Zapi SMART CONSOLE User manual

ZAPI SMART CONSOLE
Introduction for J1

Location of CAN Connection

Traction VACC
Turn on ZAPI Handset
Push and hold the power button for 3s
The Display will show: Cons AFG ZP021*
The Display will show : Cons AFG ZP021*
CAN CONSOLE
Press or button until CAN
CONSOLE shows on the display
Press OK to go into the
CANCONSOLE Menu

The Display will show:
The Display will show:
CANCONSOLE
SELECT NODE
Push , or
To select Node 2
SELECT NODE
NODE 2
Press OK to go into the
Traction controller
The Display will show: ACOT2BESK EP0.45
24V 150A 0H
Press OK to go into the
Main Menu

The Display will show: Main Menu
Press or button until
PROGRAM VACC shows on the display
The Display will show: MAIN MENU
PROGRAM VACC
Press OK to go into the PROGRAM
VACC function
The Display will show the minimum and
maximum throttle voltage values. Both
directions will be shown
VACC SETTING
CURRENT VALUE
Press OK to clear these values.
Display will show 0.0

The display will show: FORWARD x.xV x.xV
Press pedal, Slowly depress the accelerator
forward to its maximum value. The new
minimum and maximum voltages will be
displayed on the Console plus an arrow
indicating the direction.
Repeat step for reverse direction
BACKWARD x.xV x.xV
When finished , press ESC

The Display will ask : APPLY
CHANGES ? APPLY CHANGES?
YES= OK NO=ESC
Press OK for yes
When finished, the Console shows : Main Menu
Press and hold power button for 3s
to turn off the Console

Steering Calibration
Turn on ZAPI Handset
Push and hold the power button for 3s
The Display will show: Cons AFG ZP021*
The Display will show : Cons AFG ZP021*
CAN CONSOLE
Press or button until CAN
CONSOLE shows on the display
Press OK to go into the
CANCONSOLE Menu

The Display will show:
The Display will show:
CANCONSOLE
SELECT NODE
Push , or
To select Node 6
SELECT NODE
NODE 6
Press OK to go into the
Steer controller
The Display will show: EPSAC0C2A EP161C
24V 50A 0H
Press OK to go into the
Main Menu

The Display will show: Main Menu
Press or button until
HARDWARE SETTING shows on
the display
The Display will show: MAIN MENU
HARDWARE SETTING
Press OK to go into the HARDWARE
SETTING function
Press or button until
AUTOTEACHING shows on
the display
HARDWARE SETTING
The Display will show:
The Display will show: HARDWARE SETTING
AUTOTEACHER OFF
Push , or
To select ON

When finished , press ESC
The Display will ask : APPLY
CHANGES ? APPLY CHANGES?
YES= OK NO=ESC
Press OK for yes
When finished, the Console shows : Main Menu
The Display will show: HARDWARE SETTING
AUTOTEACHER ON
Push and hold the power button for
3s to turn off the Console. Rekey
the truck, do not do anything until
autoteach completes (wheel stops
turning), rekey the truck again.
