YOKOHAMA WMT7YOKW User manual

OWNER’S MANUAL Washing MachineRead This ManualUse all instructions and explanations installation before use. Follow the instructions carefully. Keep the operation instructions handy for later use. If the is sold or passed on then ensure that the new owner always receives .ondeleteproductthismanualWMT7YOKW

1 CONTENTSSAFETY INSTRUCTIONS Safety instructions ................................................. ....INSTALLATION Product description .............................................. ..... Installation area ........................................................ Unpacking the washing machine .............................. Levelling the washing machine .................................. Selection of tap .................................................... ...... Connection of inlet hose, tap and washing machine... Preparation before washing....................................... Washing ..................................................................... After washing.............................................................. Washing matters needing attention ........................... The usage of detergent and washing powder............. Control pane .............................................................l Option......................................................................... Personalized setting of washing program................... Operations of washing process.................................... Washing program table ..............................................MAINTENANCE Cleaning and care .............................................. ........ Cleaning the cabinet.................................................... Cleaning drain pump filter ......................................... Troubleshooting.......................................................... Technical information ...................................... ........... Energy efficiency test program....................................289910111112121213131415161617181819202122OPERATIONS

SAFETY INSTRUCTIONS
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury or loss of life.
2SAFETY INSTRUCTIONS• This appliance is not intended for use by persons(including children) with reduced physical, sensory or mental capabilities or lack of experience and knowledge unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.• • • • The openings must not be obstructed by a carpet. • This appliance is intended to be used in household and similar applications such as: − staff kitchen areas in shops, offices and other working environments; − farm houses; − by clients in hotels, motels and other residential type environments; − bed and breakfast type environments; − areas for communal use in blocks of flats or in launderettes. Children should be supervised to ensure that they do not play with the appliance.The new hose-sets supplied with the appliance are to be used and that old hose-sets should not be reused.If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

SAFETY INSTRUCTIONS3
ModelWashing CapacityStandard Water Pressure
Warning!This combination of symbol and signal word indicates a potentially dangerous situation which may result in death or serious injuries unless it’s avoided.Explanation of the symbols:Caution!This combination of symbol and signal word indicates a potentially dangerous situation which may result in slight or minor injuries or damage to property and the environment.
0.03MPa~0.8MPa7.0kg WMT7YOKWNote!This combination of symbol and signal word indicates a potentially dangerous situation which may result in slight or minor injuries.

4SAFETY INSTRUCTIONSThe electric shock!Warning!•• • Hands shall not be inserted into running spin-dry tub .• If the spin-dry tub does not stop within 15 seconds after opening the cover , please stop using the machine and have it repaired. • Before any maintenance the device, unplug the appliance from the mains.• Always unplug the machine and turn off the water supply after use. The max. inlet water pressure, in pascals. The min. inlet water pressure, in pascals.• To ensure your safety, power plug must be inserted into an earthed three-pole socket. Check carefully and make sure that your socket is properly and reliably earthed.• Make sure that the water and electrical devices must be connected by a qualified technician in accordance with the manufacturer's instructions and local safety regulations. Do not put washing machine at humid place.This appliance is for indoor use only.

• EN countries: the appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.• Animals and children may climb into the machine. Check the machine before every operation.• Young children should be supervised that they do not play with the appliance.• Machine may be very hot during the operation. Keep kids and pets far away from the machine during the operation • Plug must be accessible after installation.very wet rooms as well as in the rooms with explosive or caustic gas.• • The washing machine with single inlet valve only can be connected to the cold water supply. The product inlet valves should be correctly connected to the hot water and cold water supply. with double Remove all packages before using the appliance. Otherwise, serious damage may result.Risk of explosion!• • Do not wash or dry articles that have been cleaned in, washed in, soaked in, or dabbed with combustible or explosive substances( such as wax, oil, paint, gasoline, degreasers, dry-cleaning solvents, kerosene, etc.) This may result in fire or explosion.Before hand thoroughly rinse items of washing by hand.5SAFETY INSTRUCTIONSRisk to children!

• This washing machine is for indoor use only.• It isn't intended to be built-in using.• The openings must not be obstructed by a carpet.• Washing machine shall not be installed in bath room or very wet rooms as well as in the rooms with explosive or caustic gases.• Remove all packages and transport bolts before using the appliance. Otherwise, serious damage may result.• The washing machine with single inlet valve only can be connected to the cold water supply. The product with double inlet valves should be correctly connected to the hot water and cold water supply.• Plug must be accessible after installation.Risk of damaging appliance!6SAFETY INSTRUCTIONSCautionInstalling the product!• Your product is only for home use and is only designed for the textiles suitable for machine washing.• Do not climb up and sit on top cover of the machine.• Do not lean against machine door.• Cautions during Handling Machine: 1.Transport bolts shall be reinstalled to the machine by a specialized person. 2.The accumulated water shall be drained out of the machine. 3.Handle the machine carefully. Never hold each protruded part on the machine while lifting. Machine door can not be used as the handle during the conveyance. 4.This appliance is heavy. Transport with care.

Operating the appliance!• Before washing the clothes at first time, the product shall be operated in one round of the whole procedures without the clothes inside.• Flammable and explosive or toxic solvents are forbidden. Gasoline and alcohol etc.Shall not be used as detergents. Please only select the detergents suitable for machine washing, especially for drum.• Make sure that all pockets are emptied. Sharp and rigid items such as coin, brooch, nail, screw or stone etc. may cause serious damages to this machine.• Please check whether the water inside the drum has been drained before opening its door.Please do not open the door if there is any water visible.• Be careful of burning when the product drains hot washing water.• Never refill the water by hand during washing.• After the program is completed, Please wait for two minutes to open the door. This marking indicates that this product should not be disposed with other household wastes throughout the EU.To prevent
possible harm to the environment or human health from
uncontrolled waste disposal,recycle it responsibly to promote
the sustainable reuse of material resources.To return your used device,please use the collection systems or contact the retailer where the product was purchased. They return and can take this product for environmental safe recycling.
Packaging/Old appliance
7SAFETY INSTRUCTIONS• Please do not close the door with excessive forces.• It is forbidden to wash carpets.

INSTALLATIONProduct Description
• The product line chart is for reference only, please refer to real product as standard.
Note!8Accessoriesspring clamperdrain loose ass Inlet hose assmanualscrew
cabinet baseboard
• Note: if the drain hose is already installed on the machine, then there is no spring clamper and drain hose in the accessories.
Note!Or FrameTop lidDrain hose HandlePower case and plug Control panelCabinetAdjustable foot knobWater inlet valveOr

Installation areaBefore installing the machine, the location characterized follows shall be selected:1.Rigid, dry, and level surface 2.Avoid direct sunlight3.Sufficient ventilation4.Room temperature is above 0 C 5.Keep far away from the heat resources such as coal or gas.as Unpacking the washing machine1. Remove the cardboard box and styrofoam packing.2. Lift the washing machine and remove the base packing.3. Remove the tape securing the power supply cord and drain hose.4. Remove the inlet hose from the drum.•• Stability is important to prevent the product from wandering!Make sure that the product should not stand on the power cord.Warning!• • Packaging material (e.g. Films, Styrofoam) can be dangerous for children. There is a risk of suffocation ! Keep all packaging well away from children.Warning!9INSTALLATIONwwW> 20mmThe installation of drain hoseClamping springDrain inserted into the drain hose
