Aasset ASTKJ-1201P User manual

ASTKJ-1201P
keyboard

TABLE OF CONTENTS
• CHAPTER 1 INTRODUCTION
In This Manual…………………………………………………07
Features………………………………………………………..07
Before installation……………………………………………..07
Hardware Overview…………………………………………...08
System Configuration and Wiring……………………………10
• CHAPTER 2
SYSTEM INSTALLATION & TYPICAL APPLICATIONS
System Installation…………………………………………….11
PTZ SETUP…………………………………………………….11
MAIN SETUP…………………………………………………..12
JOYSTICK CALIBRATION…………………………………...13
EASY SETTING FUNCTION (E.S.F)……………………….14
SPECIFICATIONS ……………………………………………14
• ANNEXE 1
Keyboard map Description of 360°Dome GEA001….……15
User Manual - ASTKJ-1201P - AASSET SECURITY

LIMITATION OF LIABILITY
THE INFORMATION IN THIS PUBLICATION IS BELIEVED TO BE ACCURATE IN
ALL RESPECTS, HOWEVER, WE CANNOT ASSUME RESPONSIBILITY FOR
ANY CONSEQUENCES RESULTING FROM THE USE THERE OF. THE
INFORMATION CONTAINED HEREIN IS SUBJECT TO CHANGE WITHOUT
NOTICE. REVISIONS OR NEW EDITIONS TO THIS PUBLICATION MAY BE
ISSUED TO IN CORPORATE SUCH CHANGES.
User Manual - ASTKJ-1201P - AASSET SECURITY

LIMITATION OF LIABILITY
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
PRODUCT TO RAIN OR MOISTURE.
DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS
OR OTHER OPENINGS ON THE EQUIPMENT
CAUTION
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
PRODUCT TO RAIN OR MOISTURE.
DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS
OR OTHER OPENINGS ON THE EQUIPMENT
CAUTION
CAUTION : TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER(OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
CAUTION.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrow head symbol, within an equilateral triangle,
is intended to alert the user to the presence of uninsulated dangerous
voltage within the products enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instruction in the literature accompanying the product.
User Manual - ASTKJ-1201P - AASSET SECURITY

IMPORTANT SAFEGUARDS
1. READ AND RETAIN INSTRUCTIONS
Read the instruction manual before operating the
equipment.
Retain the manual for future reference.
2. CLEANING
Turn the unit off and unplug from the power outlet
before cleaning. Use a damp cloth for cleaning.
Do not use harsh cleansers or aerosol cleaners.
3. ATTACHMENTS
Do not use attachments unless recommended by
manufactured as they may affect the functionality of the
unit and result in the risk of fire, electric shock or injury.
4. MOISTURE
Do not use equipment near water or other liquids.
5. ACCESSORIES
Equipment should be installed in a safe, stable location.
Any wall or shelf mounting accessory equipment should
be installed using the manufactures instructions. Care
should be used when moving heavy equipment. Quick
stops, excessive force, and uneven surfaces may
cause the equipment to fall causing serious injury to
persons and objects.
6. VENTILATION
Openings in the equipment, if any, are provided for
ventilation to ensure reliable operation of the unit and
to protect if from overheating. These openings must
not be blocked or covered
7. POWER SOURCES
The equipment should be operated only from the type
of power source indicated on the marking label.
If you are not sure of the type of power supplied at the
installation location, contact your dealer. For
equipment designed to operate from battery power,
refer to the operating instructions.
8. GROUNDING OR POLARIZATION
Equipment that is powered through a polarized plug
(a plug with one blade wider than the other) will fit
into the power outlet only one way. This is a safety
feature. If you are unable to insert the plug fully into
the outlet, try reversing the plug. Do not defeat the
safety purpose of the polarized plug.
Alternate Warning: If the equipment is powered
through a three way grounding type plug, a plug having
a third (grounding) pin, will only fit into a grounding-type
power outlet. This is a safety feature.
Do not defeat the safety purpose of the grounding type
plug. If your outlet does not have the grounding plug
receptacle, contact your local electrician.
9. CORD AND CABLE PROTECTION
Route power cords and cables in a manner to protect
them from damage by being walked on or pinched by
items places upon or against them.
10. LIGHTNING
For protection of the equipment during a lightning storm
or when it is left unattended and unused for long
periods of time, unplug the unit from the wall outlet.
Disconnect any antennas or cable systems that may be
connected to the equipment. This willprevent damage
to the equipment due to lightning or power line surges.
11. OVERLOADING
Do not overload wall outlets and extension cords as
this can result in a risk of fire or electric shock.
12. SERVICING
Do not attempt to service the video monitor or
equipment yourself as opening or removing covers may
expose you to dangerous voltage or other hazards.
Refer all servicing to qualified service personnel.
13. DAMAGE REQUIRING SERVICE
Unplug the equipment from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:
A. When the power supply cord or the plug has been
damaged.
B. If liquid has spilled or objects have fallen into
the unit.
C. If the equipment has been exposed to water or
other liquids.
D. If the equipment does not operate normally by
following the operating instructions, adjust only those
controls that are covered by the operating
instructions. Improper adjustment of other controls
may result in damage to the unit.
E. If the equipment has been dropped or the casing
damaged.
F. When the equipment exhibits a distinct change
in performance.
14. REPLACEMENT PARTS
When replacement parts are required, be sure the
service technician uses replacement parts specified by
the manufacturer or that have the same characteristics
as the original part. Unauthorized substitutions may
result in fire, electric shock, or other hazards.
15. SAFETY CHECK
Upon completion of any service or repairs to the
equipment, ask the service technician to perform safety
checks to verify that the equipment is in proper
operating condition.
16. FIELD INSTALLATION
The installation of equipment should be made by a
Qualified service person and should conform to all local
codes.

FCC COMPLIANCE STATEMENT
FCC INFORMATION : THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY
WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE
FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE
PROTECTION
AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMECIAL ENVIRONMENT.
THIS EQUIPMENT GENERATES, USES, AND CAN RADIATE RADIO FREQUENCY
ENERGY AND IF NOT INSTALLED AND USED IN ACCORDANCE WITH THE
INSTRUCTION MANUAL, MAY CAUSE HARMFUL INTERFERENCE TO RADIO
COMMUNICATIONS. OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS
LIKELY TO CAUSE HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE
REQUIRED TO CORRECT THE INTERFERENCE AT HIS OWN EXPENCE.
CAUTION : CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE
PARTY RESPONSIBLE FOR COMPLIANCE COULD VOID THE USERS AUTHORITY TO
OPERATE THE EQUIPMENT.
THIS CLASS A DIGITAL APPARATUS COMLIES WITH CANADIAN ICES -003.
CE COMPLIANCE STATEMENT
WARNING THIS IS A CLASS A PRODUCT. IN A DOMESTIC ENVIRONMENT THIS
PRODUCT MAY CAUSE RADIO INTERFERENCE IN WHICH CASE THE USER MAY
BE REQUIRED TO TAKE ADEQUATE MEASURES.
User Manual - ASTKJ-1201P - AASSET SECURITY

CHAPTER 1. INTRODUCTION
In This Manual
Overview - This manual covers the operation of the WTX-1200A keyboard.
ASTKJ-1201P Keyboard
This remote keyboard is an accessory for PTZ dome camera, etc
It allows the user to control from 1 to 255 cameras.
Features - Controls from 1 ~ 255 cameras.
- Multiple protocol supported in each channel (Samsung, Pelco…).
- RS 485/RS-422 communication (Tx : 3 port , Trx :1 port).
- Programmable user preferences. (preset, tour, group, etc.).
- Built-in 3-Axis proportional joystick
- Easy upload programmed data via serial communication port of PC.
- Built-in 2 lines character LCD.
- User password support.
- Designed for desktop use
- programmable transmission speed for each ID. (2.4~57.6kbps)
Note: units should be set to the communication protcol and the same baud rate.
Before installation
This keyboard system must be installed by qualified service and installation personnel.
Perform the following steps to install the keyboard system.
A. Unpack all components.
B. Place the keyboard in a convenient location.
Note: Carefully and completely read the manuals for each piece of equipment before
attempting toinstall and connect the equipment.
C. Decide on the configuration method.
D. Use one of the following sections to configure the wiring.
User Manual - ASTKJ-1201P - AASSET SECURITY

CHAPTER 1. INTRODUCTION
Hardware Overview
Hardware Components - This remote keyboard contains easy to use control keys on the
front and simple input and output connectors on the back
Control Buttons & Connection
- The unit provides the primary operator interface. Most
operations are one or two button presses.
The following Table contains a description for each buttons
on the keyboard and port of cable connection. Use Figure 1
and Figure 2 as a reference.
Number Button Description
1
ESC / POWER Pressing the ESC/POWER button enters the Power on/off or
escape key. Right description led on(red). Pressing it again exits
the POWER OFF. (Push the button (about 2~3 seconds)
and then POWER OFF)
2LCD DISPLAY Displays Camera ID, Protocol, Function status, General status, etc.
3Number Camera ID setting value change, PTZ setup(1+ ),
Main setup(2+ )
4
Controller
Function keys Hold : System locking (Unlocking : Input the Pass word 4 digit ****) SHIFT/TURBO : SHIFT-Key for special function (Customize) /
TURBO -High Speed
AUX : External equipment on/off
SET : Ptz and main setup (1 + ), (2+ )
IRES CLOSE : Camera Iris close
IRIS OPEN : Camera Iris open
5Function keys F1 ~ MENU/AUTO : Function Keys
(Preset, Tour, Pattern, Scan, Auto).
MENU :Used for Camera (Pan/Tilt) Menu adjustment.
1
2
3 4
5
6
7
< Figure 1 >
User Manual - ASTKJ-1201P - AASSET SECURITY

CHAPTER 1. INTRODUCTION
Control buttons (continued)
Number Button Description
6Camera Focus control
Camera Zoom control
7
*Before the mouse function use, you mouse be usb driver installed
(http://www.goodome.com/beta/english/e_download.php (filename:cdm20.zip)
Key operation method Push a mouse button(KEY 2~3 Seconds Push)
Description Mouse character description will be display
Reference key button
= Left button of Computer mouse
= Right button of Computer mouse
= Scroll key of Computer mouse ( Middle key).
(Simultaneously near far key push and joystick move)
DVR Connection method Push a mouse button(KEY Shortly Push)
Description
< Figure 2 >
Number Button Description
1Joystick Telemetry Joystick BIt allows precise control of Pan/Tilt/Zoom
2DV 12V Input DC 12V Input, 140mA
3USB PORT
Universal Serial Bus Port, USB Mouse function
(External Equipment communication port)
4TRx Tx3 Tx2 Tx1
RS-485 RS-485/RS-422 communications. (Tx/Rx : 3 port , Trx :1 port)
5Program Download connector (For Pragram Update)
1 2 3 4 5

CHAPTER 1. INTRODUCTION
System Configuration and Wiring
Basic Installation - Use the Keyboard Configuration when only one keyboard is
connected to the controlled units.
Connect the RS-485 output port of Remote keyboard to RS-485
input port of the first controlled unit using the terminal block
<RS-422/RS-485 Connection Diagram>
User Manual - ASTKJ-1201P - AASSET SECURITY

CHAPTER 2.
SYSTEM INSTALLATION & TYPICAL APPLICATIONS
System Installation
Keyboard Installation - Before you start connecting the keyboard equipment to your
system, make sure the units to be controlled are completely
installed and everything is working correctly. Before use of this
keyboard, you should set the protocol and baud rate
(2.4~57.6kbps) in the PTZ SETUP mode.
Use the following steps to set the communication protocol and
baud rate.
PTZ SETUP
PTZ SETUO - PTZ Setup mode, select 1+ ,(2~3 seconds)
setup screen allows you to make change ench programmable clause.
Note: The baud rate must be the same between the controlled unit and
the keyboard.
User Manual - ASTKJ-1201P - AASSET SECURITY

CHAPTER 2.
SYSTEM INSTALLATION & TYPICAL APPLICATIONS
MAIN SETUP
MAIN SETUP - Main Setup mode, select 2+ . (2~3 seconds)
setup screen allows you to make change ench programmable clause.
Note: The baud rate must be the same between the controlled unit and
the keyboard.
User Manual - ASTKJ-1201P - AASSET SECURITY

CHAPTER 2.
SYSTEM INSTALLATION & TYPICAL APPLICATIONS
JOYSTICK CALIBRATION
User Manual - ASTKJ-1201P - AASSET SECURITY

CHAPTER 2.
SYSTEM INSTALLATION & TYPICAL APPLICATIONS
EASY SETTING FUNCTION (E.S.F)
MAIN SETUP - Main Setup mode, select 2+ . (2~3 seconds)
setup screen allows you to make change ench programmable clause.
Note: The baud rate must be the same between the controlled unit and
the keyboard.
User Manual - ASTKJ-1201P - AASSET SECURITY

CHAPTER 2.
SYSTEM INSTALLATION & TYPICAL APPLICATIONS
EASY SETTING FUNCTION (E.S.F)
EASY SETTINF FUNCTION (Number key + Function key)
Number key + PSET/TOUR/PATT/SCAN/ E.S.F
is current position data (pan, tilt, focus, zoom data) save or call of Dome memory
SPECIFICATIONS
Model ASTKJ-1201P
Keyboard Communication
Interface: RS-485 (Tx 3 port, Trx 1 port) P
an/Tilt operating distance :4700 ft (1029m) No 24 AWG wire
Protocol: Multiple (Pelco-d, etc. ) (Baud rate selectable)
Connector Type Date TERMINAL BLOCK(8p)
Keyboard Keypad Rubber button
Numeric keypad and camera function key
Joystick Stick 3-axis, variable speed with zoom
Input Valtage 12V DC & 9V batt (Safe mode)
Power Consumption Max.140mA
LCD Display Graphic display : 16 * 2 Graphic display
Operating Temperature 0 to 45
Humidity 10% -70 % non-condensing
Dimension & Weight 280(W) x 174(D) x 92(H), Net : 0.7 Kg Gross: 1.7Kg
Packing include KEYBOARD, ADAPTOR
Packing include : BATT 9V(Alkaline), USB CABLE,
MANUAL, TERMINAL BLOCK(8p)
(TOUR button 2 seconds push) TOUR MENU CALL OF DOME
(PSET button 2 seconds push) Current Position Saved Preset No 2
(PSET button push) No 2 Preset position execution
(TOUR button push) No 3 Tour Execution of DOME
DATA SAVE(SET)
DATA CALL(GOTO)
User Manual - ASTKJ-1201P - AASSET SECURITY

ANNEXE 1
KEY DESCRIPTION WITH AASSET 360°DOME GEA001
AST1201P KEYBOARD MAP DESCRIPTION
Key Manual description Actual effect Replacememt key
Pressing and holding for 2-3 seconds turns keyboard on/off. Pressing momentarily has no effect when in the camera’s menus.
“MENU/AUTO” Used for camera (Pan/Tilt) menu adjustment. Does not access camera menus. User must press “9” followed by “5”, then press and hold
“PRESET” to get to the camera’s menus
“ENT” N/A Has no effect when in the camera’s menus. Behaves as expected
during keyboard setup. User must press “OPEN” when prompted by the camera
to press “ENTER” in the camera menus
“OPEN” Camera Iris open Behaves like an “ENTER” key when in the camera menus. When
Prompted to press “ENTER” in the camera menus, press this key. N/A
“CLOSE” Camera Iris close Behaves like an “ESCAPE” key when in the camera menus. Press
this key to escape from the current menu. N/A Toggles between the different view modes. eg; fisheye/quadview/ Panorama etc.
“NEAR” Camera Focus Control Toggles between which VCAM view is being controlled, when in
multiple VCAM view modes. N/A. Camera is manually focused, prior to installation.
“TELE/L” Camera Zoom Control Behaves as expected. Zooms in N/A “WIDE/R” Camera Zoom Control Behaves as expected. Zooms out N/A
Joystick Telemetry Joystick Blt allows precise control of PTZ Behaves as expected for Panning and Tilting, but twisting the
joystick has no effect, when attempting to Zoom. User must use “TELE/L” and “WIDE/R” for Zoom
functionality.
“9” followed by “5”, then press & hold “PRESET” N/A Accesses the camera’s menus N/A “9” followed by “4”, then press & hold “PRESET” N/A Accesses the recorder menus N/A
N/A. Camera is manually focused, prior to installation.Camera Focus Control“FAR”
“ESC/POWER” Press and hold for 2-3 seconds to turn keyboard on/off.
Momentarily press to use in ESC mode. When in Camera’s menus, user must press “CLOSE” to
escape from the current menu

User Manual - ASTKJ-1201P - AASSET SECURITY
