Camera Set Up
& Installation

SKYE WiFiTM Set Up & Installation Manual
- 2 -
ACCU-SCOPE, Inc. 73 Mall Drive, Commack, NY 11725 • 631-864-1000 • www.accu-scope.com
Content
CHAPTER 1 NOTES AND SAFETY REQUIREMENTS
1.1 Cautions and Notes--------------------------------------------------------------- 3 -
CHAPTER 2 SOFTWARE SYSTEM REQUIREMENTS
2.1 System Requirements under USB Work Mode ------------------------------ 4 -
2.2 System Requirements under WiFi Work Mode ------------------------------ 4 -
CHAPTER 3 PACKAGE LIST -------------------------------------------------- 5 -
CHAPTER 4 FUNCTION INTRODUCTION
4.1 Name and function for body units of SKYE WiFi Camera ---------------- 6 -
4.1.1 Body Introduction：----------------------------------------------------------- 6 -
4.1.2 Function for body units of SKYE WiFi Camera--------------------------- 6 -
4.2 Optional accessory Introduction ----------------------------------------------- 7 -
4.2.1 Connection methods and types----------------------------------------------- 8 -
CHAPTER 5 PRODUCTASSEMBLY GUIDE
5.1 SKYE WiFi Camera assembly and disassembly-------------------------- - 10 -
5.1.1 SKYE WiFi Camera Assemble with Microscopes --------------------- - 10 -
5.1.2 SKYE WiFi Camera Disassembly---------------------------------------- - 12 -
CHAPTER 6 INSTRUCTIONS
6.1 USB Wired Work Mode ------------------------------------------------------ - 13 -
6.1.1 Install SKYE View Software ---------------------------------------------- - 13 -
6.1.2 To Connect Device---------------------------------------------------------- - 13 -
6.1.3 Open Software--------------------------------------------------------------- - 13 -
6.1.4 Start to Use------------------------------------------------------------------- - 13 -
6.2 WiFi Work Mode-IOS System----------------------------------------------- - 14 -
6.2.1 Install SKYE View for iOS software------------------------------------- - 14 -
6.2.2 To Connect Device---------------------------------------------------------- - 14 -
6.2.3 Open Software--------------------------------------------------------------- - 14 -
6.2.4 Start to Use------------------------------------------------------------------- - 14 -
6.3 WiFi Work Mode-Android System ----------------------------------------- - 14 -
6.3.1 Install SKYE View for Android Software ------------------------------- - 14 -
6.3.2 To Connect Device---------------------------------------------------------- - 14 -
6.3.3 Open Software--------------------------------------------------------------- - 15 -
6.3.4 Start to Use------------------------------------------------------------------- - 15 -

SKYE WiFiTM Set Up & Installation Manual
- 3 -
ACCU-SCOPE, Inc. 73 Mall Drive, Commack, NY 11725 • 631-864-1000 • www.accu-scope.com
Chapter 1 Notes and Safety Requirements
1.1 Cautions and Notes
（
1
）
To avoid danger or damage incurred to the lens, do not touch the lens or
sensor directly with your fingers.
（
2
）
To avoid failure or electric shock hazard and so on, do not disassemble or
modify the internal structure of the device.
（
3
）
Do not plug in or unplug the USB port when hands are wet.
（
4
）
Do not use alcohol and other organic solvents to clean.
（
5
）
If the lens or sensor is dirty or damp, it is better use dry and non-linen fabric
or professional lens tissue to wipe them.
To avoid scratches on the surface,
do not touch the lens with your fingers. Wipe the lens or sensor lightly.
（
6
）
The products are not designed for outdoor use. Do not expose it to outdoor
environment without any protection. Excessive temperature and humidity
will damage the lens. Please avoid using the product under the following
environment: high temperature or high humidity environment, places with
direct sunlight, dirt or vibration and places near heat source.
（
7
）
Please use and store in the following environment:
Operating temperature ：-10℃~50℃
Storage temperature：-20℃~60℃
Operating Humidity ：30~80%RH
Storage Humidity：10~60%RH
（
8
）
If any foreign matter, water or liquid enters the device by accident,
disconnect the USB cable immediately. Please send it to the maintenance
center and do not use the hair dryer to dry it by yourself.
（
9
）
To prevent microscope from being tripped over or dropped, please put away
the device's USB cables in use or standby.
（
10
）
To avoid electric shock by accident, please power off microscope before you
move your computer or laptop.
（
11
）
The cleanliness of the device lens will directly affect clarity degree of
contents from the computer screen during preview. Problems like various
circles or spots on the screen may mostly be incurred by dirt on the lens.
When cleaning, please use professional lens tissue or other professional
detergent to clear the dirt on the lens.

SKYE WiFiTM Set Up & Installation Manual
- 4 -
ACCU-SCOPE, Inc. 73 Mall Drive, Commack, NY 11725 • 631-864-1000 • www.accu-scope.com
Chapter 2 Software System Requirements
2.1 System Requirements under USB Work Mode
● Windows XP SP3, Windows 7（32 or 64 bits), Windows 8（32 or 64 bits）, Windows 8.1（32
or 64 bits）, Windows 10（32 or 64 bits）.
 ● Dual core 1.6 GHz or higher CPU
 ● U S B 2.0 high-speed interface or USB2.0 compatible interface
 ● DVD-ROM driver (only needed when installing software)
 ●2G or more memory
 ● At least 4 GB available hard-disk space
2.2 System Requirements under WiFi Work Mode
● 2.3 or above version forAndroid system.
● 5.0 or above version for iOS system.

SKYE WiFiTM Set Up & Installation Manual
- 5 -
ACCU-SCOPE, Inc. 73 Mall Drive, Commack, NY 11725 • 631-864-1000 • www.accu-scope.com
Chapter 3 Package list
1. SKYE WiFi Camera 2. Installation disk
3. USB cable 4. USB power adapter

SKYE WiFiTM Set Up & Installation Manual
- 6 -
ACCU-SCOPE, Inc. 73 Mall Drive, Commack, NY 11725 • 631-864-1000 • www.accu-scope.com
Chapter 4 Function Introduction
4.1 Name and function for body units of SKYE WiFi Camera
4.1.1 Body Introduction
：
SKYE WiFi Camera
：
Standard C-mount SKYE WiFi Camera suitable for adapter ring of 23.3mm, 30mm and30.5mm,
achieving connections with microscopes of different interfaces; the new 5-megapixel light-sensitive
CMOS chips significantly reduce the image noise, bearing characteristics of quick transmission speed,
excellent color rendition, clear image and storage convenience, etc., which can be widely used in
industrial tubes, teaching, material analysis, clinical examination, machine vision, etc.
4.1.2 Function for body units of SKYE WiFi Camera
○
1 Antenna
：
External antenna。
○
2 Toggle key
：
Divided into Three states：
Toggle left（USB Icon)：PC enable。
Toggle middle (switch Icon): shut down。
Toggle right (WiFi Icon)：wireless WiFi enable。

SKYE WiFiTM Set Up & Installation Manual
- 7 -
ACCU-SCOPE, Inc. 73 Mall Drive, Commack, NY 11725 • 631-864-1000 • www.accu-scope.com
○
3C-mount thread: camera can be installed using a standard C-mount adapter for microscope; or can
install to a different microscope ports with different adapters (i.e. eyetube) – requires optional
accessory.（For detailed specifications, please refer to Chapter 5）
○
4 Dustproof Cover: screw it out before use for dust prevention and chip protection.
○
5LED Lights:
Two color Lights：
USB State：Red lights
WiFi State：Blinking blue lights.
○
6Micro USB interface:Operating charging and cable mode actions via USB interface.
4.2 Optional accessory Introduction
Adapter Ring for Eyetube (Optional
Components): SKYE WiFi Camera can be equipped
intomocroscopes of different calibers throughadapter ring and
eyepiece. The Camera
eyepiece body is of Standard C Port; 0.5X
eyepiece is of 23.2mm; adapter ring is of 23.2/30mm,
23.2/30.5mm. According to different assembly methods, the
equipment can be connected to eyepieces of different ports.
Contact your microscope dealer for the appropriate accessories to
fit your microscope.
C-mount Adapter for Microscope Photo Port: SKYE WiFi
Camera can be adapted to most photo ports of most
manufacturer’s microscopes. Contact your microscope
dealer for the appropriate C-mount adapter to fit your particular
model of microscope.

SKYE WiFiTM Set Up & Installation Manual
- 8 -
ACCU-SCOPE, Inc. 73 Mall Drive, Commack, NY 11725 • 631-864-1000 • www.accu-scope.com
4.2.1 Connection methods and types
1. Install to a standard C-mount interface microscope
2. Install to a 23.2mm interface microscope
3．Install to a 30mm interface microscope

SKYE WiFiTM Set Up & Installation Manual
- 9 -
ACCU-SCOPE, Inc. 73 Mall Drive, Commack, NY 11725 • 631-864-1000 • www.accu-scope.com
4．Install to a 30.5mm interface microscope

SKYE WiFiTM Set Up & Installation Manual
- 10 -
ACCU-SCOPE, Inc. 73 Mall Drive, Commack, NY 11725 • 631-864-1000 • www.accu-scope.com
Chapter 5 Product Assembly Guide
5.1 SKYE WiFi Camera assembly and disassembly
5.1.1 SKYE WiFi Camera Assemble with Microscopes
1
．
Connection of Microscope for Standard C-mount
（1）Unscrew the plastic dustproof cover at the bottom of the SKYE WiFi Camera,
take the protective film on the filter of the cavity (See Picture 1).
（2）Screw the SKYE WiFi Camera to other microscopes (Standard C-mount)
(See Picture 2).
（3）Connect the camera to the computer (WiFi or USB mode) and start the program.
Picture 1Picture 2
2. Connection with Stereomicroscope
（1）Unscrew the dustproof cover of the SKYE WiFi Camera, and remove protective film from in front
of the sensor.
（2）Connect the camera to additional eyepiece adapter (See Picture 1 and 2).
（3）Narrow the eyepiece cover (or empty sleeve) into 23.2/30mm adapter ring (or
23.2/30.5mm adapter ring).
（4）Set the adapter ring with SKYE WiFi Camera to stereomicroscope (See Picture 3).

SKYE WiFiTM Set Up & Installation Manual
- 11 -
ACCU-SCOPE, Inc. 73 Mall Drive, Commack, NY 11725 • 631-864-1000 • www.accu-scope.com
Picture 1
Picture 2
Picture 3

SKYE WiFiTM Set Up & Installation Manual
- 12 -
ACCU-SCOPE, Inc. 73 Mall Drive, Commack, NY 11725 • 631-864-1000 • www.accu-scope.com
5.1.2 SKYE WiFi Camera Disassembly
1. Disassembly with Standard C-mount SKYE WiFi Camera
（1）Turn off the software and unplug the USB cable.
（2）Unscrew the SKYE WiFi Camera from the microscope camera adapter.
（3）Screw the plastic dustproof cover on.
（4）Put the SKYE WiFi Camera back in original box for safe storage.
2. Disassembly with Stereomicroscope
（1）Take the product and adapter ring out from the stereomicroscope.
（2）Disassemble the adapter ring and eyepiece from the product.
（3）Screw the plastic dustproof cover on.
（4）Put the SKYE WiFi Camera back in original box for safe storage.

SKYE WiFiTM Set Up & Installation Manual
- 13 -
ACCU-SCOPE, Inc. 73 Mall Drive, Commack, NY 11725 • 631-864-1000 • www.accu-scope.com
Chapter 6 Instructions
6.1 USB Wired Work Mode
6.1.1 Install SKYE View Software
Put the included disc into the DVD driver of your computer, click SKYE View Install file and
finish the installation of the application software according to the on-screen prompts. For detailed
install methods, please refer to User Manual for SKYE View.
6.1.2 To Connect Device
(1) Connect the USB port of the SKYE WiFi Camera to the USB port of the computer.
(2) The device’s driver may automatically install when you first use the
SKYE WiFi Camera, and then system will finish installation automatically.
6.1.3 Open Software
(1) Attach the SKYE WiFi Camera to the microscope and, using the eyepieces, focus on the desired
object.
(2) Execute the SKYE View software in your computer to observe your needed image. You may need
to switch the light path to send light to the camera.
6.1.4 Start to Use
(1) Connect the microscope to SKYE WiFi Camera when required.
(2) Turn on the SKYE WiFi Camera and connect to the device.
(3) Adjust the microscope or SKYE WiFi Camera button to view required objects.
(4) For more detailed instructions, please refer to User Manual of SKYE View.

SKYE WiFiTM Set Up & Installation Manual
- 14 -
ACCU-SCOPE, Inc. 73 Mall Drive, Commack, NY 11725 • 631-864-1000 • www.accu-scope.com
6.2 WiFi Work Mode-iOS System
6.2.1 Install SKYE View for iOS software
Download and install SKYE View software in Apple APP Store.
6.2.2 To Connect Device
(1) Turn the work mode switch of the SKYE WiFi Camera to WiFi work mode. After 20 seconds, WiFi
work indicator of SKYE WiFi Camera blinks.
(2) Setting under iPAD or iPhone system-connect SKYE WiFi Camera under WiFi, WiFi name:
WiFiCamera-xxxxxx, default password: 12345678
6.2.3 Open Software
(1) Attach the SKYE WiFi Camera to the microscope and, using the eyepieces, focus on the desired
object.
(2) Execute the SKYE View mobile app on your iOS device to observe your needed image. You may
need to switch the light path to send light to the camera.
6.2.4 Start to Use
For more detailed instructions, please refer to User Manual of SKYE View for iOS.
6.3 WiFi Work Mode-Android System
6.3.1 Install SKYE Viewfor Android Software
You can use one of the following two methods when installing software.
(1) Download and install SKYE View software on Google Play.
(2) Copy the SKYE View for Android software to Android system for installation.
6.3.2 To Connect Device
(1) Turn the work mode switch of the SKYE WiFi Camera to WiFi work mode. After 20 seconds, WiFi
work indicator of SKYE WiFi Camera blinks.

SKYE WiFiTM Set Up & Installation Manual
- 15 -
ACCU-SCOPE, Inc. 73 Mall Drive, Commack, NY 11725 • 631-864-1000 • www.accu-scope.com
(2) Setting under Android mobile phone or tablet system-connect SKYE WiFi Camera under WiFi,
WiFi name: WiFiCamera-xxxxxx, Default password: 12345678
6.3.3 Open Software
(1) Attach the SKYE WiFi Camera to the microscope and, using the eyepieces, focus on the desired
object.
(2) Execute the SKYE View mobile app on your iOS device to observe your needed image. You may
need to switch the light path to send light to the camera.
6.3.4 Start to Use
For more detailed instructions, please refer to User Manual of SKYE View for Android.
