Adexa CB-01 User guide

Installation, Operating and Servicing Instructions
COFFEE MACHINE
Model:
CB-01 Model:
CB-02A1

Please keep this manual with this appliance
Appliance for indoor use only
3

CONTENTS
1. Important information
Please read these instruction manual before using this product. Pay
attention to all precautions and notice. Make sure you understand all
before start operating
This triangular warning symbol appears when there is a risk of personal
injury
WARNING ！
This circular warning symbol appears when there is a risk of damaging
your appliance
CAUTION !
NOTE
This symbol is to provide supplementary information, hints and tips
NOTE :
4
1. Important information
2. General Precautions
3. Specific Precautions
4. Technical Specifications
5. Checklist of Enclosures
6. Installation and Preparation before first time use
7. Operation
8. Maintenance
9. Trouble shooting
10. Servicing and Guarantee
11. Disposing
4
5-6
6-7
7-8
8
8-9
10-13
14-15
15
16
16

2. General Precautions
This electric appliance must be installed, commissioned and serviced by qualified
technician in accordance with regulations in the country of installation
This appliance is made for commercial use purpose, and please not to use it for
household purpose
This appliance must only be used for its intended use and design. Manufacturer and
seller is not responsible and liable for any damage if it is not used correctly
Please do not let people with reduced physical, sensory or mental capabilities, or lack
of experience use this appliance
Don’t let children to use this appliance
Keep the product and the power cord from accessible by children
Please check the electric plug and power cord regularly. Whenever you find the power
cord damaged, please replace it by the manufacturer, its authorized service agent, or
qualified person before operating the product
Please connect the electric plug to main socket at accessible position, so that in case
of emergency or dangers, you can disconnect the electric plug immediately
Please avoid the appliance and electric plug in touch with water and any liquids. If the
appliance falls into water, please disconnect the electric plug from the socket
immediately, and do not use the appliance until you have a throughout check by
qualified technicians. Failure to follow this instruction may lead to fatal danger
Don’t try to open the housing of the appliance yourself
Don’t insert any objects into the housing of the appliance
Never touch the plug if your hand is wet or damp
Never try to repair the appliance yourself. This may cause electric shock !
In case of malfunctioning, repair must be done by qualified persons
Don’t use malfunction or damaged product. Disconnect the electric plug from main
power and call the aftersales services for repair.
Don’t submerse any electrical parts of the appliance into water or any liquids, and don’t
put the appliance in running water
Please not to let the power cord touch any sharp or hot objects, and avoid it to be close
to open fire. To disconnect the electric plug from main socket, please always pull the
electric plug but not by pulling the power cord
Please make sure to place the power cord in a safe position to avoid from causing trip
hazard
Please keep watching the appliance when it is operating
Be care ! Whenever the electric plug is in the main socket, the product is connected to
electric power
5

Make sure your electric plug is connected to a fast accessible electrical outlet, so that
you can unplug the appliance immediately once there is any emergency
Please switch off the appliance before pull out the electric plug from the socket
Don’t hold the appliance by the power cord
Don’t use any devices which are not supplied together with the appliance
Don’t use any accessories other than those recommended by the manufacturer
Only connect the appliance to electricity supply with voltage and frequency as declared
in the appliance label
Remove any plastic coating and clean the product before use
When the appliance is operating, some parts of it may get hot, please avoid touch it or
any accidental contact
Please disconnect the power before servicing, maintenance, dissembling, assembling
cleaning, or when it is being left unintended, or when it is not in use
When the appliance is being used, don’t let it be unattended
Remember to switch off the appliance before disconnecting the electric plug
3. Specific Precautions
This appliance is intended for making coffee. If it is being used for other purpose, it
may lead to damage of the appliance and or even harmful to the user
The appliance should be operated by professional or trained users
Not to cover the appliance during operating
The appliance should be put on a level, clean and stable platform when operating
Don’t put the appliance close to other hot appliances or equipment such as electric and
gas thermal appliances, ovens, heating plates, griddles, fryers, ... and so on
Not to allow the appliance to be close to fire as well as any hot objects and surfaces
If the appliance is to be placed at a position close to a wall, partitions, kitchen furniture,
decorative finishes, etc., please make sure they are made of non-flammable material;
otherwise the appliance has to be clad with non-flammable and heat insulating
material. It’s important to pay extra attention to conform to fire prevention regulations
Place the appliance at a position that will not be reach by children or persons with
reduced mental capabilities
Clean the appliance after use for sanitation
Allow the appliance to be cool down completely before cleaning
Not to use water jet or flush water directly to the appliance. It’s possible to have
electric shock if water enters into electrical parts
6

Not to use water jet or flush water directly to the appliance. It’s possible to have
electric shock if water enters into electrical parts
Not to use steam cleaner to clean the appliance
Only put fresh and cold water into the water reservoir
Don’t put hot water into the water reservoir
This appliance is constructed for heating water but no other liquid
Don’t put more than one decanter of water into the reservoir
Be caution ! Whenever you open the cover of the water reservoir, steam may come out
Make sure the cover of the water reservoir has been closed properly when the
appliance is operating
Make sure there is enough water in the water reservoir before switch on the appliance,
and do not let the water reservoir empty during operation
Don’t move the appliance when it is operating or when it has hot water
The two warming plates could be very hot during and after operation, please do not
touch them and only hold the glass decanter with its thermal insulated handle to avoid
harmful to your hands
7
Model
Inputvoltage
Power
Capacity
Brewing Time
Brewing Temp.
Productdimension
Product weight
4. Technical Specifications
CB-02A1
230VAC50Hz
2020W
Max 100cups per hour
1.8L. / 5 min.
93 - 96oC
410.4x201.5xH.445mm
7.3kg
CB-01
230VAC50Hz
2020W
Max 100cups per hour
1.8L. / 5 min.
93 - 96oC
413.7x212xH.429.4mm
6.0kg

5. Check list of Enclosures
Coffee machine
Decanter (1.8 L. capacity)
Filter funnel (ø 25mm)
Coffee filter (paper)
Water Hose
Power cord
1
2
1
10
1
1
6. Installation and Preparation before first time use
Before use, carefully check if the appliance is without damage. Contact your
supplier if you find damage or problem, and don’t use the appliance
Remove all packaging and protective material
Place the appliance on a stable and level platform
Leave sufficient space around the appliance for ventilation
Place the filter paper on the filter holder of the appliance with coffee powder
Please note the programmes in automatic mode must always run to the end in a jug,
otherwise there is a risk of overflowing in automatic mode. In manual mode there is
always arisk of overflowing. The jug must note be left unattended in manual mode until
Model
Inputvoltage
Power
Capacity
Brewing Time
Brewing Temp.
Productdimension
Product weight
the programme has stopped.
4. Technical Specifications(continue)
1
2
3
4
5
6
Steps
NOTE Capacity of the water reservoir is 1.8 L. Please avoid it to be overflow.
8
1
CB-01
120VAC60Hz
1620W
Max 100cups per hour
1.8L. / 5 min.
93 - 96oC
413.7x212xH.429.4mm
CB-02A1
120VAC60Hz
1620W
Max 100cups per hour
1.8L. / 5 min.
93 - 96oC
410.4x201.5xH.445mm
7.3kg
6.0kg
2
1
10
1
1

7
8
Connect the power plug to power socket
Connect the water hose to the appliance and the water tap
Press the ON/OFF switch button , Select Automatic or Manual Mode
After a while, hot coffee will start dripping into the decanter
Press the ON/OFF switch button again to turn off the appliance
When you pick up the decanter, remember to hold its handle harmful to your hand,
and avoid to touch the warming plate
10
This is a Class I electrical appliance which must be connected to a safety ground
This appliance has a power cord and electrical plug with ground wire and pin
11
Grounding of the appliance
The electrical plug must be plugged into an main socketinstalled with earth connection
9
appliance ON/OFF
switch
button
socket
water inlet
9
12

7. Operation
Steps of Operation
Place the appliance on a plane and stable platform
Make sure the empty decanter is ready underneath the filter holder before brewing.
Make sure power cord has been connected to the appliance as well as to the Mains
power source.
Press the ON/OFF switch button at the back of the appliance to switch on the
appliance. The LCD will display the following screen to let user choose between
manual or automatic operation.
Make sure the water hose has been connected to the water tap and to the water inlet of
the appliance
1
2
3
4
6
manual auto
Manual Operation Mode
Please the “Manual Mode” button to enter into the Manual Operation Mode. The LCD
will display the following screen with 5 buttons.
Press the following button to switch ON the upper warming plate. Press this button
again to switch OFF the upper warming plate.
10
5

7. Operation (continue)
7
8
Press the following button to switch ON the lower warming plate. Press this button
again to switch OFF the lower warming plate.
Pour water into the water tank and the machine will start brewing automatically
The small triangle at the lower right hand corner of the button will be changed to
the pause sign as below
If the brewing process is paused, the small triangle at the lower right hand corner of the
button will reappear, and you can continue the brewing process by pressing this
button again.
You can press the return button to go back to the previous sreen.
The brewing process will be paused. Please do not enter auto mode after
return to the main page , overflow risk will occur .
You can press switch button on the screen to turn the appliance
OFF (strictly speaking it is to have the appliance entering into the
standby mode). After pressing this switch button, all functions
being canceled, and the screen will be changed into black. But you
can reactivate the appliance ( or screen) by pressing any position
on the LCD display.
9
10
1
11
1
Warming:
Pour cold water only. NO hot water, coffee power or coffee bean
Pour water as the coffee you need/ Maximum one decanter (1.8L/12 Cups)
water each time.
In case of overflow, do not pour water more than one decanter.
Can not use autofill water
8If there is no water entering into the appliance and insufficient for brewing
happens.The following warning signal will appear on the screen.

7. Operation (continue)
Automatic Operation Mode
If you press the Auto operation button in step 4, you will enter into the automatic
operation mode. The LCD will display 5 buttons as follows.
12
Press the following button to switch ON the upper warming plate. Press this button
again to switch OFF the upper warming plate.
Press the following button to switch ON the lower warming plate. Press this button
again to switch OFF the lower warming plate.
You can press switch button on the screen to turn the appliance
OFF (strictly speaking it is to have the appliance entering into the
standby mode). After pressing this switch button, all functions
being canceled, and the screen will be changed into black. But you
can reactivate the appliance (or screen) by pressing any position
on the LCD display.
13
14
1
15
2

7. Operation (continue)
Water will enter into the appliance
automatically.
You can choose between brewing half decanter
(6 cups) or full decanter (12 cups) by the
following two buttons.
half decanter (6 cups)
full decanter (12 cups)
After pressing either of the above buttons, the following screen will appear which
shows the brewing process in progress.
Brewing
The pause button at the lower right corner allows you to pause the brewing process
in case of emergency.
If the brewing process is paused, you can reactivate it by pressing the button
once again.
If there is no water entering into the appliance and insufficient for brewing
happens. The following warning signal will appear on the screen. In this
case, please check the water hose and water supply before resume the
operation. After check water source , press return button to re-enter brewing process
Please check water source
If the appliance has not been used for a relatively long time, clean the appliance again
by the step - as described in the previous section before use it
There is a overflow prevent tube underneath the appliance if water reservoir is overflow
There may still be some water inside the appliance even if the water reservoir has been
empty, thus please clean the appliance whenever the appliance before use if it has
been left unused for a certain period of time
NOTE
16
17
18
19
20
21
13
Make sure the water hose has been connected to the
water tap and the water inlet of the appliance.
The Auto mode can not use the water pour from top of the machine.

8. Maintenance
Cleaning
Before cleaning, always remember to switch off, unplug the appliance, and let it cool
down completely
You can clean the parts of the appliance, including the filter funnel, decanter, water
tubes with mild detergent and by using a soft and damp cloth
Do not use steel wool, abrasive cleaners, or chlorinated cleaners on the appliance.
Dry the appliance before connecting it to power socket
Discaling
When the appliance has been using for a certain period of time, water scale will build
up and accumulated on the heating element and the path of the waterflow. You should
clean up the water scale regularly to ensure the appliance can be operated at the
optimum condition as well as to keep the taste and flavour of the coffee
Steps of descaling:
Use de-scaling agent, lemon juice or cleaning vinegar for descaling
If you use lemon juice or cleaning vinegar, please mix 1/3 of lemon juice or
cleaning vinegar with 2/3 of water
Put the filter funnel on the holder of the appliance
Put an empty decanter under the filter funnel
Pour the de-scaling agent or lemon juice solution or the cleaning vinegar
solution into the water reservoir
Switch ON the appliance
When the descaling agent or lemon juice solution or the cleaning vinegar
solution starts to pass through the appliance, switch the appliance OFF
Leave the appliance for about 5 minutes to let the de-scaling agent or lemon
juice solution or the cleaning vinegar solution dissolve the water scale in the
appliance
Switch ON the appliance again to release out the descaling agent or lemon
juice solution or the cleaning vinegar solution
After the all the descaling agent or lemon juice solution or the cleaning
vinegar solution has been released out, switch OFF the appliance again
Put clean water into the water reservoir and repeat these procedures until
the no more odour and taste in the water
1
2
3
4
5
6
7
8
9
10
11
14

9. Trouble shooting
Problem Possible Causes Solutions
LCD display does not
operate
No power input into the appliance
The ON/OFF switch button has
been damaged
Check the power plug
Call the aftersales service
The appliance operates but
water flow is not smooth
Internal electronic control is
malfunctioning
Temperature protection is
damaged
Call the aftersales service
The fuse tripped when the
appliance has been
switched ON
Short circuit happens Call the aftersales service
Regular maintenance
To ensure the appliance can always be operating in the best state, Clean the
appliance and do descaling regularly
How frequently to do maintenance depends how heavily you use the appliance
15

10. Servicing and Guarantee
All servicing, maintenance should be carried out by our recommended service agents or
persons.
Guarantee
This unit carries a 1 year warranty. The guarantee does not cover:
Accidental damage, misuse or use not in accordance with the supplier’s instruction
Damage due to incorrect installation, modification, unauthorised service work or
damage due to scale, food debris build-up, etc.
Please make a note of your product details for
future use
Date Purchased:
Model Number:
Serial Number:
Dealer:
Please always dispose this appliance according to the regulations of the country
you are staying, and
Discarding all packing material in recycle trash containers
11. Disposing
16
