L Series & S Series Arm Replacement Instructions
IMPORTANT
Please take safety
precautions as the awning
arms are spring loaded
and can potentially cause
serious injury if not handled
properly.
1. Using a ladder, position yourself directly under the awning.
2. Secure the existing arm by wrapping it with the rope, tie downs, or bungee cords to prevent it from accidentally
springing open when removed. Leaving enough allowance for the awning to open approximately 5-7 inches.
3. Manually open the awning to 5-7 inches.
REMOVING THE EXISTING ARM
PREPARATION
What you will need:
A. New replacement arm
B. Zip Ties, Rope or Straps
C. Phillips head screw driver
D. Allen wrench
E. Socket wrench
F. 6 - 8 ft. Ladder/s
Note: We recommend having an assistant to help support the awning arm during the replacement.
Electric Models: Please disconnect from power source before proceeding with arm replacement.
Your replacement arm will arrive securely tied together, DO NOT REMOVE the tie down until the arm is securely fastened to the awning.
Replacement Arm Kit
Step1&2
Step3

www.advaning.com Toll Free (US): [phone]
3.A 3.B 3.C
Our team prides itself on quality in product and service.
Should you have any concerns or questions, do not hesitate to reach us at [email protected]
1. Use a Phillips head screw
driver to remove the
bottom locking screw
and washer from the Easy
Pitch™ arm shoulder hinge
connection.
2. Use a hex key and mallet
to gently tap on the bolt
so that it can be removed
from the top of the hinge
connection.
3. Use a socket wrench to
remove the securing nut
from the front bar and arm
connection.
Note: You may need to
gentle tug on the arm
downward to release
if from the front bar
connection.
1
2.A 2.B
Additional Notes:
• It is recommended to properly lubricate the new arm before operating. Lubrication instructions are
availableat:www.advaning.com/kcnder/upload/les/Lubricating_instruction.pdf.
• While replacing the arm, the pitch of the awning may move and will sometimes require adjustments.
• Electric Models: Please ensure to test the new arm functions and pitch manually 3-5 times before
operating with remote control.
Now that the non-functioning arm is removed, you can simply repeat the above steps in reverse starting
withStep3,2andnishwithstep1.toattachthenewarm.
