3SIXT SoundJet 3S-0950 User manual

SoundJet
Wireless Speaker
3S-0950
USER GUIDE

SAFETY NOTICES
Read the following recommendations before using the
SoundJet Wireless Speaker:
• Before recharging the SoundJet through a wall outlet,
make sure wall charger outlet voltage is 5V 1A;
• Make sure to use the Micro USB Charge Cable that came with
this product, other cables may damage your SoundJet;
• Do not drop, knock, disassemble or aempt to repair the
SoundJet. Do not immerse or put the SoundJet in water.
Store the SoundJet in a dry place;
• Do not expose the SoundJet to excessive heat including direct
sunlight and fire;
• Do not use the SoundJet near explosive gases or flammable
materials;
• Do not burn or incinerate the SoundJet;
• Do not expose the SoundJet to harsh chemicals;
• Keep the SoundJet away from young children;
• Puing anything in the SoundJet’s input or output ports other
than the supplied Micro USB Charge Cable or your device’s
charging cable will cause damage or short out the SoundJet;
• To extend the SoundJet’s charging life, do a complete recharge
of the SoundJet every four months;
• PLEASE NOTE: The SoundJet is only WATER RESISTANT.
It has a level 6 water ingression rating that means it can
sustain high pressure water jets for 30 minutes. It
cannot be fully submerged in water.
2

3
For more information and support
visit www.3sixtgear.com
Welcome
This User Guide will give you the
information on how to enjoy your
3SIXT SoundJet Wireless Speaker.

GETTING TO KNOW YOUR
SOUNDJET WIRELESS SPEAKER
Front Back
Top Le
Boom Right
Buons & Ports & Lights
1 Power Buon
2AUX-In
3Charge Indicator Buon
4Micro USB Charge Port
5Charge Indicators
6Power/Paring/AUX-In Light
7Multi Function
8Volume Down
9Volume Up
10 USB 5V 1A Input Port
5 6
1789
2
3
4
10
4

ACCESSORIES
1) SoundJet Wireless Speaker
2) Micro USB Charge Cable
3) 3.5mm AUX Cable
4) User Guide
HIGHLIGHTS
The 3SIXT SoundJet Wireless Speaker can be connected to Bluetooth®
devices such as smart phones, tablets and computers to playback your
favourite music via streaming services or through your own music
library. Thanks to the powerful speakers and passive woofer system the
SoundJet delivers crisp full stereo sound. The SoundJet can sustain
around 8 hours of music assisted by the internal 4000mAh power bank
and is the perfect companion for you to use in the park, while camping,
at the beach...anywhere!
WIRELESS CONNECTION
Turn the SoundJet on by pressing the power buon for several
seconds, then the blue LED flashes quickly. The SoundJet has now
entered the wireless pairing mode.
CONNECT TO MOBILE PHONES/TABLETS/COMPUTERS
Activating Bluetooth® on your device:
1) Go to your device Bluetooth® seings and scan for new Bluetooth®
devices;
2) Search for 3SIXT 3S-0950 and once found, click on it to pair with the
SoundJet;
3) If your device asks for a pairing code, please enter ‘0000’ and confirm it.
4) Aer successful pairing, the SoundJet will make a sound and the
LED light stays blue.
1
6
6
5

Note: Pairing time varies with dierent devices. The SoundJet only
needs to be paired the first time and it will automatically connect when
the device is back in range or is turned back on (the SoundJet
remembers the last 8 paired devices' names).
AUX AUDIO-IN CONNECTOR
The SoundJet also features 1 x AUX audio-in port . Simply connect
the SoundJet with your device via the 3.5mm jack audio cable. The
green indicator light will illuminate. Now you are ready to play music
via the wired AUX connection.
POWER BANK FUNCTION
Aer connecting a device for charging, short press the buon near the
AUX port to show the remaining baery capacity.
The red LED lights will be illuminated: Four red lights: 100%, three red
lights: 75%, two red lights: 50%, one red light: 25% (or below), which
means the baery needs charging.
LOW POWER INDICATOR
The SoundJet will make a voice prompt to remind you to charge if the
baery is low (baery <10%). You will need to charge the SoundJet
regularly to maintain a full charge.
CHARGING AND COMPUTER CONNECTION
Connect the Micro USB Charge Cable to a USB 5V 1A charger to
recharge the SoundJet’s internal baery via the Micro USB port .
Whilst charging, the red LED lights will be illuminated - Four static
red lights: 100%, three static red lights: 75%, two static red lights: 50%,
one static red light: 25% (or below).
2
3
4
5
5
6
6

Powering On/O
Answering a call
Ending or refusing a call
Making a call
Play/Pause
Volume - or +
Next/Previous
Disconnect wireless
connection
Long press to power on/o.
During an incoming call, short press ‘-’ key to
answer the phone, short press again to end the call
and return to music.
Short press ‘MF’ key to end the call or long press
‘MF’ to refuse the call.
Long press ‘MF’ key to call the last dialed number.
Short press ‘MF’ key to adjust.
Short press ‘+/-’ / to adjust.
Long press ‘+’ to go to the next track. Long press
‘-’ to go to the previous track.
Long press ‘+’ and ‘-’ / to disconnect the
current wireless connection. The SoundJet will then
start searching for a new device.
Audio input connector
Ingress Rating
Baery
Wireless Protocol
Distance
Input/Output
Audio Output
Unit
Playback Time
Recharge Time
Dimensions
Weight
Frequency Range
DistortionTHD
Working Temperature
Storage Temperature
3.5 mm
IPX6 Water Resistant
Lithium Ion 3.7v/4000mAh
BT v4.1
Up to 10m
5V 1A
5W x 2 Speaker
40 mm x 2
5-8 hours
4-5 hours
181 x 58 x 75 mm
450g
160Hz-20KHz
1%
Temperature: 0°C - 40°C / Humidity: 0% -85%
Temperature: -30°C - 60° C / Humidity: 0% -90%
7
GENERAL OPERATION
TECHNICAL SPECIFICATIONS
8
8
7
7
7
9
9
8
9 8

Wireless Status
Blue light flashes
Blue light steady
Line in Mode
Green light illuminates
Charging Status
Red light illuminates when connected to a power source
One red light
Two red lights
Three red lights
Four red lights
Power Bank Capacity
Red light illuminates when the Indicator Buon is pressed
One red light
Two red lights
Three red lights
Four red lights
Please note: When in wireless mode if the 3.5mm AUX cable, the
SoundJet will switch to 'line in' status automatically. Please turn o the
SoundJet when not in use to prevent power drain.
5
5 3
6
6
6
8
Pairing mode
Connected
Line in mode
5V 1A
20%
50%
75%
100%
450g
20%
50%
75%
100%
LED STATUS

TROUBLESHOOTING
1. My device can’t find any new Bluetooth® devices
a) Make sure the SoundJet has entered pairing mode.
b) Ensure the SoundJet is within the eective working range (10m)
2. Bluetooth® devices cannot pair
a) Make sure your device allows new Bluetooth® connections.
b) Make sure the pairing password entered is ’0000'. If you are using
a Bluetooth® transmier device, please ensure the responding
password of your Bluetooth transmier supports the ‘0000’ code.
3. My SoundJet does not play music or answer calls when it is
connected to a Bluetooth® device
a) Make sure your Bluetooth® device supports A2DP and HSF profile
b) Ensure your Bluetooth® enabled device is within the eective
working range.
4. When paired with my computer, Windows asks for a new
driver. Can you supply?
Sorry, we do not supply drivers. Please visit your PC manufacturer's
website for the latest driver updates.
5. Is the SoundJet waterproof?
No, the SoundJet is only water resistant. It has a level 6 water
ingression rating that means it can sustain high pressure water jets
for 30 minutes. It cannot be fully submerged in water.
9

EN
3SIXT PRODUCT SUPPORT
For more information, visit www.3sixtgear.com/support
DE
3SIXT PRODUKT-SUPPORT
Bie besuchen Sie www.3sixtgear.com/support
FR
ASSISTANCE PRODUIT 3SIXT
Veuillez consulter www.3sixtgear.com/support
ES
ASISTENCIA TÉCNICA DEL PRODUCTO 3SIXT
Visite www.3sixtgear.com/support
IT
ASSISTENZA TECNICA 3SIXT
Si prega di visitare www.3sixtgear.com/support
10

11
AUSTRALIA & NEW ZEALAND
TWO YEAR WARRANTY
3SIXT will replace the faulty product at no cost to the consumer. The
warranty does not extend to any consequential damages or costs that may
be incurred and is valid for TWO YEARS from date of purchase. The
consumer must return the faulty product to the retail store it was purchased
from together with proof of purchase. The benefits to the consumer under
this warranty are in addition to other rights and remedies of the consumer
under Australian and New Zealand laws in relation to the goods to which the
warranty relates. Our goods come with guarantees that cannot be excluded
under the Australian Consumer Law. You are entitled to a replacement or
refund for major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the failure does
not amount to a major failure. The warranty is provided by: Cellnet Limited (in
Australia): 59-61 Qantas Drive, Eagle Farm, Queensland 4009. Ph: 1300
CELLNET (1300 235 563). Email: [e-mail]. Cellnet Limited (in New
Zealand): 10a Orbit Drive, Rosedale, Auckland 0632. Ph: 0800 CELLNET
(0800 235 563), Email: [e-mail]
3SIXT and its logo are trademarks of Cellnet Group Limited
in Australia & New Zealand. All Rights Reserved.
The Bluetooth® word mark is a registered trademark owned by Bluetooth
SIG, Inc.
Made in China

For more information, visit
www.3sixtgear.com/support
3SIXTgear
3S-0950
