Yones Toptech BD1005 User manual
User's Guide
Thanks:
Dear User
Thank you for purchasing our product.
These operational guidelines for the user, to ensure you a quick and convenient to
use, read the instructions carefully before use.
Contents:
1. Notes
2. Random Accessories
3. Hardware Specifications
4. Knowledge products
5. Startup and shutdown
6. Desktop
7. Button
8. System Settings
* Time and date settings
* Screen brightness
* Standby screen
* WIFI Wireless Connection
* GPS setting
9. Install, remove and run the application
10. Touch calibration
11. Music
12. Video
13. Picture
14. Network
15. Recording
16. Mail Client
17. Wallpaper
18. External equipment
* USB connection
* OTG use
* Keyboard and mouse
19. Frequently Asked Questions Treatment
Note:
* This product is a high precision electronic products, do not disassemble.
* Avoid strong beat, the collision of the product.
* Avoid using this product the following conditions: high and low temperature, moisture,
dust, magnetic fields strong and long-term exposure to sunlight.
* Please use a wet cotton cloth wrung gently wipe the product shell, do not use other
chemical cleaning solution. This product should not be dripping or splashing water, so
should not be placed near the product category, such as glass filled with a liquid items.
* Too long, use the headphone volume is too large may cause permanent hearing
damage.
* Do not cross the road, driving motor vehicle or bicycle use headphones to avoid
traffic accidents.
* Please only use permitted batteries, chargers and accessories, use any other type
of products would violate the warranty regulations and may be dangerous.
* Please follow the relevant local environmental regulations to deal with obsolete
machines and accessories.
* This product is in the course of any questions, please contact your local dealer or
directly with the company's customer service center.
* For those because the product is damaged, repair or other causes of memory loss
wipe coating, the Company assumes no responsibility, please follow the user manual
for standard operation, and timely backups.
Random accessories:
(Related diagram)
Host
5V 2A DC charger
Quick Start Guide
Warranty Card
USB cable
Hardware rules:
Memory DDR3 1G Bytes
Storage Built-in flash memory 4GB/8GB/16GB Support external TF card,
maximum capacity of 32GB
Wireless 802.11(b/g/n)
USB USB2.0 high speed interface and USB2.0 OTG
Audio
3.5mm headphone jack
High-quality stereo loud speaker
Built-in microphone
Headset maximum output power of 40mW
Frequency response: 20Hz-20KHz
SNR: greater than 90db
Screen
Size 10.1 inch
Resolution 1024×600pixels
Color 16 M color
Operating Resistance Touch Screen Single
Other
Size 270mm*170mm*15mm
Color Silver
Weight <800g
Battery Built-in lithium polymer battery 5000mAH
Annex
Power adapter (DC 5 V / 2A)
USB Cable
Certificate, quick guide and warranty card
Startup and shutdown
*Boot: Press and hold the power button, the green LED indicator light, the system will
enter the startup process, as follows:
Boot Logo startup ...
System has been started, are entering the Android system:
The system enters the default home interface
*Shutdown: Press the power button, pop-up device options, select Shut Down, as
follows:
Click OK, you can safely shut down.
*Sleep: the machine under normal operating conditions, Short press the power button,
Into hibernation, Now, Screen will close. Short press the power button again, Be able
to resume normal mode. When the time being use this MID can enable this
feature when, To reduce power consumption.
Desktop:
System after the completion of normal start, Desktop can see The default desktop by
the: Status Bar、Main menu labels and a number of shortcut icons form.
The status bar to display the current system of network status, Battery, Time
information. Middle right of the screen the main menu tab stop, Click or drag to the
main menu bar to start the default.
Bottom of the screen displaying the browser shortcut icon.
Optimization of the status bar results, Increase the volume of two icons ,
Volume reduction .Click to adjust the volume. Equivalent to Volume + and
Volume – features.
Button:
Android system uses in the course of the keys:
Volume keys: the task bar Volume +, Volume-achieve changes in the volume.
Power key: Press and switch machines. Short press to enter or leave the hibernation.
Menu button: Displays the current form of the menu items (if any).
Home button: Back to the main interface or choose.
Return: Return on an interface.
Main Menu Operation:
Click or drag the main interface of the main menu tab, the main menu will be from right
to left (or bottom-first, last), and is as follows:
In the main menu, the system can be set to run existing applications, install a new
application, start the touch calibration, music player, video player, web browsing,
games and other operations.
System Settings:
Click the main menu interface in the "Settings" icon, you can open the system settings
interface, as shown below:
Select the appropriate operation of the relevant items, such as:
* Wireless and network
* Sound and display
* Date and time settings
* About Equipment
Etc.
*Date and time settings:
Set interface options "time and date settings options" to enter the date and time
Settings interface:
Can choose to automatically: use the Network Time.
Can also select to set the date, select the time zone, set the time, time format, date
format and other information.
For example, choose to set the date, as follows:
Select ▲: that the increase of 1 unit,
Select ▼: that the reduction of 1 unit.
Also can choose the number, enter the input mode. Directly entering the desired
number, then select Done.
Select "Settings." If you enter the number of legitimate, then the operation is
successful, the system will set the option to use the new.
*Screen brightness:
In the setup interface choose "sound and display settings" to enter the sound and
display settings interface, scroll down section, select "Brightness", there are interface:
*Standby screen:
Standby screen: the screen automatically locks the delay before.
In the setup interface choose "sound and display settings" to enter the sound and display settings
interface, scroll down section, select the "standby screen" interface appears, as follows:
Note: In the video, the screen auto-standby function does not work
*WIFI Wireless Connection:
Click the main menu "Settings" icon, go to "System Settings" screen, click on
"Wireless and network" into the "Wireless and network" setup interface. Click the
"WIFI" section to quickly open the WIFI feature, click on "WIFI settings" column enter
"WIFI set interface" as shown below:
In the "WIFI settings" interface (above), click on the WIFI column also can open and
close the WIFI feature, click on the "Network Notice" lists MID701 search to the
wireless router, wireless router, click the search name will pop up settings window ,
please follow the prompts to complete the WIFI network links. Some encrypted
network, need to enter a valid key. Link diagram below:
*GPS Setting:(If the GPS function is available)
In the setup interface choose " Location services" to enter the GPS settings interface, ,
select "GPS satellites", there are interface:
Turned on GPS will be consumes more power
You need buy a map program to use GPS function, More knowledge, Please refer to
the map ‘User manual’.
Install, uninstall, run the application
*Installation: Android install the application there are a variety of ways, such as
through USB install, install third-party program aid.
Users can "Andrews market" online installation, or download via the computer, or online
through the machine built-in browser to download and install.
*Uninstall applications: You can use the appropriate third-party software
management tools or applications that use the Android comes with management
software
Select "Settings" / "Apps" / "DOWNLOADED", select the appropriate application has
been installed, to view program information, the uninstall program and other
operations.
Network:
Web browsing:
When the connected network, open the Web browser enter the URL, you can
quickly browse the Web; or through the main desktop search bar enter the URL,
open the web page.
Free page can use the zoom controls zoom, as shown:
Online video:
Through "Andrews market" or other means to download online video player software,
online TV player, online music software, then install to this machine. Open the
software installed, you can watch online video or online TV, listening to online radio
stations.
Users can also download other third-party Web applications, including web browsing,
video playback, Web client, instant messaging software, etc.
Music:
Click the main menu in the "music" icon, you can enter the music player interface.
Here lists the system default user data area of all audio files. As shown below:
We can spread through the USB audio files synchronized manner, or by inserting
the SD card with audio files were audio files, you can also download the audio files
via the network.
Select the appropriate tab key, you can see for example "Artist", "album", "songs"
and other interfaces. Select song to play.
Video:
Click the main menu in the "Super-HD Player" into the " Super-HD Player " the main
interface, there will list all the video files and picture files. As shown below:
Select video file into the video player interface, as shown below. Can select "Play",
"stop", "Volume +", "Volume -", "fast forward", "rewind", "progress bar" and control
keys to control playback of the progress.
Photo Browse:
Click the main menu in the " Super-HD Player " into the " Super-HD Player " the
main interface, there will list all the picture files and video files. As shown below:
Select a picture file, enter the picture playback interface, as shown below. Can
select "Zoom", "narrow" "sharing", "Previous" "Next," "set" and "delete" operation.
Wallpaper:
System supports static image wallpaper, as well as 3D wallpaper.
In the desktop interface, hold down the Menu button, pop-up menu option, select the
"wallpaper", the pop-up "Choose wallpaper source" selection box:
Have the following options:
Select "Wallpaper Gallery": You can select the system provides a static picture as
wallpaper.
Select "Current Wallpaper": You can select the system provides 3D wallpaper.
Select "Photo": You can use the picture as wallpaper Customize.
Recording:
Click the main menu in the "Hi-Q MP3 Recorder" icon into the " Hi-Q MP3 Recorder
" the main interface. As shown below:
Note: when inserting SD card recording, audio file will be saved in the SD card.
Select "Record" button recording, recording is completed, select "Stop" button. At
this point you can select the "Play" button plays the sound just recorded. Select
"Use this record" button, save the recording, this can be found in the SD card in the
appropriate recording documentation; If you do not save, you can select the
"Discard" button.
E-mail client:
In the main menu, click "Email" icon to enter the e-mail client. The first entry will ask
to configure the account information. As shown below:
E-mail require network support, please email links to ensure normal.
[email protected](Enter the email address bar inside your valid e-mail address:
In the Password field enter your valid password: 123456789.
You can then select the "Next", select the account type interface appears as shown
below:
Here we are using a POP3 account type. Appears to accept the server after setting
the interface as follows:
Please e-mail providers, each based on the information, set different parameters,
such as:
POP3 server: The system default is "126.com", should be amended to
"pop.126.com"
Port number "110"
Then select "Next", will enter the "Check to accept the server settings", if set
correctly, there will be "outgoing server settings" interface as follows:
sed SMIP server "126.com" as "smtp.126.com"
Modify the port number "587" to "25"
Drag the scroll bar, select "Next" and enter "Check outgoing server settings"
interface. If the settings are correct, will enter the following interface:
Select "Next", you can enter the account information to customize the interface:
In the "Your Name" enter the bar you want to show the name of outgoing mail, enter
here: Rocky
Then click "Finish" button to enter the mail interface. It will automatically load the
e-mail, mailing list below shows:
Select a column can view the messages, you can view the column inside a "reply",
"delete", "Open attachment" and other operations.
External devices:
*USB connection:
MID using the USB connection and PC, the default connection method is the
synchronous mode. Can drag the status bar pulled down, there are interface:
"USB Connected (Internal)": that built-in memory.
"USB is connected": said external memory (SD card).
If you need to copy data using USB, you can select the load you need the memory,
as:
Table of contents
