ADEMCO RapidDome Gold Installation and operation manual

FEATURES:
ADEMCO Video’s RapidDome Gold indoor domes are the premier choice for any
application. RapidDome Gold’s high-resolution, low light sensitivity and extended zoom capabilities
can satisfy even the most extreme, complex viewing requirements.
RapidDome Gold is extremely flexible, offering three different imager/lens options. All feature
frame integration modes that allow RapidDome Gold to deliver images at far lower light levels
than conventional cameras. The color/mono changeover imager automatically removes its IR cut
filter in extreme low light conditions, allowing outstanding performance in light levels as low as
0.01 lux.
RapidDome Gold features continuous autofocus and either a 144X zoom (18X optical, 8X digital)
or an even more powerful 176X zoom (22X optical, 8X digital). Its intelligent zoom automatically
adjusts pan and tilt speeds in proportion to zoom position. The dome provides 360˚ continuous
pan rotation and manual variable speed control at 0.1-100˚/second. And its attractive, compact
design is low profile at only 5", making it the perfect choice for applications where aesthetics are
critical and discreet surveillance is a must. RapidDome Gold also provides advanced features
such as Privacy Zones that can mask sensitive areas of a scene from view, home position which
automatically returns the dome to a preset tour after a specified period of inactivity. Mimic tours
allow operations programmed at the keyboard to be memorized and recalled, allowing for
unattended operation.
RapidDome Gold indoor domes are available in two standard assemblies; a false ceiling mount
and a plug and play pendant. The false ceiling version provides quick and easy installation into
any drop or false ceiling—no additional mounts or accessories are required. The standard
pendant version provides the ultimate in flexibility. Its plug and play design and wide range of
mounting accessories gives you the freedom to choose the perfect configuration for any
installation.
For outdoor applications, choose RapidDome Gold Environmental domes, which are available in
a wide range of versatile mounting configurations.
RapidDome Gold
RapidDome Gold
The Premier High-Performance Color Dome for Indoor Installations
• Compact low profile design at only 5”
• High resolution, low-light DSP camera options
• Eight alarm inputs and two relay outputs
resident in the dome
• Automatic digital backlight compensation
• 144X zoom (18X optical, 8X digital) or 176X
zoom (22X optical, 8X digital)
• Continuous auto focus and auto iris with
manual overrides
• 28 Privacy Zones
• Home Position
• Intelligent zoom
• Automatic 180˚ flip circuitry
• Sector Identification
• 128 presets, 4 preset tours, and 4 mimic tours
• Built-in intelligent receiver for up-the-coax
(UTC) or RS485 twisted pair (TP) operation
• Built-in code translator provides compatibility
with PELCO P or D based systems
• Automatic vertical sync-phase adjustment
False Ceiling Version
Plug & Play Pendant Version
(shown with AD5PB80 mount)
Indoor Domes

RETAINING
DISC
LANYARD
FLYING LEAD
(3 METER CABLE SUPPLIED)
RD-001-V0
(75mm)
2.95"
(145mm)
5.71"
(145mm)
5.71"
(270mm)
10.63"
RD-002-V0
(23.8mm)
0.94"
(220mm)
8.66"
(158mm)
6.22"
(145mm)
5.71"
(42mm)
(82mm)
(54mm)
1.65"
2.12"
3.22 "
(142mm)
(161mm)
6.34"
5.59"
Plug & Play Wall
Bracket (Gray)
Plug & Play 1-1/2 inch
NPT Adapter
False Ceiling Versions Plug & Play Extensions
RapidDome Gold’s powerful features and sleek, low profile design make it the ideal dome for any
indoor surveillance application.
Plug & Play Pendants
1-1/2"
(38.60)
1-5/8"
(42.30)
0.3"
(8.00)
ø1-1/4"
(31.95)
MOUNTING ACCESSORIES
STANDARD DOME ASSEMBLIES
• Easy installation and servicing:
RapidDome Gold’s pendant version features an innovative
“plug and play” design that make installation and servicing
quick and convenient.
• High resolution, low-light cameras:
RapidDome Gold’s high resolution DSP cameras with low-
light sensitivity (down to 0.01 lux) make them the ideal dome
for any installation.
• Continuous auto focus with manual override:
No matter what the zoom position, RapidDome Gold’s
images remain in sharp focus. When the scene requires
extra fine control, RapidDome Gold allows the operator to
override the auto focus settings.
• Intelligent zoom:
RapidDome Gold automatically adjusts pan and tilt speeds in
proportion to zoom position for greater control. The lens
pauses at the end of its optical zoom, then enters digital
zoom mode.
• Continuous rotation, high-speed pan, tilt, and
zoom systems:
RapidDome Gold features 360˚ continuous rotation on gold
slip rings. RapidDome Gold also features high-speed
precision control with electronic braking for up to
400˚/second operation down to 0.1˚/second.
• Home Position:
This feature allows the dome to return to a preset or start a
tour after it remans inactive for a specific, user definable
period of time. This ensures that even when a dome is
unattended, it can be viewing an important area.
• 180˚ flip ON/OFF:
When this feature is ON, RapidDome Gold automatically
turns 180˚ when reaching its lower tilt limit. This allows the
operator to continuously track objects moving directly below
the camera.
• Preset positioning and tour capabilities:
RapidDome Gold’s presets can easily be set up and recalled
by the operator when using ADEMCO Video RapidView
systems. Four preset tours and four mimic tours may be
programmed.
• Privacy Zones:
Twenty eight programmable privacy zones allows the camera
to block private views from the monitor.
• Sector Identification:
RapidDome Gold supports up to 16 user definable sectors,
each with a definable title of up to 10 characters.
• Up-the-coax or RS485 twisted pair operation:
Utilizing lift and gain circuitry, up-the-coax operation of up to
1,640 feet (500 meters) is possible with appropriate cable.
RS485 twisted pair operation allows up to 32 RapidDome
Gold domes to be daisy chained at a maximum of
5,000 feet (1,500 meters).
• Automatic sync-phase adjustment:
Using compatible RapidView Matrix Systems, the video
signal can be synchronized with other system inputs with the
touch of a button.
AD5PBNPT
ADWBG
AD5PB80, 80mm (3”)
AD5PB300, 300mm (12”)
AD5PB600, 600mm (24”)
AD5GCPP18 (NTSC)
AD5GCPP18X (PAL)
AD5GCMPP18 (NTSC)
AD5GCMPP18X (PAL)
AD5GCPP22 (NTSC)
AD5GCPP22X (PAL)
AD5GCFC18 (NTSC)
AD5GCFC18X (PAL)
AD5GCMFC18 (NTSC)
AD5GCMFC18X (PAL)
AD5GCFC22 (NTSC)
AD5GCFC22X (PAL)

Environmental
Operating Temperature . . . . . . . . . . . . . . . . . .14° to 122°F (-10 to +50˚C)
Humidity . . . . . . . . . . . . . . . . . . . . . . . . . . . .20% to 90%
Storage Temperature: . . . . . . . . . . . . . . . . . .-20º to 60˚C
Storage Humidity: . . . . . . . . . . . . . . . . . . . .20% to 90%
Regulatory
Emmisions: . . . . . . . . . . . . . . . . . . . . . . . . . .FCC:47 CFR Part 15,
Subpart B, Class A,
CE: EN55022 Class B
Immunity: . . . . . . . . . . . . . . . . . . . . . . . . . . . .CE: EN50082-1
Operational
Manual Pan Speed: . . . . . . . . . . . . . . . . . . . .0.1°-100°/second
Preset Pan Speed . . . . . . . . . . . . . . . . . . . . .400°/second maximum
Pan Travel: . . . . . . . . . . . . . . . . . . . . . . . . . .360° continuous
Manual Tilt Speed: . . . . . . . . . . . . . . . . . . . .0.1° to 100°/second
Preset Tilt Speed . . . . . . . . . . . . . . . . . . . . . .200°/second maximum
Tilt Travel: . . . . . . . . . . . . . . . . . . . . . . . . . . .90°
Pan/Tilt Accuracy . . . . . . . . . . . . . . . . . . . . . .2%
Total Zoom
Optical Zoom . . . . . . . . . . . . . . . . . . . . . . .18X, 22X
Digital Zoom . . . . . . . . . . . . . . . . . . . . . . . .8X
Maximum Zoom . . . . . . . . . . . . . . . . . . . . .144X, 176X
Zoom/Focus Accuracy . . . . . . . . . . . . . . . .0.25%
Light Loss . . . . . . . . . . . . . . . . . . . . . . . . . . .ƒ 1.0
(For ƒ 0, order AD5LDC- lower dome w/clear viewing slot)
Programmable Presets . . . . . . . . . . . . . . . . . .128 Preset Positions
(Each Preset includes Pan,Tilt, Zoom, Iris, Focus)
Programmable Preset Tours . . . . . . . . . . . . . .4; 128 steps
(Each step consists of a preset, speed and dwell-time)
Programmable Mimic Tours . . . . . . . . . . . . . . .4 each, up to three
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .minutes in length
Auto Synchronization . . . . . . . . . . . . . . . . . . .Line-Locked w/ remote
synchronization adjustment
(system dependent)
Video Output Connector . . . . . . . . . . . . . . . .BNC flying lead connector
(supplied)
Electrical
Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24VAC, Class 2 LPS, 60 Hz
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40 Watts
Power On-Rush Current . . . . . . . . . . . . . . . . .2.1 AMPS
Surge Protection
- RS485 . . . . . . . . . . . . . . . . . . . . . . . . . . .Protection diodes w/Optical
Isolation
Distance from
Power Supply
(in feet)
(in meters) 692 436 274 173 108 68 43
211 133 83 53 33 21 13
10 12 14 16 18 20 22
Wire Gauge
TECHNICAL SPECIFICATIONS
Camera
Imager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1/4-inch CCD
Scanning System . . . . . . . . . . . . . . . . . . . . . .2:1 interlaced
Signal-to-noise ratio . . . . . . . . . . . . . . . . . . . .> 50db
Sync System . . . . . . . . . . . . . . . . . . . . . . . . .Linelock
NTSC Horizontal Resolution
18X . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .> 470TVL
22X . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .>460TVL
Effective Pixels . . . . . . . . . . . . . . . . . . . . . .768 x 494
Scanning . . . . . . . . . . . . . . . . . . . . . . . . . .525 lines, 60 fields, 30 frames
Horizontal . . . . . . . . . . . . . . . . . . . . . . . . . .15.734 kHz
Vertical . . . . . . . . . . . . . . . . . . . . . . . . . . .59.94 Hz
PAL Horizontal Resolution . . . . . . . . . . . . . . .
18X . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .> 460TVL
22X . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .> 460TVL
Effective Pixels . . . . . . . . . . . . . . . . . . . . .752 x 582
Scanning . . . . . . . . . . . . . . . . . . . . . . . . . .625 lines, 50 fields, 25 frames
Horizontal . . . . . . . . . . . . . . . . . . . . . . . . . .15.625 kHz
Vertical . . . . . . . . . . . . . . . . . . . . . . . . . . .50 Hz
Video Output . . . . . . . . . . . . . . . . . . . . . . . . .1.0 Vp-p, 75 Ω
Sensitivity (50 IRE, AGC on)
Color Camera (18X)
Color . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.0lux
Color Integration . . . . . . . . . . . . . . . . . . . . .0.4 lux
Color/Mono Camera (18x)
Color . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.0 lux
Color Integration . . . . . . . . . . . . . . . . . . . . .0.4 lux
Mono . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0.1 lux
Mono Integration . . . . . . . . . . . . . . . . . . . . .0.01 lux
Color Camera (22X)
Color . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.0 lux
Color Integration . . . . . . . . . . . . . . . . . . . . .0.1 lux
White Balance . . . . . . . . . . . . . . . . . . . . . . .Through the Lens (TTL)
Automatic Tracing White Balance (ATW)
Lens
Optical Zoom . . . . . . . . . . . . . . . . . . . . . . . . .18X, 22X
Digital Zoom . . . . . . . . . . . . . . . . . . . . . . . . .8X
Focus and Iris . . . . . . . . . . . . . . . . . . . . . . . .Auto/Manual Override
Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Aspherical
Focal Length
18X . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1-73.8 mm
22X . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-88mm
Aperture . . . . . . . . . . . . . . . . . . . . . . . . . . . .F 1.4
Viewing Angle, 18X
4.1mm . . . . . . . . . . . . . . . . . . . . . . . . . . . .47.5˚ (H) x 37.0˚ (V)
73.8mm . . . . . . . . . . . . . . . . . . . . . . . . . . .2.8º (H) x 1.7º (V)
Viewing Angle, 22X
4.0mm . . . . . . . . . . . . . . . . . . . . . . . . . . . .48.0˚ (H) x 37.0˚ (V)
88.0mm . . . . . . . . . . . . . . . . . . . . . . . . . . .2.3º (H) x 1.7º (V)
Mechanical
Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8.46” (215mm)
Diameter . . . . . . . . . . . . . . . . . . . . . . . . . . . .5.71” (145mm)
Unit Weight . . . . . . . . . . . . . . . . . . . . . . . . . .2 lbs (1.81 Kg)
Shipping Weight . . . . . . . . . . . . . . . . . . . . . . .4 lbs (2.72 Kg)

171 Eileen Way, Syosset, NY 11791
Copyright © 2002 Pittway Corporation
ADEMCO is an ISO9001 Registered
Company
COMPATIBLE DEVICES
RapidDome Gold is compatible with the following RapidView Series Controllers
and Matrix Switch/Control Systems:
ADEMCO Video RapidView™ Controllers
ADCT Variable speed, RS485 TP, 1 dome, touchstick
ADCJ Variable speed, RS485 TP, 1 to 128 domes, joystick
AKJX8 Dome/Multiplexer Controller, 1 to 128 domes,
up to 8 multiplexers, joystick
ADEMCO Video RapidView Matrix
Switch/Control Systems
(Keyboard required for the following units)
AS81 8 input x 1 output, RS485 TP and UTC control
AS82 8 input x 2 output, RS485 TP and UTC control
AS84TP 8 input x 4 output, RS485 TP control
AS161 16 input x 1 output, RS485 TP and UTC control
AS162 16 input x 2 output, RS485 TP and UTC control
AS164TP 16 input x 4 output, RS485 TP control
AS322 32 input x 2 output, RS485 TP and UTC control
AS324TP 32 input x 4 output, RS485 TP control
AS328TP 32 input x 8 output, RS485 TP control
ADEMCO Video RapidView Keyboards
AKJ8 Variable speed & zoom joystick
AKT8 Variable speed touchstick
Code Distribution Unit
ADCD16TP 8 independent RS485 TP code outputs
TP= Twisted Pair, UTC= Up-the-Coax
ADEMCO Video VideoBloX Matrix Switch/Control systems:
premier modular matrix switcher offering configurations up to
4080 x 256 for video/audio peripherals and alarms.
RapidDome
High Speed
Indoor Domes
ORDERING:
For more information on RapidDome or ADEMCO Video products, please
contact your sales representative or visit our Web site
at www.ademcovideo.com
ADEMCO Video is committed to ongoing product improvement; we therefore
reserve the right to change specifications without notice.
L/RDOMEGIN/D 3/02
Part No. Part No.
NTSC PAL Description
AD5GCPP18 AD5GCPP18X RapidDome Gold, Indoor, Color, 18/144X, UTC/TP, Plug & Play
AD5GCFC18 AD5GCFC18X RapidDome Gold, Indoor, Color, 18/144X, UTC/TP, False Ceiling
AD5GCMPP18 AD5GCMPP18X RapidDome Gold, Indoor, Color/Mono, 18/144X, UTC/TP, Plug & Play
AD5GCMFC18 AD5GCMFC18X RapidDome Gold, Indoor, Color/Mono, 18/144X, UTC/TP, False Ceiling
AD5GCPP22 AD5GCPP22X RapidDome Gold, Indoor, Color, 22/176X, UTC/TP, Plug & Play
AD5GCFC22 AD5GCFC22X RapidDome Gold, Indoor, Color, 22/176X, UTC/TP, False Ceiling
AD5PB80 Plug & Play Extension, 80mm (3”)
AD5PB300 Plug & Play Extension, 300mm (12”)
AD5PB600 Plug & Play Extension, 600mm (24”)
AD5PBNPT Plug & Play 1-1/2 inch NPT Adapter
AD5WBG Plug & Play Wall Bracket, Gray
PS1824 Power Supply, 120 VAC to 24 VAC - 40VA
AD5LDC 5” Black Lower Dome w/ Clear Viewing Slot
AD5LDT 5” Black Lower Dome w/ Tinted Viewing Slot (replacement)
ADEMCO VIDEO
Customer Service . .1-800-352-9169
Applications . . . . . .1-877-653-0302
Technical Support . .1-888-238-7978
Fax . . . . . . . . . . . . .1-516-921-4307
Web site . . .www.ademcovideo.com
