AEG Powertools ALT58LI401 User manual

ALT58LI401
ALT58B

2
2
Important!
It is essential that you read the instructions in this manual
before assembling, operating, and maintaining the product.
Subject to technical modifications.

33
GRASS DEFLECTOR
BATTERY
THROTTLE
TRIGGER
REAR
HANDLE
FRONT HANDLE
KNOB
TRIMMER HEAD
ON/OFF
SWITCH

4
4
7
10
9 13
6
15
11
START
STOP

55
7
10
9 13
6
15
11
START
STOP

6
6
1
2
3

77
1
2
3
click
1

8
8
2
3

99
1
2

10
10
1
2
3
4

11 11
6
7
8
5
click

12
12
9
10

13 13
3
4
2
1

14
14
7
8
6
5

15 15
1
2
2
1
click

16
16
INTENDED USE
The product is only intended for use outdoors.
The product is designed for cutting grass, light weeds, and other
similar vegetation at or about ground level. The cutting plane should
be approximately parallel to the ground surface.
The product should not be used to cut or trim hedges, bushes, or
other vegetation where the cutting plane is not parallel to the ground
surface.
GENERAL SAFETY WARNINGS
WARNING! Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in electric
shock, re, and/or serious injury.
Save all warnings and instructions for future reference. The
term “power tool” in the warnings refers to your mains-operated
(corded) power tool or battery-operated (cordless) power tool.
WORK AREA SAFETY
■Keep work area clean and well lit. Cluttered or dark areas
invite accidents.
■Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases, or
dust. Power tools create sparks, which may ignite the dust or
fumes.
■Keep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.
ELECTRICAL SAFETY
■Power tool plugs must match the outlet. Never modify the
plug in any way. Do not use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs and matching
outlets will reduce risk of electric shock.
■Avoid body contact with earthed or grounded surfaces,
such as pipes, radiators, ranges, and refrigerators. There
is an increased risk of electric shock if your body is earthed or
grounded.
■Do not expose power tools to rain or wet conditions. Water
entering a power tool will increase the risk of electric shock.
■Do not abuse the cord. Never use the cord for carrying,
pulling, or unplugging the power tool. Keep cord away
from heat, oil, sharp edges, or moving parts. Damaged or
entangled cords increase the risk of electric shock.
■When operating a power tool outdoors, use an extension
cord suitable for outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric shock.
■If operating a power tool in a damp location is unavoidable,
use a residual current device (RCD) protected supply. Use
of an RCD reduces the risk of electric shock.
PERSONAL SAFETY
■Stay alert, watch what you are doing, and use common
sense when operating a power tool. Do not use a power tool
while you are tired or under the influence of drugs, alcohol
or medication. A moment of inattention while operating power
tools may result in serious personal injury.
■Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask, non-
skid safety shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injury.
■Prevent unintentional starting. Ensure the switch is in the
off-position before connecting to power source and/or
battery pack, picking up or carrying the tool. Carrying power
tools with your finger on the switch or energising power tools
that have the switch on invites accidents.
■Remove any adjusting key or wrench before turning the
power tool on. A wrench or a key left attached to a rotating part
of the power tool may result in personal injury.
■Do not overreach. Keep proper footing and balance at all
times. This enables better control of the power in unexpected
situations.
■Dress properly. Do not wear loose clothing or jewellery.
Keep your hair, clothing and gloves away from moving
parts. Loose clothes, jewellery or long hair can be caught in
moving parts.
TECHNICAL DATA CORDLESS LINE TRIMMER
Rated voltage 58V
High speed 6700 r/min - Cut swath 380 mm
6400 r/min - Cut swath 430 mm
Low speed 5200 r/min - Cut swath 380 mm
4800 r/min - Cut swath 430 mm
Cutting line diameter 2.4 mm
Cutting swath 380-430 mm
Weight without battery pack (with harness) ......................................... 4.8 kg
BATTERY AND CHARGER
Model ALT58LI401 ALT58B
Battery pack ABP58LI-401 Not included
Charger ABC58S Not included
Compatible battery packs ABP58LI-201
ABP58LI-401
Compatible charger ABC58S

17 17
■If devices are provided for the connection of dust extraction
and collection facilities, ensure these are connected and
properly used. Use of dust collection can reduce dust-related
hazards.
POWER TOOL USE AND CARE
■Do not force the power tool. Use the correct power tool for
your application. The correct power tool will do the job better
and safer at the rate for which it was designed.
■Do not use the power tool if the switch does not turn it on
and off. Any power tool that cannot be controlled with switch is
dangerous and must be repaired.
■Disconnect the plug from the power source and/or the
battery pack from the power tool before making any
adjustments, changing accessories, or storing power
tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
■Store idle power tools out of the reach of children and do
not allow persons unfamiliar with the power tool or these
instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.
■Maintain power tools. Check for misalignment or binding
of moving parts, breakage of parts and any other condition
that may affect the power tool’s operation. If damaged,
have the power tool repaired before use. Many accidents are
caused by poorly maintained power tools.
■Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to bind and
are easier to control.
■Use the power tool, accessories and tool bits etc. in
accordance with these instructions, taking into account
the working conditions and the work to be performed. Use
of the power tool for operations different from those intended
could result in a hazardous situation.
BATTERY TOOL USE AND CARE
■Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type of battery
pack may create a risk of fire when used with another battery
pack.
■Use power tools only with specifically designated battery
packs. Use of any other battery packs may create a risk of
injury and fire.
■When battery pack is not in use, keep it away from other
metal objects, like paper clips, coins, keys, nails, screws,
or other small metal objects, that can make a connection
from one terminal to another. Shorting the battery terminals
together may cause burns or a fire.
■Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally occurs,
flush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause
irritation or burns.
SERVICE
■Have your power tool serviced by a qualified repair person
using only identical replacement parts. This will ensure that
safety of the power tool is maintained.
ADDITIONAL SAFETY WARNINGS
■Never allow children, persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge or
people unfamiliar with these instructions to use the product.
Local regulations may restrict the age of the operator.
■Use the product in daylight or good artificial light.
■Avoid using on wet grass.
■Keep proper footing and balance at all times.
■Do not walk backwards when using the product.
■Walk, never run.
■Keep bystanders, children and pets 15 m away from the area of
operation. Stop the product if anyone enters the area.
■Keep the head attachment below waist level.
■Never operate the product with damaged guards or without
guards in place.
■Never fit a metal replacement line.
■Keep hands and feet away from the cutting means at all times
and especially when switching on the motor.
■Beware, the cutting elements continue to rotate after the motor
is switched off.
■Beware of objects thrown by the cutting means. Clear debris
like small stones, gravel, and other foreign objects from the
work area before starting operation. Wires or string may
become entangled with the cutting means.
■Switch off and remove battery pack before:
●servicing
●leaving the product unattended
●cleaning your product
●changing accessories
●checking for any damage after hitting an object
●checking for any damage if the product starts to vibrate
abnormally
●performing maintenance
■Wear full eye and hearing protection while operating the
product. If working in an area where there is a risk of falling
objects, head protection must be worn.
■Hearing protection may restrict the operator’s ability to hear
warning sounds. Pay particular attention to potential hazards
around and inside the work area.
■Wear heavy long trousers, boots, and gloves. Do not wear loose
fitting clothing, short trousers, jewellery of any kind, or use with
bare feet.
■Secure long hair so it is above shoulder level to prevent
entanglement in moving parts.
■The small blade fitted to the lawn guard is designed to trim the
new extended line to the correct length for safe and optimum
performance. It is very sharp; do not touch it, particularly when
cleaning the tool.
■Always ensure that ventilation openings are kept clear of debris.
■Before use and after any impact, check that there are no
damaged parts. A defective switch or any part that is damaged
should be properly repaired or replaced by an authorised
service facility.
■Make sure the cutting head attachment is properly installed and
securely fastened.
■Make sure all guards, deflectors, and handles are properly and
securely attached.
■Do not modify the product in any way. This may increase the
risk of injury to yourself or others.
■Use only the manufacturer’s replacement cutting line. Do not
use any other cutting attachment.
WARNING! Some regions have regulations that restrict the use
of the product to some operations. Check with your local authority
for advice.

18
18
TRANSPORTATION AND STORAGE
■Stop the product and allow it to cool before storing or
transporting. Do not store or transport the product with batteries
fitted. Remove the battery and store separately.
■Clean all foreign materials from the product. Store the product
in a cool, dry, and well-ventilated place that is inaccessible to
children. Keep away from corrosive agents, such as garden
chemicals and de-icing salts. Do not store outdoors.
■For transportation, secure the product against movement or
falling to prevent injury to persons or damage to the product.
MAINTENANCE
WARNING! Use only original manufacturer’s replacement
parts, accessories and attachments. Failure to do so can cause
possible injury, poor performance, and may void your warranty.=
WARNING! Servicing requires extreme care and knowledge
and should be performed only by a qualied service technician.
For service, we suggest you bring the product to your nearest
authorised service centre. When servicing, use only identical
replacement parts.
You may make adjustments and repairs described here. For other
repairs, contact the authorised service agent.
■Before any maintenance or adjustment, disable the machine by
removing the power source.
■For replacement line, use only nylon filament line of the
diameter described in the specification table of this manual.
■After extending the new cutter line, always return the product to
its normal operating position before starting.
■After each use, clean the product with a soft dry cloth. Any part
that is damaged should be properly repaired or replaced by an
authorised service centre.
■Check all nuts, bolts, and screws at frequent intervals for proper
tightness to ensure the product is in safe working condition.
RESIDUAL RISK
Even when the product is used as prescribed, it is still impossible
to completely eliminate certain residual risk factors. The following
hazards may arise in use and the operator should pay special
attention to avoid the following:
– Injury caused by vibration.
Hold the product by designated handles and restrict working
time and exposure.
– Injury caused by exposure to noise
Wear hearing protection and limit exposure.
RISK REDUCTION
It has been reported that vibrations from handheld tools may
contribute to a condition called Raynaud’s Syndrome in certain
individuals. Symptoms may include tingling, numbness and
blanching of the ngers, usually apparent upon exposure to cold.
Hereditary factors, exposure to cold and dampness, diet, smoking
and work practices are all thought to contribute to the development
of the these symptoms. There are measures that can be taken by
the operator to possibly reduce the effects of vibration:
■Keep your body warm in cold weather. When operating the unit,
wear gloves to keep the hands and wrists warm. It is reported
that cold weather is a major factor contributing to Raynaud’s
Syndrome.
■After each period of operation, exercise to increase blood
circulation.
■Take frequent work breaks. Limit the amount of exposure per
day.
If you experience any of the symptoms of this condition, immediately
discontinue use and see your doctor about these symptoms.
WARNING! Injuries may be caused, or aggravated, by
prolonged use of a tool. When using any tool for prolonged periods,
ensure you take regular breaks.
SYMBOLS
Read and understand all instructions before
operating the product, follow all warnings and
safety instructions.
Regulatory Compliance Mark (RCM). Product
meets applicable regulatory requirements.
Please read the instructions carefully before
starting the machine.
Wear ear protection
Wear eye protection
Do not expose to rain or damp condition.
Beware of thrown or flying objects.
Do not use metal blade(s) on the product.
7353
Rotational direction and maximum speed of the
shaft for the cutting attachment.
Keep hands away from cut-off blade
Remove the battery pack before starting any work
on the product.
Class II tool, double insulation
Do not dispose of electric tools together with
household waste material! In observance of
European Directive 2002/96/EC on waste electrical
and electronic equipment and its implementation
in accordance with national law, electric tools that
have reached the end of their life must be collected
separately and returned to an environmentally
compatible recycling facility.

19 19
The following signal words and meanings are intended to explain
the levels of risk associated with this product:
The following signal words and meanings are intended to explain
the levels of risk associated with this product.
DANGER
Indicates an imminently hazardous situation, which, if not
avoided, will result in death or serious injury.
WARNING
Indicates a potentially hazardous situation, which, if not
avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation, which, if not
avoided, may result in minor or moderate injury.
CAUTION
Without safety alert symbol
Indicates a situation that may result in property damage.

Techtronic Industries GmbH
Max-Eyth-Straße 10
71364 Winnenden
Germany
Techtronic Industries (Australia) Pty. Ltd.
31 Gilby Road,
Mount Waverley VIC 3149,
Australia
Techtronic Industries New Zealand Ltd.
2 Landing Drive, Auckland Airport,
Mangere, New Zealand 2022
960087124-02
