ACESEE IMX222 User guide

4 Parameter Description
2 Product Notes
1 Unpacking Inspection
｜Accessories list
1. Once receive the product, the user should open the
outer packing box to check the appearance for obvious
damage.
2. Please referring to the following list to check whether
the accessories are complete.
｜ External camera structure diagram
3 Main Features
5 Camera Structure
Accessory name Number
IP camera 1
CD（users guide）1
Quick Operation Guide 1
Thank you for buying our IP camera, please read
the following instructions carefully to learn the
related operation.
1. Before using the camera，please read this
guide book carefully and make sure the power
supply is normal.
2. Users should follow the manufacturer's instruc-
tions to install device professionally and must
not dismantle the equipment without permission.
3. To prevent the sensor pull light phenomenon,
prohibit putting the lens under bright light for a
long time.
4. If the lens is dirty or foggy, please use a dry soft
cloth to clean it.
5. The equipment must not be installed under the
air door of air conditioner , otherwise the lens
will become blurry and condenses into moisture.
6. When install, repair or clean the equipment,
please make sure the power has been turned
off.
7. Stay away from high temperature and heat
source environment, pay attention to ventilation.
8. To avoid damage and electrical shock, non-
professionals are forbidden to dismantle the
equipment.
9. Prohibit putting this equipment to work in strong
magnetic field and laser beam environment.
10. If there is lightning during installation, please
take grounding lightning protection measures.
11. Damages to the machine and all other
economic losses caused by human are at
your own risk.
Mind you respected user, important
operations and maintenance (repair)
guide are described in the attached
product instruction.
Mind you respected user, uninsulated
"dangerous voltage" exists, please be
aware of electric shock.
Reminders:
• Power supply must pass safety certification ,Its
output voltage, current, voltage polarity and oper-
ating temper ature must match requirement of this
equipment.
• Please install lightning protection devices or cut off
the power in thunder and lightning conditions.
• To capture high-quality video and pictures, please
make sure the network connection is stable and
smooth.
1. Ultra-low illumination and high-performance real-time
screen, support ABLC image effect.
2. Support WEB configuration, and IE network Monitoring
3. Support dual-stream.
4. Support OSD, color, brightness, saturation and digital
zoom settings settings.
5. Support real-time video transmission, video motion
detection and privacy masking.
6. Support remote monitoring, ONVIF2.4 protocol and
IR-CUT switch.
7. Support P2P network platform.
Illustration
The following structure diagram is used as an example
for the different appearances of different models.
Sequence NO. Interface Functional description
1Power connector 12V DC input power
2Network interface Network data transmission
3Power connector（for
stand-by power）12V DC input power
4Network interface Network data transmission ,
12V DC input power
1. Input interface
2. Device connection
PC
IMX222 + A5S66
HD IP CAMERA
Quick Operation Guide
Thank you for using our product, please read this manual
carefully before use.
Please refer to the complete User manual for more information
from the CD.
Type1
Type2
Name IMX222+A5S66
Description A 2MP IP CAMERA
Sensor type 1/2.8" 2.43 Megapixel CMOS Image sensor.
Minimum Illumination 0.5 lux
S/N Ratio >50db
Shutter 1—1/10000s(adjustable)
Lens 2.8mm/3.6mm/4mm/6mm/8mm/2.8-12mm
(adjustable),Lens optional
Lens interface type C/CS
WDR WDR
Digital noise 3D DNR
Day/Night ICR-infrared filter
Video Compression H.264
Bit Rate 64-12000Kbps
Max image size 1920×1080
Frame Rate 50Hz:25fps(1920×1080)
60Hz:30fps(1920×1080)
Image setting Brightness, contrast, saturation, sharpness
can be adjusted
Backlight Compensa-
tion Support
Storage function FTP、Local、NVR、SMTP
Onvif Onvif 2.4
Intelligent alarm Motion detection、Privacy
Protocol TCP/IP、HTTP、DHCP、FTP、DNS、
DDNS、RTSP、NTP、SMTP
General function Single/Dual/Tri-Stream/Mirror
Communication
interface RJ45（10M/100M）Adaptive Ethernet port
Temperature -20℃～55℃
Humidity 0%-90%RH Without Condensation
Power DC12V±5% / PoE(802.3af)
Size 38×38mm

2. Enter URL : http://192.168.1.168
6Quick Configuration Tool
7 IE Connection
1.Install Client Software
Find out the document“IP Search.exe”,
make a copy in the computer and double
click to open it.
As shown in the picture:
2. Change the Camera’s IP Settings
Make sure IP camera is connected, and
click Search to search the IP camera, find
it, click it, and then change the IP settings.
Finally, click Modify IP to confirm the change.
As shown in the picture:
9 Mobile Client Connection
8 Computer Client Connection
1. Install Mobile Monitoring Software
Enter URL on your phone: www.danale.com,
download and install mobile monitoring software
“Danale”.
2. Add Device
Click “Add Device ”, enter device name, serial number
and password (You can directly scan the QR code to
get the device serial number ).
4
5
6
1
23
※ Search to add device: Configuration Management→Device
Management→ Add Device→ Online Searching→ Query
→ Select Device
1. Install Computer Client Software CMS
Find out the document “HeroSpeedCMS.exe”,
make a copy in your computer and double click to
install it .
2.Search Add Device
Click “Search Device” to search for device in LAN,
or add device manually.
1
23
※ Add device manually: Configuration→Device Management
→Add Manually
3. Install control
An OCX control is needed in your computer for
the first IP camera installation, click the pop up
tip "OK" and install OCX control.
As shown in the picture:
4. User login
Refresh the website and enter correct user name
and password.
Both the default user name and password are
admin.
1.Browser settings
Open your IE browser ，Click Tool→ Internet Op-
tion→ Security→ Customized Level→ Active X
Control and Plug-in, select all "Enable".
