USER MANUAL
SUBMERSIBLE PUMP
HYDROPONIC FLOW SYSTEM

3
WELCOME
Thank you for choosing AC Innity. We are committed to product quality and friendly
customer service. If you have any questions or suggestions, please don’t hesitate to
contact us. Visit www.acinnity.com and click contact for our contact information.
EMAIL
support@acinnity.com
WEB
www.acinnity.com
LOCATION
Los Angeles, CA

PRODUCT
WATERPUMP 8W 500L/H
WATERPUMP 18W 800L/H
WATERPUMP 20W 1500L/H
WATERPUMP 36W 3000L/H
MODEL
AC-WPA1
AC-WPA3
AC-WPA5
AC-WPA7
UPC-A
819137021976
819137021983
819137022003
819137021990
MANUAL CODE WP2109X1

5
MANUAL INDEX
Manual Index .................................................................................
Product Contents ...........................................................................
Key Features .................................................................................
Installation .....................................................................................
Maintenance ..................................................................................
Other AC Innity Products .............................................................
Warranty ........................................................................................
Page 5
Page 6
Page 7
Page 8
Page 10
Page 12
Page 13

6
PRODUCT CONTENTS
SUBMERSIBLE
WATER PUMP
(x1)
MEDIUM
NOZZLE
LARGE
NOZZLE
SMALL
NOZZLE
WATERPUMP 8W 500L/H
WATERPUMP 18W 800L/H
WATERPUMP 20W 1500L/H
WATERPUMP 36W 3000L/H
x1 x1 N/A
x1 N/A N/A
x1
x1
x1
x1
N/A
x1

7
KEY FEATURES
DEEP WATER DELIVERY
10 ft. maximum lift height,
using the small nozzle, to spout
water from lower depths.
GREATER VOLUME
Pumps up to 800 GPH, using
the large nozzle, to spout
larger amounts of water.
OMNIDIRECTIONAL
Removable suction cup
feet tightly secures the
unit on at surfaces and
in any orientation.
FLOW CONTROL
Turn dial widens or closes
the opening to adjust
water ow and pressure for
many applications.
EASY TO CLEAN
Quickly detach the
impeller and panels to
easily wash off debris
and build-up.
VERSATILE DESIGN
Interchangeable outlet
nozzles included to support
a variety of tubing sizes.

8
INSTALLATION
STEP 2
Place the water pump submerged in your
tank and at on your surface.
Wiggle the water pump to make sure its
suction cup feet tightly secures it.
STEP 1
Determine your desired water pump position.

9
INSTALLATION
SWAPPING NOZZLES
Twist to remove the nozzle from the water
pump body.
Twist your replacement nozzle into the water
pump to complete the swap.
STEP 3
Plug the water pump's power cord into a
wall outlet.
Make sure the cord is set below your outlet
to prevent water from running down into the
electrical socket.

10
STEP 2
Rotate the round plate counterclockwise and
pull to remove it. Pull the impeller blade out
from the water pump body.
MAINTENANCE
STEP 1
Separate the dial casing from the water
pump body.
12

11
STEP 4
Replace the impeller, round plate, and dial
casing in the reverse order you removed
them to reassemble the water pump.
MAINTENANCE
STEP 3
Run water or your preferred solvent over
the removed components. Dry them with a
paper towel.

12
AC INFINITY PRODUCTS
Discover the latest innovations in cooling and ventilation at acinnity.com
Advance Grow Tents
The CLOUDLAB series is a line of grow tents designed to create ideal growing
conditions and facilitate indoor plant cultivation year-round. Features 2000D thick
oxford canvas lined with inner diamond patterned mylar that maximizes grow light
luminosity, and a reinforced frame with 150 lb. weight capacity. Includes a mounting
plate to install your AC Innity controller onto.
Fabric Pots
A set of gardening grow bags designed to create wider root networks and improve
plant growth by air pruning roots while draining excess water. Features industry
leading 500G thick nonwoven fabric sewn with metal rings to enable air-suspended
hanging or twist tie passthrough for low stress plant training.
Net Cups
A set of long lasting, reusable net cups designed to promote stronger root structures
and even drainage to achieve greater water and nutrient absorption. Features wide
lips and durable netting that can withstand use with many soil-based and hydroponic
media such as expanded clay pebbles, lava rocks, pumice, and rock wool.

13
WARRANTY
This warranty program is our commitment to you, the product sold by AC Innity will be free from
defects in manufacturing for a period of two years from the date of purchase. If a product is found to
have a defect in material or workmanship, we will take the appropriate actions dened in this warranty
to resolve any issues.
The warranty program applies to any order, purchase, receipt, or use of any products sold by AC
Innity or our authorized dealerships. The program covers products that have become defective,
malfunctioned, or expressively if the product becomes unusable. The warranty program goes into effect
on the date of purchase. The program will expire two years from the date of purchase. If your product
becomes defective during that period, AC Innity will replace your product with a new one or issue you
a full refund.
The warranty program does not cover abuse or misuse. This includes physical damage, submersion of
the product in water, incorrect Installation such as wrong voltage input, and misuse for any reason other
than intended purposes. AC Innity is not responsible for consequential loss or incidental damages of
any nature caused by the product. We will not warrant damage from normal wear such as scratches
and dings.
For more information about our dealers and distributors, please contact our customer service at
support@acinnity.com or [phone] Monday to Friday (9:00 am to 5:00 pm PST).
If you run into any issues with this product, contact us and we'll happily issue a
replacement or a full refund!
