5PC Motion Cushioned Seating Set
(Stationary Rocker)
# BCF00822J01
UPC # 0-50874-52638-0

ROCKER PLATE
ROCKER
ASSEMBLY
H
"U" BAR
IMPORTANT!! PLEASE READ ENTIRE INSTRUCTION SHEET BEFORE ASSEMBLY!!
TO EXPEDITE ANY FUTURE WARRANTY CLAIMS, PLEASE KEEP INSTRUCTION SHEET, WARRANTY CARD AND RECEIPT
Fig. 1
FOOT CAP
L
M
N
D
IMPORTANT!! PLEASE READ ENTIRE INSTRUCTION SHEET BEFORE ASSEMBLY!!
TO EXPEDITE ANY FUTURE WARRANTY CLAIMS, PLEASE KEEP INSTRUCTION SHEET, WARRANTY CARD AND RECEIPT
Fig. 2 Fig. 3 Fig. 4
NOTE: MAKE SURE ARROWS
FROM BOTH THE "U" BAR
AND ROCKER ASSEMBLY
ARE POINTING IN THE
SAME DIRECTION!
SEAT DESIGNS MAY
VARY BUT THE ASSEMBLY
IS THE SAME
Step 1:
Do not attempt assembly if any parts are missing or damaged.
Step 2: Fig 1 Hand tighten only
Step 4: Do not over tighten. Over tightening may strip bolts.
Step 5:
See Fig.2
Step 6: Critical Step: The "U" metal plates must be installed in the proper location.
Fig.3
Fig.4 Hand tighten nuts 3-4 revolutions only.
CAUTION: Failure to place "U" metal plates under the rocker plates and above the "U" bar exactly as shown in diagram will cause the bolt heads and nuts to damage the structure of the rocker
plates and the "U" bar. Damage due to over tightening of bolts or improper assembly could cause injury and may void your warranty.
Step 7: Do not over tighten.
Step 8:
.,
Identify all parts packed in the carton against the parts list. Remove all protective materials. Place parts on a non-abrasive surface to avoid scratching. If you are missing any parts or are unsure how to proceed with the assembly, call
our Customer Service Center at 1-800-416-3511.
Attach the right arm to the chair frame by using a 1/4"x15mm bolt and a 1/4"x55mm bolt as shown in . Guide the bolts through the holes in the right arm into pre-drilled holes in the chair frame. . Repeat for the
left arm.
At this time make any adjustments to alignment of all parts. Tighten all bolts a few revolutions at a time, alternating between bolts until tightened.
Note the arrow labels on the "U" bar and the rocker assembly. Also note the horseshoe shape of the rocker plate. Point the open end of the horseshoe away from you. The arrows on the rocker assembly should be pointing towards you.
Set the chair frame on the rocker assembly with front of the seat facing you and the arrows on the "U" bar pointing towards you ( ). This is very important for a safe, balanced rocking motion. If chair frame has been
properly positioned on the rocker assembly, all arrows on the "U" bar and rocker assembly will be pointing in the same direction.
Insert the "U" metal plate, so that the "U" bar and rocker plate are between both sides of the "U" metal plate. Make
sure that the holes in the "U" metal plate are completely aligned with the holes in the "U" bar as shown in . Guide the bolts through the holes on the top side of the "U" metal plate, through the holes in the "U" bar portion of the
chair, through the holes in the rocker plate and then, most importantly, through the holes in the bottom side of the "U" metal plate. It is very important that the holes in the bottom portion of the "U" metal plate be placed directly beneath
the holes in the rocker plate. Add a spring washer and a nut to each bolt as shown in . Repeat the same procedure on the other side.
Tighten all nuts and bolts with the hex wrenches provided. Remove arrow labels from "U" bar and rocker assembly. Cover all bolts with bolt covers.
Your chair is ready for use. If you need any assistance, please call our Customer Service Center at 1-800-416-3511.
Read this step and carefully examine.
IMPORTANT NOTE: Damage to welds or frames resulting from over tightened bolts or improper assembly is not covered under our warranty. Please read all instructions carefully before assembly. If you have any questions
regarding your assembly, call our Customer Service Center at 1-800-416-3511.
Page 2
O
"U" BAR
E
E
F
G
B
C
D
AP

Page 3
HEX WRENCH
PARTS LIST DESCRIPTION ORDER PART # QTY
A
B
C
D
HW0015 4
NUT
HW0007 1
PLASTIC WASHER 4
HW0028
BOLT COVER 8
J
HW0003
E
2
HW0798
4
5/16" X 35 MM BOLT HW0066
F
H"U" METAL
PLATE
HW0008
HEX WRENCH
K
PARTS LIST
DESCRIPTION
ORDER PART #
QTY
1
2
1/4" X 55 MM BOLT HW0141
2
1/4" X 15 MM BOLT HW0034
Ø.6 5 X 1.0 MM
WASHER HW0004 4
HW0006
HEX BOLT DRIVER 1
G
I

* NOTE: PARTS SHOWN BELOW ARE NOT TO SCALE
CHAIR FRAME
LEFT ARM
PARTS LIST DESCRIPTION ORDER PART # QTY
1
1
L
O
P
Page 4
FOOT CAP
FACTORY ASSEMBLY FC0030
1
BASE & ROCKER
FACTORY ASSEMBLY
RIGHT ARM 1
M
N
G0008
ROCKER PLATE
FACTORY ASSEMBLY
BCF00822
PROTECT CAP 2
FC0752
SR0203
SR0204
SR0205
SR0206

ACOV118
Page 5
CARE AND MAINTENANCE
LIMITED WARRANTY
FRAMES
FABRICS (CUSHIONS/SLINGS)
STRAPS
Frames.
Finishes.
Fabrics.
Straps and/or wicker.
Umbrellas
Table tops
Warranty limitations:
Warranty exclusions:
Some states do not allow exclusion or limitation of incidental or consequential damages, so that limitation above may not apply
to you. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Cleaning
Maintenance
Cleaning -
Maintenance
Cleaning -
Maintenance -
- Use mild soap and warm water. Do not use abrasive materials, cleansers or bleach products. Rinse with clean water and
dry thoroughly.
- Periodically clean and dry thoroughly. Be sure to drain any water accumulated inside the frames. To thoroughly drain
frames, remove foot caps and tilt the frames, if necessary, to remove all water. This is critical. Water allowed to accumulate inside the
frames and then exposed to sub-freezing temperatures can cause damage to the frame tubing. Such damage is not covered under
warranty. Always clean, drain and dry thoroughly before storing for the winter. For best results, always store or cover your furniture
when not in use. We recommend commercially available outdoor furniture covers. Any small nicks or scratches can be covered with a
light application of touch-up paint.
** When cleaning or moving large or heavy items, always have two people work together. Never drag furniture.
Wipe minor spills immediately. Clean with mild soap, warm clean water and soft cloth. Do not use abrasive materials,
cleansers or bleach products. Although fabric has been treated to resist stains, occasional use of commercially available fabric cleaners
may be necessary. Follow manufacturer's instructions.
- The best way to maintain the beauty of cushions and slings is to store them in a dry area and out of the elements when
not in use or cover with commercially available outdoor furniture covers.
Wash frequently with mild soap, warm water and a soft cloth. Rinse thoroughly with warm, clean water. Do not use
abrasive materials, cleansers or bleach products.
Periodic application of commercially available vinyl cleaners and vinyl protectors will enhance the look and prolong the
life of straps. If your strap chair has cushions, make sure any vinyl protectors applied are completely dry before placing cushion back
on the chair.
Frame construction is warranted against defects in material and workmanship for oen year from purchase date.
Damage to frames or welds resulting from improper assembly or exposure to water and/or sub-freezing temperatures is not
covered.
Paint finishes are warranted against peeling, cracking and blistering for one year from purchase date provided the unit
has not been scratched or abraded. Chips and scratches resulting from normal wear and tear are not covered.
Fabric and cushions (if applicable) are warranted against separation at the seams for one year from purchase date.
Fading and/or discoloration resulting from exposure to the elements, oils, spills, fluids, chemicals, or any other cause is not
covered.
Straps and/or wicker weave (if applicable) are warranted against separation and tearing for one year
from purchase date. Fading and/or discoloration resulting from exposure to the elements, oils, spills, fluids, chemicals, or any
other cause is not covered.
. Umbrellas (if applicable) are warranted against defects in material and workmanship only for one year from
purchase date. Umbrella bases (if applicable) are not covered under any circumstance.
. Natural stone tabletops only are warranted against defects in materials or workmanship only for one year from
purchase date. All other table tops (including without limitation glass and faux stone) are not covered under any circumstances.
This warranty is subject to the limitations set forth above. In addition, this warranty is made to the original
purchaser only, and is effective only when item(s) is purchased from one of our authorized dealers. This warranty is not transferable.
For warranty replacements based on warranty claims submitted within the first year of purchase, we will pay shipping and handling
charges within the continental North America. After the first year, shipping and handling charges are your responsibility. We will not
be responsible for charges associated with shipments outside the continental North America at any time or for any reason.
This warranty is subject to the exclusions as set forth above. In addition, the following are excluded from
coverage under this warranty: any item used for commercial, contract or any other non-residential purpose; clearance items, display
models or items purchased "as is"; freight damage; items subject to misuse, abuse, neglect or lack of proper care and maintenance
(including without limitation as provided in any "care and maintenance guide"); normal wear and tear; damage caused by acts of
nature, acts of force majeure, vandalism, fire or other casualty, or improper assembly; hardware against corrosion or rusting; purchased
or replacement parts; and all plastic parts. Also excluded are loss of use or time; inconvenience; money; travel; packaging; or
incidental, special or consequential damages of any kind. Replacement of defective items as provided herein shall constitute your sole
and exclusive remedy for items which are not as warranted. In no event shall our responsibility exceed the purchase price of the items
found to be other than as warranted. This warranty is the exclusive statement of your rights with respect to the defects in the items you
have purchased and supersedes any other express warranty or statement, written or oral, made in connection with the purchase and sale
of such items. When used herein, the term "item" when used in the singular, refers to the specific item found to be defective, and not to
the entire set of which the item is a part.
·
·
·
·
·
·
PATIO FURNITURE & ACCESSORIES
ASSEMBLY INSTRUCTIONS
IMPORTANT!!!
STOP! PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE
ASSEMBLY. MAKE SURE YOU HAVE ALL THE PARTS AND
HARDWARE AS IDENTIFIED ON THE PARTS LIST.
CALL OUR CUSTOMER SERVICE CENTER AT 1-800-416-3511
BETWEEN 9:00AM AND 5:00PM (EASTERN TIME) MONDAY
THROUGH FRIDAY (CLOSED HOLIDAYS).
OR, VISIT OUR WEBSITE AT: www.shianco.com
TO EXPEDITE ANY FUTURE WARRANTY CLAIMS, RETAIN THE
INSTRUCTION SHEET, WARRANTY CARD AND RECEIPT FOR
FUTURE USE. YOU ARE ENCOURAGED TO REGISTER YOUR
PURCHASE ON OUR WEBSITE AT www.shianco.com
MISSING PARTS? DAMAGED PARTS? DON'T GO BACK TO THE
RETAILER. WE CAN HELP YOU FASTER!
FOR ADDITIONAL ONLINE VIDEO SUPPORT ON ASSEMBLY,
TROUBLESHOOTING, AND CARE AND MAINTENANCE OF YOUR
SHIANCO OUTDOOR FURNITURE, PLEASE VISIT OUR WEBSITE AT:
www.shianco.com/support
