Zanussi ZWY 51024WI User manual

GETTING
STARTED?
EASY.
User Manual
ZWY 51024WI
EN User Manual 2
Washing Machine
RU Инструкция по эксплуатации 16
Стиральная машина

SAFETY INFORMATION
Before the installation and use of the appliance, carefully read the
supplied instructions. The manufacturer is not responsible for any
injuries or damages that are the result of incorrect installation or
usage. Always keep the instructions in a safe and accessible
location for future reference.
CHILDREN AND VULNERABLE PEOPLE SAFETY
•This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning the use of the
appliance in a safe way and understand the hazards involved.
•Do not let children play with the appliance.
•Children aged 3 years and under must be kept away from this
appliance when it is in operation at all times.
•Keep all packaging away from children and dispose of it
appropriately.
•Keep detergents away from children.
•Keep children and pets away from the appliance when the door
is open.
•If the appliance has a child safety device, this should be
activated.
•Children shall not carry out cleaning and user maintenance of
the appliance without supervision.
GENERAL SAFETY
•Do not change the specification of this appliance.
•Do not exceed the maximum load of 5.5 kg (refer to the
"Programme chart" chapter).
•The operating water pressure at the water entry point from the
outlet connection must be between 0.5 bar (0.05 MPa) and 8
bar (0.8 MPa).
•The ventilation opening in the base (if applicable) must not be
covered by a carpet, mat, or any floor covering.
2

•The appliance must be connected to the water mains using the
new supplied hose sets, or other new hose sets supplied by
the Authorised Service Centre.
•Old hose sets must not be reused.
•If the mains power supply cable is damaged, it must be
replaced by the manufacturer, its Authorised Service Centre or
similarly qualified persons to avoid an electrical hazard.
•Before any maintenance operation, deactivate the appliance
and disconnect the mains plug from the socket.
•Do not use high pressure water sprays and/or steam to clean
the appliance.
•Clean the appliance with a moist cloth. Use only neutral
detergents. Do not use abrasive products, abrasive cleaning
pads, solvents or metal objects.
SAFETY INSTRUCTIONS
INSTALLATION
• Remove all the packaging and the transit bolts.
• Keep the transit bolts in a safe place. If the
appliance is to be moved in future they must be
reattached to lock the drum to prevent internal
damage.
• Always take care when moving the appliance as
it is heavy. Always use safety gloves and
enclosed footwear.
• Do not install or use a damaged appliance.
• Follow the installation instruction supplied with
the appliance.
• Do not install or use the appliance where the
temperature can be less than 0°C or where it is
exposed to the weather.
• The floor area where the appliance is to be
installed must be flat, stable, heat resistant and
clean.
• Make sure that there is air circulation between
the appliance and the floor.
• Adjust the feet to have the necessary space
between the appliance and the flooring.
• Do not install the appliance where the appliance
lid cannot be fully opened.
• Do not put a container to collect possible water
leakage under the appliance. Contact the
Authorised Service Centre to ensure which
accessories can be used.
ELECTRICAL CONNECTION
• The appliance must be earthed.
• Always use a correctly installed shockproof
socket.
• Make sure that the parameters on the rating
plate are compatible with the electrical ratings
of the mains power supply.
• Do not use multi-plug adapters and extension
cables.
• Make sure not to cause damage to the mains
plug and to the mains cable. Should the mains
cable need to be replaced, this must be carried
out by our Authorised Service Centre.
• Connect the mains plug to the mains socket
only at the end of the installation. Make sure that
there is access to the mains plug after the
installation.
• Do not touch the mains cable or the mains plug
with wet hands.
• Do not pull the mains cable to disconnect the
appliance. Always pull the mains plug.
• This appliance complies with the E.E.C.
Directives.
WATER CONNECTION
• Do not cause damage to the water hoses.
• Before connection to new pipes, pipes not used
for a long time, where repair work has been
carried out or new devices fitted (water meters,
etc.), let the water flow until it is clean and clear.
• Ensure that there are no visible water leaks
during and after the first use of the appliance.
3

USE
WARNING! Risk of injury, electrical
shock, fire, burns or damage to the
appliance.
• This appliance is for household use only.
• Follow the safety instructions on the detergent
packaging.
• Do not put flammable products or items that are
wet with flammable products in, near or on the
appliance.
• Make sure that all metal objects are removed
from the laundry.
• Do not wash fabrics which are heavily soiled
with oil, grease or other greasy substances. It
can damage rubber parts of the washing
machine. Prewash such fabrics by hand before
loading them into the washing machine.
SERVICE
• To repair the appliance contact an Authorised
Service Centre.
• Use original spare parts only.
DISPOSAL
WARNING! Risk of injury or
suffocation.
• Disconnect the appliance from the mains
electrical and water supplies.
• Cut off the mains electrical cable close to the
appliance and dispose of it.
• Remove the door catch to prevent children or
pets from becoming trapped in the drum.
• Dispose of the appliance in accordance with
local requirements for the disposal of Waste
Electrical and Electronic Equipment (WEEE).
PRODUCT DESCRIPTION
APPLIANCE OVERVIEW
3
1
4
5
2
1Control panel
2Lid
3Lid handle
4Feet for levelling the appliance
5Rating plate
4

CONTROL PANEL DESCRIPTION
1000
800
600
20
7 8621 3 4 5
1On/Off button
2Programme selection touchpad
3Temperature selection touchpad
4Spin selection touchpad
5Options selection touchpad
6Start/Pause touchpad
7Indicators:
Child lock indicator
Extra rinse indicator
Door locked indicator
8Delay start touchpad
PROGRAMME CHART
Programme
Temperature range Maximum load Maximum spin speed Programme description (Type of load and soil level)
30'@30°
30°C 2 kg 800 rpm A short cycle for synthetic and delicate items with light soil level or for items to freshen up.
Cottons
90°C - Cold
5.5 kg
1000 rpm White cotton and coloured cotton. Normal soil and light soil.
Cotton
ECO1)
60°C - 40°C
5.5 kg
1000 rpm White cotton and fast-coloured cotton. Normal soil. The energy consumption decreases and the
time of the washing programme is extended.
Synthetics
60°C - Cold
2.5 kg
1000 rpm Synthetic items or mixed fabric items. Normal soil.
5

Programme
Temperature range Maximum load Maximum spin speed Programme description (Type of load and soil level)
Delicates
40°C - Cold
2.5 kg
1000 rpm Delicate fabrics such as acrylics, viscose, pol- yester items. Normal soil.
Wool/Handwash
40°C - Cold
1 kg
1000 rpm Machine washable wool, hand washable wool and delicate fabrics with «hand washing» care
symbol.2)
Refresh 20 min
40°C - 30°C
1 kg
1000 rpm Cotton and synthetic items with light soil level or worn only once.
Mix 20°
20°C
2.5 kg
1000 rpm Special programme for cotton, synthetic and mixed fabrics with light soil. Set this programme to de-
crease the energy consumption. Make sure that the
detergent is for low temperature in order to have
good washing results3).
1) Cottons energy saving programme. This programme at a 60ºC with a load of 5.5 kg is the reference
programme for data entered in the energy label, in compliance with EEC 92/75 standards. Set this pro-
gramme to have a good washing results and decrease the energy consumption. The time of the washing
programme is extended.
2) During this cycle the drum rotates slowly to ensure a gentle wash. It can seem that the drum doesn't
rotate or doesn't rotate properly, but this is normal for this programme.
3) No temperature indicator is on .
Programme options compatibility
Programme 1)
30'@30° ■ ■ ■■■
■ ■ ■ ■ ■ ■ ■ ■ ■ ■
■ ■ ■ ■ ■ ■ ■ ■ ■
■ ■ ■ ■ ■ ■ ■ ■ ■ ■
■ ■ ■ ■ ■ ■ ■ ■ ■
■ ■ ■ ■■■
■ ■ ■ ■■■
■ ■ ■ ■■■
1) When you set this option, we recommend that you decrease the quantity of the laundry. It is possible to
keep the full load but the washing results can be unsatisfactory. Recommended load: cotton: 2.75 kg, syn-
thetics and delicates: 1.5 kg.
6

CONSUMPTION VALUES
The data in this table are approximate. Different variables can affect the data: the quantity
and type of laundry, the water and ambient temperature.
Programmes Load (kg) Energy con- sumption
(kWh)
Water con-
sumption (litre)
Approximate pro-
gramme duration (mi-
nutes)
Cottons 60°C 5.5 1,20 55 150
Cotton Energy Saving Pro-
gramme 60°C1) 5.5 0,77 44 224
Cottons 40°C 5.5 0,70 55 120
Synthetics 40°C 2.5 0,55 45 103
Delicates 40°C 2.5 0,50 45 80
Wool/Handwash 30°C 1 0,35 50 70
1) «Cotton Energy Saving programme » at 60°C with a load of 5.5 kg is the reference programme for the
data entered in the energy label, in compliance with EU Commission Directive 95/12/EC and measured
according to EN 60456/2005.
Off Mode (W) Left On Mode (W)
0,48 0,48
The information given in the chart above is compliant with the EU Commission regulation 1015/2010
implementing directive 2009/125/EC
OPTIONS
TEMPERATURE
With this option you can change the default
temperature.
Indicator = cold water.
The indicator of the set temperature comes on.
SPIN
With this option you can change the default spin
speed.
The indicator of the set speed comes on.
Additional spin options:
No Spin
• Set this option to deactivate all spin phases.
Only the drain phase is available.
• The related indicator comes on.
• Set this option for very delicate fabrics.
• The rinses phase uses more water for some
washing programmes.
Rinse Hold
• Set this option to prevent the laundry creases.
• The related indicator comes on.
• There is a water in the drum when the
programme is completed.
• The drum turns regularly to prevent the laundry
creases.
• The lid stays locked. You must drain the water
to unlock the lid.
7

To drain the water refer to ‘At the end
of the programme’.
QUICK
With this option you can decrease the programme
duration.
Use this option for items with light soil or items to
refresh.
The related indicator comes on.
PREWASH
With this option you can add a prewash phase to a
washing programme.
Use this option for heavy soil. When you set this
option the programme duration increases.
The related indicator comes on.
EASY IRON
The appliance carefully washes and spins the
laundry to prevent the creases.
The appliance decreases the spin speed, uses
more water and adapts the programme duration to
the type of laundry.
The related indicator comes on.
RINSE
With this option you can perform only a last rinse of
a selected washing programme.
If you set also the Extra Rinse function ( ) the
appliance adds two or more rinses.
The related indicator comes on.
DRAIN AND SPIN
With this option you can perform the spin and drain
cycle.
This spin phase is suitable to the washing
programme you set.
If you set also the No Spin ( )
option, the appliance only drains.
DELAY START
With this option you can delay the start of a
programme by 9, 6 or 3 hours.
The indicator of the set value is on.
EXTRA RINSE
With this option you can add some rinses to a
washing programme.
Use this option for persons allergic to detergents
and in areas where the water is soft.
The related indicator comes on.1)
SETTINGS
PERMANENT EXTRA RINSE
With this option you can permanently have an extra
rinse when you set a new programme.
• To activate/deactivate this option touch the
buttons and at the same time until the
indicator comes on/goes off.
CHILD LOCK
With this option you can prevent that the children
play with the control panel.
• To activate/deactivate this option, touch the
buttons and at the same time until the
indicator comes on/goes off.
Activate this option after you touch the button :
the buttons are locked (except for the button ) .
This option stays active even when you
switch off the appliance.
ACOUSTIC SIGNALS
The acoustic signals operate when:
• The programme is completed.
• The appliance has a malfunction.
To deactivate/activate the acoustic signals,
touch the buttons and at the same time for 4
seconds.
1) See in "Settings" how to activate this option.
8

If you deactivate the acoustic signals,
they continue operate when the
appliance has a malfunction.
BEFORE FIRST USE
1. Put a small quantity of detergent in the
compartment for washing phase.
2. Set and start a programme for cotton at the
highest temperature without laundry.
This removes all possible dirt from the drum and the
tub.
DAILY USE
WARNING! Refer to Safety chapters.
LOADING THE LAUNDRY
1. Open the appliance lid.
2. Push the button A.
The drum opens automatically.
3. Put the laundry in the drum, one item at a time.
4. Shake the items before you put them in the
appliance.
Make sure not to put too much laundry in the drum.
5. Close the drum and the lid.
A
CAUTION! Before you close the lid of
your appliance, make sure that you
close the drum correctly.
USING DETERGENT AND ADDITIVES
Measure out the detergent and the fabric
conditioner.
DETERGENT COMPARTMENTS
Detergent compartment for wash-
ing phase.
Compartment for liquid additives
(fabric conditioner, starch).
CAUTION! Do not
exceed the MAX lev-
el.
When you set a prewash option, put the deter-
gent for prewash phase directly into the drum.
ACTIVATING THE APPLIANCE
Press and hold for a couple of seconds the On/Off
button to activate or deactivate the appliance.
A tune sounds when the appliance is activated.
SETTING A PROGRAMME
1. Touch the programme button and set the
programme:
• The indicator of the button flashes
slowly.
2. If necessary, change the temperature and the
spin speed or add available options. When you
activate an option, the indicator of the set
option comes on.
If you set something incorrect, the
indicator of the button flashes red
three times.
STARTING A PROGRAMME WITHOUT THE
DELAY START
Touch the button .
9

• The indicator of the button stops to
flash and stays on.
• The programme starts, the lid locks, the
indicator is on.
The drain pump can operate for a
short time at the beginning of the
washing cycle.
STARTING A PROGRAMME WITH THE DELAY
START
The start of the programme can be delayed by 9, 6
or 3 hours.
1. Touch the button to choose the delay you
want to set.
The indicator of the selected delay is on.
2. Touch the button :
• The appliance starts the countdown.
• When the countdown is completed, the
programme starts automatically.
You can cancel or change the set of
the delay start before you touch the
button . After touching the button
you can only cancel the delay.
To cancel the delay start:
1. Touch the button to set the appliance to
pause.
2. Touch the button until the indicator of the
set delay goes off.
Touch the button again to start the
programme immediately.
INTERRUPTING A PROGRAMME AND
CHANGING THE OPTIONS
You can change only some options before they
operate.
1. Touch .
The indicator of this button flashes.
2. Change the options.
3. Touch again.
The programme continues.
CANCELLING A PROGRAMME
1. Press the button for some seconds to
cancel the programme and to deactivate the
appliance.
2. Press the same button again to activate the
appliance. Now, you can set a new washing
programme.
Before starting the new programme
the appliance could drain the water. In
this case, make sure that the detergent
is still in the detergent compartment, if
not fill the detergent again.
OPENING THE LID
While a programme or the delay start operates, the
appliance lid is locked. The indicator is on.
CAUTION! If the temperature and
level of the water in the drum are too
high, you cannot open the lid.
Open the lid during the first 10 minutes of the
cycle and when the delay start operates:
1. Press the to pause the appliance.
2. Wait until the lid lock indicator goes off.
3. You can open the lid.
4. Close the lid and press the again. The
programme (or the delay start) continues.
Open the lid when the programme operates:
1. Turn the programme knob to position On/Off to
deactivate the appliance.
2. Wait for some minutes and then open the
appliance lid.
3. Close the lid and set the programme again.
AT THE END OF THE PROGRAMME
• The appliance stops automatically.
• The acoustic signal operates (if it is activated).
• The indicator of the button goes off.
• The lid lock indicator blinks (when the lid is
unlocking) and then goes off.
• You can open the lid.
• Remove the laundry from the appliance. Make
sure that the drum is empty.
• Press the button for some seconds to
deactivate the appliance.
• Close the water tap.
• Keep the lid ajar, to prevent the mildew and
odours.
The washing programme is completed, but
there is water in the drum:
• The drum turns regularly to prevent the creases
in the laundry.
• The indicator flashes to remind you to drain
the water.
10
