Victoria Arduino Athena Leva User manual

13
Compliments, you have chosen a machine that's unique in its kind.
Read carefully what is advised in the manual to "prepare" your “Athena Leva”. You
will realise how easy it is to make excellent coffees and creamy cappuccinos. As time
will pass you will also realise how little maintenance it needs.
Victoria Arduino
ATHENALEVA
02_Athena_Leva_UK.qxp 25-10-2006 8:44 Pagina 13

14
02_Athena_Leva_UK.qxp 25-10-2006 8:44 Pagina 14

15
Model: Athena 2 Groups - Net weight: 60 Kg - Gross weight: 70 Kg - Thermal power: 3000 W - Boiler capacity 15,2 lt.
Dimensions: 640 x 550 x 710h mm - Packaging dimensions: 850 x 630 x 580h mm - Finishing in hammered sheet: copper, chrome, brass
Model: Athena 3 Groups - Net weight: 75 Kg - Gross weight: 85 Kg - Thermal power: 5000 W - Boiler capacity 22,8 lt.
Dimensions: 840 x 550 x 710h mm - Packaging dimensions: 1050 x 630 x 580h mm - Finishing in hammered sheet: copper, chrome, brass
The international marks of approval certify that all the machines have undergone very careful tests and inspections
ATHENALEVA
02_Athena_Leva_UK.qxp 25-10-2006 8:44 Pagina 15

16
SAFETY DIRECTIONS
 This manual is an integral and essential part of
the product and it will have to be consigned to
the user. Read carefully the directions stated in
this manual as they supply important advice
about the safety of the set up, of the use and the
maintenance.
Keep this manual with care for any further con-
sultations.
 After having taken off the packaging, make
sure about the machine's integrity. If in doubt, do
not use it and ask to professionally qualified per-
sonnel. The packaging elements must not be left
at children's reach as they are potential sources
of danger, and be disposed of carefully.
 D ANGER OF POLLUTION
 Before connecting the machine make sure
that the data on the plate correspond to the
electric supply net. The set up must be carried
out respecting the actual regulations within the
Country where the machine is set up, according
to the manufacturer's instructions and by quali-
fied personnel.
The manufacturer cannot be considered respon-
sible for possible damages caused by the lack of
grounding of the plant. For the electrical safety
of this machine it is compulsory to arrange the
plant of grounding, asking to a certified and
qualified electrician to check that the electric
power of the plant is suitable for the maximum
power stated on the plate.
In particular he/she will also have to make sure
that the section of the plant's cables is suitable
for the power absorbed by the set.
It is forbidden to use adapters, multiple sockets
and extensions.
If their use were crucial it is necessary to call a
qualified electrician.
 The machine has to be set up according to
the local health regulations in being for the
hydraulic plants. So for the hydraulic plant ask
to an authorised technician.
 This set must only be used in the way descri-
bed in this manual.
The manufacturer cannot be considered respon-
sible for possible damages caused by improper,
GENERAL NOTES ON THE CONSIGNMENT
02_Athena_Leva_UK.qxp 25-10-2006 8:45 Pagina 16

17
wrong or irrational uses.
 W
ARNING
Before using the machine read the whole manual
or at least the safety prescriptions and the get-
ting ready.
 The use of any electric set implies complying
with some fundamental regulations. In particular:
• do not touch the set with wet hands or feet
• do not use the set barefoot;
• do not use extension in rooms with showers or
baths;
• do not pull the feeding cable to disconnect the
set from the power supply net;
• do not leave the set exposed to atmospheric
agents (rain, sun etc.);
• do not allow children to use the set, neither
unauthorised personnel and anyone who hasn't
read and completely understood this manual.
 The authorised technician before performing
any operation, has to unplug the machine after
having switched off the switch.
 bis For the cleansing operations, the machi-
ne has to be set on energetic state “O”, that is
to say “machine's switch switched off
and ” and one has to strictly keep to what is
foreseen in this manual.
 In case of breakdown, fault or bad working,
switch the set off. It is strictly forbidden to inter-
vene. Ask only to professionally qualified person-
nel.
The possible fixing of the products will have to be
carried out by the manufacturer or by an autho-
rised assistance centre by using exclusively origi-
nal spare parts.
Failing the respect of what is written above, the
safety of the set can be compromised
 At the set up, the certified electrician will
have to foresee a unipolar switch as it is foreseen
by the actual safety regulations with contacts'
opening distance equal to or bigger than 3 mm.
 To avoid dangerous overheating we suggest
unrolling the power cable for its full length.
 The user must not replace the power cable of
this set. In case of damage, switch the set off and
for its replacement ask only to professionally
qualified personnel.
 If you decide not to use this kind of set any-
more, we suggest to make it ineffective after
unplugging it, and to cut the power supply cable.
 W
ARNING ! D ANGER OF POLLUTION
Dispose of the machine carefully: either ask to an
02_Athena_Leva_UK.qxp 25-10-2006 8:45 Pagina 17

18
authorised centre for its disposal or get in touch
with the manufacturer that will supply you with
the necessary information about it.
 To help the machine's aeration place it at cm
15 from the walls from other machines.
 When using the steam pipe, pay attention
not to put your hands under it and not to touch
it soon after the use.
 W ARNING ! D ANGER OF BURNING
 Remember that before any set up operations,
maintenance, unloading, regulation, the quali-
fied operator will have to wear gloves and shoes
for accident-prevention.

WARNING
INFORMATION TO THE USERS
Under the senses of art. 13 of
Law Decree 25th July 2005, n.
151 “Implementation of the
Directives/ Guidelines
2002/95/CE, 2002/96/CE and
2003/108/CE, concerning the
reduction of the use of dangerous sub-
stances in electric and electronic equip-
ment, as well as the disposal of wastes“.
The symbol of the crossed large rubbish con-
tainer that is present on the machine points
out that the product at the end of its life cycle
must be collected separately from the other
wastes. The user for this reason will have to
give the equipment that got to its life cycle to
the suitable separate waste collection centres
of electronic and electrotechnical wastes, or to
give it back to the seller or dealer when buying
a new equipment of equivalent type, in terms
of one to one. The suitable separate waste col-
lection for the following sending of the disused
equipment to recycling, the dealing or hand-
ling and compatible environment disposal con-
tributes to avoid possible negative effects on
the environment and on the people's health
and helps the recycling of the materials the
machine is composed of. The user's illegal
disposal of the product implies the application
of administrative fines as stated in Law Decree
n.22/1997” (article 50 and followings of the
Law Decree n.22/1997)
02_Athena_Leva_UK.qxp 25-10-2006 8:45 Pagina 18

19
DESCRIPTION OF MACHINE
CONTROLS AND OPERATION
Heating plate
Lever
Vapor tap
Vapor tap
Water level
indicator
Main switch
Filterhalter
Work bench
Manometer with
double scale
Coffee dispensing unit
Warm water tap
02_Athena_Leva_UK.qxp 25-10-2006 8:45 Pagina 19

20
TRANSPORT AND MOVEMENT
MACHINE IDENTIFICATION
For any communication with the manufacturer
Victoria Arduino, always quote the machine's
number plate.
The machine is carried in pallett with other
machines in cardboard boxes fastened to the pal-
lett through centring or ropes.
Before carrying out any transport or movement
operations, the operator will have to:
• wear gloves and shoes suitable for accident-preven-
tion and an overall with elastic bands on the limbs.
The pallett transportation has to be carried out
with a suitable lifting means (like a forklift truck).
 WARNING! D ANGER OF CRASH OR COMPRESSION
The operator during the movement, has always
to pay attention that people, things or objects
are not in the way in the operation's area.
Lift the pallett slowly at about 30 cm from the
ground and reach the loading area. After
checking that there are no obstacles, things nor
people, proceed to the loading.
Once you get at destination, always using an
adequate lifting means (e.g. forklift truck), after
making sure there aren't things nor people in the
unloading area, take the pallett to the ground
and move it up to 30 cm from the ground, until
the stocking area.
 WARNING! D ANGER OF CRASH OR COMPRESSION
Before performing the following operation,
check the load is safe at its place and that when
cutting the centring or ropes it doesn't fall down.
The operator wearing gloves and shoes for acci-
dent-prevention, will have to proceed to the cut-
ting of the centring or ropes and to the stocking
of the product. During this operation, please
check the technical characteristics of the product
to see the machine's weight to be stocked and
be able to act consequently.
 WARNING! DANGER OF POLLUTION
Once you have freed the machine from the pal-
lett or the container, dispose of it carefully, dan-
ger of pollution.
02_Athena_Leva_UK.qxp 25-10-2006 8:45 Pagina 20

21
After having checked that nothing fails in the
packaging, put the machine in the place fore-
seen and pay attention that it is level by adju-
sting the pins. If the extension pins are fore-
seen, the assembling will be carried out by
untwisting completely the pin and twisting it
back again on the metal insert supplied with
the extension, then put the cylindrical shell
made of plastic on the insert.
Then twist the levers' arms that are on the
respective supply groups.
Place the softener in the space foreseen. We
remind that for the VICTORIA ARDUINO
ATHENA LEVA does not have a pump, the
pressure that is necessary for the coffee sup-
ply is gained by the lever group, so the con-
nections' operations are quite simplified.
the pump is built-in the machine itself, so the faste-
ning operations will be extremely simplified.
We advice to avoid narrowing in the tubes, to
pay attention to the unloading and to use an
electric cable of equal section, if the one sup-
plied is not enough.
The machine must always be protected with an
automatic switch of adequate power.
It is advisable to fit a pressure reducer between the
machine and the water mains. This piece, which is
supplied with the machine, serves to guarantee the
correct pressure level of the water entering the
machine. The inlet pressure for the coffee machi-
ne should be approximately 2 bar.
The Company is not responsible for any damage
caused to things or people deriving from failing
the safety regulations' observance.
STARTING
Even if all the machines VICTORIA ARDUINO
have an automatic level, it's good rule, in the
initial phase, to fill the boiler manually to avoid
that the electric resistance is damaged and the
electronic safety is connected (this one stucks
the machine if the self-level is inserted more
than 90 seconds. If this happens it is anyway
enough to switch the machine off and then
switch it on again, to complete the boiler's loa-
ding)
Removing the grill and the worktop drip tray it
is possible to operate on the hydraulic circuit of
the machine (see picture).
The entrance machine tap 1 must always be
turned open after the connection to the machi-
ne's net has been carried out.
SET-UP INSTRUCTIONS
02_Athena_Leva_UK.qxp 25-10-2006 8:45 Pagina 21

22
To carry out the manual filling, before swit-
ching the machine on, turn the manual loading
tap 2 that is below the worktop.
Once the boiler is half filled, turn again the
manual loading tap 2 and switch the machine
on in order to activate the automatic level, also
check that the water inlet cock 1 and the auto-
matic level cock 3 are open.
Remark: a tap is turned open when turning the
lever it is parallel to the tap's body.
After about 20 minutes the machine will have
reached the working pressure that can be noti-
ced and taken from the double scale manome-
ter. To change the boiler working pressure, (and
also its temperature) according to the different
needs or characteristics of the coffee used, it is
necessary to remove the cups warming band,
the cups warming plate and the side right
panel and to turn the manostat regulation
screw, by turning it clockwise the pressure
2
3
1
02_Athena_Leva_UK.qxp 25-10-2006 8:45 Pagina 22

23
decreases and vice versa (normally the machine
that has been tested is adjusted at about 1-1.2
bar)
STEAM PIPE'S USE
To use the steam it is necessary to turn the
steam tap anticlockwise: a steam's flux regula-
tion is possible when coming out from the
pipe.
When the steam comes out, do not touch the
pipe with any of parts of your body nor put
your hands under the pipe.
WARNING! D ANGER OF BURNING
To get the cream when warming the milk, dip
the steam pipe at the bottom of the container
for its 3/4 (preferably in a truncated- conic
shape). When the milk boils, move the steam
pipe to the surface skimming the milk with
small vertical movements to get the cream you
want. At the end of each operation, remember
to clean carefully the steam pipe using a wet
cloth.
USE OF HOT WATER
To use hot water it is enough to turn the hot
water tap anticlockwise.
When hot water comes out, do not touch with
the parts of your body nor put your hands
under the pipe.
W ARNING ! DANGER OF BURNING
ESPRESSO COFFEE PREPARATION
Unfasten the filter holder from the group and
put one or two quantities of grounded coffee
according to the filter you are using; press the
coffee using the appropriate small press sup-
plied with the kit and before fastening the fil-
ter-holder to the group, clean the ring edge of
the filter to take off possible coffee remains
that could also damage the perfect grip of the
group and the filter-holder.
Then insert the filter-holder in the group,
fastening it; push the lever down until its end
of run. Wait some seconds for a possible pre-
infusion of the coffee delivery. Start the lever's
coming up and pay attention that your body
does not obstruct the lever's way.
Only remove the filter holder when the lever
has returned to its original position
BODY CLEANSING
To keep unchanged the machine's characteri-
stics in time, you have to clean it quite often.
Do not use any detergent product, use only a
soft clean sponge and some water.
Possible body oxidation is normal, as it is
made of brass or natural copper (according to
the model).
02_Athena_Leva_UK.qxp 25-10-2006 8:45 Pagina 23

24
FILTERS AND FILTER HOLDERS' CLEAN-
SING
Add two teaspoons of detergent in half a litre
boiling water and dip in the filters and the hol-
ders for about half an hour. Rinse carefully in
fresh water.
Use glass or inox steel containers and keep the
filter holder's handle outside the detergent
liquids.
02_Athena_Leva_UK.qxp 25-10-2006 8:45 Pagina 24
