items, all of which are not covered under
warranty of this product.
• Use at your own risk. Manufacturer(s) and/or suppliers/agents are not
responsible for any damages/repairs, loss to cameras/electronic items
including but not limited to any user’s personal items directly and/or
indirectly resulted in the use of this product. Damage(s) resulting from any
use, misuse, accident, and normal wear and tear are understandably not
covered under this product warranty nor be responsible by manufacturer(s)
and/or suppliers/agents.
EXCLUSIONS
BATTERY. This warranty does not include the battery.
Never replace the original SEASCOOTER BATTERY with an
AFTERMARKET BATTERY. Seascooter with aftermarket battery will not be
covered by this warranty.
