Above All ABWP20LED50DS User manual

LED FULL CUTOFF WALL PACK
Instructions Manual
SUITABLE FOR MODEL
IMAGE MAY VARY FROM ACTUAL PRODUCT
SAFETY INSTRUCTION
MAINTENANCE CAUTION
READ CAREFULLY BEFORE INSTALLING FIXTURE. PLEASE KEEP THIS MANUAL FOR FUTURE USING.
Fixtures must be wired in accordance with the National Electrical Code and all applicable local codes. Proper grounding
is required for safety.
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICATION CODE BY A PERSON
FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED.
MAKE CERTAIN POWER OFF BEFORE INSTALLING OR MAINTAINING FIXTURE.
CHECK THAT VOLTAGE IS COMPATIBLE WITH FIXTURE DRIVER, USE APPROVED CONNECTORS FOR
ALL ELECTRICAL CONNECTIONS.
1. Review the wire connection before beginning, and make sure fixture is grounded properly.
2. For lighting controls, using functioning correctly.
3. Turn power off and wait for fixture cooling to operate.
4. Maintenance must be done by professionals.
WIRE CONNECTION
FOR 20W/30W/ 38W FULL CUTOFF WALL PACK WITH
PHOTOCELL
FOR 52W FULL CUTOFF WALL PACK WITH PHOTOCELL
Led Board DC IN+ Led Board DC IN-
BLACKRED
WAGO WAGO
RED
BLACK
AC INAC IN
PHOTOCELL
GROUND IN
BLACK
WHITE
RED
WAGO WAGO
WAGO
WAGO
RED
BLACK
POWER OUT(DC) POWER IN(DC)
POWER SUPPLY
RED
BLACK
WHITE
GREEN
BLACK
Led Board DC IN+ Led Board DC IN-
BLACKRED AC INAC IN
PHOTOCELL
GROUND IN
WAGO WAGO WAGO WAGO
POWER SUPPLY
POWER OUT(DC) POWER IN(DC)
WAGO WAGO
BLACK
WHITE
RED
Universal voltage driver permits operation at 120 or
277V, 60Hz
Universal voltage driver permits operation at 120 or
277V, 60Hz
Add: 1501 Industrial Way N. Toms River, NJ 08755 Phone: [phone] E-mail: [email protected]
Web: www.aboveallLighting.com ©2016 ABOVE ALL, Inc. All rights reserved

LED FULL CUTOFF WALL PACK
FOR 30W/ 38W FULL CUTOFF WALL PACK
Universal voltage driver permits operation at 120V
thru 277V,50/60Hz
FOR 20W FULL CUTOFF WALL PACK
Universal voltage driver permits operation at 120V
thru 277V,50/60Hz
FOR 52W FULL CUTOFF WALL PACK
Universal voltage driver permits operation at
120V thru 277V,50/60Hz
Ref#: 10050-21020
INSTALLATION
Install the fixture as the picture shows.(Installation height
≥ 6.6ft.)
≥6.6 FT.
GROUND
WALL FIXED HOLE
CLIP
SCREW
BASE COVER
TOP COVER
WARRANTY
LED
BOARD
GROUND GROUND
L
N
ACN(WHITE)
ACL(BLACK)
POWER
RED(+)
RED
(DC+)
BLACK
(DC-)
BLACK(-)
WAGO
WAGO
WAGO
WAGO
WAGO
GROUND GROUND
LED
BOARD
RED(+)
RED
(DC+)
BLACK
(DC-)
BLACK(-)
POWER
DIMMER
ACN(WHITE)
ACL(BLACK)
N
L
DIM+(PURPLE)
DIM-(GRAY)
VAUX/12V
(YELLOW)
WAGO
WAGO
WAGO
WAGO
WAGO
WAGO
WAGO
WAGO
WAGO
WAGO
WAGO
WAGO
WAGO
WAGO
WAGO
GROUND
N
L
DIM+(BLUE)
RED(+)
RED
(DC+)
BLACK
(DC-)
BLACK(-)
DIM-(WHITE) DIMMER
ACN(BLUE)
GREEN/YELLOW
ACL(BROWN)
LED
BOARD
POWER
Instructions Manual
1.Cut off the power before installation.
2.Unscrew the two fixed screws,unload the top cover, and fix
the base cover to the wall.
3. Pass the three phase cable by the base or 1/2NPT hole,
and connect it with AC driver and ground wire.
4. Connect DC wire from the reflector hole with DC LED
board. (Caution: red to red, black to black)
5.Close the cover, and tighten the two fixed screws.
6.Choose the suitable place to install, connect the power to
lighten up.(Finish the installation)
LIMITED FIVE-YEAR WARRANTY. Should this product fail to perform satisfactorily due to a defect or poor workmanship
within five years from the date of purchase, return it to the place of purchase and it will be replaced, free of charge.
Incidental or consequential damages are excluded from the warranty.
