ADC EcoWash EWH-25 M Operating instructions

USER AND MAINTENANCE MANUAL
MANUAL DE USO Y MANTENIMIENTO
08
Otoño
EWH-25 M / EWH-30 M / EWH-40 M / EWH-60 M
EWH-25 MR / EWH-30 MR / EWH-40 MR / EWH-60 MR
EWH-25 MC / EWH-30 MC / EWH-40 MC / EWH-60 MC
EWR-25 M / EWR-30 M / EWR-40 M / EWR-60 M
EWR-25 MR / EWR-30 MR / EWR-40 MR / EWR-60 MR
EWR-25 MC / EWR-30 MC / EWR-40 MC / EWR-60 MC
EWS-25 M / EWS-30 M / EWS-40 M / EWS-60 M / EWS-80 M
EWS-25 MR / EWS-30 MR / EWS-40 MR / EWS-60 MR / EWS-80 MR
EWS-25 MC / EWS-30 MC / EWS-40 MC / EWS-60 MC / EWS-80 MC
P628211000-08
12001399

CONTENTS
CONTENTS...................................................................................................................................................................1
1INTRODUCTION .......................................................................................................................................................2
IMPORTANT INSTRUCTIONS REGARDING SAFETY AND USE..............................................................................3
2USE..........................................................................................................................................................................10
2.1 Controls..............................................................................................................................................................10
2.2 Programs............................................................................................................................................................10
3OPL..........................................................................................................................................................................11
3.1 Operation............................................................................................................................................................12
3.1.1 Running a program......................................................................................................................................12
3.1.2 Program end................................................................................................................................................12
4COIN........................................................................................................................................................................13
5COIN/CP MODE ......................................................................................................................................................14
5.1 Operation............................................................................................................................................................14
5.2 Pay centre/card..................................................................................................................................................14
5.3 COIN ..................................................................................................................................................................14
5.4 Operating modes................................................................................................................................................15
5.4.1 OPL Mode ...................................................................................................................................................15
5.4.2 Coin Mode...................................................................................................................................................15
5.4.3 CP Mode .....................................................................................................................................................16
5.4.4 Credit Mode.................................................................................................................................................16
5.5 Configuration Menu............................................................................................................................................16
5.5.1 PRIC (Price) ................................................................................................................................................16
5.5.2 LEuL (Configuration of levels).....................................................................................................................16
5.5.3 StCL (Configuration of standard cycles) .....................................................................................................16
5.5.4 ECL (Configuration of extended cycles)......................................................................................................17
5.5.5 P7 (Configuration of the OPL program) ......................................................................................................17
5.5.6 Cur (Currency).............................................................................................................................................17
5.5.7 TiMr (Wash time remaining)........................................................................................................................18
5.5.8 PAY (Operating mode)................................................................................................................................18
5.5.9 AVAn (Advance cycle).................................................................................................................................18
5.5.10 StOP (Thermal stop switch) ....................................................................................................................18
5.5.11 Grd (Change between ºF & ºC)...............................................................................................................18
5.5.12 Beep (Acoustic signal).............................................................................................................................18
5.6 Maintenance Menu.............................................................................................................................................19
5.6.1 In/Out (Inputs/Outputs)................................................................................................................................19
5.6.2 Std (Statistics) .............................................................................................................................................19
5.6.3 Def...............................................................................................................................................................19
5.6.4 Last..............................................................................................................................................................19
5.7 Menu Mod ..........................................................................................................................................................19
5.8 Machine operating..............................................................................................................................................19
6MAINTENANCE.......................................................................................................................................................20
6.1 Electrical and mechanical troubleshooting.........................................................................................................20
6.2 Error messages..................................................................................................................................................20

2
1INTRODUCTION
Dear customer,
Thank you for the confidence you have placed in our product. We hope it meets your needs.
The guarantee does not cover damage to glass components, or consumables (seals, bulbs, etc.) nor damage to
insulation material or damage due to the incorrect installation of the appliance, or to inappropriate use, inadequate
maintenance or poor repair processes.
This appliance is subject to changes and modifications for its technical progress.
Retain This Manual In A Safe Place For Future Reference
American Dryer Corporation products embody advanced concepts in engineering, design, and safety. If this product
is properly maintained, it will provide many years of safe, efficient, and trouble free operation.
ONLY qualified technicians should service this equipment.
OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation manual included
with the dryer.
The following “FOR YOUR SAFETY” caution must be posted near the dryer in a prominent location.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
POUR VOTRE SÉCURITÉ
Ne pas entreposer ni utiliser d’essence ni d’autres vapeurs ou liquides inflammables à proximité de cet appareil ou de
tout autre appareil.
We have tried to make this manual as complete as possible and hope you will find it useful. ADC reserves the right to
make changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to
change or discontinue models. The illustrations included in this manual may not depict your particular dryer exactly.
IMPORTANT
For your convenience, log the following information:
DATE OF PURCHASE__________________________________________ MODEL NO. ______________________
RESELLER’S NAME _____________________________________________________________________________
Serial Number(s) ________________________________________________________________________________
______________________________________________________________________________________________
______________________________________________________________________________________________
Replacement parts can be obtained from your reseller or the ADC factory. When ordering replacement parts from the
factory, you can FAX your order to ADC at [phone] or telephone your order directly to the ADC Parts
Department at [phone]. Please specify the dryer model number and serial number in addition to the
description and part number, so that your order is processed accurately and promptly.

3
IMPORTANT INSTRUCTIONS REGARDING SAFETY AND USE
WARNING: To reduce the risk of electrical shocks
or injury when using the appliance, the basic
precautions should be observed, including the
following:
1- READ all the instructions prior to using the
appliance and KEEP THEM in an easily
accessible place for reference in the event of
doubt.
2- Do NOT wash clothes which have been
previously treated, washed, soaked or stained
with petrol, dry cleaning solvents, or other
inflammable or explosive substances, as these
give off vapours which may catch fire or
explode.
3- Do NOT add petrol, dry cleaning solvents or
other inflammable substances to the washing
water. These substances give off vapours
which could catch fire or explode.
4- In some conditions, hydrogen gas may be
produced in a hot water system which has not
been used for more than two weeks. Hydrogen
gas is explosive. If the hot water system has
not been used for a while, before using the
washing machine turn on all the hot water taps
and let the water run for a few minutes. This
will release any accumulated hydrogen gas.
As the gas is inflammable, do not smoke or
use open flames during this operation.
5- Do NOT allow children to play in or on the
appliance. Children should be strictly
supervised when in the vicinity of a machine
which is operating.
6- Remove the door from the appliance before
disposal or before leaving it out of service.
7- DO NOT TRY TO OPEN THE DOOR if the
drum is moving.
8- Washer MUST be installed in a location/
environment, which the ambient temperature
remains between 40° F (4.44° C) and 130° F
(54.44° C).
9- Do NOT try to force the controls.
10-Washer must not be installed or stored in an
area where it will be exposed to water or
weather.
11-Do not repair or replace parts of the
appliance or carry out any servicing unless
recommended to do so in the User Instruction
Manual. Make sure that you fully understand
the instructions and have the necessary skills
to carry out the operations described.
12-Do NOT remove any safety device or modify
any components in the washing machine. DO
NOT INSTALL components not belonging to
the machine in the appliance.
13-Failure to comply with any of the instructions
given in the Instruction Manual may result in
personal injury to the user. It is no possible to
provide for all possible situations and
contingencies with warnings about risk and
hazards. Therefore, any person involved in the
transportation, installation, use or maintenance
of the machine should always employ
common sense, caution and care.
14-Do NOT use the machine unless all the covers
and guards are correctly fitted and secured.
15-The distributor (vendor) MUST correctly
instruct the user during commissioning.
16-Pour the correct doses of detergent, fabric
softener and lay into the dispenser drawer, as
indicated by the manufacturer. Heed tips
concerning the treatment of different materials
given by the manufacturers.
17-Daily remove any traces of detergent or liquids
from the dispenser drawer. Never use
powdered or abrasive detergents for cleaning;
use only water and soap.
18-Clean the water inlet filters and the external
dispenser conducts once a month.
19-Never clean the exterior by water injection;
functional parts of the machine could damage.
20-If the washing machine is to be idle for long
periods, apply a coat of Vaseline oil to all its
stainless steel surfaces.
21-An annual general revision is recommended.

4
GROUP A - High Spin Floating Washing Machines
EWH-25
EWH-30
EWH-40
EWH-60
DC (Drum capacity)
litres
100
130
180
250
CM (Maximum load)
Lb
Kg
25
10
30
13
40
18
60
25
SP1 (Wash speed)
r.p.m.
50
50
47
45
SP2 (low spin)
rpm
500
500
475
450
SP3 (High spin)
r.p.m.
1000
1000
950
900
SP4 (Delicates spin)
rpm
800
800
750
700
LV1 (Minimum level)
mm
70
75
85
95
LV2 (Low level)
mm
90
105
115
125
LV3 (Medium level)
mm
110
135
145
155
LV4 (Highl level)
mm
130
165
175
185
LV5 (Maximum level)
mm
180
225
240
260
Minimum safety level
mm
40
40
40
20
GROUP B - Fast Spin Rigid Washing Machines
EWR-25
EWR-30
EWR-40
EWR-60
DC (Drum capacity)
litres
100
130
180
250
CM (Maximum load)
Lb
Kg
25
10
30
13
40
18
60
25
SP1 (Wash speed)
r.p.m.
50
50
47
45
SP2 (low spin)
rpm
500
500
475
450
SP3 (High spin)
r.p.m.
820
760
760
714
SP4 (Delicates spin)
rpm
820
760
760
714
LV1 (Minimum level)
mm
70
75
85
95
LV2 (Low level)
mm
90
105
115
125
LV3 (Medium level)
mm
110
135
145
155
LV4 (Highl level)
mm
130
165
175
185
LV5 (Maximum level)
mm
180
225
240
260
Minimum safety level
mm
40
40
40
20
GROUP C - Standard Spin Rigid Washing Machines
EWS-25
EWS-30
EWS-40
EWS-60
EWS-80
DC (Drum capacity)
litres
100
130
180
250
350
CM (Maximum load)
Lb
Kg
25
10
30
13
40
18
60
25
80
35
SP1 (Wash speed)
r.p.m.
53
53
50
48
45
SP2 (low spin)
rpm
538
538
507
483
458
SP3 (High spin)
r.p.m.
538
538
507
483
458
SP4 (Delicates spin)
rpm
538
538
507
483
458
LV1 (Minimum level)
mm
75
75
85
95
125
LV2 (Low level)
mm
105
105
115
125
155
LV3 (Medium level)
mm
135
135
145
155
175
LV4 (Highl level)
mm
165
165
175
185
205
LV5 (Maximum level)
mm
225
225
240
260
290
Minimum safety level
mm
40
40
40
20
20

5
SOFTENER
BLEACH
PREWASH
WASH
TRAY
CONTROLS

6
P1 - COLD
PHASE
Pre-wash
Wash
Rinse1
Rinse2
Short spin
Final rinse
Long spin
STOP PROGRAM
NO
NO
NO
NO
NO
NO
NO
SPEED
50rpm
50rpm
50rpm
50rpm
500rpm
50rpm
1000rpm
RHYTHM
12/3
12/3
12/3
12/3
---
12/3
---
HOT WATER INPUT
NO
NO
NO
NO
---
NO
---
COLD WATER INPUT
YES
YES
YES
YES
---
YES
---
DECALCIFIED WATER INPUT
NO
NO
NO
NO
---
NO
---
WATER LEVEL
MINIMUM
MINIMUM
MEDIUM
MEDIUM
---
MEDIUM
---
MOVEMENT DURING FILLING
YES
YES
YES
YES
---
YES
---
WATER TEMPERATURE
COLD
COLD
COLD
COLD
---
COLD
---
THERMAL STOP
NO
NO
---
---
---
---
---
TIME(min)
0
10
0
2
2
2
6
OPTIMUM DISTRIBUTION
---
---
---
---
YES
---
YES
MOVEMENT DURING DRAINING
YES
YES
YES
YES
---
YES
---
DISPENSER 1
T60/R0
T60/R0
0
0
---
0
---
DISPENSER 2
0
T60/R0
0
0
---
0
---
DISPENSER 3
0
T60/R0
0
0
---
0
---
DISPENSER 4
0
0
0
0
---
T60/R0
---
DISPENSER 5
0
0
0
0
---
T60/R0
---
DISPENSER 6
0
0
0
0
---
0
---
DISPENSER 7
0
0
0
0
---
0
---
P2 - WARM
PHASE
Pre-wash
Wash
Rinse1
Rinse2
Short spin
Final rinse
Long spin
STOP PROGRAM
NO
NO
NO
NO
NO
NO
NO
SPEED
50rpm
50rpm
50rpm
50rpm
500rpm
50rpm
1000rpm
RHYTHM
12/3
12/3
12/3
12/3
---
12/3
---
HOT WATER INPUT
NO
REGULATED
NO
NO
---
NO
---
COLD WATER INPUT
YES
YES
YES
YES
---
YES
---
DECALCIFIED WATER INPUT
NO
NO
NO
NO
---
NO
---
WATER LEVEL
MINIMUM
MINIMUM
MEDIUM
MEDIUM
---
MEDIUM
---
MOVEMENT DURING FILLING
YES
YES
YES
YES
---
YES
---
WATER TEMPERATURE
COLD
104ºF
COLD
COLD
---
COLD
---
THERMAL STOP
NO
YES
---
---
---
---
---
TIME(min)
0
10
0
2
2
2
6
OPTIMUM DISTRIBUTION
---
---
---
---
YES
---
YES
MOVEMENT DURING DRAINING
YES
YES
YES
YES
---
YES
---
DISPENSER 1
T60/R0
T60/R0
0
0
---
0
---
DISPENSER 2
0
T60/R0
0
0
---
0
---
DISPENSER 3
0
T60/R0
0
0
---
0
---
DISPENSER 4
0
0
0
0
---
T60/R0
---
DISPENSER 5
0
0
0
0
---
T60/R0
---
DISPENSER 6
0
0
0
0
---
0
---
DISPENSER 7
0
0
0
0
---
0
---

7
P3 - HOT
PHASE
Pre-wash
Wash
Rinse1
Rinse2
Short spin
Final rinse
Long spin
STOP PROGRAM
NO
NO
NO
NO
NO
NO
NO
SPEED
50rpm
50rpm
50rpm
50rpm
500rpm
50rpm
1000rpm
RHYTHM
12/3
12/3
12/3
12/3
---
12/3
---
HOT WATER INPUT
NO
REGULATED
NO
NO
---
NO
---
COLD WATER INPUT
YES
YES
YES
YES
---
YES
---
DECALCIFIED WATER INPUT
NO
NO
NO
NO
---
NO
---
WATER LEVEL
MINIMUM
MINIMUM
MEDIUM
MEDIUM
---
MEDIUM
---
MOVEMENT DURING FILLING
YES
YES
YES
YES
---
YES
---
WATER TEMPERATURE
COLD
140ºF
COLD
COLD
---
COLD
---
THERMAL STOP
NO
YES
---
---
---
---
---
TIME(min)
0
10
0
2
2
2
6
OPTIMUM DISTRIBUTION
---
---
---
---
YES
---
YES
MOVEMENT DURING DRAINING
YES
YES
YES
YES
---
YES
---
DISPENSER 1
T60/R0
T60/R0
0
0
---
0
---
DISPENSER 2
0
T60/R0
0
0
---
0
---
DISPENSER 3
0
T60/R0
0
0
---
0
---
DISPENSER 4
0
0
0
0
---
T60/R0
---
DISPENSER 5
0
0
0
0
---
T60/R0
---
DISPENSER 6
0
0
0
0
---
0
---
DISPENSER 7
0
0
0
0
---
0
---
P4 - DELICATES
PHASE
Pre-wash
Wash
Rinse1
Rinse2
Short spin
Final rinse
Long spin
STOP PROGRAM
NO
NO
NO
NO
NO
NO
NO
SPEED
50rpm
50rpm
50rpm
50rpm
500rpm
50rpm
800rpm
RHYTHM
8/4
8/4
8/4
8/4
---
8/4
---
HOT WATER INPUT
NO
NO
NO
NO
---
NO
---
COLD WATER INPUT
YES
YES
YES
YES
---
YES
---
DECALCIFIED WATER INPUT
NO
NO
NO
NO
---
NO
---
WATER LEVEL
MEDIUM
MEDIUM
HIGH
HIGH
---
HIGH
---
MOVEMENT DURING FILLING
NO
NO
NO
NO
---
NO
---
WATER TEMPERATURE
COLD
COLD
COLD
COLD
---
COLD
---
THERMAL STOP
NO
NO
---
---
---
---
---
TIME(min)
0
10
0
2
2
2
6
OPTIMUM DISTRIBUTION
---
---
---
---
YES
---
YES
MOVEMENT DURING DRAINING
NO
NO
NO
NO
---
NO
---
DISPENSER 1
T60/R0
T60/R0
0
0
---
0
---
DISPENSER 2
0
T60/R0
0
0
---
0
---
DISPENSER 3
0
T60/R0
0
0
---
0
---
DISPENSER 4
0
0
0
0
---
T60/R0
---
DISPENSER 5
0
0
0
0
---
T60/R0
---
DISPENSER 6
0
0
0
0
---
0
---
DISPENSER 7
0
0
0
0
---
0
---

8
P5- EXTENDED COLD
PHASE
Pre-wash
Wash
Rinse1
Rinse2
Short spin
Final rinse
Long spin
STOP PROGRAM
NO
NO
NO
NO
NO
NO
NO
SPEED
50rpm
50rpm
50rpm
50rpm
500rpm
50rpm
1000rpm
RHYTHM
12/3
12/3
12/3
12/3
---
12/3
---
HOT WATER INPUT
NO
NO
NO
NO
---
NO
---
COLD WATER INPUT
YES
YES
YES
YES
---
YES
---
DECALCIFIED WATER INPUT
NO
NO
NO
NO
---
NO
---
WATER LEVEL
MINIMUM
MINIMUM
MEDIUM
MEDIUM
---
MEDIUM
---
MOVEMENT DURING FILLING
YES
YES
YES
YES
---
YES
---
WATER TEMPERATURE
COLD
COLD
COLD
COLD
---
COLD
---
THERMAL STOP
NO
NO
---
---
---
---
---
TIME(min)
5
10
2
2
2
2
6
OPTIMUM DISTRIBUTION
---
---
---
---
YES
---
YES
MOVEMENT DURING DRAINING
YES
YES
YES
YES
---
YES
---
DISPENSER 1
T60/R0
T60/R0
0
0
---
0
---
DISPENSER 2
0
T60/R0
0
0
---
0
---
DISPENSER 3
0
T60/R0
0
0
---
0
---
DISPENSER 4
0
0
0
0
---
T60/R0
---
DISPENSER 5
0
0
0
0
---
T60/R0
---
DISPENSER 6
0
0
0
0
---
0
---
DISPENSER 7
0
0
0
0
---
0
---
P6 –EXTENDED HOT
PHASE
Pre-wash
Wash
Rinse1
Rinse2
Short spin
Final rinse
Long spin
STOP PROGRAM
NO
NO
NO
NO
NO
NO
NO
SPEED
50rpm
50rpm
50rpm
50rpm
500rpm
50rpm
1000rpm
RHYTHM
12/3
12/3
12/3
12/3
---
12/3
---
HOT WATER INPUT
NO
REGULATED
NO
NO
---
NO
---
COLD WATER INPUT
YES
YES
YES
YES
---
YES
---
DECALCIFIED WATER INPUT
NO
NO
NO
NO
---
NO
---
WATER LEVEL
MINIMUM
MINIMUM
MEDIUM
MEDIUM
---
MEDIUM
---
MOVEMENT DURING FILLING
YES
YES
YES
YES
---
YES
---
WATER TEMPERATURE
COLD
140ºF
COLD
COLD
---
COLD
---
THERMAL STOP
---
---
---
---
---
---
---
TIME(min)
5
10
2
2
2
2
6
OPTIMUM DISTRIBUTION
---
---
---
---
YES
---
YES
MOVEMENT DURING DRAINING
YES
YES
YES
YES
---
YES
---
DISPENSER 1
T60/R0
T60/R0
0
0
---
0
---
DISPENSER 2
0
T60/R0
0
0
---
0
---
DISPENSER 3
0
T60/R0
0
0
---
0
---
DISPENSER 4
0
0
0
0
---
T60/R0
---
DISPENSER 5
0
0
0
0
---
T60/R0
---
DISPENSER 6
0
0
0
0
---
0
---
DISPENSER 7
0
0
0
0
---
0
---

9
P7 / P8 / P9 / P10 - OPL
PHASE
Soak
Pre-wash
Wash
Rinse1
Rinse2
Short spin
Final rinse
Long spin
STOP PROGRAM
NO
NO
NO
NO
NO
NO
NO
NO
SPEED
50rpm
50rpm
50rpm
50rpm
50rpm
500rpm
50rpm
1000rpm
RHYTHM
12/3
12/3
12/3
12/3
12/3
---
12/3
---
HOT WATER INPUT
NO
NO
REGULATED
NO
NO
---
NO
---
COLD WATER INPUT
YES
YES
YES
YES
YES
---
YES
---
DECALCIFIED WATER INPUT
NO
NO
NO
NO
NO
---
NO
---
WATER LEVEL
MINIMUM
MINIMUM
MINIMUM
MEDIUM
MEDIUM
---
MEDIUM
---
MOVEMENT DURING FILLING
YES
YES
YES
YES
YES
---
YES
---
WATER TEMPERATURE
COLD
COLD
104ºF(CONF)
COLD
COLD
---
COLD
---
THERMAL STOP
NO
NO
NO
---
---
---
---
---
TIME(min)
0
5
10
2
2
2
2
6
OPTIMUM DISTRIBUTION
---
---
---
---
---
YES
---
YES
MOVEMENT DURING DRAINING
YES
YES
YES
YES
YES
---
YES
---
DISPENSER 1
T60/R0
T60/R0
T60/R0
0
0
---
0
---
DISPENSER 2
0
0
T60/R0
0
0
---
0
---
DISPENSER 3
0
0
T60/R0
0
0
---
0
---
DISPENSER 4
0
0
0
0
0
---
T60/R0
---
DISPENSER 5
0
0
0
0
0
---
T60/R0
---
DISPENSER 6
0
0
0
0
0
---
0
---
DISPENSER 7
0
0
0
0
0
---
0
---

10
2USE
2.1 Controls
Screen (2)
The screen has 4 displays with 7 segments each and gives information regarding
the current operation.
START key
Press Start to start a program, pause or continue the program after the pause. In
the menu navigation use the ENTER function to enter or go the next level in a
menu.
ADVANCE (>>) key
OPL
Press advance to accelerate a program. When this key is pressed the programmer
goes directly to run the next cycle of the program; where the cycle currently running
is the last, the program ends. Please note that if you press this key during a spin
cycle, the machine will not move to the next cycle until completion of the required
safety time to permit the drum to come to a complete standstill.
This option is not available in self-service mode.
INC () and DEC () keys
The INC () and DEC () keys have different functions depending on the screen
and the programmer operating mode. Use these keys to select a wash program or
to scroll through different menus.
ESC key OPL
Use this button to scroll back through the different menus, or to end a program that
is running after pressing the START button.
Cycle indicators (LEDS)
The programmer has 6 amber LEDs that indicate the status of the washer extractor
and the progress of the washing program in its different cycles. The seventh LED is
green and shows the door status: if it is lit then the door can be opened, as the
drum is no longer moving.
2.2 Programs
Program
Remarks
P1
Cold
Wash in cold water and two rinses
P2
Warm (104ºF)
Wash at 104ºF and two rinses
P3
Hot (140ºF)
Wash at 140ºF and two rinses
P4
Delicates
Wash in cold water and delicates spin
P5
Extended cold
Wash in cold water and three rinses
P6
Extended hot (140ºF)
Wash at 140ºF and three rinses
P7
OPL (programmable)
Default setting: Prewash, wash at 104ºF, three rinses and fast spin
NOTE: When the thermal stop is deactivated, the programmed wash time starts to run immediately without waiting for the programmed water
temperature to be reached.

11
3OPL
Start/Pause wash
Program ended/
Door unlocked
Spin cycle
Rinse cycle
Wash cycle
Prewash cycle
INC
Scroll through menus/
Up
DEC
Scroll through menus/
Down
Advance cycle
Return

12
3.1 Operation
This machine has been designed to wash or treat most
materials. Its use for other purposes than those given
is considered as undue and dangerous.
The machine should be loaded with the nominal load,
smaller or bigger loads should be avoided.
Clothes should not be washed in sacks or cloth bags.
If this is absolutely necessary, make sure the machine
is loaded to the nominal load to avoid possible
unbalanced loads.
Canvas, waterproof items, mops, carpets or rugs
should not be spun.
The machine is controlled using a microprocessor able
to adapt to the needs of each user.
There are 7 programs, which can be modified to
varying degrees. In the standard cycles (P1, P2, P3 &
P4), it is possible to change the time of each cycle,
making the same changes to all four programs. The
cycle times for the extended programs (P5 and P6)
can also be changed, without affecting the other
programs. Lastly, in OPL mode, it is possible to
configure P7, which offers more options, allowing the
cycle time, the wash temperature and the spin speed
to be changed.
For further details, please see the sections
Configuration and Standardised Programs.
The machine has an intelligent control to control the
water temperature; if hot water is available, it should
be connected. The machine adjusts the different water
inputs to maintain the programmed temperature.
It has intelligent control for spin cycle management.
The washer extractor controls any unbalanced loads
and manages the spin to ensure a good spin, reducing
noise and extending the useful life of wearable
components, thus significantly reducing fatigue in the
mechanical components.
3.1.1 Running a program
In order to carry out a wash program, the following
steps should be followed:
1- Put garments to be cleaned in washer
extractor drum.
2- Close washer extractor door.
3- Add detergent.
4- Select desired program.
5- Press START key.
After starting a program, the LEDs indicate its
condition and evolution.
With the START key the program stops, and pauses. If
you want the program to continue, press the Start key
again. If the program is in spin mode, it is not possible
to pause the machine, and therefore pressing the
START key will have no effect.
3.1.2 Program end
The program can finish in several ways:
Normal end: the program finishes when all cycles
have been carried out.
By pressing the ESC key when the washer
extractor is in PAUSE mode.
By pressing the ADVANCE key from any point in
the program, repeatedly, the end of the program
can be reached. If a spin is being carried out, the
ADVANCE key will not respond until the braking
safety time has finished (approx 1 min.).
When a program ends, before allowing the door to be
opened, the clothes are untangled during 30 seconds.
An acoustic signal indicates when the door can be
opened.

13
4COIN
Start/Pause wash
Program ended/ Door
unlocked
Spin cycle
Rinse cycle
Wash cycle
INC
Scroll through menus/
Up
DEC
Scroll through menus/
Down
Prewash cycle

14
5COIN/CP MODE
5.1 Operation
The configuration of the machine is different for self-
service models.
As long as the key for the top left-hand lock is not
in the lock, or the lock is closed, the machine will
be configured as a self-service machine. Therefore
the user will only be able to select the required
program and start the machine.
By defect, only 6 programs are activated:
Self-service programs
P1
Cold
P2
Warm (104ºF)
P3
Hot (140ºF)
P4
Delicates
P5
Extended cold wash
P6
Extended hot wash
(140ºF)
P7
OPL (programmable)
In order to use P7, it is necessary to change to
CREDIT MODE or go to CONF/PAY and activate the
OPL option.
To change the washer extractor configuration, go to
CONF/PAY (see section 5.5.8) and select the required
option.
The different functions in each case are shown below:
5.2 Pay centre/card
Use this option if the washer extractor is a pay centre
or card model.
Program execution
In order to carry out a wash program, the following
steps should be followed:
1- Place dirty washing in the machine.
2- Close the door.
3- Add detergent.
4- Insert card or coins in the pay centre.
5- Select program.
6- Press START.
The price rate is the same for all the programs. To
change the price, please see the pay centre manual or
the card reader if using card payments.
5.3 COIN
Use this option if the machine has a coin slot.
In order to carry out a wash program, the following
steps should be followed:
1- Place dirty washing in the machine.
2- Close the door.
3- Add detergent.
4- Select program.
5- Confirm price.
6- Insert the coins.
7- Press START.
The program number and price are shown on the
screen intermittently; use the INC and DEC (,) keys
to change the program and the price will be updated.
If, after five minutes there has not been any activity in
the keys or in the coin slot, the P1 price is displayed
continuously until any button is touched or a coin is
inserted.
This type of coin slot allows you to allocate a price to
each program; the configuration menu has two
submenus, CUR and PRIC, allowing you to define the
currency and the price respectively (see sections 5.5.6
& 5.5.1).

15
5.4 Operating modes
The machine can be used in three different modes,
offering different options: OPL MODE, COIN MODE &
CP MODE.
5.4.1 OPL Mode
The operating mode, OPL MODE, permits access to
all the machine options, and use of the machine
without paying.
If the washer extractor does not have a prepaid device,
the factory settings of the machine are set to this
mode.
If machine is in Coin Mode and OPL is desired, insert
a key, in the left-hand lock of the top cover and turn.
After turning the key, go to the CONF menu and then
to the PAY submenu (see section 5.5.8). In this menu,
select the OPL option using the INC and DEC keys
(,) and press START.
The user will have access to all the configuration
options and all the programs.
5.4.2 Coin Mode
This operating mode is used for a coin-operated self-
service washer extractor. In this mode, the user is only
able to select the required program and start the
machine. All other options are disabled.
To ensure the machine in Coin Mode, insert a key in

16
the left-hand lock of the top cover and turn.
After turning the key, go to the CONF menu and then
to the PAY submenu (see section 5.5.8). In this menu,
select the COIN option using the INC and DEC keys
(,) and press START.
5.4.3 CP Mode
The CP Mode is also used in self-service machines,
but in this case, the machine is operated using a pay
station or card. As with the Coin Mode, the user is only
able to select and start the program.
To ensure the machine in CP Mode, insert a key in the
left-hand lock of the top cover and turn.
After turning the key, go to the CONF menu and then
to the PAY submenu (see section 5.5.8). In this menu,
select the CP option using the INC and DEC keys
(,) and press START.
5.4.4 Credit Mode
When the machine is configured to Coin Mode or CP
Mode, the owner can choose to access certain
additional options that will allow them to modify certain
parameters. To do so, enter Credit Mode.
To enter CREDIT Mode, insert a key in the left-hand
lock of the top cover and turn. Then press and hold the
upper left key for 3 seconds. A short buzz is heard.
To exit CREDIT MODE, turn the key in the other
direction to close the lock and remove the key.
5.5 Configuration Menu
To access the menu, with the washer extractor turned
on and stopped, press the INC and DEC (,) keys at
the same time for 3 seconds. With self-service washer
extractors, it is first necessary to open the lock in the
top cover, as this enables access to the menus. The
screen displays the CONF (Configuration) menu.
Use the INC and DEC (,) keys to scroll through the
different available options in the menus. To go to the
required option, press START, and to go back, press
ESC (bottom left button).
On entering the CONF menu, different submenus are
available which permit the modification of some of the
parameters of the wash programs. These submenus
are not always available. Access to the menus will
depend on the current operating mode (OPL MODE,
COIN MODE or CP MODE) of the washer extractor.
5.5.1 PRIC (Price)
This allows the price of each program to be
established independently. It is only available in COIN
MODE (see section 5.4.2).
Use the INC & DEC (,) keys to select the program
for which the price is to be changed. Press START to
enter the program, and select the price using the INC
& DEC (,) keys; press START to confirm the price.
The price is conditioned by the currency selected; if
the currency is changed, the prices will be reset,
therefore it is IMPORTANT to select the currency first
(see section 5.5.6).
5.5.2 LEuL (Configuration of levels)
The water levels can be varied; there are three
different settings:
1- Low (factory setting)
2- Intermediate
3- High
If the configuration is modified, this will affect all the
levels of water used. Press start and the current level
is displayed (Leu1), use the INC and DEC (,) keys
to change the level to suit your needs. Press Start
again to confirm the level selected.
5.5.3 StCL (Configuration of standard cycles)
This submenu allows you to change the length of the
different wash cycles. The standard programs are P1,
P2, P3 and P4, therefore the changes made using this
submenu will apply to these programs, but not to P5,
P6 and P7.

17
5.5.4 ECL (Configuration of extended cycles)
Use the ECL submenu to change the length of each of
the cycles of the extended programs, P5 and P6.
The changes made will only apply to these two
programs.
The default times of each cycle and the range within
which they can be changed are as follows:
5.5.5 P7 (Configuration of the OPL program)
This option is only available when the machine is in
OPL MODE, therefore it is necessary to activate this
operating mode (see section 5.4.1).
The OPL program is independent to the other six
programs and it is possible to change more settings in
the program. It offers the option to add an additional
soak, prior to the prewash. In addition to the times for
each cycle, it is also possible to modify the wash
temperature and the spin speed.
The temperature of the wash cycle can be set between
cold water and 194ºF, with a default value of 104ºF.
The spin speed varies according to the type of washer
extractor: standard, medium or high speed.
Nevertheless, it is possible to change this speed and
establish a lower speed. This change will only affect
the maximum spin cycles, as the average spin is
always at 100G. The available speeds are as follows:
SP1: 100G (standard speed)
SP2: 200G (fast speed)
SP3: 350G (high speed)
5.5.6 Cur (Currency)
This is only available in COIN MODE (see section
5.4.2). This allows the currency to be selected. The
default currency of the coin slot is USD (Code 3), but it
is also possible to configure the machine for use with
other currencies. Please refer to the coin drop kit
manual and check whether the coin slot installed in
your machine accepts the currency used in your
country. Allocate the currency to the washer extractor
programmer. The table below shows the available
currencies is (Code 3) United States:
CODE
MINIMUM PRICE
0
Token
1
1
Kuwait
Oman
0.05
2
Azerbaijan
Bulgaria
Bahrain
China
Fiji
Malaysia
Panama
Singapore
0.1
3
Argentina
Bermuda
Brazil
Canada
Ecuador
Egypt
Ethiopia
Guatemala
Cayman Islands
Saudi Arabia
El Salvador
Turkey
United States
0.25
4
United Arab Emirates
Bolivia
Estonia
Euro-Countries
United Kingdom
Georgia
Ghana
Croatia
Latvia
New Zealand
Qatar
Ukraine
0.5

18
5
Bosnia and Herzegovina
Bangladesh
Switzerland
Dominican Republic
Hong Kong
Israel
India
Sri Lanka
Lithuania
Morocco
Macedonia
Peru
Philippines
Poland
Russian Federation
Sweden
Slovakia
Thailand
Tunisia
Uruguay
Yugoslavia
South Africa
Australia
1
6
Czech Republic
Denmark
Kenya
Mexico
Norway
Romania
5
7
Algeria
Guyana
Hungary
Iceland
Kazakhstan
Slovenia
Taiwan
10
8
Chile
Costa Rica
Iran, Islamic Republic of
Paraguay
French Polynesia
50
9
Colombia
Indonesia
Japan
South Korea
Uganda
Venezuela
100
NOTE: This list is continuously updated, if you cannot find your country in the
list, please ask your distributor for the latest available update.
5.5.7 TiMr (Wash time remaining)
This indicates the time remaining until the program
ends. The default setting is ON for all the programs,
but if the StOP option (Thermal stop, see section
5.5.10) is activated, the remaining time option is
automatically deactivated.
5.5.8 PAY (Operating mode)
This allows the machine operating mode to be
changed between CP MODE, COIN MODE & OPL
MODE (see section 5.4).
5.5.9 AVAn (Advance cycle)
This option is only available in OPL MODE. The key >
can be deactivated, to prevent the advance of a cycle
thus ensuring the wash program is completed
correctly. By default, it is ON.
5.5.10 StOP (Thermal stop switch)
This option is only available in OPL MODE. When the
thermal stop switch is activated, the cycle time does
not start until the programmed temperature has been
reached in order to guarantee the wash cycle is
correctly completed; this switch can be deactivated so
that the time is counted from the moment the
programmed level is reached. The default setting is
OFF. 5.5.11 Grd (Change between ºF & ºC)
This option is only available in OPL MODE. This
submenu allows you to select the temperature display
in degrees Fahrenheit (ºF) or degrees Celsius (ºC).
The default setting is degrees Fahrenheit.
5.5.12 Beep (Acoustic signal)
This option is only available in OPL MODE. This allows
you to switch the acoustic signals on or off. By default,
they are ON.
