EXPLANATION
This Instruction Manual is the universal-purpose version for
the models of wine cabinet manufactured by our Co. The
appearance of the units that you purchase might be slightly
different from the Manual, but it does not affect your proper
operations and usage.
Please read carefully the sections corresponding to the
specific model you choose, and keep the manual properly so as
to facilitate your reference at later time.
Electrical Requirement
Make sure there is a suitable power Outlet (220-240V/50Hz)
with proper grounding to power the wine cellar.
Avoid the use of three plug adapters or cutting off the third
grounding in order to accommodate a two plug outlet. This is an
dangerous practice since it provides no effective grounding for
the wine cellar and may result in shock hazard.
Install Limitations
Do not install your wine cellar in any location not properly
insulated or heated e.g. garage etc.
Select a suitable location for the wine cellar on a hard even
surface away from direct sunlight or heat source e.g.
radiators, baseboard heaters, cooking appliances etc. Any
floor unevenness should be corrected with the leveling legs
located on the front and rear bottom corners of wine cellar.
Use of Extension Cords
Avoid the use of an extension cord because of potential
safety hazards under certain conditions. If it is necessary to
use an extension cord, use only a 3-wire extension cord that
has a 3-blade grounding plug and a 3-slot outlet that will accept
the plug. The marked rating of the extension cord must be
equal to or greater than the electrical rating of the appliance. ３

Wine cabinet Installation:
 When you receive the cabinet, please unpack the unit and
make sure there is no flaws in its external appearance (from
shocks, deformation, ect.)
 Open the door and check all interior fittings and supplied
items if are all complete (shelves, instruction, control panel,
etc.) Please install it according to the following points if the
shelves or shelf brackets fall off during transit.
 After checking, if no problem, then, pls carry to the final
place, which should be care as follows:
 Leaving space of minimum 5cm between your wine cabinet
and left & right wall; at least 8cm between back of cabinet and
the wall. (Freestanding only)
 Position the wine cabinet on a flat level surface, if not,
adjust the feet of wine cabinet to keep level.
 Away from sources of heat and high humidity areas
(laundry room and bathroom, etc).
 Do not tilt it at an angle of more than 45° when move the
cabinet. Allow a minimum 10 minutes interval between transit
and re-starting.
Make sure the ventilation is free if you wish to install your
cabinet into a worktable, otherwise, it will reduce the effect of
usage.
Wine Cellar Features and Use Initial Setup
 Before connecting the wine cellar to the power source, let it
stand upright for approximately 24 hours. This will reduce the
possibility of a malfunction in the cooling system from handling
during transportation.
Once you have plugged the unit into an electrical outlet, let
the unit run for at least 4 hours to acclimate before making any
adjustments.
４

 Shelving
(Type and number of shelves will vary per model)
 Remove packing materials from shelves once unit is stable
and ready for storage.
 Disperse the bottles evenly to avoid concentrating weight in
one place. Bottles must not touch either the back of the cabinet
or the step at the bottom.
 Make sure that the bottles are not all grouped together
either at the top or bottom of the cabinet.
 Only pull out one rolling shelf at a time. Never attempt to pull
more than one.
 The wine cellar will hold 'standard' Bordeaux sized bottles,
as shown below. If up to half of your collection consists of non-
standard Bordeaux-size bottles, your maximum capacity may
be reduced by 20-25%. If your collection consists mostly of
these larger sized bottles, your maximum capacity may be
reduced by as much as 40%.
Important Safety Instructions
 Basic precautions when using,
 Only use your wine cabinet for intended purposes, as
described in this guide.
 Never unplug the wine cabinet by pulling out the power cord,
grip the plug firmly and pull straight out to remove from wall
socket.
 Immediately repair or replace any worn or damaged cord,
never use a cord that is split or which shows signs of wear
along its length or on its ends.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the
appliance by a person responsible for their safety
５

Children should be supervised to ensure that they do not
play with the appliance. Do not allow children to climb on, sit on
or stand on the wine cabinet, nor hang from its shelves. They
could damage the cabinet.
Do not use an extension cord. Do not operate this device if
its power cable or plug is damaged, or it does not work
properly, or it is damaged, or hasn't work properly, or it is
damaged, or has been dropped. If the power cable is damaged,
it will need to be replaced by the manufacturer or his service
agency or a similar qualified person, to avoid any dangers.
Do not place other appliance inside the cabinet.
Operating Your Wine Cellar
1. Removing the Shelf
Once wood shelf need to change, please check which kind of
slider
To remove a rolling shelf:
1. Remove all bottles
2. Pull the shelf out as far as it will go
3. If design A, lift the shelf up and off the slides. Please make
sure the wood hole need to match with slider hook when you
assemble the shelf
If design B, a) unscrew the wood shelf from slider b) take out
the old wood shelf and change new one c) Screw the wood
shelf again from shelf bottom as previous
If design C, which without slider, please close the limit and
take out the shelf.
６

2. Installing Your Handle (If it has handle)
1. Pull back the door seal behind handle location
2. Insert screws into pre-drilled screw holes.
3. Attach gasket
4. Attach handle
5. Tighten screws and press door seal back into place.
3. Operating Your Wine Cellar
Each wine cellar includes an operating panel on the front of the
unit. This operating panel includes several features to operate
and control the temperature.
4. Temperature Setting
4.1 The temperature setting of wine cabinet
4.1.1 Control panel for single zone
ON/OFF of the whole system
ON/OFF of inside cabinet LED light
Temperature Up setting
Temperature Down setting
７

4.1.2 Control Panel for dual zone
Upper Control Panel
ON/OFF of the whole system
ON/OFF of inside cabinet LED light
Temperature Up setting
Temperature Down setting
Down Control Panel
ON/OFF of the whole system
ON/OFF of inside cabinet LED light
Temperature Up setting
Temperature Down setting
4.1.3 Pushing the temperature key up and down for 5 seconds,
then, temperature display will be exchange between ℃ and ℉
4.1.4 Temperature setting range of cabinet is 5 ℃~20℃ (41℉
~68℉) . Customers can set the temperature according to their
actual demands.
８

4.2 The temperature setting of SW-24
1. Temperature UP, the upper zone's temperature increases
1℃ each time the butt on is pressed
2. Temperature DOWN, the upper zone's temperature
decreases 1℃ each time the button is pressed
3. Upper Zone Temperature Display
4. Temperature UP, the lower zone's temperature increases
1℃ each time the button is pressed
5. Temperature DOWN, the lower zone's temperature
decreases 1℃ each time the button is pressed
7. Choose the mode of LED light
a) Mode 1 (Default setting) : ECO, the panel will show ECO
that means the LED light is under Mode 1, at that time, the LED
light will be ON/OFF automatically when door open/close.
b) Mode 2 : when you press the LED light button for 5
seconds, ECO on panel will disappear, at that time, the LED
light is under Mode 2, the LED light will be ON, but it will OFF
automatically after 4 hours.
8. Turn the Power ON and OFF.
9.Toggle the LED display between Celsius or Fahrenheit
readings -- Press Button 1 and Button 2 simultaneously for 3
seconds to toggle the LED display between Celsius or
Fahrenheit readings.
10. Door alarm, when the door open for 60 seconds, the alarm
will sound and the panel will show H1.
11. Temp. setting range of cabinet is 5 ℃~20℃ (41℉~68℉) .
Customers can set the temp. according to their actual demands. ９

4.3 The temperature setting of SW-54
(1) Hinge (2) Door Gasket (3) Door Frame
(4) Door Handle (5) Door Hinge (6) Foot
(7) Rack (8) Fan (9) Casing (10) Control Panel
4.3.1 Two temperature zones are controlled separately, left
control panel controls left zone, right control panel
controls right zone.
Please control the button according to your requirement.
1. ON/OFF of the Left/Right system
2. ON/OFF of Left/Right zone inside LED light
3. Temperature UP, the Left/Right zone's temperature
increases 1℃ each time the button is pressed
4.Temperature DOWN, the Left/Right zone's temperature
decreases 1℃ each time the button is pressed
5. Press button of and simultaneously for 3 seconds to
toggle the LED display between Celsius or Fahrenheit
readings.
6. Temperature setting range of cabinet is 5 ℃~20℃ (41℉
~68℉) . Customers can set the temperature according to their
actual demands.
7. This model refrigerate from left zone for five minutes first,
then, refrigerate to right zone for five minutes, each zone
１０

refrigerate for 5minutes, the cycle repeats until the set
temperature is reached.
8
4.4 The temperature setting of SW-122
ON/OFF of inside cabinet LED light
4. Toggle the LED display between Celsius or Fahrenheit
readings
5. Temperature Up setting
6. Temperature Down setting
7. Temperature quick setting
8. Unlock the panel
- Power Button
When the equipment is connecting the power but not turn on,
the backlight of the power button will flash, other keys and
. It is normal that the key is flashing after turn off the
power, but the plug is connected.
Please refer to the manual for detailed operation steps.
1. Turn the power ON and OFF
2. Mute key
3.

１１

display screen are off. Press the power button to turn on the
corresponding temperature zone and long press the power
button for 3 seconds to close the corresponding temperature
zone.
- Unlock the control panel
When the control is not operate for 10 seconds, the panel
will be automatically locked. After the button is locked, the
backlight of the button will be off and the lock icon on screen
will be lit. Then, the screen will enter the energy-saving mode
and the brightness of the screen will decrease after 3 minutes.
Long press the unlock key for 3 seconds to unlock the key.
After unlocking, the backlight of the key will be on and the
brightness of the display will return to the normal brightness.
When the key is locked, the machine cannot be controlled by
touching the key, but the buzzer will sound. Only unlocking the
panel can the equipment be operated.
- Temperature Setting
Temperature setting range of cabinet is 2 ℃~20℃ (36℉
~68℉) . Customers can set the temperature according to their
actual demands.
The temperature readout shows the actual cellar
temperature, it will temporarily show the set temperature while
making adjustments, then reverts back after 5 seconds without
any operation.
Temperature quick setting
Press the temperature quick setting button to switch quickly
at 5℃(41℉),9℃(48℉),12℃(53℉),16℃(60℉).
Temperature recommendations:
Champagne & Sparkling wines: 5°C – 9°C(41°F – 48°F).
White wine:8°C – 12°C(47°F – 53°F)
Red wine: 12°C – 16°C(53°F – 60°F)
１２

- Toggle Key
Toggle the LED display between Celsius or Fahrenheit
readings
When you press the toggle key, the display for both of zone
will toggle together.
- LED light button
Press the LED light button to turn the LED light ON & OFF
Long press the LED light key for 3 seconds, the display
screen will display the current brightness level. The
brightness of the LED light is divided into four levels, namely
L0, L1,L2, L3, the brightness of L0 is the lowest, and the
brightness of L3 is the highest. The user can use the Up and
Down button to choose the brightness level.
- Mute key
When you don’t want to be disturbed by anything, you can
turn on the mute key. After the mute key is pressed, there will
has a bell icon light up on the display screen, and all prompt
and alarm sounds of the equipment will disable. You can press
again the mute key to cancel the mute function.
4.5 The item will be used under the room temperature ranging
from 16 to 38℃ (61℉-100℉)
Remark:
a) There is no heating element for single zone, so temperature
for single zone will be affected by the ambient temperature.
b) The temperature readout shows the actual cellar
temperature, it will temporarily show the set temperature while
making adjustments, then reverts back after 5 seconds without
any operation.
d) Temperatures may fluctuate depending on whether the
interior light is ON or OFF and depending on the position of the
bottles.
１３

5. Loading and Storage of Wine Bottle:
5.1 Bottle Loading Method:
Wooden shelf capacity: 3,4,5,9 or 11 bottles / shelf
Bottom shelf capacity: 3,5, 8 or 12 bottles / shelf
Maintain a minimum 20mm between bottle and back plate
Ensure storage Bottle bottom Dia.78mm & Height 300mm,
otherwise, less Bottle loading
5.1.1 Bottle Loading for SW-122
Wooden shelf capacity: 4 bottles / shelf
Top shelf capacity: 7 bottles / shelf
１４

Bottom shelf capacity: 5 bottles / shelf
Maintain a minimum 20mm between bottle and back plate
Ensure storage Bottle dimension is Dia.84mm & Height
300mm or Dia.76mm & Height 330mm. And the can dimension
is Dia.66mm & Height 123mm, otherwise, less Bottle loading
 Ensure the bottles are placed smoothly on the shelf.
5.2 Ensure bottle and shelf safety, check the following tips:
A. Spread your bottles out as evenly as possible over the
shelves, so weight is not concentrated in one point, and make
sure your bottles will not touch the back of the cabinet
B. Make sure bottles are not all grouped together at the top or
bottom of the cabinet
C. Following loading instructions provided in section 6.1,
according to the type of storage fixtures with which your
cabinet is equipped, and never stack bottles on a sliding shelf.
D. Due to Humidity will be fluctuated based on Room
Humidity and Temperature, please make special film to pack
before storage inside cabinet, which will ensure the label of
bottle could not be damaged.
5.3 Humidity percentage inside cabinet: 50%-80%
１５

6. Maintenance
In order to ensure best performance & long-last reliable
working item, pls follow the simple maintenance and cleaning
operations as below:
- Make sure the power cord is unplugged before cleaning the
back of your cabinet, or before moving it.
- Clean the inside of your cabinet thoroughly once a year, after
unplugging and unloading it (uses water and a mild cleaning
item, then rinse carefully).
- To assure that your wine cabinet provides long-lasting
reliable performance, you should check it regularly and inform
your dealer if anything unusual is found.
7. Trouble Shooting
１６

Note: normal operation for following phenomenon:
A) Compressor not start:
Compressor will not start if room temperature is lower than
desired temperature, but item is still working with heater inside
till desired temperature achieved.
B) Compressor re-start:
Compressor will stop working when cooling system in the
cabinet reaches presetting temperature, and re-start working
until the desired temperature is achieved. Allow a minimum 5
minute interval before re-starting.
C) Dew on the surface of cabinet:
The surface of wine cabinet especially the glass door
appears some frost if item in a damp room. This is due to the
moisture in the air coming into contact with the cabinet. Please
wipe it away with dry cloth.
D) Normal Operating sounds you may hear
Boiling water, gurgling sounds or slight vibrations that are
the result of the refrigerant circulating through the cooling
coils.
Popping or cracking noises due to the auto defrost cycle
melting frost build-up.
Liquid Sound:
1) The sound of compressor when starts or stops working
2) The flowing sound of refrigerant in the refrigeration system
3) The evaporating sound of refrigerant in the evaporator
E) Condensation formed inside the cabinet
Under the environment with high level of humidity or the door
of wine cabinet has been left open for a long period or opened
frequently, there are much condensation, and pls wipe off the
water from the door and walls and leave the door closed as
long as possible
１７

F) Heat function on bottom zone:
Heat function on bottom zone will automatically be on as
below reason.
1) When setting temp. is upper than Room Temp.
2) When inside bottom Temperature is lower than setting
temp.
G) Indicator light:
When temperature inside cabinet is out of range of setting
temperature,
both up and down indicator light will be on. Once temperature
reaches
setting temperature, then, this light will be off automatically.
Error code:
E9 - The signal cable is loose, it needs to re-connect the signal
cable
E2.1/H2 - Problem with temperature sensor failure
E2 - The main problem is refrigeration failure
H1 - Door alarm, when the door open for 60 seconds, the alarm
will sound and the panel will display H1
H3 - The actual temperature inside casing is too high or too
low
Matters need attention
Waste disposal tips
Wrappage is used to protect electric appliance during
transport and every part of materials are recycled materials.
 Corrugated paperboard/paperboard (made from waste
paper)
 Polystyrene block (foam fluoride-free polystyrene)
 Plastic film, bag (polystyrene)
 Packing string (polystyrene)
 Never let child play with packing materials, plastic film may
cause suffocation.
１８

 Waste cold wine cabinet still has many valuable raw
materials and shall be treated separately in residential area
not adopting garbage classification.
 Waste cold wine cabinet shall be scraped timely; take off
plug, and remove power soft cable. Destroy lock to prevent
such situation that a kid is locked by him/herself when playing
the lock.
 Before sending the waste cold wine cabinet to
public collection depot, cold circulation system
shall not be damaged to ensure that the refrigerant
and oil of cold wine cabinet suffers no leakage.
 For situations on waste collection date and collection depot,
please consult with local environmental sanitation department
or government agency.
Warning
 Refrigerant and foam layer is flammable, Pay attention to the
fire when maintenance, installation, transportation and
handling. Used product need to be recycled by specialized
companies, do not arbitrarily discarded.
 It is prohibited to place the machine in a place where is
possible to leak corrosive and flammable gas, it is easy to
explode or damage the machine.
 The grounding wires cannot be connected with the gas pipe,
the water pipe system, the lightning rod and the telephone. If
ignore this, it will has the possibility to cause the receiving an
electric shock accident.
 Cannot lengthen the power cord without authorization,
meanwhile, this appliance couldn't share a socket with other
appliance, otherwise, it is easy to cause short circuit or
１９

This product does not contain any spare parts, please do not
disassemble. The refrigerant used in this product is
combustible, non-professional maintenance personnel shall
not repair the machine, improper repair may be the risk of fire
or explosion. If the machine is faulty, please contact the
service personnel.
 This appliance is not intended for use by persons
(including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of
the appliance by a person responsible for their safety.
 Children should be supervised to ensure that they do not
play with the appliance.
 If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified person in
order to avoid a hazard.
 WARNING: Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
 WARNING: Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
 WARNING: Do not damage the refrigerant circuit.
 WARNING: Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are of the
type recommended by the manufacturer.
 WARNING: When positioning the appliance, ensure the
supply cord is not trapped or damaged.
 WARNING: Do not locate multiple portable socket-outlets or
portable power supplies at the rear of the appliance.
 Do not store explosive substances such as aerosol cans with
a flammable propellant in this appliance.
 The plug must can be accessible after the product installed.
２０
