Yield Technology Super Guard PT-2 User manual

SuperGuard
GPS Personal Tracker
---------- Operation Manual ----------
Portable GPS/GSM/GPRS Device Model PT-2

Warranty
The Yield Technology Co., Ltd. (YTC) warrants to the purchaser that this product, under
normal use and conditions, will be free from defects in materials and workmanship for a
period of 12 months from the date of original purchase. If a product proves defective
during this warranty period, YTC, at its option, either will repair the defective product
without charge for parts and labor, or will provide an exchange for the defective product.
In order to obtain service under this warranty, the purchaser must notify YTC of the defect
before the expiration of the warranty period and make suitable arrangements for the
performance of service. The purchaser shall be responsible for appropriate packaging and
shipping with a carrier designated by YTC, with shipping charges paid by recipient (YTC).
This warranty shall not apply to any defect, failure or damage caused by improper use or
improper or inadequate maintenance and care, alterations, mishandling or accidents. YTC
shall not be obligated to furnish service under this warranty to costs incurred for
installation, to correction of antenna problems, removal or reinstallation or to damage to
video tapes, discs, speakers, accessories or vehicle electrical system.
The extend of YTC’s liability under this warranty is limited to the repair or replacement
provided above and, in no event, shall the company’s liability exceed the purchase price
paid for this product.
THIS WARRANTY IS GIVEN BY YTC IN LIEU OF ANY OTHER WARRANTIES,
EXPRESS OR IMPLIED. YTC AND ITS VENDORS DISCLAIM ANY IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. YTC’S RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE
PRODUCTS IS THE SOLE AND EXCLUSIVE REMEDY PROVIDED TO THE
PURCHASER FOR BREACH OF THIS WARRANTY. YTC AND ITS VENDORS
WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER YTC OR THE
VENDOR HAS ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.
Thank you for purchasing the
SuperGuard Personal Communication
and Tracking device. Please read all
instructions carefully before
operation, to ensure your complete
understanding and to obtain the best
possible performance from the unit.
Notices
 To decrease the influence of electromagnetic interference, please use the
device properly. The SAR standard value is 1.6W/Kg, and the result of testing
the product is: 0.322 W/Kg. (Note: Mobile phone modules are free from testing
and SAR label).
 Do not touch the battery charger connector with any metal objects such as
coins or key rings to avoid the danger of short circuit.
 Do not dispose of the battery in fire.
 Do not put the battery in your mouth. Unintentionally swallowing the battery
may result in poisoning.
 Do not try to disassemble the product or accessories.
 The product has a built-in battery, which can only be replaced or changed by
qualified technicians or authorized service personnel. Using an improper type
of battery may result in explosion. Follow the manufacturer's instructions to
dispose of the used batteries.
 Use of other batteries, DC adapter, car charger (optional) or desktop charger
(optional) not specified by the manufacturer may result in possible danger.
 Under normal operation or charging, the handset may become warm or hot.
 Use an anti-static cloth to clean the product. Do not use any dry cloth or
materials, which generate static electricity.
 Do not use chemical cleaning agents or cleaning agents with grinding
components. It might scratch the surface of the outer casing.
 Recycle the cardboard and other packaging materials for environmental
protection.
Flight Security Notes
Turn off the product on board an airplane or within the flight security range.
Using mobile phones in an airplane is illegal and may endanger flight
security. IPSs may reject services due to misuse of product, violation of
law or offense against public security. Do not use the product in the airport
unless permitted by airport personnel.
General Security Notices
 Turn off the product according to the instructions on two-way radio
device security rules in vicinity of oil storage, chemical storage, or
explosive substances.
 Tiny parts in the package should be placed out of reach of children to
avoid accidents.
 Operating the product may affect the functionality of medical devices
and equipment such as hearing aids or pacemakers. Follow the
warnings and manufacturer's recommendations.

Automobiles with Air Bags
Do not place any object (including fixed or handheld wireless devices) in
the effective range of air bags because huge air pressure may result in
harm. If the wireless device is not properly installed, it may cause serious
damage or injury when the air bags are inflated.
Security Notices During Driving
 Always drive with full concentration.
 Follow the local traffic rules and regulations.
 Use a headset or hands-free device to receive or place phone calls
during driving.
 Do not park on a shoulder for calling except in emergencies.
 Turn off the product when entering a gas station.
 Do not put the product near combustible objects, explosive substances,
or radio transmitters.
 Generally the electronic systems in car such as anti-lock braking
system, active cruise control, and fuel injection system are not
influenced by radio transmission. Manufacturers for the mentioned
systems or devices provide you with information on anti-
electromagnetic interruption function. If you have any question or doubt
about radio transmission influence, consult your distributor.
 Unauthorized personnel should not open or disassemble the product.
Service and Maintenance
Users cannot repair or replace any part in the product, battery, or charger.
It is strongly recommended that you should return the product to service
centers authorized by YTC for service or maintenance. For more
information, consult YTC or your distributors.
Effective Use
To enhance performance and reduce power consumption the product is
built with embedded antenna. Do not cover any part of the antenna to
maintain superior talking performance. To cover the antenna causes
greater power consumption, which reduces talking time and standby time.
Table of Contents
1. Parts & Accessories page 6
2. Personal Tracker - Features page 8
GPS Features
3. Preparations page 10
4. LED Status Description page 11
5. Getting Started page 12
6. Phone Operation page 13
Make a Phone Call
Receive Incoming Calls
Power On/ Off the Device
7. SOS Emergency Calls page 14
8. Monitoring Features page 15
Geo-Fence Alarms
Maximum Speed Alarms
Battery Low Warning
9. Locating and Tracking page 17
Quick Locator
Get Detailed Locations
Online Tracking
10. Technical Specifications page 20

1. Parts & Accessories
On receipt of your Personal Tracker package, please check that all
contents are complete and correct.
6
2
5
1
3
4
1. SuperGuard Personal Tracker PT-2 Unit
2. 3.6V Rechargeable Battery
3. Carry bag with belt clip and carrying strap
4. Earphone set
5. Charger
The following chapters describe the Personal Tracker in detail and
help you familiarize yourself with functions and features. Read the
manual carefully before you use the Personal Tracker. 7
This manual covers SuperGuard Personal Tracker
model PT-2.
The PT-2 combines Global Positioning System (GPS)
technology and GSM/GPRS mobile communication with
online tracking and remote setup features.
All SuperGuard products can be managed and
monitored over Control Base and Tracking System
Server software or online over Internet Websites
provided by professional service centers.
LEDs (GSM/GPRS/SOS)
GPS non-directional antenna
Speaker
SOS help button
First speed dial button and
receive button
Second speed dial button and
hang up button
Microphone
Ear
p
hone connecto
r
Charger connector

2. Personal Tracker – Features

The Personal Tracker is designed as a simple mobile phone with
limited functions. It can memorize two preset numbers for quick
dialing. You can use the Personal Tracker to place phone calls or
receive incoming calls from any caller.
 You can memorize and label 5 GPS reference points and receive
distance and directions by SMS.
 The Personal tracker comes with one SOS button designed for
emergency calls. Pressing it will trigger an alarm message to
Control Base and up to 3 authorized contact numbers. In addition,
an automatic phone call will be placed to the main contact person.

Users are able to setup and configure device settings, monitoring
activities and alerts online, using Control Base software or
Tracking Web services via Internet Explorer or mobile on GPRS
enabled cell phones.
 Authorized contact persons can locate and track users per SMS
and online maps over Internet Website or GPRS cell phones.
 Users can define and load up to 4 restricted areas (Geo-Fence areas)
to the device and setup maximum speed limit alerts.
8
GPS Features:
The SuperGuard Personal Tracker employs an advanced tracking
system, which helps you determine your location, enable preset
contacts to track your position any time, and place SOS calls in case of
emergency.
The Personal Tracker is easy to configure over Internet or GPRS
enabled cell phones, user-friendly, and especially convenient for
monitoring children, elderly and business travelers.
Global Positioning System (GPS) is a global radio navigation system,
which consists of 24 MEO satellites and stations on the earth. A GPS
receiver built in the device calculates your location and altitude via the
signal from satellite. Based on triangulation of signals of at least three
of the satellites, it applies a “Pseudoranging” technique to calculate the
transmission time of the radio signal from the satellite in order to
measure the distance of each satellite, and then pinpoint the current
location.
GPS Satellites emit two types of radio signals, “C/A”
(Coarse/Acquisition) and “P” (Precision). The latter one is preserved
for military use and requires decryption. Like other commercial GPS
appliances, the Personal tracker uses “C/A” signal to pinpoint location
and altitude. Likewise, the display accuracy of location will depend on
varied factors, which include time.
Please note that those variations are fundamental characteristics of
GPS, it doesn’t indicate any malfunction of the mini tracker.
The following situations may affect accuracy of GPS:
1. Narrow alley between tall buildings in built up area.
2. Indoors
3. Bad weather
4. Under shelter
5. In tunnels
6. Inside a car with metal heat insulation. (We suggest avoid use near metal heat
insulation while you are using the mini tracker in the car.)
9

3. Preparations
In order to use the Personal Tracker, the following preparations
should be carried out:
Prepare one operational GSM SIM card. Make sure that the SIM card
can operate without PIN protection (ask the GSM operator to do this).
Ask the GSM operator for the SMSC (SMS Service Center) number.
Empty the SMS storage of the SIM card using operational GSM phone
(please refer your GSM phone manual to do this).
1. Remove the back cover of the Personal
tracker by pressing down the rounded
edge of the battery release button and
push the cover downwards.
2. Insert the SIM card into the SIM slot in
the direction as shown in picture until it
is engaged.
(To remove the SIM card later, push it
in again to release)
3. Place the battery in the compartment.
4. Replace the cover and let it snap in
completely.
Closing the battery cover will automatically power up the device.
Removing the cover will disconnect the battery.
10
4. LED Status Description
 Power/ GSM LED (green)
 If LED is on:
Device is powered on
 If LED flashes:
Device is registered to GSM network, able to send/
receive SMS and place or receive phone calls
 If LED is off for a period of time:
Device is communicating with Control Base or
Contact numbers
GPS/ GPRS LED (red)
 If LED flashes:
Device has GPS lock
 If LED stays on for a period of time:
Device is dialing GPRS service. If connected, LED
will flash several times if connection to Control
Base was successful. Will repeat if not successful.
SOS LED (red)
 When SOS button been pressed for 2 seconds, will turn
on.
 All three LED flashing repeatedly and simultaneously
indicate battery low. Please charge battery.
11
 

5. Getting Started
After closing the battery cover, the Personal Tracker will power up
and automatically attempt to register to GSM network.
Provided that your device is positioned in an area with clear un-
obstructed view of the sky, the device will start scanning for GPS
satellites to obtain its first GPS lock. This first fix can take several
minutes.
To use all communication and tracking features of the device, some
mandatory setup parameters need to be configured from the Control
Base software or Tracking Websites before it is able to operate
properly. Please refer to your Tracking Web or software guide to do
the account and device configurations.
After setting up a user account at the Control Base, please make sure
that all required SIM card details, SMS and GPRS dial-up
information and Contact numbers have been entered correctly, before
you send them through SMS initialization command to the device:
Name: This name will appear to identify the device when you
receive GPS location and alarm SMS
NO: Refers to the GSM number used with the device
SMSC: Service Center Number of the Cellular Service Provider
from which you purchased the SIM card used in your
device.
Cont 1: Phone number of the main authorized contact person to
remote control security features and receive SMS
alarms.
GPRS uID: (if required) User name or ID to enable GPRS services
GPRS PSW: (if required) Password to enable GPRS services
GPRS Dial: Dial-up number to connect to GPRS network
APN: Access Point Nod address to connect to GPRS network
Submit and initialize all these information to the device in order to
complete the setup of your Personal Tracker.
12
6. Phone Operation
The Personal Tracker allows you to receive and accept phone calls and
quick-dial to two preset phone numbers.
Make a Phone Call
Press the first button to quick-dial to
the main contact number you have
setup at your Control Base software or
online Tracking Web.
Press the third button to quick-dial to
the second contact number you have
setup at your Control Base software or
online Tracking Web.
To end a call, press the first or third
button.
Receive Incoming Calls
Press the first button to accept an
incoming phone call.
To end the call, press the first or third
button.
NOTE: The Personal Tracker’s first 12 seconds of ring time (ca. 2-6
rings) are reserved for the Single Location Request function.
The ring tone will only be audible at the device after this period.
To power off the device, press the third button and hold for 5 seconds.
Press again to turn the device on. 13
Quick-Dial 1
Hang-up
Quick-Dial 2
Hang-up
Receive Call
Hang-up;
Power Off
(hold 5 sec)

7. SOS Emergency Calls
The Personal Tracker comes with an SOS emergency button, which
can be pressed to notify contact persons about current location and
automatically place a call to the main contact.
Press the second (middle) button and
hold for 2 seconds to place an
emergency call.
The SOS LED will turn on to indicate
that data is being sent to the Control
Base.
 The device will send an alarm message and GPS coordinates to the
Control Base. The Control Base software will find the street name
and closest intersection from a map server and send these details
through SMS short messages to all Contact numbers, with the text
(example):
 The Personal Tracker will then automatically dial a phone call to
main Contact number.
 To end the SOS call, press the first or third button on the device.
 After placing the SOS phone call, the Personal Tracker will
automatically start tracking and update GPS positions to the
Control Base every 60 seconds over a period of 30 minutes.
Tracking can be stopped during that time from the Control Base
or Tracking Website.
14
SOS Button
(
hold 2 sec
)
Hang-up
Robert is in Madison Ave,
near intersection Brixton
Rd.; SOS !
8. Monitoring Features
Users are able to setup and configure monitoring activities and alerts
to the Personal Tracker, using Control Base software or Tracking
Web services via Internet Explorer or mobile on GPRS enabled cell
phones.
Geo-Fence Alarms
 If the device has been configured with a set of restricted
geographic areas (Geo-Fences), the following activities will be
triggered when a Geo-Fence violation occurs:
 The Personal Tracker will send an alarm message and GPS
coordinates to the Control Base. The Control Base software will
find the street name and closest intersection from a map server and
send these details through SMS short messages to the list of
authorized Contact persons, with the text:
 The Geo-Fence alert and location updates will be repeated every 60
min if the device still stayed in the restricted area.
Maximum Speed Alarms
 If the device has been configured with a maximum speed limit, the
following activities will be triggered when the moving speed
exceeds the speed limit:
15
Robert is in Arlington., near
intersection Fairfax Ramp;
GEO Fence Violation !

 The Personal Tracker will send an alarm message and GPS
coordinates to the Control Base. The Control Base software will
find the street name and closest intersection from a map server and
send these details through SMS short messages to all Contact
numbers, with the text:
Battery Low Warning
 If the included battery pack in the Personal Tracker runs low on
power:
 The device will send an alarm message and GPS coordinates to the
Control Base. The Control Base software will find the street name
and closest intersection from a map server and send these details
through SMS short messages to all Contact numbers, with the text:
16
Robert is in Highway 166,
near intersection Gleebe;
Speeding
Robert is in Madison Ave.,
near intersection Brixton
Rd.; GPS Car Alarm:
Batter
y
Low
9. Locating and Tracking
Authorized users can interrogate the Personal Tracker to receive
locations, street names and details. If present, they can poll and track
devices through Control Base software or Tracking Web services via
Internet Explorer or mobile on GPRS enabled cell phones.
Quick Locator
 To setup reference points and receive current positions and
directions directly from the Personal Tracker, authorized Contact
persons can configure and label up to 5 GPS location points:
 From your GSM phone, use SMS text message to configure the
device with a local time zone, used for Quick Locator function
(example for GMT +2 hours):
$TIME,02 Enter Personal Tracker Number Send
 From your GSM phone, use SMS text message to setup a reference
point at the current location of the device (example for point
number 1; do accordingly for points 2 ~ 5):
$SET,1,OFFICE Enter Personal Tracker Number
Send
The Device will set the current GPS position as reference
point 1, labeled “OFFICE”. 17
N
OTE: Only the Contact Numbers and Contro
l
B
ase will be ab
l
e to send location and trackin
g
commands. Using other cell phones or dial-up
s
oftware to send commands to the unit will hav
e
no effect on the Device.

 To poll the distance and direction of the device from a preset
reference point, use the GSM cell phone to send SMS text message
(example for reference point number 1):
$GET,1 Enter Vehicle Unit Number Send
You will receive an SMS from the device shortly (example):
with the meaning: “Robert is 36 km South West of
reference point OFFICE. His current speed is 58 km/h at
19:45:23 hours, date: August 7th “.
Get Detailed Locations
 To receive detailed location information from the device or Control
Base, do the following:
 From one of the contact numbers, place a call to the device and let
it ring. Hang up after 4-5 seconds (ca. 2 rings).
Dial Call to Personal Tracker 2 Rings Hang Up
 The device will go GPRS online and send it’s latest GPS position to
the Control Base. The Control Base software will find the street
name and closest intersection from a map server and send these
details through SMS text message to you.
If the device’s first attempt to dial GPRS failed for any reason,
the GPS data will be sent to the Control Base through SMS
instead. In that case, you will receive location details sent from
the Control Base directly (backup feature).
18
Robert is 36 km SW of
OFFICE. Speed: 58 km/h,
19:45:23, 08-07
Online Tracking
 From the Control Base software, over Internet from the Tracking
Website or GPRS enabled cell phones, you are able to receive
updated GPS locations from your devices and display them on a
map, and view Tracking history and results over unlimited time.

From the Control Base or Websites, you are also able to setup
Tracking schedules for periods up to 45 days, in intervals between
30 seconds and 17 hours.
 You can start and end tracking your devices in real-time, following
its route on a map (GPRS connection and network coverage
required).
 You can setup and modify device configurations, define Geo-Fence
areas and speed limits. You will also be able to configure sleeping
modes for the GPS engine to reduce power consumption.
19
N
OTE: To send location requests from authorize
d
Contact numbers, you will need to enable Calle
r
I
D features on your cell phone.

10. Technical Specifications
General
The unit utilizes GPS to receive time, date, longitude, latitude,
speed, direction data; GPRS for data exchange with Control Base
and GSM for communication and short messa
g
in
g
.
GSM
GSM/GPRS module Telit GM 862 GPRSmodule
GSM 900 MHz (2 watt) Class 4
GSM 1800 MHz (1 watt) Class 1
GSM Antenna Built-in
GPS
GPS module L1, C/A code receiver, 12 channels
Protocol NMEA-0183 V3.0, proprietary iTALK
binary protocol
GPS Antenna Sarantel S-type
Standard dual band frequency
Input: >2W peak power
Accuracy 10m-20m
Update rate 1 Hz/sec.
Start time Cold start: 44sec
Hot start: 8sec
Speed/Accuracy 0.2 M/sec. (50%)
Acceleration Max: 4g
Max Height 18,000 M
Sensitivity -145 dBW
Datum Coordinate WGS-84
Electrical
Operating Voltage 3.6V
Charge Voltage 6-8V
Stand by 15mA
Operating 80mA
Talk 100mA
Battery Motorola 998 1000 mAh
Operating time: >8h, Talk time: 3h,
Standby time: 36h
Others
Operating temperature -10℃to +50℃
Dimensions (88+21*)x54x25.2mm(*Antenna: 21mm)
Speaker (Built-in) 32Ohm/0.5W
Microphone (Built-in) 58db
Yield Technology Co., Ltd.
No. 5-7 Shia Shin Nan, Chungli
Taoyuan, TAIWAN R.O.C.
TEL: [phone]
FAX: [phone]
E-MAIL: [email protected]
