AHRI Swegon PARAGON b Guide

1
PARAGON b
PARAGON b
Installation - Commissioning - Maintenance 2015-06-23
4.33 + .20
1.18
5.51 + .20
7.87 + .20
A + .20
B + .20
C = 18.51
Size L A B
900 35 30.5 34.4
110 0 43 38.4 42.3
1300 51 46.3 50.2
1500 59 54.1 58.1
C
D
1.4 24.6
7.5
5.9
PARAGON b T-SG PARAGON b T-OE-SG PARAGON b T-TE-SG
Supply air grille incl. Supply air grille incl.
Spigot
C = 1.77"
Extra spigot
C = 3.54"
Telescopic spigot
C = 3.94" - 5.51"
PARAGON b T-RG PARAGON b T-OE-RG
Return air grille incl.
Spigot
D = 0.51"-1.38"
Extra spigot
D = 1.38" -2.76"

2
PARAGON b - m
Swegon reserves the right to alter specifications 2015-06-23 www.swegon.com
Ø.33
Ø 2.05
M8
Spigot
E = 3.15"
Extra spigot
E = 4.92"
Telescopic spigot
5.31" - 6.89"
24.61
1.97 L + 0.79
E
1.97
E
L + 0.79

3
PARAGON b - m
Swegon reserves the right to alter specifications 2015-06-23 www.swegon.com
Heating
return
Cooling
supply
Cooling
return
Heating
supply
230 psi
350 psi
A
C
B
A: Min. 2.76 mm
B: Min. 12.99 mm
A: Min. 30.31 mm
B: Min. 14.17 mm

4
PARAGON b - m
Swegon reserves the right to alter specifications 2015-06-23 www.swegon.com
PH2
PH2
Standard
.51“-
1.38“
1.77“

5
PARAGON b - m
Swegon reserves the right to alter specifications 2015-06-23 www.swegon.com
Extra spigot for the supply air
3.94“-5.51“
Thelescopic spigot for the supply air
3.54”

6
PARAGON b - m
Swegon reserves the right to alter specifications 2015-06-23 www.swegon.com
Extra spigot for the return air
PH2
.51“-1.38“

7
PARAGON b
Installation - Commissioning - Maintenance 2015-06-23
PARAGON b
Room 203
PARAGON 51.2 (1300)
46,6 cfm
PARAGON 51.2 (1300)
q=34,7-69,5 cfm
k=77,5
Nozzle=L/L
1. 2.
L
M
H
4.
Storlek Dystryck Luftflöde Kpl Dysinställning
(mm) (Pa) (l/s)
900 50 - 150 Pa 10,6 - 18,4 1,5 L / L
900 50 - 150 Pa 12 - 20,8 1,7 L / M
900 50 - 150 Pa 13,4 - 23,1 1,89 M / M
900 50 - 150 Pa 16,8 - 29 2,37 L / H
900 50 - 150 Pa 18,2 - 31,5 2,57 M / H
900 50 - 150 Pa 22,9 - 39,7 3,24 H / H
1100 50 - 150 Pa 13,7 - 23,8 1,94 L / L
1100 50 - 150 Pa 15,5 - 26,8 2,19 L / M
3.
LM H
LM
H
LM
H
LM H

8
PARAGON b - m
Swegon reserves the right to alter specifications 2015-06-23 www.swegon.com
Length (in) pi (in wg) Airflow (cfm) Kpl Nozzle
35.4 0.201-0.804 22.5-44.9 50.2 L / L
35.4 0.201-0.804 25.4-50.9 56.7 L / M
35.4 0.201-0.804 28.4-56.6 63.2 M / M
35.4 0.201-0.804 35.6-71.0 79.4 L / H
35.4 0.201-0.804 38.6-76.9 85.9 M / H
35.4 0.201-0.804 48.5-97.0 108.5 H / H
43.3 0.201-0.804 29.0-58.1 64.9 L / L
43.3 0.201-0.804 32.8-65.7 73.3 L / M
43.3 0.201-0.804 36.7-73.1 81.7 M / M
43.3 0.201-0.804 46.0-92.0 102.5 L / H
43.3 0.201-0.804 49.8-99.6 110.9 M / H
43.3 0.201-0.804 62.7-125.6 140.2 H / H
51.2 0.201-0.804 34.7-69.5 77.5 L / L
51.2 0.201-0.804 39.2-78.6 87.5 L / M
51.2 0.201-0.804 43.6-87.5 97.5 M / M
51.2 0.201-0.804 54.9-109.8 122.4 L / H
51.2 0.201-0.804 59.3-118.7 132.4 M / H
51.2 0.201-0.804 75.0-149.8 167.3 H / H
59.1 0.201-0.804 29.5-59.1 65.9 L / L
59.1 0.201-0.804 39.8-79.7 89 L / M
59.1 0.201-0.804 50.2-100.4 112.1 M / M
59.1 0.201-0.804 53.2-106.4 118.6 L / H
59.1 0.201-0.804 63.6-127.1 141.7 M / H
59.1 0.201-0.804 76.7-153.4 171.3 H / H

9
PARAGON b
Installation - Commissioning - Maintenance 2015-06-23
PARAGON b
2.
1. 4.
3.
5.
6.

10
PARAGON b - m
Swegon reserves the right to alter specifications 2015-06-23 www.swegon.com
Art.No 942428009
