adapt GR29 User manual
Wireless Bluetooth
GPS Receiver
User’s Manual
page 2
Contents
Disciption 3
Product Features 3
2.Specication 4
2.1Spec 4
2.2PositioningAccuracy 4
2.3Acquisitiontime 4
2.4input&output 4
2.5Powersupport 4
2.6 Dynamic condition 5
2.7 Dimension, Weight 5
2.8 Other function 5
3. LED indcator 6
4.Packagecontents 7
5. User guide 7
5.1. Charging 7
5.2. Power on 7
4.3DriverandTestsoftware 7
Discription
TheGR29isaBluetoothGPSReceiverthatcanbeusedindependently.Not
onlydoesitcantransferdatawithPDA,orNotebookviaBluetooth,butalso
itcantransferdatathroughUSBcablewiththosedeviceswithoutBluetooth.
Itiscompact,stylish,andportable,evencanbeworeonthekeychain,
integratedtherechargeablepolymerLithium-ionbatterymadetheproduct
sensitivitywhilelowpowerconsumer.Thereare3LEDsindicatethe
Bluetooth,GPSinformation,andbatteryinformationrespectively,enable
therunningstatusmonitoredclearly.
Product Features
Compactsizethatevenkeychainportable.
Highsensitivity,powerfulGPSchipset,fastacquisitionfor16-channel.
Built-inWASS/EGNOSDemodulator.
Built-inUSBdriver,thatcantransferdatavianormalUSBcable;
SupportBluetoothSPPprole.
SupportNMEA0183v2.3,9600bps.
Built-instable,highperformancepolymerlithiumionbattery,lowpower
consumerforatleast8hoursoperation.
page 3
page4
Specication
2.1 Spec
Frequency:1575.42MHz
Channel:acquisitionandtrackupto16satellitessignal
Receiver:L1,C/Acode
Update rate: 1Hz
Minimumsignaltracked:-158dBm
2.2 Positioning Accuracy:
2.5m CEP accuracy
<2mCEPaccuracy(DGPS,WAASorEGNOS)
Velocity:0.1meter/sec
2.3 Acquisition time:
Hotstart:4sec.
Warmstart:34sec.
Coldstart:42sec.
2.4 Input & output:
Bluetoothprotocol:SerialPortProle
CSRBC04,2.0
Baudrate:9600bps
Distance:Morethan10meters(noobstacle)
USBdriverfullspeedUSB2.0(USB1.0/1.1Compatible)
NMEA0183v2.3
2.5 Power support:
Input:4.7~5.2V
Built-inpolymerLithium-ionbatterywithcapacityof
520mA/hforatleast8hoursoperation
page 5
2.6 Dynamic condition
Altitude:18,000metermax.
Velocity:515meter/sec.max.
Acceleration:4Gmax.
Jerk:20meter/sec.
2.7 Dimension, Weight
Dimension:65(L)×28(W)×15(H)mm
Weight:30g
OperationTemperature:-10˚C-+60˚C
StoreTemperature:-20˚C-+60˚C
Operationhumidity:5%to95%nocondensing
2.8 Other function
Switch:Mechanicalslideswitcher
Antenna:Built-inGPSantenna
LEDFunction:Bluetooth,GPSpositioning,Batterystatus
Ring
GPSPower
Bluetooth
indicator (uptodown)
switcher
USBPort
page 6
Status Color Indicator Information
On Searching
bluetoothdevice
Blue Blink
interval 1/sec Waitingfordata
transferring
1/sec Connectedand
start to transfer
data
Red On Lowpower
Green On Charging
N/A Off Working
GPS Yellow On Positioning
Off Positioned
LED indicator
Power switch
a.Poweron:YellowLEDandblueLEDon.
b.Poweroff:YellowLEDandblueLEDoff.
USBPort
MiniUSB5Pinsfemaleconnector.
page7
Package contents
• OneGR29Bluetoothreceiver
• OnesetMiniCarCharger
• OneMiniUSBcable
• OnedriverCD
• Oneusermanual
User Guide
1. Charging
t’srecommendedtochargethebatteryfortherstusing.
Whenthebatteryisfull,thepowerLEDwillbeoff.
ItalsocanbechargedwithcarchargerorUSBcable.
2. Power on
2.1Switchon,yellowLEDandblueLEDon,GPSstarttopositioning;
whenitgottheposition,theyellowLEDwillstarttoblink.
2.2Datatransferringviabluetooth:BlueLEDonindicatesit’ssearching
Bluetoothdevice.TheIDofthisproductis‘SCBT’,it’snotnecessaryto
matchitwithotherdevice,ifpasswordrequired,pleasetype‘0000’.
Afteritisconnected,theblueLEDblinkwithintervalof1time/sec
indicates data transferring.
2.3DatatransferringviaUSB:Theproductwillbeallocatedtoaport
numberautomaticallywhenconnectedtothecomputer
(pleaseinstallthedriverrst),whichusedtocommunicatewiththe
computer.
3.DriverandTestsoftware
ThedriverandtestsoftwareareplacedontheattachedCD.Forthe
detailspleaseseetheReadme.txt.
page8
www.adapt-mobile.com
