Ableconn VGA2HDMIB User manual

VGA to HDMI Converter
User's Manual
www.ableconn.com
[email protected]

i
Table of Contents
SAFETY INSTRUCTIONS .......................................... 2
COPYRIGHT......................................................... 2
TRADEMARKS...................................................... 2
REGULATORY COMPLIANCE .............................. 3
FCC CONDITIONS ................................................ 3
CE.................................................................... 3
WEEE INFORMATION........................................... 3
INTRODUCTION ................................................ 4
FEATURES........................................................... 4
PACKAGE CONTENTS............................................. 5
PRODUCT OVERVIEW........................................ 6
SPECIFICATION .................................................... 7
CONNECTION...................................................... 9
RESOLUTION CONFIGURATION ....................... 10
TECHNICAL SUPPORT...................................... 12

Before attempting to connect, operate or adjust this product,
please save and read the User's Manual completely. The style
of the product shown in this User's Manual may be different
from the actual unit due to various models.
Safety Instructions
Always read the safety instructions carefully:
Keep this User’s Manual for future reference
Keep this equipment away from humidity
If any of the following situation arises, get the
equipment checked by a service technician:
- The equipment has been exposed to moisture.
- The equipment has been dropped and damaged.
- The equipment has obvious sign of breakage.
- The equipment has not been working well or
cannot get it to work according to the User’s
Manual.
Copyright
This document contains proprietary information
protected by copyright. All right are reserved. No part of
this manual may be reproduced by any mechanical,
electronic or other means, in any form, without prior
written permission of the manufacturer.
Trademarks
All trademarks and registered trademarks are the
property of their respective owners or companies.

3
Regulatory Compliance
FCC Conditions
This equipment has been tested and found to comply
with Part 15 Class B of the FCC Rules. Operation is
subject to the following two conditions: (1) This device
may not cause harmful interference. (2) This device
must accept any interference received and include
interference that may cause undesired operation.
CE
This equipment is in compliance with the requirements
of the following regulations: EN 55 022: CLASS B
WEEE Information
For EU (European Union) member users: According to the
WEEE (Waste electrical and electronic equipment)
Directive, do not dispose of this product as household
waste or commercial waste. Waste electrical and electronic
equipment should be appropriately collected and recycled
as required by practices established for your country. For
information on recycling of this product, please contact
your local authorities, your household waste disposal
service or the shop where you purchased the product.

4
Introduction
The VGA to HDMI Converter is a high performance
single port converter, compliant with the VGA standard.
The product allows the user to convert and transmit the
video signals from the VGA embedded device, such as
laptop, smart phone, tablet or PC, to the HDMI
embedded device, such as projector. In addition, the
converter is capable of receiving the audio signals along
with the VGA signals. Last but not least, slim design
makes the converter handy to carry and brings the user
great mobility experience.
Incorporates HDMI®technology.
Features
Mini-sized and stylish design
VGA to HDMI function
- VGA + Audio input detection
- HDMI output detection
Compliant with HDMI specification
High resolution up to 1920x1080p@60Hz pixels
Support audio jack input

5
Package Contents
VGA to HDMI Converter x1
USB cable x1
User’s Manual x1

6
Product Overview
Item
Description
VGA Connector
Connect to input the source from
the VGA enabled device
Audio Jack
Connect to input the audio source
HDMI Connector
Connect to output the signals to a
HDMI embedded display device
Micro USB Connector
(Power in)
Connect to an available USB
connector on a computer to charge
the power
Micro USB
Connector
(Power in)
HDMI
Connector
VGA
Connector
Audio Jack

7
Specification
Item
Description
Connector
Video Input
VGA Female Connector *
Audio Port
3.5mm stereo jack
Video
Output
Standard HDMI Female
Connector
(A-Type)
Video
Resolution
640x480@60
1280x720p@60
720x480p@60
1280x1024@75
800x600@60
1600x1200@60
1024x768@60
1920x1080p@60
Color Depth
16 Bits
Power
Supply**
Bus-powered **
Self-powered (DC 5V)
Power
Consumption
Max. 650mW at 1080p
Physical
Properties
Housing
Plastic (PC+ABS)
Dimension
55(L)x55(W)x16.5(H)mm
Weight
29.5g approx.
Working
Environment
Operation
Temperature
10℃~40℃
Storage
Temperature
-20℃~70℃
Compliance
CE, FCC

8
*If the VGA output signals of your video source are not compliant with
the VESA standard, the video source may not be displayed properly.
**If the device does not work properly with bus power, please connect
the external power to the device.

9
Connection
Follow the instructions below to check and connect your
mobile device to a display.
Make sure the source device is equipped with VGA port.
Make sure the terminal device is equipped with HDMI
port.
Connect the power first to make sure the device work
properly. (If the device does not work properly with bus
power, please connect the external power to the device.)
Prepare a HDMI male to male cable to connect the
HDMI end to a terminal device. (Note that this cable is
not supplied)
Prepare a VGA male to male cable to connect the VGA
end to a source device. (Note that this cable is not
supplied)

10
Resolution Configuration
With plug and play feature, the adapter will
automatically detect the resolution of the display device
once plugged in. If the default settings do not match the
resolution, you can select or adjust the settings following
the instructions below.
*Actual strings depend on your operating system. The screen
shots are from Windows®7 and might vary slightly for each
operating system.
Windows®7/ Windows®8/ Windows®10
Step 1. Go to Start\Control Panel\Appearance and
Personalization\Adjust screen resolution

11
Step 2. Adjust Resolution to the desired value.

12
Technical Support
If you have any technical or application issues
about our products, please email us:
[e-mail] or visit our website:
http://www.ableconn.com

VGA to HDMI Converter
User's Manual
V1.0
