Acson ACM15E User manual

Ceiling Convertible
Split Systems
ACM-E_(i)
ACM15E/ER
ACM20E/ER
ACM25E/ER
ACM28E/ER
ACM35E/ER
ACM40E/ER
A5CM15E/ER
A5CM20E/ER
A5CM25E/ER
A5CM28E/ER
A5CM35E/ER
A5CM40E/ER
Models:

ACM-E_(i)
Table of Contents
Table of Contents
Nomenclature......................................................................................................................1
Indoor Unit .....................................................................................................................1
Outdoor Unit ..................................................................................................................2
Product Line-Up.............................................................................................................3
Features...............................................................................................................................9
Application Information .................................................................................................. 10
Operating Range ........................................................................................................ 10
Refrigerant Circuit Diagram .........................................................................................11
Controller .................................................................................................................... 20
Installation................................................................................................................... 22
Sound Data....................................................................................................................... 36
Sound Pressure Level ................................................................................................ 36
NC Curve.................................................................................................................... 37
Engineering & Physical Data.......................................................................................... 40
General Data .............................................................................................................. 40
Component Data......................................................................................................... 62
Safety Device.............................................................................................................. 84
Performance Data............................................................................................................ 92
Calculation Steps........................................................................................................ 92
Performance Table...................................................................................................... 98
Outline and Dimension ................................................................................................. 127
Electrical Data................................................................................................................ 130
Wiring Diagram .............................................................................................................. 142
Service and Maintenance.............................................................................................. 160
Troubleshooting ............................................................................................................ 162
Exploded View and Part List ........................................................................................ 169

ACM-E_(i)
1
Nomenclature
Model Type
“ “ : Omitted if cooling only
R : Heatpump
Series
E : E Series
Capacity Index
15 : 15,000 Btu/h
Model Name
CM : Ceiling Convertible
Brand
A : ACSON
A 5 CM 15 E R
Nomenclature
Indoor unit
Nomenclature
Refrigerant
“ “ : Omitted if R22
4 : R407C
5 : R410A

ACM-E_(i)
2
Nomenclature
A 5 LC 15 C R
Series
C : C Series
Capacity Index
15 : 15,000 Btu/h
Model Name
LC : Single Split Condensing Unit
Brand
A : ACSON
Outdoor unit
Refrigerant
“ “ : Omitted if R22
4 : R407C
5 : R410A
Model Type
“ “ : Omitted if cooling only
R : Heatpump

ACM-E_(i)
3
Nomenclature
Product Line Up
Indoor unit
ACM-E
L2 G18 Bare Cap Tube W/o Cap Tube CE W/ out Marking Convertible Ionizer
15EACHIAX XXXXXX
20EACHIAX XXXXXX
25EACHIAX XXXXXX
28EACHIAX XXXXXX
35EACHIAX XXXXXX
40EACHIAX XXXXXX
15ER ACHIAX XXXXXX
20ER ACHIAX XXXXXX
25ER ACHIAX XXXXXX
28ER ACHIAX XXXXXX
35ER ACHIAX XXXXXX
40ER ACHIAX XXXXXX
COOLING ONLYHEATPUMP
ACM
Nomenclature
PCB Handset
Classification
Refrigerant Control Marking Air Purification Fin Others

ACM-E_(i)
4
Nomenclature
Indoor unit
A5CM-E
L2 G18 Bare W/o Cap Tube CE W/ out Marking Convertible Ionizer
15EACHIAX XXXXXX
20EACHIAX XXXXXX
25EACHIAX XXXXXX
28EACHIAX XXXXXX
35EACHIAX XXXXXX
40EACHIAX XXXXXX
15ER ACHIAX XXXXXX
20ER ACHIAX XXXXXX
25ER ACHIAX XXXXXX
28ER ACHIAX XXXXXX
35ER ACHIAX XXXXXX
40ER ACHIAX XXXXXX
COOLING ONLYHEATPUMP
Classification
A5CM
Nomenclature
PCB Handset Air Purification Fin Marking Refrigerant Control Others

ACM-E_(i)
5
Nomenclature
Outdoor unit
ALC
Cap Tube TXV Gold Coated Bare Scroll/ Digital Scroll Rotary/ Fixed Scroll Contactor High Pressure Switch Low Pressure Switch Phase Sequencer CE High Ambient Kit Drain Elbow
ACPODX XX X
ACPIDX XX X
ACPODX XX X
ACPIDX XX X
ACPBDX XXXX
ACPODX XX X
ACPIDX XX X
ACPHBX XX XX
ACPBDX XXXX
ACPODX XX X
ACPIDX XX X
ACPBDX XXXX
ACPHBX XX XX
ACHOBXXX
ACHIBX XX
ACHBBXXX X
AFGE XX XXXX
AFGG XXXXXX
FFGE XX XXXXX
FFGG XXXXXXX
AFGJ XXXXXXX
AFGE XX XXXX
AFGG XXXXXX
AFGE XX XXXX
AFGG XXXXXX
FFGE XX XXXXX
FFGF XX XXXXXX
FFGG XXXXXXX
FFGL XXXXXXX
AUCOAXXXXX X
FUDOAXXXXX X
COOLING ONLY
15C
35C
20C
25C
Compressor Others
Classification
ALC
Nomenclature
Refrigerant Control Fin Marking Safety Devices
30C
28C
40C
18C

ACM-E_(i)
6
Nomenclature
Outdoor unit
ALC
Cap Tube TXV Gold Coated Bare Scroll/ Digital Scroll Rotary/ Fixed Scroll Contactor High Pressure Switch Low Pressure Switch Phase Sequencer CE High Ambient Kit Drain Elbow
ACPOAX XX X
ACPIAX XX X
ACPODX XX X
ACPIDX XX X
ACPODX XX X
ACPIDX XX X
ACPHBX XX XX
ACPODX XX X
ACPIDX XX X
ACPHBX XX XX
ACHOBXXX
ACHIBX XX
AFFB XX XX XX XX
AFFC XX XX XX XXX
AFFD XXX XXXXX
FFFB XX XX XX XX X
FFFD XXX XXXXXX
AFFB XX XX XX XX
AFFD XXX XXXXX
AFFB XX XX XX XX
AFFD XXX XXXXX
FFFB XX XX XX XX X
FFFD XXX XXXXXX
HEATPUMP
20CR
15CR
18CR
35CR
Compressor Others
Classification
ALC
Nomenclature
Refrigerant Control Fin Marking Safety Devices
40CR
30CR
25CR
28CR

ACM-E_(i)
7
Nomenclature
Outdoor unit
A5LC
Cap Tube TXV Gold Coated Bare Scroll/ Digital Scroll Rotary/ Fixed Scroll Contactor High Pressure Switch Low Pressure Switch Phase Sequencer CE Drain Elbow
ACPOCX XX X
ACPICX XX X
ACPICX XX X
ACPOCX XX X
FCPOCX XXXXX
ACPICX XX X
ACPOCX XX X
FCPOCX XXXXX
ACPOAX XX X
ACPIAX XX X
FCPOAX XXXXX
ACCOBX XX XXXX
ACCGBX XXXXXX
FCCOBX XX XXXXX
FCCGBX XXXXXXX
FCCGBX XXXXXXX
FCCOBX XX XXXXX
ACCOBX XX XXXX
ACCGBX XXXXXX
Others
COOLING ONLY
20C
25C
28C
15C
35C
40C
Classification
A5LC
Nomenclature
Refrigerant Control Fin Marking Safety Devices Compressor

ACM-E_(i)
8
Nomenclature
Outdoor unit
A5LC
Cap Tube TXV Gold Coated Bare Scroll/ Digital Scroll Rotary/ Fixed Scroll Contactor High Pressure Switch Low Pressure Switch Phase Sequencer CE Drain Elbow
ACPOCX XX X
ACPICX XX X
ACPSD XX XX X
ACPICX XX X
ACPOCX XX X
FCPOCX XXXXX
ACPSD XX XX X
ACPICX XX X
ACPOCX XX X
FCPOCX XXXXX
ACPSD XX XX X
ACPOAX XX X
ACPIAX XX X
FCPOAX XXXXX
ACPSD XX XX X
ACCOBX XX XXXX
ACCGBX XXXXXX
FCCOBX XX XXXXX
FCCGBX XXXXXXX
ACCGBX XXXXXX
ACCOBX XX XXXX
FCCOBX XX XXXXX
FCCGBX XXXXXXX
Others
HEATPUMP
Classification
A5LC
Nomenclature
Refrigerant Control Fin Marking Safety Devices Compressor
40CR
25CR
28CR
35CR
20CR
15CR

ACM-E_(i)
9
Features
Features
Ceiling and Floor Installation Option
The unit is uniquely designed with the option to install either below the ceiling or mounted at low wall position
without any modication needed. Furthermore, the unit is design adds a touch of elegance to suit any interior
design requirement.
Negative Ion Generator
ACSON emphasis on provide indoor air quality solution. Therefore, the negative ionizer technology is being
brought in as an essential part of the unit. The negative ion generator increases the amount of negative ion in
the air-conditioning area, creating a refreshing and healthy living environment.
Easy Installation
The ceiling convertible split unit is easily installed with a very economical and space saving installation. No
need renovation on wall or ceiling for installation. This easy to install and ready to operate unit ensure rapid
and low installation cost.
Better Serviceability
The washable lter can be easily access by just pulling down the intake grill. During servicing or repairing, only
the bottom panel need to removed in order to access
• Fan Motor
• Blower
• Wiring Connection
• Control Box
• Piping Connection
Wireless Remote Controller
The standard unit comes with a simple, user friendly and stylish wireless controller. The G18 controller offers
many features:
• The compact LCD transmitter is able to operate the indoor unit within 8 meters of distance.
• Fan speed can be set at low/medium/high or automatic.
• Sleep mode auto control will gradually increase or decrease the set temperature to provide a comfortable
surrounding for sleeping.
• The real time timer allows the unit to be switched ON and OFF automatically based on user settings.
• Ionizer or non-thermal plasma is available to create better air quality.
• Turbo mode function is available to enables the required set temperature to be achieved in a short
time.
• Personalized Setting allows user to preset and store 2 groups of personal settings (including timer
setting) in the handset.
Self Diagnosis
The microprocessor provides the possibility to detect and diagnose any fault or malfunction that occurs in the
system. The error will be reected by the blinking of the LED lights.
Auto Random Restart
Auto random restart function allows the unit to automatic restart as the last setting condition when the power
supply is resumed after power failure. However, the compressor will restart randomly if more than one unit is
installed and sharing the same phase of power.

ACM-E_(i)
10
Application Information
Ensure the operating temperature is in allowable range.
Cooling only
Cooling
Heatpump
Cooling Heating
Application Information
Operating Range
Outdoor temp. (°CDB)
Indoor temp. (°CWB)
-5
19
35
15
46
24
54
Standard
point
High ambient
unit
Low ambient kit
Indoor temp. (°CDB)
Outdoor temp. (°CWB)
-9
15 21
6
27
18
Standard
point
Outdoor temp. (°CDB)
Indoor temp. (°CWB)
-5
19
35
15
46
24
54
Standard
point
High ambient
unit
Low ambient kit
Standard operating range.
With High ambient unit. (Optional item)
Please refer to local dealer for unit of this specification.
With Low ambient kit. (Optional item)
Please refer to local dealer for unit of this specification.
Note:
Caution :
The use of your air conditioner
outside the range of working
temperature and humidity can
result in serious failure.

ACM-E_(i)
11
Application Information
Refrigerant Circuit Diagram
Model : ACM/A5CM15E - ALC/A5LC15C ACM20E - ALC18C
ACM/A5CM20E - ALC/A5LC20C A5CM25E - A5LC25C
Model : ACM25E - ALC25C
A5CM28E - A5LC28C

ACM-E_(i)
12
Application Information
Model : ACM28E - ALC28C
Model : ACM28E - ALC30C

ACM-E_(i)
13
Application Information
Model : A5CM28E - A5LC35C
Model: ACM35E – ALC35C
ACM40E – ALC40C
70034 049181

ACM-E_(i)
14
Application Information
Model: A5CM35E – A5LC35C
A5CM35E – A5LC40C
Model : A5CM40E – A5LC40C
70034 104607
70034097007

ACM-E_(i)
15
Application Information
Model : ACM/A5CM20ER - ALC/A5LC20CR
A5CM25ER - A5LC25CR
Model : ACM/A5CM15ER - ALC/A5LC15CR

ACM-E_(i)
16
Application Information
Model : ACM25ER - ALC25CR
ACM28ER - ALC28CR
Model : A5CM28ER - A5LC28CR

ACM-E_(i)
17
Application Information
Model : ACM28ER - ALC30CR
Model : A5CM28ER - A5LC35CR

ACM-E_(i)
18
Application Information
Model : ACM35ER – ALC35CR
ACM40ER – ALC40CR
70034095246
Model : A5CM35ER – A5LC35CR
A5CM35ER – A5LC40CR
70034104606
