回路図
CAUTION /
このマークのついている部品は、安全上重要な部品です。
必ず指定されている部品番号の部品を使用して下さい。
ここに記載したサービスに関する指示事項は、サービスに関する資格を
有する者のみが使用するものです。感電防止の観点から、サービス資格
を有していない方は、取扱指示事項以外のサービスは絶対に行わないよ
うにして下さい。
To eliminate the risk of electrical shock, unqualified personnel are not
allowed to perform technical services beyond the instructions herein
provided. Following service instructions are prepared only for personnel
qualified for technical services.
Those bearing the specified part number shall always be used. The part
or component having this mark is important to safety.
For Qualified Service Engineers Only

Precautions for DP-430 Repair
DP-430修理時の注意事項
－
1
－
･Soldering Notes
ﾊﾝﾀﾞについて Pb free solder part number
for PC Board Sn-3Ag-0.5Cu SENJU METAL INDUSTLY
Main-body wiring SN100C NIHON SUPERIOR CO., LTD.
鉛ﾌﾘｰﾊﾝﾀﾞ型番 ﾌﾟﾘﾝﾄ基板用 Sn-3Ag-0.5Cu (千住金属製)
本体配線用 SN100C (日本ｽﾍﾟﾘｱ製)
Precaution and meaning of symbols/注意および記号の意味
Precautions on tasks that involve danger or are related to critical locations in terms of safety.
作業に危険を伴うまたは、安全上重要な箇所に関わる作業
Make sure to provide anti-static measures when you perform the work.
作業時に静電気対策実施のこと
Precautions (Main Unit)注意事項(本体)
Warning
注意事項(共通)
Following Ass'y PCB requires the control of static electricity:CD Mechanical Ass'y,DAC Ass'y,Display Ass'y
注静電気対策が必要なAss'y：CDﾒｶﾆｶﾙAss'y,DAC Ass'y､ﾃﾞｨｽﾌﾟﾚｲAss'y
Precautions (Individual Ass'y PCB)
注意事項(Ass'y個別)
分解、修理を実施した場合、組立後必ず絶縁試験を行い、検査記録に残すこと (国内のみ D only)
This unit is heavy and therefore exercises caution when you perform the work. Weight of
finished product:14kg
重量物につき作業注意 完成時質量14Kg
･Precautions for Assembly (Tightening torque for screws)
･組立上の注意(ﾈｼﾞの締付けﾄﾙｸ）
OPTICL/Optical connector
fixing screw
OPTICL/光ｺﾈｸﾀ取付ﾈｼﾞ
Specified torque
指定ﾄﾙｸ70N.cm
Line/Pin Jack Terminal screw
ﾗｲﾝ/ﾋﾟﾝｼﾞｬｯｸ端子ﾈｼﾞ
HS Link Terminal screw
Line Filter Terminal screw
HS ﾗｲﾝ端子ﾈｼﾞ
ﾗｲﾝﾌｨﾙﾀ取付ﾈｼﾞ
Specified torque
指定ﾄﾙｸ100N.cm
Balance Terminal screw
ﾊﾞﾗﾝｽ端子ﾈｼﾞ
Specified torque
指定ﾄﾙｸ40N.cm
TORQUE SCREW DRIVER
ﾄﾙｸ ｽｸﾘｭ ﾄﾞﾗｲﾊﾞｰ
3
4
5
1
6
17
10
8
13
7
9
1211
14 15
16
2
The attachment order of
screws for Bottom Plate.
ﾎﾞﾄﾑﾌﾟﾚｰﾄ､ﾈｼﾞ取付け順番
Bottom Plate/ﾎﾞﾄﾑﾌﾟﾚｰﾄ
・How to place the set at the time of bottom plate removal
ﾎﾞﾄﾑﾌﾟﾚｰﾄ取り外し時のｾｯﾄの置き方
Since a mechanism part will come out When you remove the
bottom plate Please be cafeful for placing a set.
ﾎﾞﾄﾑを外すとCDﾒｶ部が下に出るので、当たらない様に注意する｡
CD Mechanical/CDﾒｶ部
REAR FACE/後面
When removing the traverse unit,pls have the protection terminals solder-short before disconnecting the wires
.
光学ﾄﾞﾗｲﾌﾞﾕﾆｯﾄ(ﾄﾗﾊﾞｰｽ)を取り外すときは、配線を外す前に保護端子をﾊﾝﾀﾞでｼｮｰﾄすること。(P9 頁参照)

Power button Assembly
ﾊﾟﾜｰﾎﾞﾀﾝAss'y
(730-1002-00)
Push-button for POWER
ﾌﾟｯｼｭﾎﾞﾀﾝ
(388-5062-03)
Power Switch Assembly
ﾊﾟﾜｰｽｲｯﾁ Ass'y
(726-0275-01/02/03)
Power Switch
ﾊﾟﾜｰｽｲｯﾁ
(354-1026-00)
Front Panel Assembly
ﾌﾛﾝﾄﾊﾟﾈﾙ Ass'y
(130-0252-01)
Front Glass
ﾌﾛﾝﾄｶﾞﾗｽ
(172-0188-03)
Leg
脚
(238-0023-00)
Case Assembly
ﾄｯﾌﾟﾌﾟﾚｰﾄ Ass'y
(150-0079-12A4)
Top Plate(B)
ﾄｯﾌﾟﾌﾟﾚｰﾄB
(150-0057-04)
－ ２ －
E
X
P
L
A
N
A
T
I
O
N
O
F
S
U
R
F
A
C
E
P
A
R
T
S
Push-button/5-gang
ﾌﾟｯｼｭﾎﾞﾀﾝ/5連
(388-5113-03)
★
Binding Screw
ﾊﾞｲﾝﾄﾞねじ/4pcs.
(604-0408-00)
Washer
平ﾜｯｼｬ/4pcs.
(637-0042-07)
Panel End-cap (L)
ﾊﾟﾈﾙｴﾝﾄﾞｷｬｯﾌﾟ (左)
(132-0132-14)
Panel End-cap(R)
ﾊﾟﾈﾙｴﾝﾄﾞｷｬｯﾌﾟ(右)
(132-0133-14)
Push-button(Open/Close)
ﾌﾟｯｼｭﾎﾞﾀﾝ(ｵｰﾌﾟﾝ/ｸﾛｰｽﾞ）
(388-5115-04)
★
Push-button(Input)
ﾌﾟｯｼｭﾎﾞﾀﾝ(ｲﾝﾌﾟｯﾄ)
(388-5115-04)
Bottom Plate Assembly
ﾎﾞﾄﾑﾌﾟﾚｰﾄ Ass'y
(155-0093-01A4)
Tray Sub-panel Assembly
ﾄﾚｨｻﾌﾞﾊﾟﾈﾙAss'y
(134-0159-14A6)
(a)Tray Sub-panel
ﾄﾚｨｻﾌﾞﾊﾟﾈﾙ
(134-0159-14)
(b)Push-button
ﾌﾟｯｼｭﾎﾞﾀﾝ(Open/Close)
(388-5115-04)
(c)Push-button
ﾌﾟｯｼｭﾎﾞﾀﾝ(Input)
(388-5115-04)
★
Side Panel
ｻｲﾄﾞﾊﾟﾈﾙ
(139-0053-12)
★
Side Panel
ｻｲﾄﾞﾊﾟﾈﾙ
(139-0053-12)
★
★The part or component having
this mark is not supplied separately.

FRONT FACE (前面)
REAR FACE (後面)
Leg
脚
(238-0023-00)
Line Filter
ﾗｲﾝﾌｲﾙﾀ
(520-9012-00)
Power Supply Cord
電源ｺｰﾄﾞ
D type :680-1406-10
U/T type :680-2403-00
E/K type :680-3403-00
Rear Panel
ﾊﾞｯｸﾊﾟﾈﾙ
(135-0254-02)
Front Panel Assembly
ﾌﾛﾝﾄﾊﾟﾈﾙ Ass'y
(130-0252-01)
1 Front Panel=131-0252-01
ﾌﾛﾝﾄﾊﾟﾈﾙ
2 Tray Sub-panel Ass'y=134-0159-14A6
ﾄﾚｨｻﾌﾞﾊﾟﾈﾙ Ass'y
2-1Input button=388-5115-04
ｲﾝﾌﾟｯﾄﾎﾞﾀﾝ
2-2 Open/Close-button=388-5115-04
ｵｰﾌﾟﾝ/ｸﾛｰｽﾞﾎﾞﾀﾝ
3 Push-button/5-gang=388-5113-03
ﾌﾟｯｼｭﾎﾞﾀﾝ /5連(PLAY,PAUSE)
4 Push-button=388-5062-03
ﾌﾟｯｼｭﾎﾞﾀﾝ/POWER
4-1 Push-button Frame=113-0123-04
ﾌﾟｯｼｭﾎﾞﾀﾝﾌﾚｰﾑ
4-2 Coil Spring=285-1016-04
ｺｲﾙｽﾌﾟﾘﾝｸﾞ
4-3 E-ring=647-1054-00
Eﾘﾝｸﾞ
1pce.
1pce.
1pce.
1pce.
1pce.
1pce.
1pce.
1pce.
1pce.
5 Front Glass=172-0188-03
ﾌﾛﾝﾄｶﾞﾗｽ
5-1 Glass Frame=247-1445-03
ｶﾞﾗｽ取付金具
6 Indicator=173-9164-03
ｲﾝﾃﾞｨｹｰﾀ
6-1 Indicator Mounting
Bracket=247-1452-03
ｲﾝﾃﾞｨｹｰﾀ取付金具
6-2 Push-in Rivet=643-0304-50
ﾌﾟｯｼｭﾘﾍﾞｯﾄ
7 Position Indicator=173-0907-04
ﾎﾟｼﾞｼｮﾝｲﾝﾃﾞｨｹｰﾀ
1pce.
1pce.
1pce.
1pce.
2pce.
2pcs.
1
23
7
－ ３ －
Pin Jack
ﾋﾟﾝｼﾞｬｯｸ
(302-0116-10)
Pin Jack Cover
ﾋﾟﾝｼﾞｬｯｸｶﾊﾞ
(254-2015-04)
6
4
5
★
★
★
★
Pin Jack
ﾋﾟﾝｼﾞｬｯｸ
(302-0116-10)
Pin Jack Cover
ﾋﾟﾝｼﾞｬｯｸｶﾊﾞ
(254-2015-04)
Audio Connector Plug
ｵｰﾃﾞｨｵｺﾈｸﾀﾌﾟﾗｸﾞ
(301-8015-00)
Connector Cover /Male
ｺﾈｸﾀｶﾊﾞ
(254-2027-04)
Optical Receiver
ｵﾌﾟﾄﾚｼｰﾊﾞ/IC34
(PLR135/T9)
2-12-2
Connector Jack(USB)
ｺﾈｸﾀｼﾞｬｯｸ(USB)
(307-0415-00)
USB Dust Cover
USB ﾀﾞｽﾄｶﾊﾞ
(254-2038-00)
Slide Switch
ｽﾗｲﾄﾞｽｲｯﾁ
(350-0207-00)
The part or component having
this mark is not supplied separately.
★The part or component having this mark is important to safety. Those
bearing the specified part number shall always be used.
このマークのついている部品は、安全上重要な部品です。
必ず指定されている部品番号の部品を使用して下さい。
Optical Transmitter
ｵﾌﾟﾄﾄﾗﾝｽﾐｯﾀ/IC25
(PLT133/T9B)
Pin Jack
ﾋﾟﾝｼﾞｬｯｸ
(302-0116-10)
Pin Jack Cover
ﾋﾟﾝｼﾞｬｯｸｶﾊﾞ
(254-2015-04)

CD Mechanical Assembly
CDﾒｶﾆｶﾙ Ass'y
(731-0020-00)
Optical Drive Unit
光学ﾄﾞﾗｲﾌﾞﾕﾆｯﾄ
(733-0001-00)
T
O
P
F
A
C
E
－ ４ －
DAC Assembly
(725-0066-00)
Power Management(ERP)
Assembly
電源管理(ERP)Ass'y
(716-0961-01/13)
Power Switch Assembly
ﾊﾟﾜｰｽｲｯﾁ Ass'y
(726-0275-01/02/03)
Power Push Switch
ﾊﾟﾜｰﾌﾟｯｼｭｽｲｯﾁ /POWER
(354-1026-00)
Motor Assembly
ﾓｰﾀAss'y
(726-0276-00)
Motor/ﾓｰﾀ
(224-0001-00) Switch Assembly
ｽｲｯﾁAss'y
(726-0277-00)
Decoration plate
化粧板
(159-0113-04)
Bridge
ﾌﾞﾘｯｼﾞ
(112-1435-21)
CD Mechanical Assembly
CD ﾒｶﾆｶﾙ Ass'y
(731-0020-00)
Power Supply Assembly
電源 Ass'y
(719-0093-00)
The part or component having this mark is important to safety. Those
bearing the specified part number shall always be used.
このマークのついている部品は、安全上重要な部品です。
必ず指定されている部品番号の部品を使用して下さい。
BOTTOM SIDE ( )
Line Filter/AC Power Plug
ﾗｲﾝﾌｨﾙﾀ /ACｺﾈｸﾀﾌﾟﾗｸﾞ
(520-9012-00)
Power Switch Assembly
ﾊﾟﾜｰｽｲｯﾁ Ass'y
(726-0275-01/02/03)
Fuse/ﾌｭｰｽﾞ
T315mA AC250V/100-120V
(354-1032-00)
T160mA AC250V/220-240V
(354-1013-00)
DAC Assembly
(725-0066-00)
Power Transformer
ﾊﾟﾜｰﾄﾗﾝｽ
(510-4049-10)
Optical Drive Unit
光学ﾄﾞﾗｲﾌﾞﾕﾆｯﾄ
(733-0001-00)
Power Transformer
ﾊﾟﾜｰﾄﾗﾝｽ
(510-4049-10)

－ ５ －
S
U
B
-
C
H
A
S
S
I
S
-
F
R
O
N
T
V
I
E
W
SACD Mechanical Assembly
SACD ﾒｶﾆｶﾙ Ass'y
(731-0020-00)
Push Button/5-gang
ﾌﾟｯｼｭﾎﾞﾀﾝ /5連
(388-5113-03)
FRONT PANEL - REAR VIEW
Front Glass
ﾌﾛﾝﾄｶﾞﾗｽ
(172-0188-03)
★
★
★
Power Switch Assembly
ﾊﾟﾜｰｽｲｯﾁ Ass'y
(726-0275-01/02/03)
Power Push Switch
ﾊﾟﾜｰｽｲｯﾁ
(354-1026-00)
Leaf Spring
板ばね/2pcs.
(285-2008-04)
Light Insulator
ﾗｲﾄｲﾝｼｭﾚｰﾀｰ
(234-1183-04)
★
★
Glass Mounting Bracket
ｶﾞﾗｽ取付金具
(247-1445-03)
★
Push-button
ﾌﾟｯｼｭﾎﾞﾀﾝ
(388-5062-03)
The part or component having this mark is important to safety. Those
bearing the specified part number shall always be used.
このマークのついている部品は、安全上重要な部品です。
必ず指定されている部品番号の部品を使用して下さい。 ★
The part or component having
this mark is not supplied separately.
★
Position Indicator
ﾎﾟｼﾞｼｮﾝｲﾝﾃﾞｨｹｰﾀ
(173-0907-04)
Push-button Frame
ﾌﾟｯｼｭﾎﾞﾀﾝﾌﾚｰﾑ
(113-0159-02)
Display Assembly
ﾃﾞｨｽﾌﾟﾚｨ Ass'y
(723-0250-00)
Infrared
Receiver
赤外線ﾚｼｰﾊﾞ/IC1
(RPM7238-H8R)
Push Switch
ﾌﾟｯｼｭｽｲｯﾁ/S2
(354-1121-00)
Push Switch
ﾌﾟｯｼｭｽｲｯﾁ/S1
(354-1121-00)
Indicator Mounting
Bracket
ｲﾝﾃﾞｨｹｰﾀ取付金具
(247-1452-03)
★
Push-button
ﾌﾟｯｼｭﾎﾞﾀﾝ
(388-5062-03)
Frame
ﾌﾚｰﾑ
(113-0123-04)
Display Assembly
ﾃﾞｨｽﾌﾟﾚｨ Ass'y
(723-0250-00)
Push Switch
ﾌﾟｯｼｭｽｲｯﾁ/S3～7
(354-1122-00)
Indicator
ｲﾝﾃﾞｨｹｰﾀ
(173-9164-03)
★
Filter
ﾌｨﾙﾀ/2pcs.
(179-0071-04)
Panel End cap(R)
ﾊﾟﾈﾙｴﾝﾄﾞｷｬｯﾌﾟ(R)
(132-0133-14)
Panel End cap(L)
ﾊﾟﾈﾙｴﾝﾄﾞｷｬｯﾌﾟ(L)
(132-0132-14)
Tape
布ﾃｰﾌﾟ
(813-1151-00)

MISCELLANEOUS(本体その他使用部品)
No.
T001
Packing
Material
梱包材
Description(部品名)
PC Board for
Power Supply Ass'y
Display Ass'y
Display Ass'y
Display Ass'y
Display(A) Ass'y
Display(B) Ass'y
DAC Ass'y
Traverse/光学ﾄﾞﾗｲﾌﾞﾕﾆｯﾄ
Switch Ass'y /ｽｲｯﾁAss'y
Motor Ass'y /ﾓｰﾀ Ass'y
Motor/ ﾓｰﾀ
Belt / 角ﾍﾞﾙﾄ
Fuse T315mA L 250V
ﾌｭｰｽﾞ T160mA L 250V
Power Transformer / ﾊﾟﾜｰﾄﾗﾝｽ
Outer Carton Box(外ﾀﾞﾝﾎﾞｰﾙ箱)
Inner Carton Box(内ﾀﾞﾝﾎﾞｰﾙ箱)
Top Pad (Front)
ﾄｯﾌﾟﾊﾟｯﾄﾞF
Top Pad (Rear)
ﾄｯﾌﾟﾊﾟｯﾄﾞR
Bottom Pad (Front)
ﾎﾞﾄﾑﾊﾟｯﾄﾞF
Bottom Pad (Rear)
ﾎﾞﾄﾑﾊﾟｯﾄﾞR
Top Board /天地当板
Cover /保護ｶﾊﾞ
Caution Tag/注意銘板 (保護ｽﾍﾟｰｻ)
Accessories Case /付属品ｹｰｽ
Wrapping Sheet /付属品ｹｰｽ用ｼｰﾄ
Bag for AC Cord/保護ｶﾊﾞ
Bag for Remote /保護ｶﾊﾞ
Poly Bag /ﾋﾞﾆｰﾙ袋 for Manual
Poly Bag /ﾋﾞﾆｰﾙ袋 for Battery
Part No.
115-2671-00
115-2667-00
115-2672-00
115-2673-00
115-2668-00
115-2669-00
115-2666-10
733-0001-00
726-0277-00
726-0276-00
224-0001-00
214-0001-00
310-1032-00
310-1013-00
510-4049-10
800-0346-04
801-0172-04
803-0328-10
803-0329-10
803-0401-00
803-0331-10
803-0033-14
810-4843-04
180-2043-14
801-0287-00
810-4545-04
810-2030-04
810-0930-04
812-2435-04
812-0507-00
Remarks
INPUT
OPNE/CLOSE
for 100-120V
for 220-240V
(前)
(後)
(前)
(後)
(本体用)
ﾄﾚｨﾊﾟﾈﾙ用
ACｺｰﾄﾞ
ﾘﾓｺﾝ
取説用
電池用
No.
Screws
for
ﾈｼﾞ類
Description(部品名)
Front Panel /ﾌﾛﾝﾄﾊﾟﾈﾙ用ﾈｼﾞ
Binding Screw /ﾊﾞｲﾝﾄﾞﾂﾒﾂｷBﾀｲﾄﾈｼﾞ
Panel End Cap/ﾊﾟﾈﾙｴﾝﾄﾞｷｬｯﾌﾟ
Pan Head ISO Metric Screw
ﾊﾞｲﾝﾄﾞ平ﾜｯｼｬ付きﾈｼﾞ
Top Plate Ass'y /ﾄｯﾌﾟﾌﾟﾚｰﾄ
Binding Screw /ﾌﾞﾚｻﾞｰﾂﾒﾂｷBﾀｲﾄﾈｼﾞ
Binding Neil Screw
ﾊﾞｲﾝﾄﾞﾂﾒﾂｷBﾀｲﾄﾈｼﾞ
Side Plate/ｻｲﾄﾞﾌﾟﾚｰﾄ
Brazier Head Screw/ﾊﾞｲﾝﾄﾞﾈｼﾞ
Binding Screw/ﾊﾞｲﾝﾄﾞﾈｼﾞBﾀｲﾄﾈｼﾞ
Washer/平ﾜｯｼｬ
Bottom Plate /ﾎﾞﾄﾑﾌﾟﾚｰﾄ
Binding Screw/ﾊﾞｲﾝﾄﾞﾂﾒ付Bﾀｲﾄﾈｼﾞ
Leg / 脚用
Binding Screw /ﾌﾞﾚｻﾞｰBﾀｲﾄﾈｼﾞ
Power Transforer/ﾊﾟﾜｰﾄﾗﾝｽ用
Binding Screw /ﾌﾞﾚｻﾞｰBﾀｲﾄﾈｼﾞ
Owner's Manual(多ヶ国語)
取扱説明書 ERP(Eco/ｴｺﾓｰﾄﾞ）
取扱説明書 (日本語)
Notes (多ヶ国語)
注意書(日本語)
USB Utilities Setup Guide
USBﾕｰﾃｨﾘﾃｨｾｯﾄｱｯﾌﾟｶﾞｲﾄﾞ
目隠しｼｰﾙ/ｽﾃｯｶ
案内状
USB Utility CD /USBﾕｰﾃｨﾘﾃｨCD
Power Supply Cord (J type)
電源ｺｰﾄﾞ (U,T type)
(E type)
(C type)
Remote Commander/ﾘﾓｰﾄｺﾏﾝﾀﾞ
Battery / 電池
Audio Cord Set/ ｵｰﾃﾞｨｵｺｰﾄﾞ ｾｯﾄ
Pin Jack Cover / ﾋﾟﾝｼﾞｬｯｸｶﾊﾞ
Connector Cover for male/ｺﾈｸﾀｶﾊﾞ
USB Dust Cover/USBﾀﾞｽﾄｶﾊﾞ
Part No.
61B-0308-04
631-0044-10
616-0306-02
631-0054-00
604-0408-00
614-0308-00
637-0042-07
631-0054-00
611-0414-02
611-0408-02
820-3312-10
820-4312-10
820-0312-10
821-0011-00
821-0010-00
820-3300-10
820-0300-10
180-9230-00
859-1011-00
783-0005-00
680-1406-10
680-2403-00
680-3403-00
680-5402-00
729-0130-00
569-0008-00
686-0025-00
254-2015-04
254-2027-04
254-2038-00
Remarks
3×8mm 6pcs.
3×6mm 4pcs.
3×6mm 6pcs.
2pcs.
M3×6 4pcs.
4pcs.
4pcs.
3×10mm 17pcs.
4×14mm 4pcs.
2pcs.
Multi-lingual
E type only
Japanese
Multi-lingual
Japanese
Multi-lingual
Japanese
国内のみ
国内のみ
2-conductor
2-conductor
3-conductor
RC-130
LR6 単3型
L/R ２本組
4pcs.
2pcs./出力用
USB用
Accessories
付属品
－ ６ －
REPEAT button
INPUT selector button
PLAY button
FR-/FF+ button (長押し)
STOP button
Direct play button
TIME button
PAUSE button
VOLUME Control
Battery /LR6
電池/単 三
(569-0008-00)
The button key ofa
gray character can
be used with Pre amp・
Integrated amp of our
products.
ｸﾞﾚｰ文字のﾎﾞﾀﾝｷｰは
当社のﾌﾟﾘ・ﾌﾟﾘﾒｲﾝ
ｱﾝﾌﾟで使用すること
ができます。
LEVEL Volume button
BACK-/NEXT+ :track search
OPEN/CLOSE button
＋
－
Battery Case
Assembly
電池ｹｰｽAss'y
(249-0046-02A)
Screw
ﾈｼﾞ/4pcs.
(631-0106-00)
Spacer
ｽﾍﾟｰｻ/2pcs.
(250-1392-04)

－ ７ －
CD Mechanical Assembly
CD ﾒｶﾆｶﾙ Ass'y
(731-0020-00)
Oval Head Screw
丸皿ﾛｯｸﾈｼﾞ/6pcs.
(631-0088-00) Decoration Plate
化粧板
(159-0113-04)
※Bridge
ﾌﾞﾘｯｼﾞ
(112-1435-21)
Recessed Head
screw /8pcs.
W ｾﾑｽﾈｼﾞ
(631-0076-00)
Traverse/ﾄﾗﾊﾞｰｽ
(Optical Pickup)
光学ﾄﾞﾗｲﾌﾞﾕﾆｯﾄ
(733-0001-00）
Shaft
ｼｬﾌﾄ
(203-5026-04)
Bearing Guide
ﾛｰﾃﾞｨﾝｸﾞ 軸受
(283-0003-04)
Disc Tray
ﾃﾞｽｸﾄﾚｨ
(136-0001-52)
Sub-Panel
ｻﾌﾞﾊﾟﾈﾙ
(134-0159-14)
Sub-Panel Ass'y
ｻﾌﾞﾊﾟﾈﾙAss'y
(134-0159-14A6）
Disc Cushion
ﾃﾞｨｽｸｸｯｼｮﾝ/3pcs.
(250-1311-04)
Guide Frame
ｶﾞｲﾄﾞﾌﾚｰﾑ
(113-0132-03)
Bearing
軸受
(283-0004-04)
Spacer
ｽﾍﾟｰｻ/ 茶色
(250-0085-04)
Bearing
軸受
(283-0011-03)
Spacer
ｽﾍﾟｰｻ/ｵﾚﾝｼﾞ色
(250-1310-04)
Bearing
軸受 2psc.
(283-0005-04
)
Sub-panel Fixed
Bracket
ｻﾌﾞﾊﾟﾈﾙ取付 金具
(247-1158-04)
Disc Tray Guide
ﾃﾞｽｸﾄﾚｨｶﾞｲﾄﾞ
(249-0040-22)
Motor Assembly
ﾓｰﾀ Ass'y
(726-0276-00)
Motor/ﾓｰﾀ
(224-0001-00)
Traverse Holder
ﾄﾗﾊﾞｰｽﾎﾙﾀﾞ
(249-0041-02)
Switch Assembly
ｽｲｯﾁAss'y
(726-0277-00)
Belt
角ﾍﾞﾙﾄ
(214-0001-00)
Guide Pin
ｶﾞｲﾄﾞﾋﾟﾝ
(281-0001-04)
Information"001"
※ﾌﾞﾘｯｼﾞ取付け向き
P-13頁参照
Conductive Tape
導電ﾃｰﾌﾟ(27mm)
(813-1193-00)

－ ８ －
Traverse / ﾄﾗﾊﾞｰｽ
(Optical Pickup)
光学ﾄﾞﾗｲﾌﾞﾕﾆｯﾄ
(733-0001-00）
Polyacetal
Washer
ｼﾞｭﾗｺﾝﾜｯｼｬ
(637-9058-00)
Traverse Holder
ﾄﾗﾊﾞｰｽﾎﾙﾀﾞ
(249-0041-02)
Flat Washer
平ﾜｯｼｬ
(637-1032-02)
P Tight Screw
薄平 段 付Pﾀｲﾄﾈｼﾞ
(631-0075-00)
Rubber Spacer
ﾗﾊﾞｰｽﾍﾟｰｻ
(250-0065-04)
Optical Device
光学ﾃﾞﾊﾞｲｽ
Buffer Spacer
緩衝ｽﾍﾟｰｻ
(250-1318-24)
Chucking Pulley(B)
ﾁｬｯｷﾝｸﾞﾌﾟｰﾘ(B)
(201-0003-03)
Bridge
ﾌﾞﾘｯｼﾞ
(112-1435-21)
Chucking Pulley(A)
ﾁｬｯｷﾝｸﾞﾌﾟｰﾘ(A)
(201-0002-03）
Construction for Bridge
ﾌﾞﾘｯｼﾞの構造
Decoration Plate
化粧 板
(159-0113-04)
Magnet
ﾏｸﾞﾈｯﾄ
(271-0003-00)
Oval Head Screw
丸皿ﾛｯｸﾈｼﾞ/6pcs.
(631-0088-00)
Please perform lens cleaning
of an optical pickup by air blow.
The cleaning in a swab etc.
causes failure.
光ﾋﾟｯｸｱｯﾌﾟのﾚﾝｽﾞｸﾘｰﾆﾝｸﾞは
ｴｱｰﾌﾞﾛｱｰ で 行 っ て 下 さい 。
綿 棒 な どで のｸﾘｰﾆﾝｸﾞ は 故 障 の
原 因 と なり ま す 。
Information"001"
※
※ﾌﾞﾘｯｼﾞ取 付け向き
P-13頁参照
This work is carrying out by taking the
measures against static electricity.
この作業は静電気対策をして行う事。
ﾏｸﾞﾈｯﾄ に黒ﾏｰｸがある
面を上にする。

－ ９ －
Mechanical Assembly (731-0020-00)
Ass'y
Disc Tray
ﾃﾞｨｽｸﾄﾚｲ
Belt(214-0001-00)
ﾍﾞﾙﾄ
The exchange method of a Traverse(Optical-pickup)
A bridge attachment screw is removed and
a bridge is removed.
ﾌﾞﾘｯｼﾞ 取り 付 けﾈｼﾞ を 外しﾌﾞﾘｯｼﾞを外 し ます 。
It pulls out before a disk tray and a traverse
attachment screw is removed.
At this time,It warns against losing the washer
of a screw.
ﾃﾞｨｽｸﾄﾚｲ を前に 引き出し､ﾄﾗﾊﾞｰｽ取付ﾈｼﾞ を外します
。
この時､ﾈｼﾞのﾜｯｼｬ類を紛失しないように注意します。
The circle mark portion of the following figure
of Connector on the back of a traverse is made
to short-circuit with solder.
Next, the flat cable shown in is removed.
ﾄﾗﾊﾞｰｽ裏面 の､ｺﾈｸﾀの下図の 枠部分をﾊﾝﾀﾞｼｮｰﾄ
させ ま す｡次に に 示すﾌﾗｯﾄｹｰﾌﾞﾙ を外し ます｡
The flat cable of 6P connector of spindle motor Ass'y
on the back is removed.
裏面のｽﾋﾟﾝﾄﾞﾙﾓｰﾀAss'yの6Pｺﾈｸﾀのﾌﾗｯﾄｹｰﾌﾞﾙを外します。
The flat cable shown in the left figure is
connected to the new traverse. And please
make a style of a flat cable in the ↓ mark
direction. Next, in figure shown Solder short-circuit
of circle mark portion is removed.
新らしいﾄﾗﾊﾞｰｽに左図 に示すﾌﾗｯﾄｹｰﾌﾞﾙを接続 します｡
ﾌﾗｯﾄｹｰﾌﾞﾙは 印 方向に膨らませるよ うにして 下さい｡
次に左図 の 印部分の、ﾊﾝﾀﾞｼｮｰﾄを 除去しま す。
Rubber Spacer
ﾗﾊﾞｰｽﾍﾟｰｻ
(250-0065-04) A new traverse is attached in the reverse order
of the removed procedure.
ﾄﾗﾊﾞｰｽを外した逆 の順序で取付 けます。
Flat Cable/ﾌﾗｯﾄｹｰﾌﾞﾙ(674-0005-30)
The removed rubber spacer is
attached to a new traverse.
新ﾄﾗﾊﾞｰｽに､外したﾗﾊﾞｰｽﾍﾟｰｻを
取付けま す｡
Disc Pulley
ﾃﾞｨｽｸﾌﾟｰﾘｰ
Disc Tray
ﾃﾞｨｽｸﾄﾚｲ
Bridge
ﾌﾞﾘｯｼﾞ
SIDE VIEW( 側面)
Traverse Fixing Screw
ﾄﾗﾊﾞｰｽ取付ﾈｼﾞ
Spindle Motor Ass'y
ｽﾋﾟﾝﾄﾞﾙﾓｰﾀAss'y
The Solder for Short circuit.
ﾊﾝﾀﾞｼｮｰﾄ
Remove the Solder
ﾊﾝﾀﾞｼｮｰﾄを除去 する
Connector / ｺﾈｸﾀ
Connector / ｺﾈｸﾀ
This work is carrying out by taking the
measures against static electricity.
この作業は静電気対策をして行う事。
Top View
(上面)
Expansion/拡大

－ １０ －
Display(A) Assembly (723-0251-00)
(A)Ass'y
LED D1～5,7,8 LAP-301DLTU
D9～12 SEL2610C-C/D
Indicator D1～5,7,8用 173-9161-04
ｲﾝﾃﾞｨｹｰﾀ
Display Holder D1～5,7,8用 234-1179-12
表示器ﾎﾙﾀﾞ
LED Spacer D9～12用 250-1116-00
LEDｽﾍﾟｰｻ
Connector Assembly K1 309-2829-04
ｺﾈｸﾀAss'y
IC IC1 NJU3719AV-TE1
Aluminum Electrolytic C2 CE04W0J470MA 47uF/6.3V
Capacitor
ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ
Display(B) Assembly (723-0252-00)
(B)Ass'y
LED D1～7 LAP-301DLTU
D8,9 SEL2610C-C/D
Indicator D1～7用 173-9162-04
ｲﾝﾃﾞｨｹｰﾀ
Display Holder D1～7用 234-1180-12
表示器ﾎﾙﾀﾞ
LED Spacer D8,9用 250-1116-00
LEDｽﾍﾟｰｻ
Connector Assembly K1 309-0996-04
ｺﾈｸﾀAss'y
IC IC1 NJU3718AV-TE1
Aluminum Electrolytic C1 CE04W0J470MA 47uF/6.3V
Capacitor
ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ
D
i
s
p
l
a
y
A
s
s
e
m
b
l
y
(
7
2
3
-
0
2
5
0
-
0
0
)
Ass'y
Transistor Q1 2SC2712-GR
ﾄﾗﾝｼﾞｽﾀ
Digital Transistor X1 RN1505
ﾃﾞｼﾞﾀﾙﾄﾗﾝｼﾞｽﾀ
Infrared Receiver IC1 RPM7238-H8R
赤 外 線ﾚｼ ｰﾊﾞ
IC IC2 TC74VHCT08AF/EL
Push Switch S1,2 354-1121-00
ﾌﾟｯｼｭｽｲｯﾁ S3,4,5,6,7 354-1122-00
Aluminum Electrolytic C1,2 CE04W0J470MA 47uF/6.3V
Capacitor
ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ
PC Board 115-2667-00
PCﾎﾞｰﾄ 115-2672-00
115-2673-00
LED D1 NSPB310B-1366
D2,3 SEL2610C-C/D
Light Guide Holder D1用 234-1149-03
ﾗｲﾄｶﾞｲﾄﾞﾎﾙﾀﾞ
LED Spacer D1用 250-0061-00
LEDｽﾍﾟｰｻ D2,3用 250-1122-00
Connector Assembly K1,2 309-3257-04
ｺﾈｸﾀAss'y K3,4 309-3258-04
Connector Plug K5 308-1206-00
ｺﾈｸﾀﾌﾟﾗｸﾞ K6 308-0906-00
K7 308-0809-00
PC Board
PCﾎﾞｰﾄﾞ
115-2672-00
PC Board
PCﾎﾞｰﾄﾞ
115-2673-00
PC Board
PCﾎﾞｰﾄﾞ
115-2667-00
Power Supply Assembly (719-0093-00)
電源 Ass'y
Fuse F1 310-2252-00
ﾌｭｰｽﾞ F2 310-2162-00
F3,4 310-2082-00
Connector Assembly K1 309-2732-14
ｺﾈｸﾀAss'y
Connector Plug K2 308-0709-00
ｺﾈｸﾀﾌﾟﾗｸﾞ

－ １１ －
PC Board 115-2666-10
PCﾎﾞｰﾄﾞ
Diode D1,2,16,17,19 ISS387
ﾀﾞｲｵｰﾄ D3 SJPL-H2VL
D4,5,6,7,13 CRG03
D12 D3SBA60
D18 D4SBS4
LED D8,14,15 SML-E12DWT86ST
Ferrite Beads FB2,3,12 BLM18HE152SN1D
ﾌｪﾗｲﾄﾋﾞｰｽﾞ FB4～6,8～11 BLM18AG102SN1D
Pin Jack JK1,2,5,6 302-0116-10
ﾋﾟﾝｼﾞｬｯｸ
Audio Connector Plug JK3,4 301-8015-00
ｵｰﾃﾞｨｵｺﾈｸﾀﾌﾟﾗｸﾞ
Connector Plug K1 308-0508-00
ｺﾈｸﾀﾌﾟﾗｸﾞ K2 308-0606-00
K4 308-0242-00
K5,10 308-0206-00
K6 308-1206-00
K7 308-0709-00
K8 308-1102-00
Connector Jack K3 307-0415-00
ｺﾈｸﾀｼﾞｬｯｸ K9 307-1609-00
Low Pass Filter LPF1 520-5007-00
ﾛｰﾊﾟｽﾌｨﾙﾀ
Digital Transistor X1,3 RN1427
ﾃﾞｼﾞﾀﾙﾄﾗﾝｼﾞｽﾀ X2 RN1304
IC IC1,6,9,14 AK4490EQ-L
IC2,7,13 NJM5532M-TE1
IC3,4,10,11 BA4580RF-E2
IC5,12 NJM2122M
IC8 DS90LV048ATMTCN0PB
IC15 M93C46-WMN6TP
IC16 R5F100LCAFB
IC17 CXD3059AR
IC18,19,20 LMR822FVM-GTR
IC21,22 BD8226EFV-E2
IC23 AK4117VF-E2
IC24 AK4104ET-E2
IC26 5M160ZT100C5N
IC27 TC74HCU04AF/EL
IC28 XC6501B251MR-G
IC29 XC6501B181MR-G
IC30 BA80BC0FP
IC32 TPD4S012DRYR
IC33 SA9227A
IC35 BR24G128F-3GTE2
DAC Assembly (725-0066-00)
Opt-transmitter IC25 PLT133/T9B
ｵﾌﾟﾄﾄﾗﾝｼﾐｯﾀ
Optical Receiver IC34 PLR135/T9
ｵﾌﾟﾄﾚｼｰﾊﾞ
RELAY RELAY1～5 362-0211-00
ﾘﾚｨ
Slide Switch S1 350-0207-00
ｽﾗｲﾄﾞｽｲｯﾁ
Conductive Bracket SHIELD1 246-0038-04
導 電 金 具
Crystal Resonator XTAL1 527-0060-00
水晶振動子 XTAL3 527-0055-00
Crystal XTAL2 527-0058-00
ｾﾗﾛｯｸ
Aluminum C1,46,54,61, CE04W1E101ZL 100uF /25V
Electrolytic 68,110
Capacitor C6,26,45,59, CE04W0J101BKME 100uF/6.3V
ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ 72,89
C8,102 CE04W1E220ROS 22uF / 25V
C13,20,57,60, CE04W1E470UTSJ 47uF / 25V
87,99
C18,29,35,75,82, CE04W1H100ZL 10uF / 25V
88,112,195,196,
217,232,237
C25,30,80,85 CE04W1E390LXVE 39uF / 25V
C119 CE04W1C101CAE 100uF /16V
C122,131,132, CE04W1E101VL 100uF /25V
142,143,167,168
C169～171,186, CE04W1E470VRE 47uF / 25V
208,230,234
C197 CE04W1H150PJ 15uF / 50V
C201,202 CE04W1E561PJ 560uF /25V
C204,205 CE04W1E821LXZE 820uF /25V
C220 CE04W1E472VL 4700uF/25V
C233 CE04W1E472KMQ 4700uF/25V
Transistor Q1 2SA1182-Y
ﾄﾗﾝｼﾞｽﾀ Q2 2SA1586-GR
Q3 2S C5819
Q4 2SA2069
Some of the Surface Mount devices are omitted from the lists.
※一部の表面実装部品はﾘｽﾄから省略しています
Power Switch Assembly (726-0275-01/02/03)
Ass'y
Connector Plug K1 308-0332-00
ｺﾈｸﾀﾌﾟﾗｸﾞ K2 308-0236-00
K3 308-0432-00
Power Switch S1 354-1026-00
電源ｽｲｯﾁ
MPP Capacitor C1 CF99PC2E103KLE 0.01uF/250V
MPPｺﾝﾃﾞﾝｻ
PC Board 115-2670-00
PC ﾎﾞｰﾄﾞ
Fuse Holder FH1,2 306-2001-00
ﾌｭｰｽﾞﾎﾙﾀﾞ

－ １２ －
M
o
t
o
r
A
s
s
e
m
b
l
y
(
7
2
6
-
0
2
7
6
-
0
0
)
Ass'y PC Board 115-2675-00
PC ﾎﾞｰﾄﾞ
Connector Assembly K1 309-2283-04
ｺﾈｸﾀAss'y
Switch Assembly (726-0277-00)
Ass'y PC Board 115-2676-00
PCﾎﾞｰﾄ
Connector Plug K1 308-0206-00
ｺﾈｸﾀﾌﾟﾗｸﾞ K2 308-0508-00
Lever Switch S1 356-0102-00
ﾚﾊﾞｰｽｲｯﾁ
About the voltage of a product/ 製品の電圧について
For Japan domestic use, the voltage of products are set at 100V as required by law
The voltage in the major regions of the world are as below.
Products which are suited to each regions voltage condition are allowed to be used.
日本国内の電圧は１００Ｖと定められています。
世界主要地域の例として電圧は次の通り、地域に適合する製品以外は使用出来ません。
Japan / 日本 :１００Ｖ
North America・Taiwan / 北米・台湾 :１２０Ｖ
Europe / ﾖｰﾛｯﾊﾟ :２３０Ｖ
Other Countries /その他の国々 :２２０Ｖ
ｴｺﾓｰﾄﾞON/OFF切替え方法
初めに操作ﾓｰﾄﾞに入る、 OPEN/CLOSEとSA-CD/CDﾎﾞﾀﾝを同時に押しながら電源を入れると全てのLEDが点灯、入ったことを表す。
操作は本体のﾎﾞﾀﾝｷｰを使用する。NEXT(進む)/BACK(戻る)ﾎﾞﾀﾝを押して項目を選びます。
NEXTを6回押し ”ALL InIt du” ( D,Uﾀｲﾌﾟ向け、ｴｺﾓｰﾄﾞはOFFになる)
NEXTを7回押し ”ALL InIt E ” ( E ﾀｲﾌﾟ 向け、ｴｺﾓｰﾄﾞはONになる)
ON/OFFの設定が決まったら、PLAYﾎﾞﾀﾝを押し設定が確定し出荷状態に初期化します。電源を切り終了します。
Turning on/off Eco Mode
First enter Operation Mode. Pressing and holding the [OPEN/CLOSE] button and [SA-CD/CD] button simultaneously, turn
on the main unit power. All LEDs will light. It indicates that the main unit enters Operation Mode.
Use buttons on the main unit to perform an operation. Press the [NEXT] and [BACK] buttons to select the next and previous
item, respectively.
When you press the [NEXT] button four times, "ALL InIt du" appears (Types D and U models with Eco Mode set to off).
When you press the [NEXT] button five times, "ALL InIt E" appears (Type E model with Eco Mode set to on).
After setting Eco Mode to on or off, press the [PLAY] button to initialize the unit to default setting. The setting is finalized.
Turn off power to end the procedure.
Power Management(ERP) Assembly (716-0961-01/13)
電源管理(ERP) Ass'y
PC Board 115-2227-20
PCﾎﾞｰﾄ
Connector Plug K1 308-0327-00
ｺﾈｸﾀﾌﾟﾗｸﾞ K2 308-0206-00
Jumper Wire J1 678-0070-00
ｼﾞｬﾝﾊﾟｰﾘｰﾄﾞ
PC Board 115-2227-20
PCﾎﾞｰﾄ
Zener Diode D1 UDZV6.2B
ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ
Diode D2 S1ZB60-7062
ﾀﾞｲｵｰﾄﾞ
IC IC1 NJU7231U33
IC4 NJU7700F4-28-TE1
Opt-isolator IC2 TLP170J/TP/F
ｵﾌﾟﾄｱｲｿﾚｰﾀ IC3 PC123X2YFZ0F
716-0961-13
Connector Plug K1 308-0327-00
ｺﾈｸﾀﾌﾟﾗｸﾞ K2 308-0206-00
FET Q1,2 RUC002N05
RELAY RELAY1 362-8101-00
ﾘﾚｨ
Varistor VS1 420-0001-00
ﾊﾞﾘｽﾀ
Ceramic Capacitor C1 CK725B1C226M32TM 22uF / 16V
磁器ｺﾝﾃﾞﾝｻ C2,4 CK725B1E104K16TM 0.1uF /25V
C3 CK725B1E105K16TM 1uF / 25V
MPP Capacitor C5,6 CF922MF2E104MR46 0.1uF/250V
MPPｺﾝﾃﾞﾝｻ
Metal Mixed Thick R1 RK73K1J112JE-T 1.1kΩ1/10W
Film Resistor R2 RK73K2H102KETSG 1kΩ 1/2W
金属混合皮膜抵抗器 R3 RK73K1J682JE-T 6.8kΩ1/10W
R4 RK73K1J102JE-T 1kΩ 1/10W
716-0961-01

Accuphase Laboratory Inc.
Issued 2017-09-04
MODEL : DP-400,DP-600,DP-500,DP-410,DP-510,DP-550,DP-430
SUBJECT : Select the correct hole of Chucking pulley
項 目 ： CD/SACD兼用ﾌﾞﾘｯｼﾞの向き
Service Information
Details ; In 7 models (DP-400/DP-600/DP-500/DP-410/DP-510/DP-550/DP-430), use of a combination bridge
is possible.
The chucking pulley attachment hole in a bridge has an object for CD, and an object for
SACD, and the attachment direction of a bridge changes with use models.
In exchange, please refer to the following figure.
詳細； 兼用ﾌﾞﾘｯｼﾞは7機種において使用可能となりますが、ﾌﾞﾘｯｼﾞ内のﾁｬｷﾝｸﾞﾌﾟｰﾘは取付け穴が
CD用とSACD用があり、使用機種によりﾌﾞﾘｯｼﾞの取付け方向が異なります。
交換の場合は下図を参照してください。
No. DP-430-001
Bridge/ﾌﾞﾘｯｼﾞ
(112-1435-21)
Bottom View
(底面)
Top View
(上面)
Side View(側面)
Hole for Chucking pulley
ﾁｬｯｷﾝｸﾞﾌﾟｰﾘ取付け穴
for CD
for SACD
The hole by the side of a projection of the object
for CD, and opposite side is an object for SACD.
横又は底から見て突起がある方の穴がCD用になり
逆側はSACD用に なりま す 。
In the chucking pulley attachment hole of
a figure, red is CD and green is SACD,as
for a diameter, CD becomes large from SACD.
ﾁｬｯｷﾝｸﾞﾌﾟｰﾘｰ取付 穴 は赤 がCD､ 緑がSACDを示
します が､CD径 はSACD 径より 大きく なりま す。
Projection
突起
The bridge attachment direction / ﾌﾞﾘｯｼﾞ取付け方向
CD用
SACD用
CD PLAYER / CDﾌﾟﾚｰﾔｰ(DP-400/500/410/510/430)
It is attached so that a projection may come to the Front side.
(front panel side).
突起 が 前側(ﾌﾛﾝﾄﾊﾟﾈﾙ側)に 来るよ うに取 付けに な りま す 。
SACD PLAYER (DP-600/550)
It is attached so that a projection may come to the backward (back panel side).
突起 が 後側(ﾊﾞｯｸﾊﾟﾈﾙ側)に 来るよ うに取 付けに な りま す 。
Projection
突起
CD
SACD
CD ＞SACD
CD
SACD
－ １3－

K2-3
K1-1
K3
K1-3
K1-5
K2-1
726-0275
POWER SWITCH Ass'y
K1 K2
719-0093
POWER SUPPLY Ass'y
N
L
E
N(W)
520-9012-00
K1
726-0276
MOTOR Ass'y
CN6P
CN16P
731-0020
CD MECHANICAL Ass'y
K2
K1
726-0277
SWITCH Ass'y
K7
K6
K10
K9
K8
725-0066
DAC Ass'y
K5
K6
K7
723-0250
DISPLAY Ass'y
T160mA L 250V at 220-240V
T315mA L 250V at 100-120V
FUSE:
BRN
BLU
WHT
BLU
AC100/120/230V
50/60Hz
T1
!
!
!Attention mark indicating critical components for safety.
Replacement must be made with identical parts of specified part number.
FUSE
!
K1-5
K1-3
K1-1
K2
716-0961
POWER MANAGEMENT Ass'y
K1
DISPLAY(A) Ass'y
723-0251
K1
DISPLAY(B) Ass'y
723-0252
BRN
- 14 -
DP-430 MASTER CIRCUIT DIAGRAM

1
2
3
4
5
6
7
K2
308-0709-00
AC6V
AC6V
AC12V
AC12V
AC9V
AC CT
AC9V
2
100V
120V
230V
10.4V
CT
10.4V
11.9V
11.9V
6.9V
6.9V
3
4
5
6 13
14
15
16
17
18
19
T1
510-4049-10
1 2
1 2
1 2
1 2
DAC Ass'y K7
Power switch Ass'y K3
!Attention mark indicating critical components for safety.
Replacement must be made with identical parts of specified part number.
!
!
!
!
!
!
1
3
5
7
K1
309-2732-14
- 15 -
POWER SUPPLY ASS'Y (719-0093-00)
Text

/RET0 /RET1 /RET2 /RET3 /SCAN1 /RET1 /SCAN0 /SCAN0 /RET0 /SCAN0 /RET2
/RET0 /RET1 /RET2 /RET3
VCC
SCLK SDATA EN_DISP /LAT_DISP
VCC
-GR
Q1
2SC2712_
1.8k
R4
1k
R3
110
R2
G
4
G
2O 1
G
5
V
3
IC1
RPM7238-H8R
/RCON
33
R1
47u 6.3V
C1
/RCON
EN_DISP_BUF
1 2
K1
309-3257-04
1 2
K2 309-3257-04
1 2
K4
309-3258-04
1 2
K3 309-3258-04
SCLK_BUF SDATAL EN_DISP_BUF /LAT_DISP_BUF LED_PLAY LED_PAUSE
VCC
SCLK_BUF SDATA_BUF EN_DISP_BUF /LAT_DISP_BUF SCAN0 SCAN1
VCC
1 2 3 4 5 6 7 8 9 10 11 12
K5 308-1206-00
+3.3VD
+3.3VD
/SCAN1 /SCAN0
SCLK_BUF
EN_DISP_BUF
/LAT_DISP_BUF
SDATA_BUF
SCLK
SDATA
EN_DISP
/LAT_DISP
47u
6.3V
C2 VCC
LED_PLAY LED_PAUSE
D2
SEL2610C-C/D
1.2k
R5
D3
SEL2610C-C/D
1.2k
R6
/SCAN1 /SCAN1 /SCAN1
1
2
3
4
INPUTS1
354-1121-00
1
2
3
4
TRAYS2
354-1121-00
1
2
3
4
PLAY
S3
354-1122-00
1
2
3
4
PAUSE
S4
354-1122-00
1
2
3
4
BACK
S5
354-1122-00
1
2
3
4
NEXT
S6
354-1122-00
1
2
3
4
STOP
S7
354-1122-00
12
13 11
IC2D
TC74VHCT08AF/EL
1
23
IC2A
4
56
IC2B
9
10 8
IC2C
X1
RN1505
100n
C3
1 2 3 4 5 6 7 8
K7
308-0809-00
1 2 3 4 5 6 7 8 9
K6
308-0906-00
to Display (A) Ass'y (K1) to Display (B) Ass'y (K1)
from DAC Ass'y (K6)
D1
NSPB310B-1366
- 16 -
DISPLAY ASS'Y (723-0250-00)

A
1
F
2
G
3
E
4
D
5DPK 6
DPA 7
C8
COM 9
B10
D8
LAP-301DLTU
SEG_LA SEG_LB
SEG_LC
SEG_LD
SEG_LE
SEG_LF
SEG_LG
/DIG_L0
SEG_LH
/DIG_L0
A
1
F
2
G
3
E
4
D
5DPK 6
DPA 7
C8
COM 9
B10
D7
LAP-301DLTU
SEG_LA SEG_LB
SEG_LC
SEG_LD
SEG_LE
SEG_LF
SEG_LG
/DIG_L1
SEG_LH
/DIG_L1
*
A
1
F
2
G
3
E
4
D
5DPK 6
DPA 7
C8
COM 9
B10
D6
LAP-301DLTU
SEG_LA SEG_LB
SEG_LC
SEG_LD
SEG_LE
SEG_LF
SEG_LG
/DIG_L2
SEG_LH
/DIG_L2
A
1
F
2
G
3
E
4
D
5DPK 6
DPA 7
C8
COM 9
B10
D5
LAP-301DLTU
SEG_LA SEG_LB
SEG_LC
SEG_LD
SEG_LE
SEG_LF
SEG_LG
/DIG_L3
SEG_LH
/DIG_L3
A
1
F
2
G
3
E
4
D
5DPK 6
DPA 7
C8
COM 9
B10
D4
LAP-301DLTU
SEG_LA SEG_LB
SEG_LC
SEG_LD
SEG_LE
SEG_LF
SEG_LG
/DIG_L4
SEG_LH
/DIG_L4
A
1
F
2
G
3
E
4
D
5DPK 6
DPA 7
C8
COM 9
B10
D3
LAP-301DLTU
SEG_LA SEG_LB
SEG_LC
SEG_LD
SEG_LE
SEG_LF
SEG_LG
/DIG_L5
SEG_LH
/DIG_L5
A
1
F
2
G
3
E
4
D
5DPK 6
DPA 7
C8
COM 9
B10
D2
LAP-301DLTU
SEG_LA SEG_LB
SEG_LC
SEG_LD
SEG_LE
SEG_LF
SEG_LG
/DIG_L6
SEG_LH
/DIG_L6
A
1
F
2
G
3
E
4
D
5DPK 6
DPA 7
C8
COM 9
B10
D1
LAP-301DLTU
SEG_LA SEG_LB
SEG_LC
SEG_LD
SEG_LE
SEG_LF
SEG_LG
/DIG_L7
SEG_LH
/DIG_L7
D9
SEL2610C-C/D
LED_USB
1.2k
R1
D10
SEL2610C-C/D
LED_OPT
1.2k
R2
D11
SEL2610C-C/D
LED_COAX
1.2k
R3
D12
SEL2610C-C/D
LED_FREQ
1.2k
R6
100k
R4
/CLRLED /STBLED SCLK SDATAL
2.2kR9
2.2kR5
VCC
100n
C3
1kR10 SEG_LA 1kR8 1kR7 1kR14 1kR15 1kR13 1kR12 1kR11
SEG_LB SEG_LC SEG_LD SEG_LE SEG_LF SEG_LG SEG_LH
/DIG_L0 /DIG_L1 /DIG_L2 /DIG_L3 /DIG_L4 /DIG_L5 /DIG_L6 /DIG_L7 LED_USB LED_OPT LED_COAX LED_FREQ
VCC
SCLK SDATAL
47u
6.3V
C2
VCC
/LAT_DISP
EN_DISP
EN_DISP /LAT_DISP
100p
C4
100p
C1
P11
1
P12
2
P13
3
P14
4
P15
5
P16
6
P17
7
VSS
8
P18
9
P19
10
P20
11
P21
12
P22
13
NC
14
P23
15
P24
16 DAT 17
CLK 18
NC 19
STB 20
CLR 21
P1 22 P2 23 P3 24 P4 25 P5 26 P6 27 P7 28 P8 29 P9 30
P10 31
VDD 32
IC1
NJU3719AV-TE1
LED_PLAY LED_PAUSE
LED_PLAY LED_PAUSE
1 2 3 4 5 6 7 8
K1
309-2829-04
from Display Ass'y (K7)
Components with '*' are not normally mounted on PCB.
- 17 -
DISPLAY (A) ASS'Y (723-0251-00)

A
1
F
2
G
3
E
4
D
5DPK 6
DPA 7
C8
COM 9
B10
D7
LAP-301DLTU
SEG_RA SEG_RB
SEG_RC
SEG_RD
SEG_RE
SEG_RF
SEG_RG
/DIG_R0
SEG_RH
/DIG_R0
A
1
F
2
G
3
E
4
D
5DPK 6
DPA 7
C8
COM 9
B10
D6
LAP-301DLTU
SEG_RA SEG_RB
SEG_RC
SEG_RD
SEG_RE
SEG_RF
SEG_RG
/DIG_R1
SEG_RH
/DIG_R1
A
1
F
2
G
3
E
4
D
5DPK 6
DPA 7
C8
COM 9
B10
D5
LAP-301DLTU
SEG_RA SEG_RB
SEG_RC
SEG_RD
SEG_RE
SEG_RF
SEG_RG
/DIG_R2
SEG_RH
/DIG_R2
A
1
F
2
G
3
E
4
D
5DPK 6
DPA 7
C8
COM 9
B10
D4
LAP-301DLTU
SEG_RA SEG_RB
SEG_RC
SEG_RD
SEG_RE
SEG_RF
SEG_RG
/DIG_R3
SEG_RH
/DIG_R3
A
1
F
2
G
3
E
4
D
5DPK 6
DPA 7
C8
COM 9
B10
D3
LAP-301DLTU
SEG_RA SEG_RB
SEG_RC
SEG_RD
SEG_RE
SEG_RF
SEG_RG
/DIG_R4
SEG_RH
/DIG_R4
A
1
F
2
G
3
E
4
D
5DPK 6
DPA 7
C8
COM 9
B10
D2
LAP-301DLTU
SEG_RA SEG_RB
SEG_RC
SEG_RD
SEG_RE
SEG_RF
SEG_RG
/DIG_R5
SEG_RH
/DIG_R5
A
1
F
2
G
3
E
4
D
5DPK 6
DPA 7
C8
COM 9
B10
D1
LAP-301DLTU
SEG_RA SEG_RB
SEG_RC
SEG_RD
SEG_RE
SEG_RF
SEG_RG
/DIG_R6
SEG_RH
/DIG_R6
D8
SEL2610C-C/D
LED_ALL
1.2k
R2
D9
SEL2610C-C/D
LED_ONE
1.2k
R1
100k
R4
2.2kR3
2.2kR5
100n
C4
1kR8 SEG_RA 1kR7 1kR6 1kR12 1kR13 1kR11 1kR10 1kR9
SEG_RB SEG_RC SEG_RD SEG_RE SEG_RF SEG_RG SEG_RH
/DIG_R0 /DIG_R1 /DIG_R2 /DIG_R3 /DIG_R4 /DIG_R5 /DIG_R6 LED_ALL LED_ONE
P9
1
P10
2
NC
3
P11
4
P12
5
P13
6
P14
7
VSS
8
P15
9
P16
10
P17
11
P18
12
P19
13
NC
14
P20
15
SO
16 DAT 17
CLK 18
NC 19
STB 20
CLR 21
P1 22 P2 23
VSS 24
P3 25 P4 26 P5 27 P6 28 P7 29
NC 30
P8 31
VDD 32
IC1
NJU3718AV-TE1
SDATAL
SDATAL
/CLRLED /STBLED SCLK SDATA
VCC
VCC
SCLK SDATA
47u
6.3V
C1
VCC
/LAT_DISP
EN_DISP
EN_DISP /LAT_DISP
100p
C2
100p
C3
1 2 3 4 5 6 7 8 9
K1
309-0996-04
SCAN0 SCAN1
SCAN0 SCAN1
from Display Ass'y (K6)
- 18 -
DISPLAY (B) ASS'Y (723-0252-00)

/EXT_RST
/MUTE
SCL
SDA
DAC_DATA_P
DAC_DATA_N
DAC_LRCK_P
DAC_LRCK_N
DAC_BCK_P
DAC_BCK_N
DAC_MCK_P
DAC_MCK_N
DGND
AGND
-VA
+VA
D3.3V
D5V
DAC & Filter
004-8666-02.SchDoc
VDD 1
GND 2
V18OUT 3
VDD 4
GND 5
SPDRX 6
VDD 7
VDD18 8
SOFFLAG 9
DSDFLAG 10
DSD128FLAG 11
REXT 12
VDD 13
VDD 14
DP 15
DM 16
GND 17
XI 18
XO 19
VDD18 20
VDD 21 GND 22 GND 23 VDD 24 GND 25 VDD 26
GPIO0 27
VDD18 28
VDD 29
GPIO1 30
GPIO2/USB(HS/FS)SEL 31
GPIO3 32
GPIO4
33
GPIO5
34
GPIO6
35
GPIO7
36
GPIO8
37
RESET
38
VDD
39
SCL
40
SDA
41
DASCLK/DSDCLK
42
VDD18
43
VDD
44
DADAT/DSDDL
45
DAMCLK
46
DASYNC/DSDDR
47
SPDTX
48
ADSCLK
49
ADDAT
50
ADMCLK
51
VDD
52
ADSYNC
53
SCL1
54
SDA1
55
VDD
56
REFCLK
57
VDD18
58
TEST1
59
TEST2
60
TEST3
61
TEST4
62
TEST5
63
TEST6
64
IC33
SA9227A
MCLK
1
BCK
2
SDTI1
3
LRCK
4
PDN
5
CSN
6
CCLK
7
CDTI
8TEST1 9
TEST2 10
TEST3 11
TEST4 12
VSS 13
VDD 14
S2/CDO 15
TX 16
IC24
AK4104ET-E2
AK_BCK
AK_DATA
AK_MCK
SV_SPDIF_DUM
SV_MCK_DUM
SV_BCK_DUM
SV_LRCK_DUM
SV_DATA_DUM
/EXT_RST
100nC178
XI 1
G
2
11.289MHz
XO 3
XTAL2
527-0058-00
/EXT_RST
/CS_DIT
SCLK
SDATA
100n
C185
1 2 3 4
1S 2S
K3
307-0415-00
D+ 1
D- 2
ID 3
VBUS
6
NC
5
GND
4
IC32
TPD4S012DRYR
SV_GP7
SV_GP8
SV_GP5
SV_GP6
SV_GP4
12MHz
XTAL3
527-0055-00
22p
C207
1MD
R244 22p
C206
100n C212
100n
C218
10u
C223
100n
C215
100n
C221
100n
C226
100n
C224
100n
C225
100n
C227
100n
C219
100n
C216
/EXT_RST
100n C210
100n C213
U1.8V
10u
C209
SCL SDA
SV_DSD128
SV_DSD
SLD
1S
SLD
2S
SLD
3S
SLD
4S
SHIELD1
246-0038-04
D3.3V
FB12
BLM18HE152SN1D
CP1.8V CP1.8V
100n
C200
100n
C188
100n
C187
100n
C199
100n
C192
100n
C194
100n
C191
D3.3V
100nC211
SV3.3V
AK_INT
/CS_DIR
SCLK
SDATA
SPI_D2U
AK_LRCK
SV_GP0 SV_LOCK SV_GP2 SV_GP3
SPI_D2U
1A 1G 2G 3G
JK5
302-0116-10
D3.3V
100n
C189
1
2
3
LPF1
520-5007-00
470n
C198
FB6
BLM18AG102SN1D
D3.3V
FB8
BLM18AG102SN1D
SV_DATA
SV_BCK
33kR241
SV3.3V
33kR240 33kR242 33kR247 33kR250
33k
R237
D8
SML-E12DWT86ST
33k
R268
D15
33k
R265
D14
SV_DSD SV_DSD128 SV_LOCK
SV_GP0 SV_GP3 SV_GP4 SV_GP5 SV_GP6
FB4 BLM18AG102SN1D
100nC179
FB5
BLM18AG102SN1D
/PowerOff
/EXT_RST
/SHUTDN
SEL1
SEL0
/MUTE
AK_INT
/CP_INT
/CS_DIR
/CS_DIT
CD_MCK
CD_BCK
CD_LRCK
CD_DATA
CD_SPDIF
DGND
SDA
SCL
SCLK_UB
SDATA
SPI_D2U
/CS_CP
SCLK
MGND
M8V
D5V
D3.3V
CXMUTE
uCon & Servo
004-8666-01
1
2
3
4
5
6
7
K7
308-0709-00
AC9V
AC CT
AC9V
AC12V
AC6V
D16
1SS387
D19
1SS387
D18
D4SBS4
D12
D3SBA60
4700u
25V
C220
Q3 2SC5819_
Q4 2SA2069_ -VA
10k
R221
1k
R227
47R225
47R224
47R222
47R223
12k
R204
47R246
27R243
110
R239
10
R238
30k
R275
330
R233
100R229
100R230
330
R232
10k
R254
10k
R260
270
R251
D17
1SS387
D3.3V
24k
R274
1
2
K10
308-0206-00
/PowerOff
100n
C222
D3.3V
I
G
O
IC001
BA33BC0T
+7.5V
100
R226
/SHUTDN
1u
C239
10k
R210
11.289M 47R220
CP2.5V
220
R234
DAC_LRCK_P DAC_LRCK_N DAC_DATA_P DAC_DATA_N
3 4
IC27B
D3.3V
FB9
BLM18AG102SN1D
SPDIF_TO_RX
47R213
47R214
47R219
47R215
100R206
47R216
11 10
IC27E
47k
R261
1
2K4
308-0242-00
100nC235
SV3.3V
SV3.3V
10k
R253
10k
R252
22p
C229
22p
C228
47
R257 100
R258
47
R256
D3.3V
/SHUTDN
/PowerOff
/EXT_RST
/MUTE
AK_INT
/CP_INT
SEL1
SEL0
CD_MCK
CD_BCK
CD_LRCK
CD_DATA
CD_SPDIF
/CS_DIR
/CS_DIT
SCLK
/CS_CP
SPI_D2U
SCLK_UB
SDATA
SCL
SDA
100n
C236
D5V
I
G
O
IC002
BA50BC0T
M8V
100n
C214
+7.5V
SDA
SCL
/EXT_RST
/MUTE
DAC_BCK_P
DAC_MCK_P
DAC_MCK_N
DAC_BCK_N
DAC_LRCK_P
DAC_LRCK_N
DAC_DATA_P
DAC_DATA_N
D3.3V
D5V
+VA
-VA
D5V
+VA
D3.3V
D5V
M8V
A0
1
A1
2
A2
3
GND
4SD 5
SC 6
WP 7
VCC 8
IC35
BR24G128F-3GTE2
I
G
O
IC30
BA80BC0FP
1A 1G 2G 3G
JK6
302-0116-10
100n
C238
75
R272
56
IC27C
98
IC27D 22k
R235
D3.3V
FB11
BLM18AG102SN1D
100
R255
100n
C231
100n
C193
100
R231
2.2k
R236
X3
RN1427
CXMUTE
CXMUTE
SCLK_UB
12
7 14
IC27A
TC74HCU04AF/EL
SCLK
13 12
IC27F
D3.3V
11.289M
AK_BCK
SV_LRCK_DUM 100R211
100R217
100R218
100R212
SV_DATA_DUM
SV_MCK_DUM
SV_BCK_DUM
SV_SPDIF_DUM
SPI_D2U
AK_MCK
AK_DATA
AK_LRCK
SPDIF_TO_RX
SV_MCK
SV_LRCK 47R248
47R249
47R245
CD_LRCK CD_DATA CD_BCK /CP_INT SEL1 SEL0 CD_SPDIF CD_MCK /CS_CP
100n
C190
D3.3V
SV_GP5
SV_GP4
SV_GP3
SV_LOCK
SV_GP2
SV_GP0
SV_GP7
SV_GP8
SV_GP6
VOUT
1
GND
2
VCC
3
IC34
PLR135/T9
/EXT_RST
SV_DSD
SV_DSD128
R
1
AVDD
2
RX1
3
AVSS
4
RX0
5
VCC
6
GND
7
XTI
8
XTO
9
LRCK
10
BCK
11
SDO
12 DAUX 13
MCKO 14
NC 15
UOUT 16
CDTO 17
CDTI 18
CCLK 19
CS 20
INT1 21
INT0 22
PD 23
AVSS 24
IC23
AK4117VF-E2
GND
1
L1p
2
L1n
3
L2p
4
L2n
5
L3p
6
L3n
7
8
VCCIO1
9
GND
10
GND
11
CLK0
12
VCCINT
13
CLK1
14
15
L4p
16
L4n
17
L5p
18
L5n
19
L6p
20
L6n
21
TMS
22
TDI
23
TCK
24
TDO
25
B1p
26
B1n
27
B2p
28
B2n
29
B3p
30
VCCIO1
31
GND
32
B3n
33
B4p
34
B4n
35
B5p
36
B5n
37 38
B6p
39
B6n
40
B7p
41
B7n
42
B8p/DEV_OE
43
B8n/DEV_CLRn
44
VCCIO1
45
GND
46
B9p
47
B9n
48 49
B10p
50
B10n 51
52
R7n 53
R7p 54
R6n 55
R6p 56
R5n 57
R5p 58
VCCIO2 59
GND 60
61
CLK2 62
VCCINT 63
CLK3 64
GND 65
R4n 66
R4p 67
R3n 68
R3p 69
70
R2n 71
R2p 72
R1n 73
R1p 74
T10n 75
T10p 76
T9n 77 T9p 78
GND 79
VCCIO2 80
T8n 81 T8p 82 T7n 83 T7p 84 T6n 85 T6p 86 T5n 87 T5p 88 T4n 89 T4p 90
91
T3n 92
GND 93
VCCIO2 94
T3p 95 T2n 96 T2p 97 T1n 98 T1p 99
100
IC26
5M160ZT100C5N
CP2.5V
CP1.8V
1u
C203
1
2
K5
308-0206-00
1
2
3
4
5
6
K2
308-0606-00
D5 CRG03
D6 CRG03
D4 CRG03
D7 CRG03
FB10
BLM18AG102SN1D
D3.3V
SPD_IN
SPD_IN
D13 CRG03
27
R195
100p
C240
100p
C241
330
R276
D3.3V
TEST
GND
1VCC 2VIN 3
IC25
PLT133/T9B
VI
1
GND
2
CE
3NC 4
VO 5
IC29
XC6501B181MR-G
VI
1
GND
2
CE
3NC 4
VO 5
IC28
XC6501B251MR-G
Power management
Ass'y K2
Power supply Ass'y K2
JTAG Programmer
SV_LRCK
SV_MCK
SV_BCK
SCLK
SV_DATA
47u
25V
C208
47u
25V
C230
15u
50V
C197
820u
25V
C204
820u
25V
C205
4700u
25V
C233
47u 25V
C169
47u 25V
C170
47u
25V
C171
47u
25V
C186
47u
25V
C234
560u
25V
C201
560u
25V
C202
10u
50V
C195
10u
50V
C196
10u
50V
C217
10u
50V
C232
10u
50V
C237
DAC_MCK_P DAC_MCK_N DAC_BCK_N DAC_BCK_P
169D
R278
169D
R280
120D
R282
120D
R279
120D
R281
120D
R277
- 19 -
DAC ASS'Y (725-0066-00)
